Fema Electronica K K40-A Series User manual

Series K . K40-A
AC Voltmeter and AC Ammeter
AC voltmeter and AC ammeter for panel mount, with 20 mm digit height. Scalable reading. Measure
in True RMS. Measure up to 600 Vac and up to 5 Aac. Measure category CAT-II and CAT-III. Selectable
signal coupling mode ‘AC’ or ‘AC+DC’. Standard 96 x 48 mm size (1/8 DIN). Reading with 4 digit dis-
play. Fast access to alarm setpoints, ‘on power up’ funcon, ‘measure’ funcon, congurable reading
brightness. Universal AC and DC power. Up to 3 oponal modules for output and control (relays, tran-
sistor, control SSR, analog outputs, Modbus RTU communicaons, RS-485 ASCII, RS-232, ...)
www.fema.es
Tel. [phone] inf[email protected]
User’s Manual
ELECTRONICS FOR INDUSTRIAL AUTOMATION
PANEL METERS . SIGNAL CONVERTERS . LARGE DISPLAYS
PANEL METERS
3632r04

FEMA ELECTRÓNICA . Series K . K40-A
2
1. Panel meter K40-A
AC voltmeter and AC ammeter, size 96 x 48 mm (1/8 DIN) , with 20 mm digit height
Panel meter 96 x 48 mm (1/8 DIN) for AC voltage and AC current
signals, with 20 mm digit height. Reading with 4 digits scalable to
9999 / -1999 with selectable decimal point posion. Measure in
True RMS. Measure category CAT-II and CAT-III. AC voltage measure
up to 600 Vac, and AC current measure up to 5 Aac. Signal measure
coupling mode selectable in ‘AC’ or ‘AC+DC’.
Opons for output and control with 1, 2 and 3 relays, transistor out-
puts, controls for SSR relays, isolated analog outputs, communica-
ons in Modbus RTU, RS-485 ASCII and RS-232. Special opons with
4 and 6 relay outputs.
Independent alarms congurable as maximum or minimum, with 1
or 2 setpoints per alarm, hysteresis, independent acvaon and de-
acvaon delays and control for inverted relay.
Front protecon IP65. Connecons by plug-in screw terminals. For
industrial applicaons.
• ‘Fast access’ menu to selected funcons, accessible with key UP (5)
(see secon 1.12.5)
• ‘Field correcon’ for fast and easy on-the-eld correcon of signal
osets (see secon 1.12.2)
• ‘On power up’ for system protecon on rst ‘cold’ start-up (see
secon 1.12.7)
• Measure technique in ‘True RMS’
• Measure coupling ‘AC’ or ‘AC+DC’ (see secon 1.9)
• ‘Peak & hold’ for test-break applicaons (see secon 1.12.4)
Mulple display lters, memory for maximum and minimum reading,
password protecon, 5 brightness levels.
1.1 How to order
Index
1. Panel meter K40-A . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 How to order . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Front view . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Power connecons . . . . . . . . . . . . . . . . . . . . . 3
1.5 Signal connecons - AC voltage . . . . . . . . . . . . . . 3
1.6 Signal connecons - AC current . . . . . . . . . . . . . . 3
1.7 Technical specicaons . . . . . . . . . . . . . . . . . . 4
1.8 Mechanical dimensions (mm) . . . . . . . . . . . . . . . 5
1.9 Coupling ‘AC’ or ‘AC+DC’ . . . . . . . . . . . . . . . . . . 5
1.10 How to operate the menus. . . . . . . . . . . . . . . . 6
1.11 Messages and errors . . . . . . . . . . . . . . . . . . . 6
1.12 Conguraon menu. . . . . . . . . . . . . . . . . . . . 7
1.12.1 Inial set-up . . . . . . . . . . . . . . . . . . . . . . 7
1.12.2 Field correcon . . . . . . . . . . . . . . . . . . . . 7
1.12.3 Alarms . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.12.4 Display lters. . . . . . . . . . . . . . . . . . . . . . 9
1.12.5 Fast access . . . . . . . . . . . . . . . . . . . . . . .10
1.12.6 Super fast access . . . . . . . . . . . . . . . . . . . 10
1.12.7 Menu ‘On Power Up’ . . . . . . . . . . . . . . . . . 10
1.12.8 Menu ‘Key LE’ . . . . . . . . . . . . . . . . . . . . .11
1.12.9 AC dead band . . . . . . . . . . . . . . . . . . . . . 11
1.12.10 Funcon ‘Password’ . . . . . . . . . . . . . . . . .11
1.12.11 Factory reset . . . . . . . . . . . . . . . . . . . . .11
1.12.12 Firmware version. . . . . . . . . . . . . . . . . . . 11
1.12.13 Brightness . . . . . . . . . . . . . . . . . . . . . . 11
1.12.14 Access to oponal modules . . . . . . . . . . . . . 11
1.13 Full conguraon menu . . . . . . . . . . . . . . . . . 12
1.14 To access the instrument . . . . . . . . . . . . . . . . .14
1.15 Modular system . . . . . . . . . . . . . . . . . . . . . .14
1.16 Precauons on installaon . . . . . . . . . . . . . . . .15
1.17 Factory conguraon . . . . . . . . . . . . . . . . . . .15
1.18 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.19 CE declaraon of conformity . . . . . . . . . . . . . . . 15
2. Output and control modules . . . . . . . . . . . . . . . . . 16
2.1 Module R1. . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2 Module T1. . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Module SSR . . . . . . . . . . . . . . . . . . . . . . . . .17
2.4 Module AO . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6 Module RTU. . . . . . . . . . . . . . . . . . . . . . . . . 18
2.5 Module S4. . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.7 Module S2. . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.8 Modules R2, R4, R6. . . . . . . . . . . . . . . . . . . . . 19
3. Other opons . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.1 Opon NBT . . . . . . . . . . . . . . . . . . . . . . . . . 20
4. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .21
4.1 THM benchtop housing . . . . . . . . . . . . . . . . . . 21
4.2 Adapter DRA-M . . . . . . . . . . . . . . . . . . . . . . . 21
4.3 Adapter KA96 . . . . . . . . . . . . . . . . . . . . . . . .21
4.4 WME housing . . . . . . . . . . . . . . . . . . . . . . . . 21
4.5 Protector KIP . . . . . . . . . . . . . . . . . . . . . . . . 21
K40 A
Model Power
-
Opon 1 Others
H- - -
Opon 2
-
Opon 3
-
-R1 (1 relay)
-AO (analog output)
-RTU (Modbus RTU)
-S4 (RS-485)
-S2 (RS-232)
-T1 (1 transistor)
-SSR (1 control SSR)
- (empty)
-H (85-265 Vac/dc)
-L (11/60 Vdc,
24 Vac, 48 Vac)
-NBT (no buons)
-65 (front IP65)
-G (green led)

