Fac F 300 TSV User manual

100% Made in Italy
F 300 TSV - F 330 TSV - F 350 TSV - F 370 TSV
F 300 TCV - F 330 TCV - F 350 TCV - F 370 TCV
FAC SRL
macchine affettatrici industriali e familiari
Via Morazzone, 137 - 21044 CAVARIA (VA)
Tel. [phone] - Fax. [phone]
www.slicers.it
[email protected]
CE PROFESSIONAL VERTICAL ELETRICAL SLICERS
EN
USE AND MAINTENANCE MANUAL

100% MADE IN ITALY 100%
100% Made in Italy
F 300 TSV - F 330 TSV - F 350 TSV - F 370 TSV
F 300 TCV - F 330 TCV - F 350 TCV - F 370 TCV
CE PROFESSIONAL VERTICAL ELETRICAL SLICERS
EN
USE AND MAINTENANCE MANUAL

100% MADE IN ITALY 100%
100% Made in Italy
F 300 TSV - F 330 TSV - F 350 TSV - F 370 TSV
F 300 TCV - F 330 TCV - F 350 TCV - F 370 TCV
CE PROFESSIONAL VERTICAL ELETRICAL SLICERS
EN
USE AND MAINTENANCE MANUAL

3
EN
•GENERAL WARNINGS................................................................................................... Page 4
• USE WARNINGS .......................................................................................................... Page 10
• MANUFACTURER’S WARRANTY AND RESPONSIBILITIES .................................... Page 11
• PACKING....................................................................................................................... Page 12
• NAMEPLATES - CONFORMITY MARKINGS............................................................... Page 13
• SUPPLIED ACCESSORIES.......................................................................................... Page 14
• TECHNICAL DESCRIPTION AND INTENDED USE .................................................... Page 14
• ELECTRICAL AND MECHANICAL SAFETY DEVICES................................................ Page 16
• SPACE REQUIREMENT............................................................................................... Page 17
• MAIN TECHNICAL DATA .............................................................................................. Page 17
• MAIN COMPONENTS................................................................................................... Page 19
• INSTALLATION AND PRELIMINARY CHECKS............................................................ Page 20
• COMMANDS DESCRIPTION ....................................................................................... Page 21
• USING THE MACHINE ................................................................................................. Page 22
• SLICER CLEANING ...................................................................................................... Page 27
• MAINTENANCE ............................................................................................................ Page 33
• EXECUTION OF THE SHARPENING........................................................................... Page 34
• LUBRICATION............................................................................................................... Page 36
• MOTOR BELT TENSION ADJUSTMENT...................................................................... Page 37
• TAKING THE SLICER OUT OF SERVICE.................................................................... Page 38
• TROUBLESHOOTING .................................................................................................. Page 39
• USER NOTE ................................................................................................................. Page 40
• ELECTRICAL SCHEMES.............................................................................................. Page 41
• SPARE PARTS.............................................................................................................. Page 43
• MOCA DECLARATION.................................................................................................. Page 52
• DECLARATION OF CONFORMITY.............................................................................. Page 59
INDEX

4
EN
GENERAL WARNINGS
Meaning of warning signs found in booklet
DANGER: Indicates an imminently hazardous situation
which, if not avoided, could result in serious injury
or even death. The use of this term is limited to the
most extreme situations.
ATTENTION: Indicates a potentially hazardous situation
which, if not avoided, could result in serious injury
(and in extreme cases death).
WARNING: Indicates a potentially hazardous situation
which, if not avoided, may result in minor injuries
to personnel or damage to equipment. It also alerts
the user on incorrect operating modes.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Safety warnings
indispensable before use
Carefully read the warnings contained herein as they provide
important information regarding safe installation, use and
maintenance of the Gravity slicing machines for food use.
The purpose of this pubblication, simply dened ‘manual’ below, is to
allow the user, especially to the direct operator to take every measure
and to prepare all the necessary human and material resources for
a safe and durable use of the. This booklet MUST be kept for all the
slicer lifetime and in case of need (example: damage tamperising
even partially its consultation, etc.) the user must ask for a new copy
to the manufacturer.
☞

