Installation and Users’ Manual
FL1 Fastener
July 2010 GLO
Pub. No. 234-3458-00
Read this Manual
and Retain for
Future Reference

2© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
© Copyright Ferno-Washington, Inc. All Rights Reserved.
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.
Disclaimer
This manual contains general instructions for the use, operation and care
of this product. The instructions are not all-inclusive. Safe and proper use
of this product is solely at the discretion of the user. Safety information is
included as a service to the user. All other safety measures taken by the
user should be within and under consideration of applicable regulations. It
is recommended that training on the proper use of this product be provided
before using this product in an actual situation.
Retain this manual for future reference. Include it with the product in the
event of transfer to new users. Additional free copies are available upon
request from Ferno Customer Relations.
Proprietary Notice
The information disclosed in this manual is the property of Ferno-
Washington, Inc., Wilmington, Ohio, USA. Ferno-Washington, Inc.
reserves all patent rights, proprietary design rights, manufacturing rights,
reproduction use rights, and sales use rights thereto, and to any article
disclosed therein except to the extent those rights are expressly granted to
others or where not applicable to vendor proprietary parts.
Limited Warranty Statement
The products sold by Ferno are covered by a limited warranty, which
is printed on all Ferno invoices. The complete terms and conditions of
the limited warranty, and the limitations of liability and disclaimers,
are also available upon request by calling Ferno at 1.800.733.3766 or
1.937.382.1451.
Ferno Technical Support
Customer service and product support are important aspects of each
Ferno product. Please have the product serial number available
when calling, and include it in all written communications. For
technical support questions, please contact your Ferno distributor.
Ferno Customer Relations
For ordering assistance or general information:
CANADA AND THE U.S.A.
Telephone (Toll-free) 1.877.733.0911
Telephone [phone]
Fax (Toll-free) 1.888.388.1349
Fax [phone]
Internet www.ferno.com
ALL OTHER LOCATIONS
For assistance or information, please contact your Ferno distributor.
If you do not have a Ferno distributor, please contact Ferno
Customer Relations:
Ferno-Washington, Inc.
70 Weil Way
Wilmington, Ohio 45177-9371, U.S.A.
Telephone [phone]
Fax [phone]
Internet www.ferno.com
EUROPEAN REPRESENTATIVE
Ferno (UK) Limited
Stubs Beck Lane, Cleckheaton
West Yorkshire BD19 4TZ, United Kingdom
Telephone [phone]
Fax [phone]
Internet www.ferno.co.uk
Serial Number _________________________
Location: Rear of Tower Crossbar

3
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
TABLE OF CONTENTS
Section Page Section Page
Ferno Customer Relations______________________ 2
Ferno Technical Support _______________________ 2
1 - Safety Information___________________________ 4
1.1 Warning________________________________ 4
1.2 Important_______________________________ 4
1.3 Bloodborne Disease Notice_________________ 4
1.4 Transporter and Fastener Compatibility _______ 4
1.5 Safety and Instruction Labels _______________ 4
1.6 Symbol Glossary_________________________ 5
2 - Operator Skills and Training __________________ 5
2.1 Skills __________________________________ 5
2.2 Training________________________________ 5
3 - About the Fastener___________________________ 6
3.1 Description _____________________________ 6
3.2 Compatible Transporters___________________ 6
3.3 CE Compliance _________________________ 6
3.4 Before Placing the Fastener in Service ________ 7
3.5 GeneralSpecications ____________________ 7
3.6 Fastener Components _____________________ 7
4 - Using the Fastener ___________________________ 8
4.1 Securing the Transporter In the Fastener ______ 8
4.2 Releasing the Transporter From the Fastener ___ 8
5 - Maintenance ________________________________ 9
5.1 Maintenance Schedule ____________________ 9
5.2 Disinfecting the Fastener __________________ 9
5.3 Cleaning the Fastener _____________________ 9
5.4 Lubricating the Fastener ___________________ 9
5.5 Inspecting the Fastener ___________________ 10
6 - Installing the Fastener_______________________ 11
6.1 Before You Begin _______________________ 11
6.2 Vehicle Requirements ____________________ 11
6.3 Installer Notice:
Complying with CEN Standards____________ 11
6.4 Items Supplied and Required ______________ 12
6.5 Transporter Placement ___________________ 13
6.6 Marking the Ambulance Floor, Table or Tray__ 14
6.7 Assembling the Fastener__________________ 16
6.8 Drilling the Holes and
Installing the Backing Plates_______________ 18
6.9 Mounting the Fastener ___________________ 20
6.10 Testing the Fastener _____________________ 21
7 - Parts and Service ___________________________ 22
7.1 Service - Worldwide _____________________ 22
Training Record ______________________________ 23
Maintenance Record___________________________ 23

4© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
1  SAFETY INFORMATION
1.1 Warning
Warning notices indicate a potentially hazardous situation
which, if not avoided, could result in injury or death.
WARNING
Untrained operators can cause injury or be injured. Permit
only trained personnel to operate the fastener.
Improper use of the fastener can cause injury. Use the
fastener only for the purpose described in this manual.
An improper transporter can cause injury. Use only a
Ferno transporter designed or properly modied for use
with the fastener.
Improper or inadequate installation can cause injury.
Install the fastener only as instructed in this manual.
Improper maintenance can cause injury. Maintain the
fastener only as described in this manual.
A fastener installed without backing plates can fail in a
crash. Use properly installed backing plates to secure the
fastener at its mounting points.
Improperly installed backing plates can fail in a crash.
Secure the backing plates to primary structural members
of the ambulance.
Improper parts and service can cause injury. Use only
Ferno parts and Ferno-approved service on the fastener.
Modifying the fastener can cause injury and damage. Use
the fastener only as designed by Ferno.
1.2 Important
Important notices emphasize important usage or maintenance
information.
Important
1.3 Bloodborne Disease Notice
To reduce the risk of exposure to bloodborne diseases such
as HIV-1 and hepatitis when using the fastener, follow the
disinfecting and cleaning instructions in this manual.
1.4 Transporter and Fastener
Compatibility
For the purpose of this notice, all Ferno transporters are
included under the generic term, “cot”.
Combining different manufacturers’products into a “mixed-
component” cot/cot fastener system can increase the user’s
risk of injury and damage.
Ferno-Washington, Inc. strongly recommends that only
Ferno-manufactured cots be used in Ferno-manufactured cot
fasteners, and that only Ferno-manufactured cot fasteners be
used for securing Ferno-manufactured cots in ambulances.
ANY COMBINATION OF A FERNO COT OR COT
FASTENER WITH A NON-FERNO COT OR COT
FASTENER IS MISUSE OF THE FERNO PRODUCT.
Responsibility for the outcome of known, intentional misuse
rests squarely on the misuser.
1.5 Safety and Instruction Labels
Safety and instruction labels place important information
from the users’ manual on the fastener.
Read and follow label instructions. Replace worn or
damaged labels immediately. New labels are available from
your Ferno distributor.
Safety Information

5
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener Safety Information, Skills and Training
1.6 Symbol Glossary
The symbols dened at right are
used on the fastener and in this
users’ manual.
Ferno uses symbols recognized
by the International Standards
Organization (ISO), American
National Standards Institute
(ANSI) and the emergency
medical services industry.
General Warning of
Potential Injury
Unlock Button Product meets European
Union Standards
Do Not
Lubricate
Lubricate
Transporter Operation
Requires Two Trained
Operators
2
Read the Users’
Manual
2.1 Skills
Operators using the fastener need:
a working knowledge of emergency patient-handling●
procedures.
a complete understanding of the procedures described●
in this manual.
WARNING
Untrained operators can cause injury or be injured.
Permit only trained personnel to operate the
fastener.
2.2 Training
Operator trainees need to:
read and understand this manual and the manuals for●
the transporter and stretchers used with the fastener.
be trained on fastener, transporter, and stretcher●
operation before the ambulance with the installed
fastener is placed in service.
record their training information. A sample training●
record sheet is provided on page 23.
2  OPERATOR SKILLS AND TRAINING
C
L
Centerline Designation
(Used During Installation)

6© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
3  ABOUT THE FASTENER
3.2 Compatible Transporters
The fastener is designed for use with Ferno®Mondial™or
EFX Transporters.
About the Fastener
3.1 Description
The Ferno®FL1 Fastener (called the fastener in this manual)
is designed to secure a compatible Ferno®transporter in
the patient compartment of a ground-based ambulance.
The fastener is designed to be installed according to CEN
standards. It is for professional use only.
The fastener consists of a lock box, towers, and connecting
rails. Features include:
Locking mechanism secures transporter control end●
Pair of towers secure transporter loading end●
Easy-to-operate transporter release●
Hardware to secure the fastener to a tray is supplied. Longer
bolts (not supplied) may be needed to install the fastener to an
ambulanceoor.SeeItems Supplied and Required, page 12.
3.3 CE Compliance
MEDICAL DEVICE DIRECTIVE
Ferno products meet the requirements of Medical Device
Directive 93/42/EEC as established by the European Union.
WARNING
Improper use of the fastener can cause injury. Use
the fastener only for the purpose described in this
manual.
WARNING
An improper transporter can cause injury. Use only
a Ferno transporter designed or properly modied
for use with the fastener.
WARNING
Improper or inadequate installation can cause
injury. Install the fastener only as instructed in this
manual.

7
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener About the Fastener
3.5 General Specications
Overall Length 1852 mm 73 in
Overall Width 457 mm 18 in
Height (at lock box) 36 mm 1½ in
Height (at towers) 134 mm 5¼ in
Most general specications are rounded to the nearest whole
number. For more information, contact Ferno Customer Relations
(page 2) or your Ferno distributor.
Fernoreservestherighttochangespecicationswithoutnotice.
3.4 Before Placing the Fastener
in Service
Personnel who will work with the fastener need to●
read this manual and the manuals for the transporter
and stretcher(s) used with the fastener.
The fastener must be properly installed by professional●
personnel (see Before You Begin, page 11).
Conrm that the fastener operates properly. See●
Inspecting the Fastener, page 10.
3.6 Fastener Components
Tower (2)
Rail (2)
Lock Box

8© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
Using the Fastener
4  USING THE FASTENER
4.1 Securing the Transporter
In the Fastener
Read the transporter users’ manual for proper loading1.
instructions.
Guide the transporter into the ambulance (Figure 1)2.
and align the fastener post on the control end of the
transporter with the fastener lock box.
Push the transporter rmly into the fastener until the3.
transporter loading-end crosstube is seated in the
tower pockets and the transporter post engages the
lock inside the lock box (Figure 2 and Figure 3).
Verify that the transporter is locked in the fastener4.
by attempting to pull it out of the ambulance. The
transportershouldremainrmlylockedinthefastener.
4.2 Releasing the Transporter
From the Fastener
To release the transporter from the fastener, press the1.
release button on the lock box (Figure 2) and begin
pulling the transporter out of the ambulance.
Read the transporter users’ manual for complete2.
unloading instructions.
Figure 1 - Loading the Transporter Into the Fastener
Transporter Outline
Towers
Lock Box
Figure 2 - Lock Box
Transporter Fastener
Post Enters Here
Figure 3 - Towers
Transporter Loading-End
Crosstube Enters Here
Release
Button

9
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
5  MAINTENANCE
5.2 Disinfecting the Fastener
Wipe all surfaces with disinfectant. Follow the disinfectant
manufacturer’s instructions for application method and
contact time. Ferno recommends you inspect the fastener
for damage as you disinfect it.
5.3 Cleaning the Fastener
Hand wash all parts of the fastener with warm water and
a mild detergent. Use a brush with stiff bristles to remove
stains. Do not use a metal wire brush. Rinse with warm, clear
water. Dry with a towel or allow the fastener to air-dry.
5.4 Lubricating the Fastener
The locking mechanism inside the lock box requires
occasional lubrication. When needed, apply 1-2 drops of
WRL-191S or E-Z-1 to the lock. Wipe off excess lubricant.
Maintenance
WARNING
Improper maintenance can cause injury. Maintain
the fastener only as described in this manual.
Minimum
Maintenance Intervals
Each Use As Needed Each Month
Disinfecting (this page) •
Cleaning (this page) •
Inspecting (page 10) • •
5.1 Maintenance Schedule
The fastener requires regular maintenance. Set up and
follow a maintenance schedule. The table at right represents
minimum intervals for maintenance.
Keep maintenance records. A sample maintenance record
sheet is provided on page 23.
When using maintenance products, follow the manufacturers’
directions and read the manufacturers’ material safety data
sheets. You can purchase a recommended disinfectant from
your Ferno distributor.
Important
Using abrasive cleaning compounds or applicators
on the fastener cause damage. Do not use abrasive
materials to clean the fastener.
Important
Disinfectants and cleaners containing bleach,
phenolics, or iodines can cause damage. Do not use
products containing these chemicals.
Important
Water under high pressure, or steam, can penetrate the
locking mechanism, ush away lubricant, and cause
corrosion. Use caution when cleaning, and reapply
lubricant if needed.
Important
Lubricating parts that should not be lubricated will
allow dirt and foreign particles to collect on the
fastener, resulting in damage.

