Fisher-Price GROW WITH ME 77306 User manual

Model Number 77306
Please keep this instruction sheet for future reference,
as it contains important information.
Requires four "C" (LR14) alkaline batteries for control tower; four "AA"
(LR6) alkaline batteries for car; and one 9V (6LR61) alkaline battery
for remote controller (batteries not included).
Adult assembly is required.
Tool required for assembly:
Phillips screwdriver (not included).
D
i
s
c
o
v
e
r
w
h
a
t
’
s
p
o
s
s
i
b
l
e
™
…
w
w
w
.
f
i
s
h
e
r
-
p
r
i
c
e
.
c
o
m
Grow With Me
RC Rally
Grow With Me
RC Rally
Grow With Me
RC Rally
™

Parts
2
5 Barrels
Crash Gate
Flexible
Track
3 Cones
Dirt Track
Ring of Fire
Handle
Support
Control
Tower
Handle
2 Flags
Double
Flag
Ramp
2 Ramp Rails
Starting Ramp
3 Hay
Bales
4 Stadium
Lights
Remote
Controller
Car
Remote
Controller
Holder
#6 x 5/8" Screw - 7
Shown Actual Size Label sheet not shown.

Car
Battery Compartment Door
1.5V x 4
“AA” (LR6)
Shown Actual Size
• Locate the battery compartment
on the bottom of the car.
• Loosen the screw in the battery
compartment door with a Phillips
screwdriver. Remove the battery
compartment door.
• Insert four "AA" (LR6) alkaline
batteries, as indicated inside the
battery compartment.
• Replace the battery compartment
door and tighten the screw with
a Phillips screwdriver. Do not
over-tighten.
Battery
Compartment
Door
Battery Installation
3
• Locate the battery compartment
on the back of the control tower.
• Loosen the screws in the battery
compartment door with a Phillips
screwdriver. Remove the battery
compartment door.
• Insert four "C" (LR14) alkaline
batteries, as indicated inside the
battery compartment.
• Replace the battery compartment
door and tighten the screws with
a Phillips screwdriver. Do not
over-tighten.
Control Tower
1.5V x 4
“C” (LR14)
Shown Actual Size

4
Battery Installation
Remote Controller
Battery
Compartment
Door
9V
9V (6LR61)
Shown Actual Size
• Locate the battery compartment
on the back of the remote
controller.
• Loosen the screw in the battery
compartment door with a
Phillips screwdriver. Remove
the battery compartment door.
• Insert one 9V (6LR61) alkaline
battery, as indicated inside the
battery compartment.
• Replace the battery compart-
ment door and tighten the screw
with a Phillips screwdriver. Do
not over-tighten.

5
Battery Tips
• We recommend using alkaline batteries for longer battery life.
• Do not mix old and new batteries.
• Do not mix different types of batteries: alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium).
• Remove the batteries during long periods of non-use. Always remove
exhausted batteries from the toy. Battery leakage and corrosion can
damage this toy. Dispose of batteries safely.
• Do not dispose of batteries in a fire. The batteries may explode or leak.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to be recharged.
• Only batteries of the same or equivalent type as recommended in the
"Battery Installation" instructions are to be used.
• If removable rechargeable batteries are used, they are only to be
charged under adult supervision.
• Rechargeable batteries are to be removed from the toy before they
are charged.
• If you use a battery charger, it should be examined regularly for
damage to the cord, plug, enclosure and other parts. Do not use a
damaged battery charger until it has been properly repaired.
When To Replace Batteries
If this toy is working slowly or erratically, it’s likely that batteries need
to be replaced. While it is possible that all batteries may need replace-
ment, the batteries that will need replacement most often are the
batteries in the car, followed by the remote controller, and then the
control tower. For more information, see the troubleshooting guide
beginning on page 19.

• Position the handle support so
the pegs are facing you.
• With the checkered side facing
down, fit the double flag on to
the pegs on the handle support.
6
• Fit the handle onto the handle
support as shown.
Assembly
2
3
1
Pegs
Double
Flag
Handle
Support
Handle
Support
Handle
WARNING
This product contains small parts in its unassembled
state. Adult assembly is required.
• Insert three screws through
the holes in the handle and
into the handle support. Tighten
the screws with a Phillips
screwdriver. Do not over-tighten.

•"Snap" the remote controller
holder onto the tab on the bottom
of the starting ramp, as shown.
• Insert and "snap" the pegs on
the bottom of the handle
assembly into the matching holes
in the starting ramp as shown.
45
7
• Insert the handle and starting
ramp into the matching holes in
the control tower as shown.
• Lift the control tower storage
compartment door. Insert two
screws through the control tower
and into the handle. Tighten the
screws with a Phillips screwdriver.
Do not over-tighten.
• Insert two screws through the
holes near the bottom of the
control tower and into the pegs in
the starting ramp. Tighten the
screws with a Phillips screwdriver.
Do not over-tighten.
Assembly
Handle
Assembly
Starting
Ramp
Pegs
Starting
Ramp
Remote
Controller
Holder
Handle
Control
Tower
Tab