4
EN
GENERAL WARNINGS
Meaning of warning signs found in booklet
DANGER: Indicates an imminently hazardous situation
which, if not avoided, could result in serious injury
or even death. The use of this term is limited to the
most extreme situations.
ATTENTION: Indicates a potentially hazardous situation
which, if not avoided, could result in serious injury
(and in extreme cases death).
WARNING: Indicates a potentially hazardous situation
which, if not avoided, may result in minor injuries
to personnel or damage to equipment. It also alerts
the user on incorrect operating modes.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Safety warnings
indispensable before use
Carefully read the warnings contained herein as they provide
important information regarding safe installation, use and
maintenance of the Gravity slicing machines for food use.
The purpose of this pubblication, simply dened ‘manual’ below, is to
allow the user, especially to the direct operator to take every measure
and to prepare all the necessary human and material resources for
a safe and durable use of the. This booklet MUST be kept for all the
slicer lifetime and in case of need (example: damage tamperising
even partially its consultation, etc.) the user must ask for a new copy
to the manufacturer.
☞
5
EN
GENERAL WARNINGS
In case of sale of the slicer, deliver to the new owner this manual too.
☞
The installation must be performed following the instructions
of the manufacturer. A wrong installation can cause damages
to people, animals or things, in respect of which the
manufacturer cannot be considered responsable.
Children should not use the device as a
toy and should neither clean nor use the
equipment.
Keep away the children form the device and the power
cord.
The appliance must be used by adults adequately trained
for the purpose who have carefully red the content of this
manual.
• The elements of the packing (plasti bags, expanded polystyrene, etc.)
must be kept out of reach of children as they are potential sources of
danger.
The electrical safety of this device is ensured only when it’s
correctly connected to an efcient grounding installation
in accordance with the electrical safety standards in force.
• It’s necessary to verify this fundamental safety requirement and, in case
of doubt, ask for an accurate installation safety control by professionally
qualied personnel.
The manufacturer cannot be considered responsible for any
damage caused by lack of installation’s grounding.

6
EN
GENERAL WARNINGS
• Before plugging the appliance make sure that the data on the label
correspond to those of the electrical distribution network.
• The plate is on the bottom of the appliance.
•
For your safety, it is recommended to power the device through a circuit
breaker (DRC) with trip current not exceeding 30 mA.
• In case of incompatibility between the socket and the plug of the
appliance have the die-cast wire and plug with another one suitable
by an authorized retailer. In case of tampering the manufacturer
doesn’t answer neither for safety, nor for warranty. Alternatively have
the socket replaced with a suitable type by a qualied professional.
The latter, in particular, will also have to ensure that the section of the
socket cables is suitable for the power absorbed by the appliance.
In general it is not advisable to use adapters, multiple sockets and/or
extensions.
• Do not connect the appliance to the electrical power through external
timers or remote operating systems.
• The use of any electrical appliance requires the observance of some
basic rules. in particular:
- do not touch the appliance with wet hands
- do not use the appliance barefoot
- do not pull the power cord or the appliance itself to remove the plug
from the socket
-
do not leave the aplliance exposed to atmospheric agents (rain, sun,
etc.)
- do not move the appliance when is running.
- the appliance was not designed to be used under rain and must not
be deposited outdoor or in damp places.
• In case of failure and/or malfunction of the appliance, turn it off and
don’t tamper it.
For repairs apply only to the manufacturer or to a service center
authorized by the same and require the use of genuine spare parts.
Failure to comply with the above may compromise the security of the
device.