FEMA ELECTRÓNICA . Series K . K40-A
3
1.2 Front view
1.3 Rear view
Earth connecon - Although a
terminal is provided for earth
connecon, this connecon is
oponal. The instrument does
not need earth connecon for
correct operaon nor for com-
pliance with the security regu-
laons. ~
~+
-
8 9 0
Fuse - To comply with security regulaon 61010-1, add to the power
line a protecon fuse acng as disconnecon element, easily acces-
sible to the operator and idened as a protecon device.
Power ‘H’ fuse 250 mA me lag
Power ‘L’ fuse 400 mA me lag
1.4 Power connecons
1.5 Signal connecons - AC voltage
Buon ‘UP’
Logo
Alarms
Units
Buon ‘SQ’
Buon ‘LE’
‘Conguraon menu’
(see secon 1.12)
‘Fast access‘
(see secon 1.12.5)
Signal
(see secon 1.5)
Jumpers
(see secon 1.5 and 1.6)
Opon 1 Opon 2Opon 3
Power
(see secon 1.4)
Detail of the plug-in screw terminals provided with
the instrument. The instrument is provided with all
terminals needed, both male and female.
To congure the voltage AC measure, select the jumper for the de-
sired scale as indicated in the table below. Then acvate the selected
scale in the conguraon menu (see secon 1.12.1) and connect the
input signal to the signal terminals.
Scale Close jumper
600 Vac - - -
100 Vac 4
10 Vac 3
1 Vac 2
100 mVac 1
Table 1 - Jumper selecon ‘1234’ for AC voltage scales
Vac
Vac
123
1234
Jumper for input scale selecon
(see Table 1)
~
~
1.6 Signal connecons - AC current
To congure the current AC measure, select the jumper as indicated
in the table below. Then acvate the desired scale in the congura-
on menu (see secon 1.12.1) and connect the input signal to the
signal terminals
Aac
Aac
1234
Jumper for input scale selecon
(see Table 2)
~
~
123
Scale Close jumper
5 Aac - - -
1 Aac - - -
Table 2 - Jumper selecon ‘1234’ for AC current scales
123 890
1234

FEMA ELECTRÓNICA . Series K . K40-A
4
Digits
number of digits 4
led 7 segments led
color red
digit height 20 mm
Reading
maximum reading* 9999
minimum reading* -1999
decimal point congurable X.X.X.X.
overrange ash reading (see secon 1.11)
underrange ash reading (see secon 1.11)
acquisions 15 readings / second
display refresh 15 readings / second
step response* <300mSec (input 0 to 95% FS)
<500mSec (input 0 to 50% FS)
<1100mSec (input 0 to 10% FS)
*The response me for a TrueRMS measuring system is faster for higher am-
plitude signals. Response mes are given for input steps of 10 %, 50 % and
95 % of the full scale (FS), calculated at 99 % of end reading.
Measure
measured signals AC voltages and AC currents
measure technique True RMS
crest factor 3 for nominal accuracy
5 for accuracy of 2.5 % FS
accepted connecons phase-neutral and phase-phase
measure coupling ‘AC’ or ‘AC+DC’(see secon 1.9)
scales (see Table 3)
accuracy (see Table 3)
thermal dri (see Table 3)
signal connuity +20 % FS
minimum signal accepted 0.5 % of the scale (congurable) (see
secon 1.12.9)
reading will be ‘0’ for lower signals
input impedance (see Table 3)
bandwidth (at 99 % FS) 1.3 KHz for AC voltages
2.0 KHz for AC currents
minimum frequency 25 Hz for reading oscillaon ±1 count
1.7 Technical specicaons
Power
power ‘H’ 85 a 265 Vac/dc
power ‘L’ 11 a 60 Vdc y 24/48 Vac
isolaon* 2500 Ve with power ‘H’
1500 Ve with power ‘L’
*all units tested during 60 seconds
consumpon <1.5 W only meter
<4.0 W meter with opons
Conguraon 3 buons front keypad
(and rear jumper)
Front protecon IP65
Output and control opons relays, analog outputs, serial communi-
caons, ... (see secon 2)
Mechanical
mounng panel
connecons plug-in screw terminal
housing material ABS, polycarbonate (V0)
weight <150 grams
front size 96 x 48 mm (1/8 DIN)
panel cut-out 92 x 44 mm
depth from panel 91 mm (including terminals)
Temperature
operaon from 0 to +50 ºC
storage from -20 to +70 ºC
warm-up me 15 minutes
Scale Accuracy Zin
(at 50 Hz and 60 Hz)
Max. signal overload Oset dri Span dri*
*includes oset dri
600 Vac 0.25 % FS 14 M 1000 Vac permanent 150 ppm/ºC 200 ppm/ºC
100 Vac 0.15 % FS 2 M 200 Vac permanent 75 ppm/ºC 100 ppm/ºC
10 Vac 0.15 % FS 200 K 200 Vac permanent 75 ppm/ºC 100 ppm/ºC
1 Vac 0.15 % FS 20 K 65 Vac permanent 75 ppm/ºC 100 ppm/ºC
100 mVac 0.20 % FS 1 K 4.5 Vac permanent 75 ppm/ºC 150 ppm/ºC
5 Aac 0.20 % FS 20 mOhm 16 Aac @5 seconds 75 ppm/ºC 150 ppm/ºC
1 Aac 0.20 % FS 20 mOhm 16 Aac @5 seconds 75 ppm/ºC 150 ppm/ºC
Table 3 - Technical specicaons for each input scale