8
Assembly
67
• Insert and "snap" the tabs on
the ramp into the matching
slots in a ramp rail.
• Repeat this procedure to
attach the other ramp rail.
• Gently squeeze the ring of fire
to insert the pegs on either
end into the matching holes at
the top of the ramp assembly,
as shown.
Ramp
Rail
Ramp
Tabs
Ramp
Ramp
Assembly
Ramp
Rail
Ring of Fire
Peg
Peg
Hole
Hole

9
Label Decoration
Proper label application will help keep labels looking their best!
When applying labels, keep the following guidelines in mind:
• Wash hands before applying labels.
• Before applying labels, wipe the surface of the toy with a clean, dry
cloth to remove dust or oils.
• For best results, avoid repositioning a label once it has been applied.
• Apply labels as shown in the illustration.
One-time assembly is now complete.
11
1
12
12
3
3
5
6
2
8
10
7
9
4
4

10
Mode I - Beginner Driver
Mode I is for a beginner or younger driver. Automatic Course Control
always keeps the car hugging the track, even over obstacles. Just press
the remote controller button to go and release to stop.
End of Track
Plug
Plug
Control
Tower
Hint: For best performance, use this toy on a smooth, flat surface. We
do not recommend use on a deep, pile carpet. This toy is designed for
indoor use only.
• Unfold the flexible track into an oval shape and place it behind the
control tower.
• Insert the plugs on each end of the flexible track into the matching
slots on either side of the control tower.
IMPORTANT! For proper function, the track must be installed
behind the control tower.
• Push or pull the flexible track into any curved shape you like.
Notes:
– The track creates a magnetic field. Do not use this toy around
items that are sensitive to or affected by magnetic fields.
– Do not connect two Grow With Me ™RC Rally sets together.
Setting Up The Track

11
Mode I - Beginner Driver
• Note the grooves on the edges of the crash gate, the ring of fire
ramp and the dirt track.
• Fit the grooves on these three obstacles onto the flexible track.
Place the obstacles anywhere you like, but be sure to keep them on
the outside of the track, as shown.
Hint: For best performance, space the obstacles equally around
the course.
• Fit the four stadium lights anywhere onto the track.
• Fit the two flags into any of the holes on the dirt track.
Crash Gate
Stadium
Light
Dirt Track
Ring of Fire
Ramp
Flag

ON/OFF
Button
12
Mode I - Beginner Driver
On/Off
Button
• Slide the mode switch on top
of the car to Ifor beginner
driver mode.
• Locate the speed control switch
on the bottom of the car.
• Slide the switch to either slow
speed or fast speed .
Hint: We recommend slow speed
for first time drivers.
• Press the ON/OFF button on top
of the car to turn the car on. The
car button lights up. The car is
now ready to receive a signal
from the remote controller.
Hint: If the car has not been driven
for a few minutes, it turns off
automatically. Press the ON/OFF
button again for power in the car.
Reset Switch
On/Off
Button
• Locate the reset switch on the
back of the control tower.
• Slide the reset switch ON .
• Locate the ON/OFF button on
the front of the control tower.
• Press the ON/OFF button to
turn the track and the control
tower on. The button lights up
if the track is properly
connected!
Hint: If the car has not driven
past the control tower in a few
minutes, the control tower turns
off automatically and the control
tower button light goes out.
Press the ON/OFF button again
for power in the control tower
and track.
Speed Control Switch
Mode Switch
Let’s Go

13
Battery InstallationBattery InstallationBattery InstallationBattery Installation
Mode I - Beginner Driver
WARNING
To prevent entanglement,
keep hair away from wheels.
• Press the forward button on
the remote controller. The car
moves around the track,
hugging all the way without
steering!
Hint: The car only travels forward
in Mode I - Beginner Driver. The
reverse button and the steering
wheel also do not work on the
remote controller.
• You will hear racing sound
effects from the control tower
each time the car crosses the
starting ramp.
Forward
• Note the arrows on the
starting ramp.
• Place rear wheels of the car on
the starting ramp, making sure
the car is pointing in the same
direction as the arrows. The car
should move around the track
counter-clockwise. Listen to the
engine revving.
Arrows

ON/OFF
Button
• Slide the switch on the top of
the car to II for pro driver mode.
• Locate the speed control switch
on the bottom of the car.
• Slide the switch to either slow
speed or fast speed .
• Press the ON/OFF button on top
of the car to turn the car on. The
car button lights up. The car is
now ready to receive a signal
from the remote controller.
Hint: If the car has not been driven
for a few minutes, it turns off
automatically. Press the ON/OFF
button again for power in the car.
Mode Switch
Speed Control Switch
14
Mode II - Pro Driver
• For off-road fun, place the starting
ramp, dirt track, ring of fire or
crash gate in any layout you like.
• Place additional obstacles around
your layout like the cones or
hay bales or barrels to test
driving skills.
• You can still use the flexible track
as an obstacle or part of your
layout, but note that the “Automatic
Course Control” feature does not
work in Mode II - Pro Driver.
Setting Up The Track
Mode II is for a more experienced driver who has acquired better manual
skills. In this mode, your child can take full control of steering and
direction. For some challenging fun, your child can set up an off road
course and use the remote controller wheel to steer around obstacles.