6
EN
GENERAL WARNINGS
• Before plugging the appliance make sure that the data on the label
correspond to those of the electrical distribution network.
• The plate is on the bottom of the appliance.
•
For your safety, it is recommended to power the device through a circuit
breaker (DRC) with trip current not exceeding 30 mA.
• In case of incompatibility between the socket and the plug of the
appliance have the die-cast wire and plug with another one suitable
by an authorized retailer. In case of tampering the manufacturer
doesn’t answer neither for safety, nor for warranty. Alternatively have
the socket replaced with a suitable type by a qualied professional.
The latter, in particular, will also have to ensure that the section of the
socket cables is suitable for the power absorbed by the appliance.
In general it is not advisable to use adapters, multiple sockets and/or
extensions.
• Do not connect the appliance to the electrical power through external
timers or remote operating systems.
• The use of any electrical appliance requires the observance of some
basic rules. in particular:
- do not touch the appliance with wet hands
- do not use the appliance barefoot
- do not pull the power cord or the appliance itself to remove the plug
from the socket
-
do not leave the aplliance exposed to atmospheric agents (rain, sun,
etc.)
- do not move the appliance when is running.
- the appliance was not designed to be used under rain and must not
be deposited outdoor or in damp places.
• In case of failure and/or malfunction of the appliance, turn it off and
don’t tamper it.
For repairs apply only to the manufacturer or to a service center
authorized by the same and require the use of genuine spare parts.
Failure to comply with the above may compromise the security of the
device.
7
EN
GENERAL WARNINGS
• If you decide not to use a device of this type any more, it must be
made inoperative by cutting the power cord after removing the plug
from the socket.
It is also recommended to make harmless those parts of the equipment
which may constitute a danger, especially for children who might use
an abandoned appliance for their games.
• To avoid dangerous overheating, it is recommended to extend the
power cord to its full length and use the appliance as recommended
in “USING THE MACHINE”.
☞
During the functioning, the socket must be easily accesible
in the event that becomes necessary to unplug the appliance.
Do not place the appliance under a socket so that the wire
doesn’t interfere with the correct use of the machine.
• Do not leave the appliance plugged in unnecessarily. Unplug it from
the power supply when the device is not used.
• After use, always switch off the unit and remove the plug from the
socket.
•
After each use, always perform a thorough cleaning of all parts in contact
with food, as mentioned under “Cleaning the slicer”.
• Do not block the openings, ventilation or heat dissipation slots.
• If the power cord of this appliance is damaged, it must be replaced
by a service center authorized by the manufacturer, as special tools
are required.
Before performing aby operation turn off the appliance
and disconnect the power plug from the socket.
☞
Make sure the power cord does not protrude from the oor
to avoid that someone can pull it also inadvertently knocking
the appliance.

8
EN
GENERAL WARNINGS
☞
Place the appliance on a horizontal and rm supporting plane,
whose surface is not sensitive (eg. Lacquered furniture,
tablecloths etc.). Make sure that the appliance is safely
supported.
☞
Do not place the appliance on or near heat sources.
Place the appliance far from sinks and faucets.
☞
The blades are sharp; handle with care.
Do not use the appliance if the blades are damaged.
☞
Never immerse the appliance in water.
☞
Do not use the appliance in environments containing explosive,
combustible gases or ammable liquids (paints, glues, spray cans,
etc.).
DANGER OF EXPLOSION AND FIRE
.
• This device is intended for domestic and professional use.
☞
This appliance must be used only for the purpose for which
it was designed, that is for slicing food products (see page
15) in respect to the directives and regulations reported in
the declaration of conformity (see next to last page).
Any other use is considered improper and dangerous.
The manufacturer can not be held responsible for any
damage caused by improper, erroneous and unreasonable
use.