FEMA ELECTRÓNICA . Series K . K40-A
5
Funcons included Secon
‘Fast access’ yes 1.12.5
‘On Power Up’ yes 1.12.7
‘Field correcon’ yes, high and low signals 1.12.2
Alarms double setpoints
acvaon delays
deacvaon delays
hysteresis
inverted relays
locked alarms
1.12.3
Display lters recursive
steps
xed digits
le zeros
1.12.4
Block of ‘DC’ component yes 1.9
‘Locked alarms’ yes 1.12.8
Memory max. and min. readings 1.12.4
Password conguraon block 1.12.10
‘Measure’ yes 1.12.5
‘Peak & Hold’ yes 1.12.4
Display brightness 5 levels 1.12.13
Table 4 - Funcons included
1.7 Technical specicaons (cont.) 1.8 Mechanical dimensions (mm)
1.9 Coupling ‘AC’ or ‘AC+DC’
The instrument provides and internal jumper to block the DC
component of the signal. By default, the blocking of the DC com-
ponent is disabled. To block the DC component of the signal, ac-
cess the internal of the instrument (see secon 1.15) and open
jumper JP3.
• ‘AC+DC’ JP3 closed (by default)
• ‘only AC’ JP3 open
• the 1 Aac scale is available only with ‘AC+DC’ coupling
JP3
44
92
Panel
cut-out
16 8
75
96
48

FEMA ELECTRÓNICA . Series K . K40-A
6
The instrument has two menus accessible to the user :
‘Conguraon menu’ (key SQ) (<)
‘Fast access’ menu (key UP) (5)
Conguraon menu
The ‘conguraon menu’ modies the conguraon parameters to
adapt the instrument to the applicaon needs. To access the ‘con-
guraon menu’ press for 1 second the SQ (<) key. This access can
be blocked by acvang the ‘Password’ (‘PASS’) funcon. While
operang the ‘conguraon menu’, the alarm status is ‘hold’ to the
status they had before accessing the menu, and the output and con-
trol modules remain in ‘error’ state. When leaving the ‘conguraon
menu’, the instrument applies a system reset, followed by a brief
disconnecon of the alarms and the output and control modules.
Funconality is then recovered.
For a detailed explanaon on the ‘conguraon menu’ see secon
1.12, and for a full view of the ‘conguraon menu’ structure see
secon 1.13.
‘Fast access’ menu
The ‘fast access’ menu is an operator congurable menu, providing
fast and direct access to the most usual funcons of the instrument
with a single key pad stroke. Press key UP (5) to access this menu.
See secon 1.12.5 for a list of funcons eligible for ‘fast access’ in
this instrument. The ‘Password’ (‘PASS’) funcon does not block ac-
cess to this menu. Accessing and modifying parameters in the ‘fast
access’ menu does not interfere with the normal funconality of the
instrument, and it does not generate any system reset when validat-
ing the changes.
Front key pad descripon
Key SQ (<) - press the SQ (<) key for 1 second to access the ‘con-
guraon menu’. Inside the menu, the SQ (<) key funcons as a
‘ENTER’ key. It selects and accesses the menu opon currently dis-
played. At menus with numerical value entries, it validates the num-
ber displayed.
Key UP (5) - the UP (5) key gives access to the ‘fast access’ menu.
Inside the menus, it moves vercally through the dierent menu op-
ons. At menus with numerical value entries, it modies the digit
selected by increasing its value to 0, 1, 2, 3, 4, 5, 6, 7, 8, 9.
Key LE (3) - inside the menus, the LE (3) key funcons as the ‘ES-
CAPE’ key. It leaves the selected menu, and eventually, will leave the
whole menu. When leaving the ‘conguraon menu’ with the LE (3)
key, the changed parameters are acvated. At menus with numeri-
cal value entries, the LE (3) key allows to select the acve digit. To
modify the value of the selected digit use the UP (5) key.
Menu ‘rollback’
Aer 30 seconds without interacon from the operator, the instru-
ment will rollback and leave the ‘conguraon menu’ or the ‘fast ac-
cess’ menu. All changes will be discarded.
1.10 How to operate the menus
Messages and errors
‘h.udr’
‘h.oVr’
Hardware underrange (‘h.udr’) / overrange (‘h.ovr’). In-
put signal is lower / higher than the minimum / maxi-
mum signal the instrument can detect.
‘d.udr’
‘d.oVr’
display underrange (‘d.udr’) / overrange (‘d.ovr’). The
instrument already displays the minimum / maximum
value possible (-1999 / 9999).
‘hoLd’ the ‘hold’ funcon is acve. Display is on hold.
‘P.hLd’ the ‘Peak&Hold’ funcon is acve.
‘Err.0’* at the ‘scaling’ (‘ScAL’) menu entry, the dened slope is
higher than ‘5000’ (slope almost vercal). Entered values
are dismissed and default values are acvated.
‘Err.1’ incorrect password.
‘Err.2’ at ‘oPt.X’ menu entry. Installed module is not recognized.
Table 5 - Messages and error codes
The error messages are shown on display in ash mode.
(dhI-dLo) [counts]
(IhI-ILo) [mA or Vdc]< 5000
*slope calculaon for error ‘Err.0’.
1.11 Messages and errors
Example of operaon inside the
‘conguraon menu’.
1. The SQ (<) key enters into the
‘conguraon menu’.
2. The SQ (<) key enters into the
‘InP’ opon menu.
3. The UP (5) key moves through
the menu opons.
4. The SQ (<) key selects the
desired range and returns to the
‘InP’ menu.
5. The LE (3) key leaves the ac-
tual menu level and moves to the
previous menu level.
6. The LE (3) key leaves the ‘con-
guraon menu’. Changes are ap-
plied and saved at this moment.
Input
(2)
(3)
(3)
(3)
(3)
(3)
(4)
(4)
(4)
(4)
(5)
(5)
(5)
(5)
(3)
(3)
(6)
(6)
(1)
(3)
(3)
(3)
(5)
(5)
(5)