15
Mode II - Pro Driver
• Press the forward button
on the remote controller.The
car moves forward.
• Press the reverse button on
the remote controller. The car
moves backward.
• Use the wheel on the remote
controller to maneuver around
the track or past obstacles.
Note: The range of the remote
controller to the car is 15 feet
(with no obstructions).
Reverse
Forward
Wheel
ON/OFF
Button
• Turn the control tower power
on to hear sound effects each
time the car drives over the
starting ramp.
• Be sure the reset switch on the
control tower is set to the on
position .
• Press the ON/OFF button on the
front of the control tower to turn
power on. While power is on, the
button will not light because the
track is not connected to the
control tower in this mode.
Hint: If the car hasn’t driven
past the control tower for a few
minutes, the tower turns off
automatically. Press the ON/OFF
button again for power.
Reset Switch

16
Storage
• Fold up the track, as shown.
• Remove the flexible track from
both sides of the control tower.
• Slide the track over the
starting ramp.
• Lift the control tower storage
compartment door.
• Place the barrels, cones, hay
bales and road flags into the
control tower storage compart-
ment and door. Close the door.
1
4
3
2
Track
Storage
Door
Track

• Fold the ring of fire down onto
the ramp.
• Fit the ring of fire ramp onto
the dirt track as shown.
7
17
Storage
• Slide the edges of the dirt track
into the grooves in the handle
support and control tower.
6
• Attach the car to the hook on
the handle support as shown.
8
5
• Fit the dirt track to the crash
gate as shown.
Dirt
Track
Ring of
Fire Ramp
Hook
Dirt
Track
Crash
Gate
Control
Tower

• Place the remote controller in
the holder as shown.
10
• Fit the stadium lights onto the
track as shown.
9• Keep the car tires clean for
best performance.
• Wipe this toy with a clean cloth
dampened with a mild soap
and water solution. Do not
immerse this toy.
• This toy has no consumer
serviceable parts. Do not take
this toy apart.
• Do not drop this toy on a hard
surface.
18
Storage Care

19
Troubleshooting Guide
Car moves very slowly • Battery power in the car may be weak. Replace all
four batteries with fresh, alkaline batteries.
• The wheels may be dirty. Wipe them with a clean
cloth dampened with a mild soap and water solution.
Symptom Solution
Car responds
intermittently to the
remote controller
In Mode I, the car runs
closer and closer to
the track; or car keeps
hitting track
• Battery power in the remote controller or the car may
be weak. First, replace the battery in the remote
controller with a fresh, alkaline battery. If the problem
persists, replace all four batteries in the car with fresh,
alkaline batteries.
• You may be beyond the range of the remote controller,
which is about 15 feet (with no obstructions).
• Battery power in the control tower may be weak.
Replace all four batteries in the control tower with
fresh, alkaline batteries.
• The car may be going around the track in the wrong
direction. Be sure the car is pointing in the same
direction as the arrows on the starting ramp. The car
should go around the track counter-clockwise.
• The track may be set up on the wrong side of the
control tower. Be sure the track is set up behind the
control tower.
• The car may be running inside the track layout. Be
sure the car is running outside the track layout so the
car it crosses the starting ramp.

20
Troubleshooting Guide
• The control tower power may be turned off. Make sure
the reset button is in the on ● position. Press the
ON/OFF button again.
• The control tower may have turned off automatically and
the ON/OFF button will no longer be lit. Press ON/OFF
button on the control tower to turn it on again. The
button should light up.
• Battery power in the control tower may be weak.
Replace all four batteries in the control tower with fresh,
alkaline batteries.
Symptom Solution
Car does not respond to
the remote controller
Automatic Course
Control feature is
not working
There are no sound
effects when the
car crosses the
starting ramp
• The car mode switch may be set to off O. Be sure the
mode switch on the car is set to lor ll .
• The power indicator on the car is off, and the car may
have turned off automatically. Press the ON/OFF button
on the car to turn it on again. The button should light up.
• If the ON/OFF button on the car is lit, battery power in
the remote controller may be weak. Replace the battery
in the remote controller with a fresh, alkaline battery.
• You may be beyond the range of the remote controller
which is about 15 feet (with no obstructions).
• Make sure the mode switch on the car is set to the I
position and turned on. The ON/OFF button should be lit.
• Make sure the control tower reset button is turned on ●.
• Make sure the flexible track is completely connected to
the control tower on both sides. The ON/OFF button
should be lit up.
• The control tower may have turned off automatically and
the ON/OFF button is not lit. Press ON/OFF button on
the control tower to turn power back on. The button
should light.
• The car may be going around the track in the wrong
direction. Be sure the car is pointing in the same
direction as the arrows on the starting ramp. The car
should move around the track counter-clockwise.
• The car is too far from the flexible track. Make sure
the car is within four inches of the track for best
performance.