10 © Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
Maintenance
5.5 Inspecting the Fastener
Have your service’s equipment maintenance personnel
inspect the fastener regularly. Follow the checklist below
and use a transporter to check the operation of the fastener.
If inspection shows damage or excessive wear, replace the
Important
If the required backing plates are not present,
immediately remove the fastener from service and have
the backing plates installed. Then install a new fastener.
Important
If the ambulance is involved in a crash or trac accident,
replace the fastener.
Important
Make sure all connections are tight, but do not
overtighten the hardware. Overtightening, especially
with powered tools, can cause the nut and bolt beneath
the mounting surface to pull through the backing
plate.
If inspection indicates the components are pulling
through the backing plate, take the fastener out of
service immediately and install a new fastener with
new backing plates.
INSPECTION CHECKLIST
Are all components present?●
Are the required backing plates present, and are they●
securely welded to a primary structural member of
the ambulance?
Is the fastener free of excessive wear?●
Is all mounting hardware tight?●
Are all parts in good condition, with no bends, cracks,●
corrosion, or damage?
Do all moving parts operate smoothly and properly?●
Does the locking mechanism operate and release●
properly, and properly secure the transporter?
Does the loading-wheel crosstube on the transporter●
seat properly in the towers?
Monitortheambulanceoor,table,ortray,andcheck●
the fastener’s integrity. Is the fastener setup worn?
Has exposure to the environment caused noticeable
damage?
fastener or remove the fastener from service until repairs
can be made. See Parts and Service, page 22.
Iftheambulanceisinvolvedinacrashortrafcaccident,the
fastener could sustain damage that is not visible to the eye.
Replace the fastener if the ambulance is involved in a crash.

11
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
6  INSTALLING THE FASTENER
Installing the Fastener
6.2 Vehicle Requirements
The ambulance must comply with the current version●
of European Standard EN 1789.
The ambulance and the fastener installation must●
comply with current government regulations for the
country in which the fastener is used.
Fastener installation requires the use of backing●
plates beneath the ambulance oor, table, or tray at
the mounting points indicated in this manual. If the
ambulance does not have the required backing plates
or their equivalent, have them installed as instructed in
this manual. See Drilling the Holes and Installing the
Backing Plates, pages 18 and 19.
If installing the fastener to a tray system, the tray must●
be at least 1.75 mm thick.
6.1 Before You Begin
Use a skilled professional familiar with ambulance●
construction to install the fastener.
Consult the ambulance manufacturer for any special●
installation techniques or considerations for your
type of ambulance, and for ambulance warranty
information.
Inspect under the ambulance oor, table, or tray for●
anything that might interfere with the installation.
Important
Before installing the fastener, inspect under the
ambulance oor, table or tray for anything (wiring,
brake lines, fuel tank, oxygen lines or other items) that
might interfere with the installation.
WARNING
Improper or inadequate installation can cause
injury. Install the fastener only as instructed in this
manual.
European Standards (CEN)
To obtain an English-language version of EN 1865
or EN 1789 standards, contact the British Standards
Institution:
British Standards Institution
389 Chiswick High Road
London, England W4 4AL
For other languages, contact the CEN Standards
Organization in your country.
6.3 Installer Notice: Complying with CEN Standards
To comply with CEN standards, install the fastener according to all applicable EN guidelines and the instructions in this manual.
The FL1 Fastener, when installed properly and when used with a Mondial™transporter and RS2, RS2, or RS4 stretcher, meets or
exceeds all European Standards. To obtain a copy of current CEN standards, write to the address provided above.

