Fein WSg 20-180 Quick start guide

SERVICE
Tool service and maintenance must be performed only by qualified
repair personnel.
When servicing a tool, only use identical replacement parts available
from FEIN.
Repairs on FEIN Power Tools required the use of special tools (pulling devices
and bearing press). Authorized repair centers have trained repair technicians
andequipmentnecessarytoper-formtheserepairs.Serviceorrepairsperformed
by unqualified persons could result in operator injury.
For the location of the repair center near you, please call 1-800-441-9878.
Monday thru Friday, 9AM to 5PM EST. Or, look on our web site at
www.feinus.com and follow the link to “AuthorizedWarranty Repair Centers”
Phone: [phone] Fax: [phone] Toll Free: 1-800-441-9878
FEIN Power Tools
1030 Alcon Street
Pittsburgh, PA 15220
November 7, 2006
WSG 20-180
Angle Grinder

WSG 20-180 Parts List
Item Item Number Description Reqd
10 3-19-03-214-00-6 MOTOR HOUSING 1
20 3-07-12-090-03-1 BRUSH HOLDER 2
30 3-07-11-143-00-6 CARBON BRUSH 2
40 4-30-70-027-00-0 SCREW 4
60 5-1-275-003-36-2 FIELD COIL 1
70 4-30-72-011-00-8 SCREW 1
80 3-24-27-117-00-8 COVER 1
90 3-24-27-118-00-6 COVER 1
110 3-12-07-251-00-8 COVER 1
120 3-14-28-144-00-5 CONTACT 1
130 3-14-15-092-00-3 WASHER 1
140 3-07-62-254-99-5 ELECTRONIC 1
160 3-14-28-141-00-0 COVER 1
300 3-12-06-114-03-1 GEAR HOUSING ASSEMBLY 1
310 4-17-06-030-00-7 NEEDLE BEARING 1
320 3-24-19-122-00-9 GEAR HOUSING COVER 1
330 3-06-01-110-00-5 FELT RING 1
340 3-24-11-084-00-9 COVER 1
350 4-17-01-224-02-4 BALL BEARING 1
360 3-24-16-105-00-8 COVER 1
370 4-30-64-002-04-3 SCREW 5
380 3-34-06-291-00-3 SPINDLE 5/8 - 11 1
430 3-26-01-273-00-6 RING 1
445 3-38-09-232-01-6 GEAR SET 1
520 3-26-24-118-02-2 RING 1
530 4-24-43-004-05-7 LOCK WASHER 4
540 4-30-64-009-05-4 SCREW 4
560 3-05-07-230-00-9 BUSHING 1
570 3-02-17-335-00-5 PIN 1
580 4-06-12-137-00-8 SEALING RING 1
590 3-09-01-354-00-4 SPRING 1
600 3-28-05-180-00-4 BUTTON 1
650 3-05-07-169-00-7 BUSHING 1
660 5-32-75-002-36-0 ARMATURE 1
670 3-24-16-106-00-1 MOUNTING PLATE 1
680 3-06-01-050-00-2 FELT RING 1
690 3-24-11-083-00-1 RING 1
700 4-17-01-213-09-6 BALL BEARING 1
720 4-24-43-003-04-3 LOCK WASHER 2
740 3-05-07-168-00-3 BUSHING 1
750 4-17-01-207-03-3 BALL BEARING 1
760 4-30-70-029-00-2 SCREW 2
770 4-30-70-030-00-4 SCREW 2
780 3-18-10-245-01-2 WHEEL GUARD ASSEMBLY 1
790 3-21-19-032-00-2 HANDLE 1
800 6-38-01-095-00-8 INNER FLANGE 1
810 6-38-02-098-00-7 OUTER FLANGE 1
820 3-14-15-089-00-9 BOLSTER 1
840 3-07-19-613-01-2 CONNECTION CABLE 1
900 3-12-04-167-00-0 HANDLE 1
910 3-07-01-278-01-0 SWITCH ASSEMBLY 1
915 4-30-41-001-99-4 SCREW 1
920 3-14-13-094-00-7 PROTECTING SLEEVE 1
935 3-07-07-398-01-9 CABLE 1
940 3-24-31-042-00-8 CLIP 1
950 4-30-70-035-00-2 SCREW 1
955 3-07-17-203-01-4 SUPPORT 1
960 4-30-41-016-04-2 SCREW 2
980 3-09-01-343-00-7 SPRING 1
990 3-28-16-057-00-7 TRIGGER 1
1000 3-12-04-168-00-8 HANDLE, UPPER PART 1
1010 4-30-70-031-00-3 SCREW 8