8
EN
GENERAL WARNINGS
☞
Place the appliance on a horizontal and rm supporting plane,
whose surface is not sensitive (eg. Lacquered furniture,
tablecloths etc.). Make sure that the appliance is safely
supported.
☞
Do not place the appliance on or near heat sources.
Place the appliance far from sinks and faucets.
☞
The blades are sharp; handle with care.
Do not use the appliance if the blades are damaged.
☞
Never immerse the appliance in water.
☞
Do not use the appliance in environments containing explosive,
combustible gases or ammable liquids (paints, glues, spray cans,
etc.).
DANGER OF EXPLOSION AND FIRE
.
• This device is intended for domestic and professional use.
☞
This appliance must be used only for the purpose for which
it was designed, that is for slicing food products (see page
15) in respect to the directives and regulations reported in
the declaration of conformity (see next to last page).
Any other use is considered improper and dangerous.
The manufacturer can not be held responsible for any
damage caused by improper, erroneous and unreasonable
use.
9
EN
GENERAL WARNINGS
Do not remove safety devices and do not alter or remove
mechanical and electrical guards.
☞
Always use protective scratchproof gloves for cleaning and
maintenance.
☞
Do not operate the empty appliance.
☞
In case of problems with the appliance, contact an authorized
service center.
Do not attempt to repair the device yourself.
Any repair work carried out on the device by
unauthorized personnel will void the warranty
even if its life had not come to an end.
☞
IIf you have any doubts regarding the contents of the user
guide or require additional information, please contact the
manufacturer or technical support immediately quoting the
clause number of the topic in question.
☞
No part of this publication shall be reproduced or transmitted
without written permission from the manufacturer.
☞
Use of the machine requires great concentration, PAY
ATTENTION AT ALL TIMES!
• Do not wear loose-tting clothes particularly with open sleeves; where
necessary use suitable headgear to cover hair.
• When slicing, do not allow anyone to approach the slicer, especially
the blade.

10
EN
• Do not remove, cover or alter the rating plates tted to the machine
body and ensure their prompt replacement in case of damage.
• Ensure that the product tray, receiving tray, surrounding areas and
oor are kept clean and dry at all times.
• Do not use the slicer as a supporting surface or lay any object on it
that is extraneous to normal slicing operations.
• Place and remove the goods to be sliced on the sliding plate only with
the platter completely retracted (away from the blade) and the cart
totally towards the operator.
☞
DO NOT use slicing accessories that have not been supplied
by the slicer manufacturer.
• Do not damage the blade by cutting hard objects (bones, etc.).
• If the size of the food to be sliced are higher than those indicated
under “Working cut” in the table “Technical data”, reduce its size to
work safely.
WARNINGS OF USE

10
EN
• Do not remove, cover or alter the rating plates tted to the machine
body and ensure their prompt replacement in case of damage.
• Ensure that the product tray, receiving tray, surrounding areas and
oor are kept clean and dry at all times.
• Do not use the slicer as a supporting surface or lay any object on it
that is extraneous to normal slicing operations.
• Place and remove the goods to be sliced on the sliding plate only with
the platter completely retracted (away from the blade) and the cart
totally towards the operator.
☞
DO NOT use slicing accessories that have not been supplied
by the slicer manufacturer.
• Do not damage the blade by cutting hard objects (bones, etc.).
• If the size of the food to be sliced are higher than those indicated
under “Working cut” in the table “Technical data”, reduce its size to
work safely.
WARNINGS OF USE
11
EN
• This device is guaranteed for 24
months.
The purchase date must be proven with
the relevant document.
In the absence of valid fiscal document,
the warranty claim can not be exercised.
• In case of non-compliance the claim
must be made in writing within two
months from the observation of the
defect attaching the tax document,
compiled in the act of buying, with stamp
and signature of the store.
Manufacturer’s warranty and responsibilities
• The guarantee of proper operation and
full compliance of the machines to their
intended service depends on the correct
application of the instructions contained
in this manual.
• The manufacturer is not responsible
directly and indirectly for any damage
caused by improper use of the device
resulting from:
- failure to follow instructions contained
in this manual
- use of untrained personnel;
- use not in accordance with specific
regulations, in force in the country
of installation;
- changes and / or unauthorized
repair;
- use of accessories and unoriginal
spare parts;
- misuse of the machine with different
functionality from the one it has been
built for.
- incorrect installation.
- failure to comply with the specic
power techniques
- insufcient or incomplete periodic
maintenance.
- use by people under the age of 18.
- use by people whose physical,
sensory or mental skills are reduced.
- exceeding the loading limits allowed
by the machine
- use in environments different from
the food one
- exeptional events.
MANUFACTURER’S WARRANTY AND RESPONSIBILITIES