12 © Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
6.4 Items Supplied and Required
ITEMS REQUIRED ALL INSTALLATIONS
For a proper installation, backing plates are required at all mounting
points. If the ambulance does not have the required backing plates or
their equivalent, have them installed as instructed in this manual. See
Drilling the Holes and Installing the Backing Plates, pages 18-19.
ITEMS SUPPLIED
TRAY INSTALLATION:● All transporter fastener
components and fastening hardware are included. Backing
plates (required) are not included.
FLOOR INSTALLATION:● All transporter fastener
components are supplied. However, longer mounting bolts
(not supplied) may be required if the fastener will be installed
ontheambulanceoor.
The length of the mounting bolts will be determined○
by the combined thickness of the fastener tower holes,
tower plate, oor and backing plate. The bolts must
be long enough to extend beyond the backing plate a
minimum of 19 mm (3/4") when installed.
The bolts and nuts should be of at least SAE Grade 8, with○
a corrosion-resistant coating (zinc plating recommended)
and a UNC-2 thread.
Installing the Fastener
COMPONENTS
Part Quantity
Lock Box 1
Rail 2
Tower (1 ea. right/left) 2
Tower Plate 1
Tower Crossbar 1
Loctite®271™(Red) Threadlocker Capsule
FASTENERS
Part Quantity
M8 Stud 8
M8x1.25x70 Flat Head Machine Screw 4
Nylon Spacer 4
Flat Washer .313" SAE (.688"x.344"x.063") 12
Flat Washer ¼" SAE (.625"x.281"x.063") 4
M6x1x20 Button Head Rail Screw 2
M6x1x60 Button Head Rail Screw 4
M6x1x16 Flat Head Machine Screw 14
M8 Center Lock Nut 12
M6 Center Lock Nut 4
COMPONENTS NOT TO SCALE
M8 Stud (8)
.313" Washer (Left, 12 ea.)
¼" Washer (Right, 4 ea.)
M6x1x20 Rail Screw (Left, 2 ea.)
M6x1x60 Rail Screw (Right, 4 ea.)
Nylon
Spacer (4)
Tower Crossbar (8 holes)
Tower Plate (14 holes)
Tower (Right/Left)
Rail (2)
M6 Flat Head
Screw (14)
M8 Center Lock
Nut (12)
M6 Center Lock
Nut (4)
Loctite®271™(Red)
Capsule
Lock Box

13
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener Installing the Fastener
6.5 Transporter Placement
Before installing the fastener, determine where the transporter
should be positioned within the patient compartment.
Use the transporter’s overall dimensions to determine where
it should be positioned ontheambulanceoor,table,ortray.
This information will help determine the proper position for
the fastener.
Refer to the current CEN standards to properly position the
transporterwithinthe“treatmentarea”speciedinEN1789.
The overall dimensions of transporters compatible with the
fastener are shown at right
Model Overall Width Overall Length
Mondial™ST70 550 mm 1970 mm
Mondial™ST64 550 mm 1970 mm
EFX 565 mm 1970 mm

