FAZUA Evation User manual

pedelec drive system
© 2020 Fazua GmbH
All Rights Reserved
Original instructions
U.S. Edition 2020 | EN

3
| evation
Drive system:FUNDAMENTALS
1Overview: Drive system ........................................................................6
2About this manual ................................................................................8
2.1Terminology and structure......................................................... 8
2.2Read and keep manual...............................................................8
2.3Explanation of characters and symbols used..........................9
3Safety...................................................................................................10
3.1Functionality & intended use ...................................................10
3.2Limitation of liability .................................................................10
3.3Symbols & pictograms of the drive system............................11
3.4Important safety instructions..................................................13
3.5Notes on safe riding in road traffic..........................................20
4Usage...................................................................................................22
4.1Attaching and removing components ....................................22
4.2Switching the drive system on and off....................................25
4.3Instructions for riding with the drive system ..........................27
4.4Switching on the drive system after standstill .......................28
4.5Set support level.......................................................................29
4.6Using "Pushing support" mode ...............................................30
4.7Charging the battery.................................................................31
5Storage and transport........................................................................33
6Optional accessories..........................................................................34
7Cleaning and maintenance ................................................................35
8Troubleshooting..................................................................................37
9Disposal instructions .........................................................................39
9.1Disposal of your e-bike.............................................................39
9.2Battery disposal........................................................................39
10 Consumer Warranty ...........................................................................40
11 Service.................................................................................................42
12 Conformity ..........................................................................................43

4evation |
Components: DRIVEPACK
13 Detailed view & part designations: Drivepack ..................................44
14 Technical data.....................................................................................46
15 Using drivepack ..................................................................................46
15.1Mounting the drivepack on the e-bike.....................................46
15.2Remove drivepack from e-bike................................................48
15.3Secure/lock drivepack from e-bike.........................................49
Components: BOTTOM BRACKET
16 Detailed view & part designations: Bottom Bracket ........................50
17 Technical data.....................................................................................51
18 Using bottom bracket.........................................................................51
18.1Correct position/alignment .....................................................52
18.2Correcting incorrect position/alignment ................................52
Components: REMOTE
19 Model variants of the remote.............................................................54
20 Detailed view & part designations: Remote b...................................54
21 Technical data Remote b ...................................................................56
22 Displays on the Remote b...................................................................56
22.1Status display ...........................................................................56
22.2Display of charging level/support level...................................57
23 Using Remote b...................................................................................58
23.1Switching the drive system on and off....................................58
23.2Setting the pedal support ........................................................59
23.3Levels of support......................................................................59
23.4"Pushing support" mode..........................................................60
24 Detailed view & part designations: Remote fX and Remote bX ......62
25 Technical data Remote fX and Remote bX.......................................63
26 Displays on the Remote fX and Remote bX......................................63
26.1Status display ...........................................................................64
26.2Display of charging level/support level...................................64

5
| evation
27 Using Remote fX and Remote bX......................................................65
27.1Switching the drive system on and off....................................65
27.2Setting the pedal support ........................................................66
27.3Levels of support......................................................................67
27.4Restart drive system ................................................................68
27.5Rain mode .................................................................................68
27.6Switching bicycle lighting on and off ......................................68
27.7Bluetooth connectivity .............................................................69
Components: BATTERY
28 Model variants of the battery.............................................................70
29 Detailed view & part designations: Battery.......................................71
30 Technical data.....................................................................................72
31 Using the battery.................................................................................72
31.1Checking and switching on battery.........................................72
31.2Inserting the battery into the drivepack ..................................73
31.3Removing the battery from the drivepack ..............................75
31.4Switching off the battery..........................................................75
31.5Charging the battery.................................................................76
31.6Charging process .....................................................................77
31.7Battery charge level indicator..................................................78
Components: CHARGER
32 Model variants of the charger............................................................79
33 Detailed view & part designations: Charger......................................79
34 Technical data.....................................................................................80
35 Using charger......................................................................................81
35.1Prepare charger ........................................................................81
35.2Connector charger to the battery ............................................82
35.3Unplug charger from battery ...................................................83