12
EN
1.1 - UNPACKING
When taking delivery of the slicer, ensure
that the packaging is fully intact; if this is
not the case, please advise the courier or
local dealer immediately.
In order to remove the slicer from the
packaging, please proceed as follows:
• Cut and remove the plastic bands.
•Open the box and take out the
instruction booklet.
• Proceed as described hereafter.
- Remove the safeguards (carton
and polyurethane foam) inside the
box.
- Lift the machine with great care and
place on a solid surface.
- Remove the plastic bag in which
the slicer is wrapped.
Check that all components speci-
fied in the delivery note and this
instruction booklet are present
and fully intact.
• Should any faults be noted, such as:
- dents to the frame or guards;
- controls that are either not working
or broken;
- missing items or other problems;
pleaseadvise thecourier,manufacturer
and service centre immediately.
- Carefully dispose of packaging com-
ponents (bands, cardboard, poly-
styrene, polythene bags, etc.) as re-
ported below and in accordance with
the standards of the di seguito ed in
ottemperanza alle norme del Coun-
try of use.
PACKING
This product complied with Directive 2012/19/UE.
The crossed out wheeled bin symbol on equipment indicates that it must be treated separately
from household waste at the end of its working life and therefore taken to a recycling facility for
electrical and electronic equipment or handed over to the reseller when purchasing new equipment
of the same type.
The user is responsible for consigning the equipment to appropriate collection facilities at the end
of its working life or face the penalties provided for by current waste management legislation.
Separate collection for subsequent delivery of waste equipment to environmentally-compatible
recycling, treatment and disposal facilities to prevent possible negative impacts on the environment
and human health whilst encouraging recycling of the product’s components.
For further information regarding the available collection facilities, please contact your local refuse
collection service or the shop in which the purchase was made.
Manufacturers and/or importers fulfil their obligations concerning environmentally-compatible
recycling, treatment and disposal either directly or by joining a collective scheme.
GUIDE TO THE TREATMENT OF WASTE EQUIPMENT

12
EN
1.1 - UNPACKING
When taking delivery of the slicer, ensure
that the packaging is fully intact; if this is
not the case, please advise the courier or
local dealer immediately.
In order to remove the slicer from the
packaging, please proceed as follows:
• Cut and remove the plastic bands.
• Open the box and take out the
instruction booklet.
• Proceed as described hereafter.
- Remove the safeguards (carton
and polyurethane foam) inside the
box.
- Lift the machine with great care and
place on a solid surface.
- Remove the plastic bag in which
the slicer is wrapped.
Check that all components speci-
fied in the delivery note and this
instruction booklet are present
and fully intact.
• Should any faults be noted, such as:
- dents to the frame or guards;
- controls that are either not working
or broken;
- missing items or other problems;
pleaseadvise thecourier,manufacturer
and service centre immediately.
- Carefully dispose of packaging com-
ponents (bands, cardboard, poly-
styrene, polythene bags, etc.) as re-
ported below and in accordance with
the standards of the di seguito ed in
ottemperanza alle norme del Coun-
try of use.
PACKING
This product complied with Directive 2002/19/UE.
The crossed out wheeled bin symbol on equipment indicates that it must be treated separately
from household waste at the end of its working life and therefore taken to a recycling facility for
electrical and electronic equipment or handed over to the reseller when purchasing new equipment
of the same type.
The user is responsible for consigning the equipment to appropriate collection facilities at the end
of its working life or face the penalties provided for by current waste management legislation.
Separate collection for subsequent delivery of waste equipment to environmentally-compatible
recycling, treatment and disposal facilities to prevent possible negative impacts on the environment
and human health whilst encouraging recycling of the product’s components.
For further information regarding the available collection facilities, please contact your local refuse
collection service or the shop in which the purchase was made.
Manufacturers and/or importers fulfil their obligations concerning environmentally-compatible
recycling, treatment and disposal either directly or by joining a collective scheme.
GUIDE TO THE TREATMENT OF WASTE EQUIPMENT
13
MADE IN ITALY
F 300 TSV - F 330 TSV - F 350 TSV - F 370 TSV
F 300 TCV - F 330 TCV - F 350 TCV - F 370 TCV
Istruzioni per l’uso e la manutenzione
Affettatrici Elettriche Verticali CE Professionali
IT
Fig. 1
EN
The packing components ( bands , card-
board , polystyrene , etc.) are products
assimilable to the urban solid refusals.
The device described in this manual is
produced in accordance with the directives
in force, as amended. All component parts
are adapted to the requirements of the
Directive and the CE mark testifiying the
compliance.
The plate with the identification of the
manufacturer, the technical machine and
the CE marking is located on the base of
the slicer (gure 2).
DO NOT DUMP PACKAGING!
DISPOSE OF WASTE
RESPONSIBLY!
☞
The plate must never be re-
moved and must always be
legible.
In case of wear or dam-
age the user is required
to replace it.
NAMEPLATES - CONFORMITY MARKINGS