14 © Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
Installing the Fastener
MEASURING AND MARKING
THE LOCK BOX MOUNTING HOLES
Use the transporter overall length (see1. Transporter
Placement, page 13) to determine where the transporter
should sit on the oor, table, or tray. Draw a line
perpendicular to the Centerline to represent the exact
location of the control end (rear) of the transporter
(Figure 4 and Figure 5).
Beginning where the Centerline intersects the control-2.
end reference line, measure 250 mm (approximately
9.8") toward the front of the ambulance and draw a
line perpendicular to the Centerline. Center the lock
box on the Centerline with its at, long end on this
new line (Figure 5).
Use a marker, pen, or other tool to mark the four drilling3.
pointsforthelockboxontheoor,table,ortray.
Figure 5 - Marking the Lock-Box Mounting Points
Ambulance Doors
Transporter Control-End Reference Line
Mark the 4
Drilling Points
C
L
Lock Box
6.6 Marking the Ambulance Floor, Table or Tray
MARKING THE TRANSPORTER CENTERLINE
Installing to a oating table or tray:
Measure across the table or tray and divide the total by1.
two. This is the distance to the center of the table or tray.
Measure and mark a point at the center of the tray near2.
the door end of the ambulance. Measure and mark a
second point at the center of the tray near the forward
end of the ambulance.
Use a chalk line to mark a straight line between the two3.
points from Step 2. This is the transporter Centerline
(Figure 4).
Installing to an ambulance oor:
Follow the procedure at left to center the fastener on the
oor, OR follow the steps below to place the fastener as
close to the side wall as possible:
Starting at the side wall near the doors, measure and1.
mark a point 300 mm (minimum) from the side wall.
At the forward end of the compartment, measure and
mark a second point at the same distance.
Use a chalk line to mark a straight line between the two2.
points from Step 1. This is the transporter Centerline
(Figure 4).
Figure 4 - Ambulance Compartment Layout (Top-Down View)
Transporter Control-End
Reference Line (page 14)
(Centerline)
C
L
Ambulance
Rear Doors
Floating Table or Tray
(if present)
Transporter Outline
(Reference; not needed)
250 mm

15
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
MEASURING AND MARKING THE TOWER PLATE
MOUNTING HOLES
Beginning from the at edge at the forward end of1.
the lock box, measure 1613 mm (63.505") along the
Centerline and mark a point for the large tower plate
(Figure 6).
Center the tower plate on the Centerline and with the2.
hole pattern as shown in Figure 6.
There are two sets of seven holes in a pattern○
on the tower plate; one hole is separate from a
rectangle of six holes and is closer to the long
side of the plate. Position the plate with the two
separate holes toward the lock box (Figure 6).
The ends of the plate on one side have a slight○
ramp designed for the transporter wheels. These
ramps should face up.
The six holes designed for mounting the plate to○
the towers are countersunk. The countersunk-side
oftheplateshouldfacedown(towardtheoor).
The black dots in Figure 6 represent the mounting3.
holes. The mounting holes are the eight holes that are
NOT countersunk in the tower plate. The white dots
represent the six (smaller) countersunk holes used to
mount the plate to the towers. Mark only the eight
mounting holes on the oor, table or tray.
Verify the accuracy of your measurements before4.
proceeding with the installation.
Re-measure the distance between the lock box○
and tower plate and verify both are positioned
correctly.
Set the lock box and one tower in their marked○
positions and set the rail in its place. If there is
interference between the rail and lock box, the
measurements are incorrect.
The four mounting points for the fastener rails will beNote:
determined as the fastener is set in place.
Installing the Fastener
Figure 6 - Measuring and Marking
the Tower Plate Mounting Points
1613 mm
Ambulance Doors
C
L
Tower Plate
This Hole
Toward Lock-Box
Important
Verify the accuracy of your measurements before
installing the fastener to assure a proper installation
and avoid damage to the tray, table or ambulance oor
from incorrectly-drilled mounting holes.

16 © Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
Installing the Fastener
6.7 Assembling the Fastener
ATTACHING THE STUDS TO THE TOWERS
Items needed:
Tower 2
Studs 8
Vise Grips May be needed
Acetone/Loctite®primer (not provided) Small amount
Loctite®271™(Red) Small amount
Clean all eight studs with acetone or Loctite1. ®primer
before use.
Apply 2-3 drops of red Loctite2. ®271™(provided) to
coat approximately half the threads of each of the
eight mounting studs.
Hand-thread the stud-end with Loctite3. ®into one of
the four mounting holes in the base of each tower
(Figure 7).
If the stud cannot be hand-tightened, use vise grips4.
with a piece of cloth placed over the jaws to gently
grip the center of the stud; thread the stud using the
vise grips.
Repeat Steps 3 and 4 until all eight studs are threaded5.
into the large mounting holes in the base of the towers
(Figure 7).
Measure the length of the studs after installation.6.
Verify that only 35 mm-41 mm (1-3/8-1-5/8") of each
stud is visible. Tighten as needed.
Wipe off excess Loctite7. ®.
ATTACHING THE PLATE TO THE TOWERS
Items needed:
Tower with Studs 2
Tower Plate 1
M6x1x16 Flat Head Screw 6
4 mm Hex Key (Allen Wrench, Not Provided) 1
Loctite®271™Small amount
Acetone/Loctite®Primer (Not Provided) Small amount
CleanthesixM6x1x16atheadscrewswithacetone1.
or Loctite®primer (not provided) before use.
Apply 2-3 drops of red Loctite2. ®271™(provided) to
coat the threads of the screws.
Fit the plate over the eight tower studs, matching the3.
hole pattern in the plate with the hole pattern in the
towers (Figure 8) Reminder: the ramp-side of the plate
faces up (toward the towers) and the countersunk holes
face down (away from the towers).
Using a 4 mm hex key and the six prepared screws,4.
attach the plate to the towers (Figure 8). Completely
tighten the screws.
Wipe off excess Loctite5. ®.
Figure 7 - Attach the Studs to the Towers
Figure 8 - Attach the Plate to the Towers