FEMA ELECTRÓNICA . Series K . K40-A
7
Decimal point
1.12 Conguraon menu
Press ‘SQ’ (<) for 1 second to access the ‘conguraon menu’.
For a descripon on how to operate inside the menus see secon
1.10. For a full vision of the ‘conguraon menu’ structure see
secon 1.13.
Scaling Input low
Display low
Input high
Display high
To congure the inial set up of the instrument, select the measure
scale, the decimal point posion, and scale the reading.
Access the ‘Input’ (‘InP’) menu to select the measure scale. Opons
available are 0/600 Vac, 0/100 Vac, 0/10 Vac, 0/1 Vac, 0/100 mVac,
0/5 Aac and 0/1 Aac. Place the rear jumper according to the scale se-
lected (see secons 1.5 and 1.6).
Access the ‘Decimal point’ (‘dP’) menu to select the decimal point
posion. Move the decimal point by pressing the ‘LE’ (3) key.
Scale the reading at the ‘Scaling’ (‘ScAL’) menu. There are four pa-
rameters to congure :
• ‘Input low’ (‘ILo’) - minimum input signal, in Vac or Aac.
• ‘Display low’ (‘dLo’) - reading associated to the minimum input
signal.
• ‘Input high’ (‘IhI’) - maximum input signal, in Vac or Aac.
• ‘Display high’ (‘dhI’) - reading associated to the maximum input
signal.
The ‘Field correcon’ (‘F.cor’) funcons allows to correct the instru-
ment scaling parameters, when the instrument is being installed on
the eld, providing a fast and easy way to compensate oset signals.
To operate the ‘Field correcon’ (‘F.cor’) funcon for the oset cor-
recon, generate the minimum input signal and access the ‘Field
low’ (‘F.Lo’) funcon. Then the following sequence will start
• message with signal type (‘mA’ or ‘Vdc’)
• message ‘wait’ (‘WAIt’) in ash mode
• aer 5 seconds, message ‘ok’ (‘oK’) appears
• at this point, press key SQ (‘<‘)
• the menu returns to menu entry ‘Field Low’ (‘F.Lo’)
The instrument has read the input signal and automacally cong-
ures the ‘Input low’ (‘I.Lo’) for you.
Repeat the process generang the maximum input signal and access
the ‘Field high’ (‘F.hI’) menu. The instrument will read the input sig-
nal and automacally congure the ‘Input high’ (‘I.hI’) parameter to
match the signal read.
Applicaon - a current transformer provides a 0/5 Aac output signal
proporonal to the consumpon of an engine from 0 to 100.0 Aac.
At installaon, the operator detects that the reading at maximum
engine consumpon reads less than 100.0 Aac, although he knows it
is consuming 100.0 Aac. There is a reading mismatch due to the cur-
rent transformer characteriscs.
Congure the instrument for a measure scale of 0/5 Aac and scale
the reading for 0/100.0 Aac. When engine is consuming 100 Aac and
meter is reading less value, apply the ‘Field correcon’ / ‘F.Hi’ func-
on and the instrument will automacally correct the reading to
100.0 Aac.
If there is also oset error, the same applies when engine is stopped.
Reading should be 0.0 Aac. If it is not the case, apply the ‘Field correc-
on’ / ‘F.Lo’ funcon and the instrument will automacally correct
the reading to 0.0 Aac.
1.12.1 Inial set-up
1.12.2 Field correcon
Input
Scale 600 Vac
Scale 100 Vac
Scale 10 Vac
Scale 1 Vac
Scale 100 mVac
Scale 5 Aac
Scale 1 Aac
Field correcon
Correcon high
Correcon low Wait (5 sec.) (<)
Wait (5 sec.) (<)

FEMA ELECTRÓNICA . Series K . K40-A
8
1.10 Conguraon menu (cont.)
Alarm 1
Setpoint
Hysteresis
Setpoint 2
Acve
Alarm type
Alarms
Acvaon delay
Deacvaon delay
The ‘Alarms’ (‘ALr’) menu congures the independent acvaon of
up to 3 relay outputs (or transistor or SSR control), installed with the
R1 (or T1 or SSr) oponal modules (see secon 2.1). For outputs up
to 4 and 6 relays, see special modules R2, R4 and R6 at secon 2.6.
The alarm states are indicated in the front display with leds marked
as ‘1’, ‘2’ and ‘3’.
To congure an alarm, enter into the alarm menu (‘ALr1’, ‘ALr2’ or
‘ALr3’) and congure the following parameters :
• select ‘Acve’ (‘Act’) to ‘on’
• at ‘Alarm type’ (‘TypE’) select the alarm acng as a maximum
type alarm (‘MAX’) or a minimum type alarm (‘MIn’). The maxi-
mum type alarm (or minimum type alarm) acvates when the dis-
play value is higher (or lower) than the setpoint value.
• at ‘Setpoint’ (‘SEt’) enter the value for the alarm acvaon point.
This parameter is eligible for conguraon through the ‘Fast access’
menu (see secon 1.12.5).
• congure the hysteresis value at ‘Hysteresis’ (‘hySt’). The hys-
teresis applies to the deacvaon process of the alarm. The alarm
deacvates when the reading has passed the setpoint value plus
the hysteresis value. Hysteresis helps to avoid repeve switching
of the alarm relays, due to uctuang input signals around the set-
point.
• at ‘Acvaon delay’ (‘dEL.0’) congure the delay to apply before
alarm acvaon. The acvaon delay starts counng when the set-
point value is passed. Value from 0.0 to 99.9 seconds.
• at ‘Deacvaon delay’ (‘dEL.1’) congure the delay to apply
before alarm deacvaon. The deacvaon delay starts counng
when the setpoint value plus the hysteresis value, is passed. Value
from 0.0 to 99.9 seconds.
• to work with ‘windowed alarms’ (see graphical example below)
acvate ‘Setpoint 2’ (‘SEt2’) to ‘on’ and then congure the desired
second setpoint value. Second setpoint must always be higher in
value than the rst setpoint.
• the ‘Relay inverted’ (‘r.Inv’) parameter inverts the normal relay
connecons. When set to ‘on’ the relay will be acve when alarm is
inacve. For security applicaons where an inacve relay controls
the shutdown of the system.
• the ‘Locked alarm’ (‘A.Lck’) parameter disables the automac
deacvaon of the alarm. Alarm deacvaon must be performed
manually, by pressing the ‘LE’ front buon (see secon 1.12.8)
1.12.3 Alarms
Reading
Time
setpoint
hysteresis
Alarm as maximum,
no hysteresis, no delays
on
o Time
acvaon
delay
on
o
deacvaon
delay
Time
Alarm as maximum,
with hysteresis and delays
on
o Time
Alarm as minimum,
no hysteresis, no delays
Reading
Time
Setpoint 2
Setpoint 1
Alarm as minimum,
with double setpoint,
no hysteresis, no delays
on
o Time
Relay inverted
Locked alarm