Chapter "Overview: Drive system"
6evation |
1 OVERVIEW: DRIVE SYSTEM
Charger
(Details from page 79)
E
Charger A
Charger, Model
STC-8133LC-F (EU/US)
Drivepack
(Details from page 44)
ABottom Bracket
(Details from page 50)
B
Battery
(Details from page 70)
D
Battery 250 X
Battery 250
Remote
(Details from page 54)
C
Remote b
Remote fX
Remote bX

7
Chapter "Overview: Drive system"
| evation
+

Chapter "About this manual"
8evation |
2 ABOUT THIS MANUAL
2.1 Terminology and structure
These original instructions are part of the Fazua evation drive system.
In order to improve readability, the term "manual" will be used instead of
the term "original instructions".
To facilitate orientation within the manual, it is divided into sections:
The first section "Fundamentals" deals with the drive system as a whole.
In chapter 3"Safety" you will find the basic information on intended
use and important safety instructions. Chapters 4-8("Usage", "Storage
and transport", "Optional accessories", "Cleaning and maintenance",
"Troubleshooting") describe the procedures and steps to be taken. In
chapters 9–12 you will find information on disposal instructions, consumer
warranty, manufacturer and dealer service as well as conformity.
The remaining sections are dedicated to the individual components of
the drive system: Here you will find detailed illustrations and additional
information on the respective components. In addition, the steps listed in
chapter 4"Usage" are described in detail and supplemented with handling-
specific warnings.
2.2 Read and keep manual
This manual contains all important information on the safety and use of
the drive system as well as the individual components. It is based on the
laws and regulations applicable in the United States, as well as national
regulations such as UL® and ANSI testing standards.
Before using the drive system for the first time, be sure to read the complete
manual - especially the "Safety" chapter - carefully. Failure to follow the
instructions could result in serious injury to you or others and/or damage
to the drive system or individual components.
Always keep this manual handy for further use and pass it on if you pass
on the drive system or the equipped e-bike to third parties. In addition
to this manual for the drive system, always observe the manufacturer's
instructions for the e-bike in which the drive system is installed.
The Bluetooth® word mark and logos are registered trademarks of
Bluetooth SIG, Inc. and are used by Fazua under license.
This manual may not be reproduced, modified, distributed or used in any
way, in whole or in part, without prior written permission.

9
Chapter "About this manual"
| evation
2.3 Explanation of characters and symbols used
Certain types of notes and information in this manual are identified by
signs or symbols, which are listed below together with their meaning.
DANGER
High risk level! Risks that result in death or serious injury are indicated by
the signal word "Danger".
WARNING
Moderate risk level! Risks that can result in death or serious injury are
indicated by the signal word "Warning".
CAUTION
Lower risk level! Risks that may result in moderate injuries are indicated by
the signal word "Caution".
NOTICE
Risks relating to damage to the product itself or to property damage to
other objects are indicated by the signal word "Notice".
Useful additional information is marked with this information
symbol.

Chapter "Safety"
10 evation |
3 SAFETY
3.1 Functionality & intended use
evation is designed as an electric drive system for e-bikes that are used as
a means of transport by one person. From a speed of 20 mph (32 km/h),
the electric pedal support switches off, so that at speeds above 20 mph
(32 km/h) without motor support, you pedal exclusively with your own
muscle power.
The drive system as a whole is made up of different, coordinated
components.
These are:
A→Drivepack (incl. locker for locking to the frame),
B→Bottom Bracket (incl. Speed Sensor + spoke magnet),
C→Remote (Remote b, Remote fX, Remote bX),
D→Battery (Battery 250, Battery 250 X ),
E→Charger (Charger A, Charger, Model STC-8133LC-F (EU/US)).
The version of the drive system installed in your e-bike, i.e. the specific
combination of component variants, is specially adapted to your e-bike
and must therefore not be changed.
Categorically, the installation of the drive system and certain work on it
may only be carried out in the ways planned by the manufacturer or by an
authorized specialist. Authorized specialists for repair and maintenance
work can be found with the official Fazua Servicepartners (see chapter
11 "Service").
For information on which work you can carry out yourself and which work
must be carried out by an authorized specialist, refer to the separate
sections on the individual components.
3.2 Limitation of liability
Fazua accepts no liability for damage caused by incorrect or improper
installation or use other than that intended. Only use the drive system as
described in this manual. Any other use is considered improper and may
result in accidents, serious injury and damage to the drive system.