17
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener Installing the Fastener
ATTACHING THE CROSSBAR
Items needed:
Tower Assembly 1
Crossbar 1
M6x1x16 Flat Head Screw 8
4 mm Hex Key (Allen Wrench, Not Provided) 1
Loctite®271™Small amount
Acetone/Loctite®Primer (Not Provided) Small amount
Clean the eight M6x1x16 at head screws with1.
acetone or Loctite®primer (not provided) before use.
Apply 2-3 drops of red Loctite2. ®271™(provided) to
coat the threads of the screws.
Position the crossbar with the countersunk holes3.
facing upward (Figure 9).
Using a 4 mm hex key, attach the eight screws4.
and crossbar to the towers (Figure 9). Completely
tighten the screws into the countersunk holes.
Wipe off excess Loctite5. ®.
ATTACHING THE RAILS
Items needed:
Tower Assembly 1
Rail 2
M6x1x20 Button Head Screw 2
4 mm Hex Key (Allen Wrench, Not Provided) 1
Loctite®271™Small amount
Acetone/Loctite®Primer (Not Provided) Small amount
Clean the two M6x1x20 button head screws with1.
acetone or Loctite®primer (not provided) before use.
Apply 2-3 drops of red Loctite2. ®271™(provided) to
coat the threads of the screws.
Using a 4 mm hex key, attach the rails to the side3.
of the towers (Figure 10). Orient the rails with the
recessed area against the side of the tower and
with the bends in the rail facing inward, toward the
Centerline. Completely tighten the screws.
Wipe off excess Loctite4. ®.
CHECKING THE FASTENER SETUP
Verify that the tower assembly and lock box are sitting1.
on the marks you made in Marking the Ambulance
Floor, Table or Tray on pages 14 and 15.
Verifytherailscanbemountedtotheambulanceoor,2.
table or tray without interfering with the lock box.
The rails should abut the lock box, or have a○
small gap between the end of the rails and the
lock box.
If the gap between the lock box and rail-ends is○
more than 25 mm (1"), or if the rails interfere
with the lock-box placement, re-measure and
mark the oor, table or tray for the fastener
installation.
Figure 9 - Attaching the Crossbar
Figure 10 - Attaching the Rails
Recess
Rails Bend Toward
Each Other
Screw (2)
Figure 11 - Top-Down View of Fastener
Ambulance Doors

18 © Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
Installing the Fastener
6.8 Drilling the Holes and
Installing the Backing Plates
ATTACH THE LOCK BOX TO THE FLOOR
Items needed:
Drill with 3 mm and 10 mm size bits 1
Backing plate 165 mm x 102 mm x 6 mm 1
Backing plate 406 mm x 114 mm x 6 mm 1
Welding equipment as needed
Before drilling, inspect under the ambulance oor,1.
table, or tray for obvious obstructions to the installation.
Contact the ambulance manufacturer:
if the fuel tank, oxygen lines, or other elements○
are in the way of the installation
for information about the ambulance warranty○
to make sure the backing plates can be installed○
without interference and welded safely
Cautiously drill a small starting hole (or pilot hole)2.
throughtheoorortrayateachmountingpoint,using
a 3 mm (1/8") diameter drill bit.
Align backing plates with the holes. Use backing3.
plates at least the size of those specied in Backing
Plate Specications on page 19. Increase the size of
the backing plates as needed so that they can be welded
tosignicantstructuralmembersoftheambulance.
Weld the backing plates beneath the lock-box and4.
tower-mounting points (Figure 12), using a full
penetration weld.
Using the guide holes, drill completely through the5.
ambulanceoor,table,ortray,andthebackingplates,
using an 10 mm drill bit.
Important
Inspect the underside of the ambulance for anything
(wiring, brake lines, fuel tank, oxygen lines or other
elements) that might interfere with the installation.
WARNING
A fastener installed without backing plates can fail
in a crash. Use properly installed backing plates to
secure the fastener at its mounting points.
WARNING
Improperly installed backing plates can fail in
a crash. Secure the backing plates to primary
structural members of the ambulance.
Important
The fastener is designed to be installed with backing
plates welded to rigid structural frame members
beneath the lock-box and tower-mounting points.
If the ambulance does not have the required backing
plates, install backing plates as instructed in this
manual. Consult the ambulance manufacturer for
assistance.