FEMA ELECTRÓNICA . Series K . K40-A
9
The instrument provides several funcons to personalize the reading
of the display values
• the ‘Fixed Digits’ (‘FIX.d’) allows to x each digit to a xed value.
As an example, x the least signicant digit to a ‘0’ in order to block
noisy uctuaons. To x a digit, all digits to its right must be also
xed. Value ‘-’ means that the digit is not xed.
• the ‘Average lter’ (‘AVr’) funcon allows to reduce reading oscil-
laons due to noisy signals. It applies a recursive lter on the reading
value. To acvate the average lter set ‘AVr’ to ‘on’ and assign the l-
ter strength between ‘0.0’ and ‘99.9’. Higher values acvate stronger
lter. Stronger lters slow down the reading changes.
• the ‘Steps’ (‘StEP’) funcon allows to dene minimum reading
steps, which will be done in steps of 1, 2, 5, 10, 20 or 50 counts.
Example - selecng a step of 20 congures the reading to change in
steps of 20 counts (‘1420’, ‘1440’, ‘1460’, ...).
• the ‘Le Zero’ (‘LZEr’) funcon lights all zeros to the le.
• the ‘Memory of maximum’ (‘MAX’) funcon displays the maximum
reading value stored in memory. It also provides a way to reset the
value. This parameter is eligible for conguraon through the ‘Fast
access’ menu (see secon 1.12.5).
• the ‘Memory of minimum’ (‘MAX’) funcon displays the minimum
reading value stored in memory. It also provides a way to reset the
value. This parameter is eligible for conguraon through the ‘Fast
access’ menu (see secon 1.12.5).
• the ‘Peak & hold’ (‘P.hLd’) funcon visualizes and hold the maxi-
mum reading. For test-break applicaons, where the meter always
increases its value unl the unit under test breaks and the signal falls
down. The meter maintains the maximum reading before the signal
fell down.
To free the ‘hold’ reading, press any of the front key pad or wait the
me congured at the ‘me’ parameter.
Time 0 hold disabled (O)
Time 1 a 3999 seconds waing
Time 4000 innite hold
While ‘hold’ is acve, the instrument alarms are sll associated to
the input signal, therefore sll providing control to disconnect the
applicaon once the test has nished.
1.12.4 Display lters
Le zeros
Steps
Average lter 0.0 to 99.9
Display Fixed digits Fix digits
Memory of
maximum
Memory of
minimum
Peak & Hold Time (Sec.)
1.10 Conguraon menu (cont.)

FEMA ELECTRÓNICA . Series K . K40-A
10
On power-up Delay Seconds
Tools
1.10 Conguraon menu (cont.)
The ‘On Power Up’ (‘on.Pu’) menu congures funcons to apply at
start-up. It applies only to instrument restart aer power loss. It does
not apply to instrument restart due to change in conguraon.
• parameter ‘Delay’ (‘dLAy’) assigns a waing me in seconds. The
instrument waits the congured me before starng normal func-
on. During this waing me, the display shows all decimal points
on in ash mode, all alarms are in ‘oFF’ state, there is no signal acqui-
sion and there is no communicaons or control being performed.
Aer the congured me is over, the instrument starts in normal
funcon. Delay value between 0 and 200 seconds.
Applicaon - the start-up process for an automaon system implies
that dierent parts of the system (engines, actuators, controllers, ...)
have dierent start-up mes. The ‘Delay’ funcon gives me to the
instrument to wait unl the slowest part of the system is fully func-
onal before execung acons on the system (signal reading, relay
acvaon, ...)
1.12.7 Menu ‘On Power Up’
Key UP
(‘Fast access’)
Memory of
maximum
Memory of
minimum
Setpoint 1
Setpoint 2
Setpoint 3
‘Measure’
The ‘UP’ (5) key at the front of the instrument gives access to a list
of funcons congurable by the operator. See secon 1.10 for an ex-
planaon on how to operate the ‘fast access’ menu.
The ‘Key UP (Fast access)’ (‘K.uP’) menu allows to select which func-
ons will be accessible through the ‘fast access’ menu. Select ‘on’ to
acvate each funcon.
• the ‘Setpoint 1’ (‘ALr1’) funcon allows to visualize and modify the
alarm 1 setpoint through the ‘fast access’ menu.
• the ‘Setpoint 2’ (‘ALr2’) funcon allows to visualize and modify the
alarm 2 setpoint through the ‘fast access’ menu.
• the ‘Setpoint 3’ (‘ALr3’) funcon allows to visualize and modify the
alarm 3 setpoint through the ‘fast access’ menu.
• the ‘Memory of maximum’ (‘MAX’) or ‘Memory of minimum’
(‘MIn’) funcons allow to visualize the maximum or minimum read-
ing value stored in memory. To reset this value, visualize the memory
value at the ‘fast access’ menu with key UP (5) and when message
‘rSt’ is displayed, press (<) to reset.
• the ‘Measure’ (‘MEAS’) funcon allows to visualize the actual sig-
nal at input terminals, without scaling. Example : with an instrument
with input 4/20 mA, the ‘measure’ funcon will show the direct value
in mA.
1.12.5 Fast access
If only a single funcon is selected for the ‘fast access’ menu, press-
ing the the ‘UP’ (5) key will shortly display the funcon name and
then automacally jump to the funcon value.
1.12.6 Super fast access