11
Chapter "Safety"
| evation
3.3 Symbols & pictograms of the drive system
On individual components of the drive system you will find certain symbols
and pictograms, which are listed below including their meaning.
This symbol indicates that the user of the drive system or
the individual components must have read and understood
these original instructions before using it.
A device marked with this symbol (here: the charger) may
only be used in dry indoor areas.
DANGER
When used in a humid environment and in contact with
liquids, there is a risk of electric shock!
An electrical appliance marked with this symbol corresponds
to protection class II: The device has double or reinforced
insulation to protect against electric shock.
This symbol warns of hot surfaces.
DANGER
There is a burning risk if touched, contact with combustible
materials may cause a fire.
These symbols indicate that the lithium-ion battery must be
disposed of separately at the end of its life and must not be
disposed of with household waste.
The symbols must be affixed in the European Union in
accordance with the laws and directives in force there.
This symbol indicates that the marked component must be
disposed of separately as electrical or electronic equipment
at the end of its service life and must not be disposed of with
household waste.
The symbol must be affixed in the European Union in
accordance with the laws and directives in force there.

Chapter "Safety"
12 evation |
This symbol indicates products that meet all the requirements
for obtaining the European CE marking.
The test seal "Geprüfte Sicherheit" (GS mark) is awarded by
independent certification bodies.
A device marked with the GS test seal complies with the
safety-relevant requirements of the German Product Safety
Act (ProdSG).
The "UL®-Listed" seal of approval is awarded by the US UL®
Certification Body.
A device marked with the "UL®-Listed" test seal shown
corresponds to the safety-relevant requirements for Canada
and the USA.
The accompanying test seal is awarded by the SGS
certification body.
A device marked with this test seal complies with the safety-
relevant requirements for Canada and the USA in accordance
with UL Standards.
The drive system and the battery were tested according to
UL Standards. The following UL Standards were applied:
UL 2271 - Standard for Batteries for Use In Light Electric
Vehicle (LEV) Applications, UL 2849 - Standard for Electrical
Systems for eBikes.
The FCC seal is awarded by the Federal Communications
Commission, an independent U.S. government
agency responsible for implementing and enforcing
U.S. communications laws and regulations.
An electrical device marked with the FCC seal complies with
American standards for electromagnetic compatibility.

13
Chapter "Safety"
| evation
3.4 Important safety instructions
READ AND KEEP ALL IMPORTANT
SAFETY INSTRUCTIONS!
The following important safety instructions must always be observed
when using and handling the drive system.
►Read all the instructions before using the product.
►To reduce the risk of injury, close supervision is necessary
when the product is used near children.
►Do not put fingers or hands into the product.
►Do not use this product if the flexible power cord or output
cable is frayed, has broken insulation,or any other signs of
damage.
►This equipment is not intended to be used at ambient
temperatures less than -5°C (23 °F) or above ambient
temperatures of +40 °C;
►The battery is intended to be charged when the ambient
temperature is between 0°C (32 °F) and +45 °C (113 °F).
Never charge the battery when ambient temperatures are
outside this range.
DANGER
Dangers for users of e-bikes!
Basically there are specific dangers for the users of e-bikes,
e. g. danger of accidents when riding in road traffic. Dangers
arising from handling the corresponding e-bike model in
which the drive system is installed are dealt with in the
separate instructions of the e-bike manufacturer. Depending
on your country or location, there may also be additional legal
requirements that you must observe when using your e-bike. If
you do not fully inform yourself about existing dangers before
using your e-bike equipped with the drive system, there is an