19
© Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
Important:
Backing Plate Specications
Use● A36 grade steel, 6061-T6 grade aluminum, or
equivalent for backing plates under the lock box and
towers. You do not need to use backing plates under the
rail mounting points.
Use the following size backing plates (minimum).●
Increase the size of the backing plates as needed so they
can be welded at both ends to a rigid structural frame or
structural reinforcement.
Lock Box:
○165 mm x 102 mm x 6 mm (6.5"x4"x ¼")
Towers:○406 mm x 114 mm x 6 mm (16"x4.5"x¼")
When welding the mounting plates, use a full penetration●
weld to secure the mounting plates to the rigid structural
frameorreinforcement.Spot-weldingisnotsufcientfor
a quality installation.
If mounting to an ambulance tray, the tray must be at least●
1.75 mm thick.
Floating Table or Tray (if present)
Lock Box
Backing Plate
Tower Backing Plate
Figure 12 - Backing Plate Placement
Installing the Fastener

20 © Ferno-Washington, Inc 234-3458-00 July 2010
FL1 Fastener
6.9 Mounting the Fastener
ATTACH THE LOCK BOX TO THE FLOOR
Items needed:
Lock Box 1
M8x1.25x70 Flat Head Screw 4
.313" SAE (.688"x.344"x.063") Washer 4
M8 Center Lock Nut 4
5 mm Hex Key (Allen Wrench, Not Provided) 1
13 mm Crescent or Socket Wrench 1
Position the lock box with its mounting holes aligned1.
withtheholesintheoor(Figure13).
InsertfourM8at-headscrewsthroughthelockbox;2.
theoor,tableortray;andthebackingplates.Usethe
provided screws or longer screws if needed (see Items
Supplied and Required, page 12).
From beneath the ambulance oor or tray, place a3.
.313"atwasheronascrewandthenusea5mmhex
key and 13 mm crescent or socket wrench to begin
threading an M8 center lock nut onto the screw but do
notnishtighteningthelocknut.
Repeat Step 3 for all four mounting points. Do not4.
nishtighteningthenuts.
The screws must extend beyond the nuts aNote:minimum
of 19 mm when completely tightened later (See Securing the
Fastener, page 21). Use longer screws if needed.
MOUNTING THE TOWERS
Items needed:
Tower Assembly 1
.313" SAE (.688"x.344"x.063") Washer 8
M8 Center Lock Nut 8
13 mm Crescent or Socket Wrench 1
Align the tower assembly over the mounting holes in1.
theambulanceoor,table,ortray.
Insert the eight studs through the oor, table or tray2.
and the backing plate.
From beneath the ambulance oor, table or tray,3.
placea.313"atwasheronastud,thenusea13mm
crescent or socket wrench to thread a M8 center lock
nutsontothestudbutdonotnishtighteningthenut
(Figure 14).
Repeat Step 3 for all eight mounting points. Do not4.
nishtighteningthenuts.
Use the studs provided, or use your own, longer screws5.
if needed (see Items Supplied and Required, page 12).
The studs must extend beyond the nuts aNote:minimum of
19 mm when completely tightened later (See Securing the
Fastener, page 21). Use longer screws if needed.
Figure 13 - Mounting the Lock Box
Installing the Fastener
Figure 14 - Mounting the Towers