FEMA ELECTRÓNICA . Series K . K40-A
11
1.10 Conguraon menu (cont.)
Opon 1
Conguraon menu for the module installed at Opt.1
Opon 2
Conguraon menu for the module installed at Opt.2
Opon 3
Conguraon menu for the module installed at Opt.3
Password
Version
Factory reset
Minimum
Brightness
Maximum
Standard The ‘Version’ (‘VEr’) menu informs of the current rmware version
installed in the module.
At the ‘Password’ (‘PASS’) menu select a 4 digit code to block access
to the ‘conguraon menu’. Instrument conguraon will not be ac-
cessible to non authorized personnel. To acvate the ‘Password’ se-
lect ‘on’ and introduce the code.
The code will be requested when trying to access the ‘conguraon
menu’ (key ‘SQ’ (<)). The ‘fast access’ menu is not password pro-
tected.
1.12.8 Menu ‘Key LE’
At the ‘Brightness’ (‘LIGh’) menu select the light intensity for the
front leds. With this funcon it is possible to adapt the instrument to
the environment light intensity.
Menus ‘OPt.1’, ‘OPt.2’ and ‘OPt.3’ give access to the ‘conguraon
menus’ of the output and control modules installed at slots Opt.1,
Opt.2 and Opt.3.
See secon 2 for a list of output and control modules available for
each slot. The ‘conguraon menu’ of each module is described at
the User’s Manual of each module.
At the ‘Factory reset’ (‘FAct’) menu, select ‘yes’ to load the default
factory conguraon for the instrument (see secon 1.17).
Key LE
Alarm unlock
No funcon The ‘LE’ (3) key at the front of the instrument can be congured to
acvate several funcons. Only one funcon can be assigned to the
‘LE’ (3) key
• the ‘No funcon’ (‘nonE’) value assigns no funcon.
• the ‘Alarm unlock’ (‘A.Lck’) value assigns the manual unlock of the
alarms funcon, for instruments with the ‘Locked alarms’ (‘A.Lck’)
funcon acvated (see secon 1.12.3)
AC deadband
The ‘AC deadband’ (‘d.bnd’) parameter enables or disables the func-
on that makes reading ‘0’ when signal is below 0.5% of teh selected
range.
1.12.9 AC dead band
1.12.10 Funcon ‘Password’
1.12.11 Factory reset
1.12.12 Firmware version
1.12.13 Brightness
1.12.14 Access to oponal modules

FEMA ELECTRÓNICA . Series K . K40-A
12
Input
Select with key LE
Decimal point
Alarms
1.13 Full conguraon menu
Press ‘SQ’ (<) for 1 second to access the ‘Conguraon
menu’. See secon 1.12 for a descripon of each menu entry.
Scaling Input low
Display low
Input high
Display high
Alarm 1
Setpoint
Hysteresis
Acve
Alarm type
Acvaon delay
Setpoint 2
Deacvaon delay
Le zeros
Steps
Average lters 0.0 to 99.9
Display Fixed digits
Memory of
maximum
Memory of
minimum
Peak & Hold Time (seconds)
Alarm 2 menu
Alarm 3 menu
Relay inverted
Locked alarm
Scale 600 Vac
Scale 100 Vac
Scale 10 Vac
Scale 1 Vac
Scale 100 mVac
Scale 5 Aac
Scale 1 Aac
Field correcon
Correcon high
Correcon low Display in ash mode for 5 seconds
Display in ash mode for 5 seconds

FEMA ELECTRÓNICA . Series K . K40-A
13
1.11 Full conguraon menu (cont.)
Tools
Key UP
(‘fast access’)
Memory of max.
Memory of min.
Setpoint 1
Setpoint 2
Setpoint 3
‘Measure’
On power-up Delay Seconds
Key LE
Alarm unlock
No funcon
Opon 1
Conguraon menu for the module installed at Opt.1
Opon 2
Conguraon menu for the module installed at Opt.2
Opon 3
Conguraon menu for the module installed at Opt.3
Minimum
Brightness
Maximum
Standard
Password
Firmware version
Factory reset
AC deadband

FEMA ELECTRÓNICA . Series K . K40-A
14
1.14 To access the instrument
1.15 Modular system
K Series panel meters are designed to create a modular system. This
modular system allows for addion, replacement or substuon of
any of the internal modules conforming the instrument. Below is a
graphic explanaon for the posion of each module.
Risk of electric shock. Removing the front cover will
grant access to the internal circuits. Disconnect the
input signal to prevent electric shock to the operator.
Operation must be performed by qualied personnel
only.
To open the housing, use a at screwdriver to free the xaon clips,
if possible, in the following order : D, C, B and A. Remove the front
cover. Let the inside of the instrument slide out of the housing.
To reinsert the instrument make sure that all modules are correctly
connected to the pins on the display module. Place all the set into
the housing, assuring that the modules correctly t into the internal
guiding slides of the housing. Once introduced, place again the front
cover in front of the housing, placing rst corner ‘X’ and then insert-
ing clips ‘A’, ‘B’, ‘C’ and ‘D’ in this order.
XA
C
BD
Front Filter Display Module Oponal Control Modules
Input Signal Module
Housing
Power Supply Module
Opt.3
Opt.2
Opt.1