Chapter "Safety"
14 evation |
increased risk of accident and injury.
►Read and follow the manufacturer's instructions for your
e-bike.
►Find out about and observe any applicable national
regulations regarding e-bikes.
DANGER
Danger of battery explosion!
If you use inappropriate batteries or do not handle the battery
properly, the battery may explode.
►Only use original Fazua evation batteries approved by the
e-bike manufacturer.
►Never use a damaged battery and never try to charge a
damaged battery!
►Never open the battery! If you try to open the battery, there
is an increased risk of explosion!
►Keep the battery away from heat (e.g. strong sunlight), open
fire or water or other liquids.
DANGER
Dangers during unattended use!
Basically there are specific dangers dangers for children
(younger than 14) and persons with reduced physical, sensory
and mental abilities (e.g. partially handicapped persons, older
persons with limited physical and mental abilities) or a lack of
experience and knowledge (e.g. older children)!
If, for example, children or people with physical or mental
impairments handle the battery or charger, there is an increased
risk potential as these user groups may not be able to correctly
assess certain risks, for example.
►This appliance is not intended for use by children (younger

15
Chapter "Safety"
| evation
than 14) and persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
►Children shall not play with the appliance.
►Only for rechargeable li-ion battery.
►Don't attempt to disassemble the charger by yourself.
►Don'tusethechargerinhightemperature,moist,inflammable
or explosive outdoor environments.
►Disconnect the power supply before marking or breaking
the connections to the battery.
DANGER
Danger of impairment of medical devices!
The magnetic connections in the battery and charger can
interfere with the function of pacemakers.
►Keep the battery and charger away from pacemakers or
persons wearing a pacemaker and draw the attention of
persons with pacemakers to the danger.
DANGER
Risk of electric shock!
Improper handling of the charger or incorrect mains connection
may expose you and others to the risk of electric shock.
►Only connect the charger to an easily accessible and
properly installed power outlet.
►Make sure that the mains voltage at the mains connection
corresponds to the information on the charger.
►Only use the charger in dry indoor areas.

Chapter "Safety"
16 evation |
►Keep the charger away from any liquid or moisture.
►Do not pull on the mains or charging cable to pull the
respective cable out of a socket or outlet, but always hold
the corresponding plug.
►Do not handle the plugs of the power cord and charging
cable with wet or damp hands.
►Take care not to bend the power cord and charging cable or
lay them over sharp edges.
►Do not open the charger without authorization. The charger
may only be opened by an authorized specialist and repaired
using original spare parts.
►Before each use of the charger, check all individual parts
(mains adapter, mains cable, charging cable and all plugs)
for damage. If the charger's power cord is damaged, it must
be replaced by an authorized specialist to avoid hazards.
►Never use a damaged charger. Otherwise there is a high risk
of electric shock!
►Keep the charger in a clean condition. There is an increased
risk of electric shock if the charger is dirty or contaminated.
►Only use the battery in e-bikes equipped with an original
Fazua evation drive system. Never use the battery for other
purposes or in other drive systems.
DANGER
Dangers due to unauthorized changes!
If you make unauthorized changes to the drive system or
components, you may cause an explosion, electric shock, or
serious injury to yourself or others.
►Under no circumstances shouldyoumodify oralterindividual
components of the drive system autonomously.
►Never replace any components of the drive system without

17
Chapter "Safety"
| evation
authorization.
►Never open the drive system components without
authorization. The drive system components do not require
any maintenance. Only allow repairs to the drive system to
be carried out by an authorized specialist.
►Only allow components of the drive system to be replaced
by an authorized specialist with permissible original spare
parts.
DANGER
Fire hazard due to incorrect handling!
If you handle the battery and/or charger improperly or use
incompatible batteries and chargers together, they may cause
a fire.
►Follow all charging instructions and do not charge the
battery outside of the temperature range specified in the
instructions. Charging improperly or at temperatures
outside of the specified range may damage the battery and
increase the risk of fire.
►Do not modify or attempt to repair the charger or the battery.
►To charge the battery, use only original and compatible
evation chargers from Fazua.
►Take care not to handle metal objects such as coins, paper
clips, screws, etc. in the immediate vicinity of the battery
and to store the battery separately from metal objects.
Metal objects can close a circuit between the terminals of
the battery (i.e. "short-circuit" the battery) and so cause a
fire.
►Do not short-circuit the battery.
►Battery and charger may heat up during charging or
operation. It is therefore essential to keep the battery and