14
TYPE
N. /ANNO
KW. V- Hz.
CE USO PROFESSIONALE
MADE INI T A L Y
IPX1
Fig. 2
EN
Unless otherwise dened at the
moment of order, the machines are
supplied together with the following:
• EU conformity declaration;
• instructions manual for installation,
use and maintenance;
• oiler.
2.1 - General description
The machine is essentially composed
by a base which supports a circular
blade mounted in vertical position,
activated by an electric motor, which
has the function of slicing food products,
and by a sliding tray on guides which in
turn supports a product tray, in parallel
to the blade edge.
The slice thickness is adjustable thanks
to a feeler gauge plate placed before
the blade; this plate, which supports
the food to be cut, can be moved
transversely with respect to the blade
by a value corresponding to the desired
slice thickness.
The product supplying (moving towards
the feeler gauge plate) occurs manually.
All the machine components are
manufactured in anodically polished
and oxidized aluminium alloy, in
stainless steel and in plastic material
for alimentary usage.
SUPPLIED ACCESSORIES
TECHNICAL DESCRIPTION
AND INTENDED USE

14
TYPE
N. /ANNO
KW. V- Hz.
CE USO PROFESSIONALE
MADE INI T A L Y
IPX1
Fig. 2
EN
Unless otherwise dened at the
moment of order, the machines are
supplied together with the following:
• EU conformity declaration;
• instructions manual for installation,
use and maintenance;
• oiler.
2.1 - General description
The machine is essentially composed
by a base which supports a circular
blade mounted in vertical position,
activated by an electric motor, which
has the function of slicing food products,
and by a sliding tray on guides which in
turn supports a product tray, in parallel
to the blade edge.
The slice thickness is adjustable thanks
to a feeler gauge plate placed before
the blade; this plate, which supports
the food to be cut, can be moved
transversely with respect to the blade
by a value corresponding to the desired
slice thickness.
The product supplying (moving towards
the feeler gauge plate) occurs manually.
All the machine components are
manufactured in anodically polished
and oxidized aluminium alloy, in
stainless steel and in plastic material
for alimentary usage.
SUPPLIED ACCESSORIES
TECHNICAL DESCRIPTION
AND INTENDED USE
15
EN
The cutting blade is activated by
an electric motor and the motion
transmission is obtained with a
longitudinally rifted belt.
Start-up and stop are performed by
pressing a button connected to a
control auxiliary circuit which prevents
accidental start-ups of the machine
after a possible disruption of electrical
energy. The machine incorporates
a sharpener built for the maximum
simplicity of use and safety.
2 .2 - Environmental conditions of
the machine use
• Temperature..from -5 °C to + 40 °C
• Relative humidity max 95%
2 .3 - Slicer correct use
The slicer is only designed to slice food of
the type and within the dimensional limits
indicated in this instruction manuals .
2.3.a - Intended use
(sliceable products)
The following products may be sliced:
• All types of cold cuts (raw and cooked
ham, bacon).
• Boneless meat (cooked or raw at a
temperature of not less than +3°C).
• Bread and cheese (obviously the
sliceable type such as Gruyère,
Fontina, etc.).
2.3.b- Unexpected or improper use
(NOT sliceable products)
The following products CANNOT be sliced
as they are liable to cause serious harm to
the user and/or slicer itself:
• Frozen food.
• Deep-frozen food.
• Food with bones (meat and fish).
• Any other type of product specifically
excluded product is sliceable but not
intended to be eaten.