FEMA ELECTRÓNICA . Series K . K40-A
15
1.16 Precauons on installaon
1.17 Factory conguraon
1.18 Warranty
Manufacturer FEMA ELECTRÓNICA, S.A.
Almira 14 - Pol. Ind. Sanga
E08210 - Barberà del Vallès
BARCELONA - SPAIN
www.fema.es - [e-mail]
Products K40-A
The manufacturer declares that the instruments indicated comply with the
direcves and rules indicated below.
Electromagnec compability direcve 2014/30/EU
Low voltage direcve 2014/35/EU
Direcve ROHS 2011/65/EU
Security rules EN-61010-1
Instrument Fixed
Permanently connected
Polluon degree 1 and 2 (without condensaon)
Isolaon Double
Category CAT-III up to 300 Vac
CAT-II up to 600 Vac
Electromagnec compability rules EN-61326-1
EM environment Industrial
Immunity levels
EN-61000-4-2 By contact ±4 KV Criteria B
By air ±8 KV Criteria B
EN-61000-4-3 Criteria A
EN-61000-4-4 On AC power lines : ±2 KV Criteria B
On DC power lines : ±2 KV Criteria B
On signal lines : ±1 KV Criteria B
EN-61000-4-5 Between AC power lines ±1 KV Criteria B
Between AC power lines and earth ±2 KV Criteria B
Between DC power lines ±1 KV Criteria B
Between DC power lines and earth ±2 KV Criteria B
Between signal lines and earth ±1 KV Criteria B
EN-61000-4-6 Criteria A
EN-61000-4-8 30 A/m at 50/60 Hz Criteria A
EN-61000-4-11 0 % 1 cycle Criteria A
40 % 10 cycles Criteria A
70 % 25 cycles Criteria B
0 % 250 cycles Criteria B
Emission levels
CISPR 11 Instrument Class A, Group 1 Criteria A
Barberà del Vallès October 2017
Xavier Juncà - Product Manager
According to direcve 2012/19/EU, electronic equip-
ment must be recycled in a selecve and controlled
way at the end of its useful life.
1.19 CE declaraon of conformity
This instrument is warranted against all manufacturing defects for a
period of 24 MONTHS from the shipment date. This warranty does
not apply in case of misuse, accident or manipulaon by non-autho-
rized personnel. In case of malfuncon get in contact with your local
provider to arrange for repair. Within the warranty period and aer
examinaon by the manufacturer, the unit will be repaired or subs-
tuted when found to be defecve. The scope of this warranty is lim-
ited to the repair cost of the instrument, not being the manufacturer
eligible for responsibility on addional damages or costs.
Scale 0/600 Vac
Scaling and decimal point 0/600 Vac = 0/600.0
Alarms 1,2 and 3
Acve o (disabled)
Type alarm as maximum
Setpoint 1000
Hysteresis 0 counts
Acvaon delay 0.0 seconds
Deacvaon delay 0.0 seconds
Setpoint 2 o
Inverted relay o
Locked alarms o
Display
Fixed digits o
Average o
Steps o
Le zeros o
Maximum memory -1999
Minimum memory 9999
Peak&Hold o
Tools
‘Fast access’ o
‘On power-up’
Delay 0 seconds
Key LE no funcon
Password o
Brightness 3
This instrument has been designed and veried conforming to the 61010-1 CE Security
Regulaon, for industrial applicaons. Installaon of this instrument must be performed
by qualied personnel only. This manual contains the appropriate informaon for the in-
stallaon. Using the instrument in ways not specied by the manufacturer may lead to a
reducon of the specied protecon level. Disconnect the instrument from power before
starng any maintenance and / or installaon acon. The instrument does not have a gen-
eral switch and will start operaon as soon as power is connected. The instrument does
not have protecon fuse, the fuse must be added during installaon.
The instrument is designed to be panel mounted. An appropriate venlaon of the in-
strument must be assured. Do not expose the instrument to excess of humidity. Maintain
clean by using a humid rag and do NOT use abrasive products such as alcohols, solvents,
etc.
General recommendaons for electrical installaons apply, and for proper funconality
Risk of electrical shock. Instrument terminals can be connected
to dangerous voltage.
Instrument protected with double isolaon. No earth connecon
required.
Instrument conforms to CE rules and regulaons.
we recommend : if possible, install the instrument far from electrical noise or magnec
eld generators such as power relays, electrical motors, speed variators, ... If possible, do
not install along the same conduits power cables (power, motor controllers, electrovalves,
...) together with signal and/or control cables.
Before proceeding to the power connecon, verify that the voltage level available matches
the power levels indicated in the label on the instrument.
In case of re, disconnect the instrument from the power line, re alarm according to local
rules, disconnect the air condioning, aack re with carbonic snow, never with water.

FEMA ELECTRÓNICA . Series K . K40-A
16
2. Output and control modules
The R1 module provides 1 relay output to to install at digital panel
meters from Series K, up to a maximum of 3 relays in a single meter.
Note : for more than three relays per instrument or larger relay den-
sity per module, see special modules R2, R4 and R6.
Conguraon is performed from the frontal keypad of the meter, by
seng the parameters at the alarm menu. Check the parameters of
at the alarm menu for full informaon.
Relay with 3 contacts (common, normally open, normally closed)
with up to 250 Vac switching voltage and 8 A.
Modules R1 can be ordered pre-installed into a Series K digital panel
meter, or standalone for delayed installaon, as they do not require
soldering or special conguraon.
2.1 Module R1
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of relay 3 contact relay (NC, NO, common)
Current maximum 8 A per relay (resisve load)
Voltage maximum* 250 Vac connuous
Isolaon 3500 Ve
Type of terminal plug-in screw terminal, pitch 5.08 mm
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
Terminal A Common
Terminal B NO - Normally open
Terminal C NC - Normally closed
Power
Opt.2
Opt.1
Opt.3
A B C
A B C
Signal
A B C
The T1 module provides 1 transistor output to install at digital panel
meters from Series K, up to a maximum of 3 transistors in a single
meter.
Conguraon is performed from the frontal keypad of the meter, by
seng the parameters at the alarm menu. Check the parameters of
at the alarm menu for full informaon.
Transistor output is optoisolated, provides 2 terminals for connec-
on, and can switch up to 35 V and 50 mA.
Modules T1 can be ordered pre-installed into a Series K digital panel
meter, or standalone for delayed installaon, as they do not require
soldering or special conguraon.
2.2 Module T1
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of output transistor
Max. voltage 35 Vdc
Max. current 50 mA
Isolaon 3500 Ve
Type of terminal plug-in screw terminal, pitch 5.08 mm
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
‘B’
‘A’
Schemac for T1 output
Power
Opt.2
Opt.1
Opt.3
A B C
A B C
Signal
A B C

FEMA ELECTRÓNICA . Series K . K40-A
17
Output ranges 4/20 mA acve, 4/20 mA passive 0/10 Vdc
Accuracy (at 25 ºC) <0.1% FS
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
2.3 Module SSR
The AO module provides 1 analog output with 4/20 mA or 0/10 Vdc
congurable output range. Output current loop congurable as ac-
ve (the instrument provides the excitaon for the loop) or passive
(the loop is externally powered). Signal output proporonal to the
instruments reading. Fully congurable scaling, in direct (posive
slope) or inverse (negave slope) scaling.
Up to a maximum of 3 analog output modules can be installed in a
single instrument, all outputs isolated between them and isolated
from the power and input signal circuits.
Conguraon from instrument front keypad, through menu entries
‘Opt.1’, ‘Opt.2’ or ‘Opt.3’, depending on the posion the module is
installed.
The RTU module can be ordered pre-installed into a Series K panel
meter, or standalone for delayed
installaon, as it does not require
soldering or special conguraon.
Terminal A Vexc
Terminal B Signal in mA or Vdc
Terminal C GND
Jumper M closed for mA
Jumper V closed for Vdc
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Power
Opt.2
Opt.1
Opt.3
A B C
A B C
Signal
A B C
MV M V
MV
The SSR module provides 1 output to control SSR relays, to install at
digital panel meters from Series K, up to a maximum of 3 SSR con-
trols in a single meter.
Conguraon is performed from the frontal keypad of the meter, by
seng the parameters at the alarm menu. Check the parameters of
at the alarm menu for full informaon.
The module provides +15 Vdc voltage and up to 45 mA.
Modules SSR can be ordered pre-installed into a Series K digital panel
meter, or standalone for delayed installaon, as they do not require
soldering or special conguraon.
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of output to control an SSR relay
Voltage output 15 Vdc
Max. current 45 mA
Isolaon 1000 Vdc
Type of terminal plug-in screw terminal, pitch 5.08 mm
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
Schemac for SSR control module
‘B’
‘A’
Relé SSR
+15 Vdc ‘C’
Power
Opt.2
Opt.1
Opt.3
A B C
A B C
Signal
A B C
2.4 Module AO