Chapter "Safety"
18 evation |
charger away from flammable materials. Pay particular
attention during the charging process and always move
the battery and charger to a dry and fireproof place before
charging.
►Do not leave the battery and charger unattended during
charging.
WARNING
Risk of caustic burns due to battery acid!
The battery contains battery acid. If you come into contact with
this fluid, the affected skin area and/or mucous membrane may
be burnt. Eye contact can cause loss of vision.
►Do not touch any liquid leaking from the battery.
►Should you ever come into contact with battery acid,
immediately rinse the affected body part thoroughly under
plenty of running water.
►Consult a doctor immediately after rinsing, especially
in case of eye contact and/or if mucous membranes
(e.g. nasal mucosa) are affected.
WARNING
Health hazard due to irritation of the respiratory tract!
If the battery is damaged, gases may escape which may irritate
the respiratory tract.
►Protect the battery from mechanical influences and any
other load.
►If you notice or suspect that gas is leaking from the battery,
immediately ensure a supply of fresh air and seek medical
attention as soon as possible.

19
Chapter "Safety"
| evation
WARNING
Danger from accidental starting!
Starting the drive system in unsuitable situations can result in
accidents and serious injury.
►Remove the drivepack from the e-bike while the e-bike is
being transported or stored and during all work on the e-bike
to prevent the drive system from being started accidentally.
►Use the "Pushing support" function only when pushing the
e-bike. While the pushing support is activated, you must hold
the e-bike securely with both hands and the wheels must be
in contact with the ground, otherwise there is a risk of injury.
WARNING
Risk of burns!
The radiator in the drivepack can become very hot during
operation so that you can burn yourself on it.
►Be careful when handling the drivepack.
►Allow the drivepack to cool down completely before touching
the drivepack.
NOTICE
Risk of damage!
Improper handling can damage the drive system or individual
components.
►Have individual components of the drive system and the
e-bike replaced exclusively by identical components or other
components expressly approved by the e-bike manufacturer.
This will protect the other components or your e-bike from
possible damage.
►Never use your e-bike without a drivepack or without a

Chapter "Safety"
20 evation |
downtube cover if you use it as a conventional bicycle
without a drivepack.
►Remove the battery before cleaning the drivepack and
allow all components to dry completely before inserting.
Ifthebatterycomesintocontact withdampor wetcontactson
the drivepack during insertion, the battery may be damaged.
►When charging the battery, make sure that the mains cable
and charging cable of the charger are not trip hazards in order
to prevent components from being damaged, e.g. by a fall.
3.5 Notes on safe riding in road traffic
By following the road safety precautions listed below, you can reduce the
risk of accidents and injuries when riding a bicycle or e-bike in road traffic.
The term "road traffic" also refers to private areas open to the
public and to field or forest paths open to the public.
►Only ride your e-bike on the road if the equipment complies with national
road traffic regulations. Please contact your e-bike manufacturer for
more information.
►Find out about the regulations applicable to road traffic in your country
or region, e.g. from the Ministry of Transport. You should also keep
yourself informed about any changes to the contents of the valid
regulations.
►Observe and follow national and regional road traffic regulations.
►When riding, use a suitable bicycle helmet that complies with
national and regional regulations (CPSC (Consumer Product Safety
Commission, 16 CFR Part 1203 or ASTM F1447-06).
►When riding, wear light-colored clothing with reflective elements to
attract the attention of other road users.
►Do not ride your e-bike if you are under the influence of alcohol,
narcotics or medications.
►Do not use mobile devices such as smartphones, MP3players, etc.
while riding.
►Do not distract yourself while riding by other activities such as switching