16
EN
The mechanical safety devices taken
are the following:
• A series of aluminium and
transparent plastic guards on the
product carriage.
The electrical safety devices taken
are the following:
• Start/stop button that requires the
machine voluntary restart in case
of an outage or interruption of the
power supply.
• Start up and stop are performed with
the button connected to a control
auxiliary network that prevents
accidental start ups of the appliance
after a possible electrical power cut.
Do not tamper, remove
nor bypass, under no
circumstances, the
safety devices installed
on the equipment.
• All the models are equipped with a
ventilated motor.
3 .1 - Residual risks
During slicer use, cleaning and maintenance operations,
notwithstanding all the possible cautions taken during the design
and the construction of the machine, residual risks (cutting) still
exist during use or during cleaning or maintenance. Therefore be
careful and PAY THE UTMOST ATTENTION to what you are doing.
DO NOT use the machine if you are not in perfect psychological
and physical conditions.
DO NOT ALLOW anyone near the machine when it is in use.
ALWAYS wear gloves that can resist cuts or tears when cleaning,
lubricating or sharpening the blade.
Tensione di alimentazione: Vedere targhetta dati sul basamento macchina.
ELECTRICAL AND MECHANICAL SAFETY DEVICES

16
EN
The mechanical safety devices taken
are the following:
• A series of aluminium and
transparent plastic guards on the
product carriage.
The electrical safety devices taken
are the following:
• Start/stop button that requires the
machine voluntary restart in case
of an outage or interruption of the
power supply.
• Start up and stop are performed with
the button connected to a control
auxiliary network that prevents
accidental start ups of the appliance
after a possible electrical power cut.
Do not tamper, remove
nor bypass, under no
circumstances, the
safety devices installed
on the equipment.
• All the models are equipped with a
ventilated motor.
3 .1 - Residual risks
During slicer use, cleaning and maintenance operations,
notwithstanding all the possible cautions taken during the design
and the construction of the machine, residual risks (cutting) still
exist during use or during cleaning or maintenance. Therefore be
careful and PAY THE UTMOST ATTENTION to what you are doing.
DO NOT use the machine if you are not in perfect psychological
and physical conditions.
DO NOT ALLOW anyone near the machine when it is in use.
ALWAYS wear gloves that can resist cuts or tears when cleaning,
lubricating or sharpening the blade.
Tensione di alimentazione: Vedere targhetta dati sul basamento macchina.
ELECTRICAL AND MECHANICAL SAFETY DEVICES
17
E
AB
C D
EN
Version F 300 TSV F 330 TSV F 350 TSV F 370 TSV
Motor HP 0,50 0,50 0,50 0,50
Blade ø mm 300 330 350 370
Rpm 280 260 260 260
Slice thickness
mm
0 ÷16 0 ÷16 0 ÷16 0 ÷16
Cut
L x H mm
260 x 200 250 x 210 300 x 265 290 x 275
A mm 420 420 530 530
B mm 530 530 650 650
C mm 550 550 650 650
D mm 710 710 820 820
E mm 610 610 640 640
Weight Kg 36 37 45 46
Sharpener built-in built-in built-in built-in
MAIN TECHNICAL DATA
SPACE REQUIREMENT

18
E
AB
CD
EN
Version F 300 TCV F 330 TCV F 350 TCV F 370 TCV
Motor HP 0,50 0,50 0,50 0,50
Blade ø mm 300 330 350 370
Rpm 280 260 260 260
Slice thickness
mm
0 ÷16 0 ÷16 0 ÷16 0 ÷16
Cut
L x H mm
260 x 200 250 x 210 300 x 250 290 x 260
A mm 420 420 530 530
B mm 530 530 650 650
C mm 550 550 670 670
D mm 710 710 820 820
E mm 550 550 640 640
Weight Kg 34 35 43 44
Sharpener built-in built-in built-in built-in
MAIN TECHNICAL DATA
SPACE REQUIREMENT