FEMA ELECTRÓNICA . Series K . K40-A
18
Protocol ASCII
Bus type RS-485, up to 57.6 Kbps
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
2.5 Module S4
The S4 module provides a RS-485 communicaons module for Series
M of panel meters. ASCII protocol with ‘Master’ / ‘Slave’ architec-
ture. Addressable with up to 31 modules. Frames codied in rep-
resentable ASCII characters (codes 32 to 255), directly visible using
‘hyperterminal’ or similar programs.
• Congurable for direct retransmission to remote meters M60-
485 (14 mm digit height) and BDF Series (60 mm and 100 mm digit
height).
• Access to display values, alarm status, memory of maximum and
minimum, alarm setpoints, ...
Conguraon from instrument front keypad, through menu entries
‘Opt.1’, ‘Opt.2’ or ‘Opt.3’, depending on the posion the module is
installed.
The S4 module can be ordered pre-installed into a Series M panel
meter, or standalone for delayed installaon, as it does not require
soldering or special conguraon.
Power
Opt.2
Opt.1
Opt.3
B A G
B A G
Signal
B A G
Terminal B B signal from RS-485 bus
Terminal A A signal from RS-485 bus
Terminal G GND
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Protocol Modbus RTU
Funcons implemented 4 (Read_Input_Registers)
Bus type RS-485, up to 57.6 Kbps
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
The RTU module provides a Modbus RTU communicaons module
for Series M of panel meters. The RTU module implements funcon
‘4’ (‘Read Input Registers’) of the Modbus RTU protocol, to access the
instrument registers (reading value, alarm status, memory of maxi-
mum and minimum, ...)
Conguraon from instrument front keypad, through menu entries
‘Opt.1’, ‘Opt.2’ or ‘Opt.3’, depending on the posion the module is
installed.
The RTU module can be ordered pre-installed into a Series M panel
meter, or standalone for delayed installaon, as it does not require
soldering or special conguraon.
2.6 Module RTU
Terminal B B signal from RS-485 bus
Terminal A A signal from RS-485 bus
Terminal G GND
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Power
Opt.2
Opt.1
Opt.3
B A G
B A G
Signal
B A G

FEMA ELECTRÓNICA . Series K . K40-A
19
2.7 Module S2
Protocol ASCII
Bus type RS-232, up to 57.6 Kbps
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’, ‘Opt.3’
2.8 Modules R2, R4, R6
The R2, R4 and R6 modules provide 2, 4 and 6 relay outputs for Series
M panel meters. Relays with 3 contacts each, with switching capabil-
ity up to 250 V @ 6 A.
Modules R2, R4 and R6 are installed on slot ‘Opt.1’ and are cong-
ured from instruments front keypad, and provide setpoint congura-
on, hysteresis, independent acvaon and deacvaon delays, and
second alarm setpoint for windowed alarms.
Only one module R2, R4 or R6 can be installed per instrument. Mod-
ules R2, R4 and R6 are not compable with standard R1, T1 and SSR
modules.
The R2, R4 and R6 modules can be ordered pre-installed into a Series
M panel meter, or standalone for delayed installaon, as they do not
require soldering or special conguraon.
The S2 module provides a RS-232 communicaons module for Series
M of panel meters. ASCII protocol with ‘Master’ / ‘Slave’ architec-
ture. Addressable with up to 31 modules. Frames codied in rep-
resentable ASCII characters (codes 32 to 255), directly visible using
‘hyperterminal’ or similar programs.
• Access to display values, alarm status, memory of maximum and
minimum, alarm setpoints, ...
Conguraon from instrument front keypad, through menu entries
‘Opt.1’, ‘Opt.2’ or ‘Opt.3’, depending on the posion the module is
installed.
The S2 module can be ordered pre-installed into a Series M panel
meter, or standalone for delayed installaon, as it does not require
soldering or special conguraon.
Relay Common Normally Open
(NO)
Normally Closed
(NC)
relay 1 A B C
relay 2 D EF
relay 3 GH I
relay 4 JK L
relay 5 M N O
relay 6 P Q R
Table 6 - Connecons for modules R2, R4 and R6
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of relay 3 contact relay (NC, NO, common)
Current maximum 6 A per relay (resisve load)
Voltage maximum* 250 Vac connuous
Isolaon 2500 Ve
Type of terminal plug-in screw terminal, pitch 3.81 mm
* terminals approved for 300 V (according to UL1059, groups B and
D) and 160 V (according to VDE on CAT-III and polluon degree 3).
Module R2 occupies Opt.1
Module R4 occupies Opt.1 and Opt.2
Module R6 occupies Opt.1, Opt.2 and Opt.3
ABCDEF GHIJKL
MNOPQR
Power
Opt.2
Opt.1
Opt.3
Signal
Terminal E GND
Terminal D Rx1
Terminal C Tx1
Terminal B Rx2
Terminal A Tx2
Opt.2Opt.1
Opt.3
Power
ABCDE ABCDE
ABCDE
Signal

FEMA ELECTRÓNICA . Series K . K40-A
20
3. Other opons
Instruments without front key-
pad. To congure the instrument,
remove the meter from the panel
and remove the front lter. Inter-
nal press buons for conguraon
are accessible. Oponally, request
the instrument precongured
from factory.
Without front keypad
3.1 Opon NBT
