Fisher-Price smart cycle Assembly instructions

Assembly Tip
Please follow these instructions carefully to properly assemble the pedals to the Smart Cycle™.
• Locate the left pedal marked with an Lon the outside end.
• Now, find the left pedal axle marked with an L.
• Fit the threaded end of the left pedal into the hole in the left pedal axle.
• Hand-tighten the left pedal by turning it counter-clockwise.
• Fit the assembly tool to the end of the left pedal. Turn it
counter-clockwise to fully tighten.
Hint: You will not be able to tighten the pedal if you have tried
to attach the right pedal to the left pedal axle. Remove the pedal
and be sure you are attaching the left pedal to the left pedal axle.
Be sure to match the letter Lon each part.
• Fit the assembly tool to the end of the right pedal. Turn it
clockwise to fully tighten.
Left Pedal Right Pedal
Your Smart Cycle includes a left and right pedal along with an assembly tool.
You must use the assembly tool to attach the pedals.
• Fit the threaded end of the right pedal (marked with an R)
into the hole in the right pedal axle (also marked with an R).
• Hand-tighten the right pedal by turning it clockwise.
L R
C
o
u
n
t
e
r
-
C
l
o
c
k
w
i
s
e
C
l
o
c
k
w
i
s
e
L R
C
o
u
n
t
e
r
-
C
l
o
c
k
w
i
s
e
C
l
o
c
k
w
i
s
e
12
34
TM
Assembly Tool
L
R

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2008 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
PRINTED IN CHINA K5054a-0921
• Insert two #8 x 1" screws into the handlebar and tighten.
Hint: If the screws cannot be tightened, you have not assembled
the handlebar properly. Remove the handlebar and refer back to
Assembly steps 2 and 3.
• Next, push the handlebar forward and down in place.
34
Assembly Tip
Please follow these instructions carefully to properly assemble the handlebar to the Smart Cycle™.
• Plug the handlebar connector into the socket in the console.
Hint: The connector will only fit one way into the socket. If it does
not seem to fit, turn it around and try again!
• Place the handlebar, at an angle, onto the top of the post.
• Push to insert the tab on the back of the handlebar into the
slot in the console.
12
TOP VIEW
Handlebar
Connector
Socket
IMPORTANT! For proper function, you must connect the
connector on the handlebar into the socket in the console!
Tab
Post
