User Manual
Hotplate Stirrer
HPS RT2 Basic
Operation Manual 9240-11-011

Thermo Scientific
MANUAL NUMBER 9240-11-011
0 -- 11/15/13 Original ccs
REV ECR/ECN DATE DESCRIPTION By
Preface
Hotplate Stirrer i
Important Before using this product, read this entire operation manual carefully. Users should
follow all of the operational guidelines contained in this manual and take all necessary safety
precautions while using this product. Failure to follow these guidelines could result in potentially
irreparable bodily harm and/or property damage. ▲
Caution All internal adjustments and maintenance must be performed by qualified service personnel. ▲
Material in this manual is for information purposes only. Thermo Fisher Scientific is committed to a continuing
program of product development and improvement, and reserves the right to change information, such as
specifications, appearance, and dimensions, described in this document without notice. Thermo makes no
representations or warranties with respect to this manual. In no event shall Thermo be held liable for any
damages, direct or incidental, arising out of or related to the use of this manual.
No part of this manual may be reproduced or transmitted in any form or by any means, including
photocopying, recording, or using information storage and retrieval systems, for any purpose other than the
purchaser's own use, without the express written permission of the manufacturer.
Any other product names and services identified in this manual are trademarks or registered trademarks of their
respective owners. No such use, or the use of any trade name, is intended to convey endorsement or other
affiliation with Thermo Fisher Scientific.
©2013 Thermo Fisher Scientific. All rights reserved.

Thermo Scientificii Hotplate Stirrer
Preface
This manual contains important safety and operation information. You must carefully read, understand, and
follow all the instructions in this manual prior to operating this instrument. Keep this manual in a safe place
nearby for reference and make it easily available to all users.
1) This manual highlights DANGER/WARNING/CAUTION/NOTICE alerts to prevent injury or property
damage and also to achieve optimum performance of your instrument.
(2) These alerts are classified into four types in this manual depending on the importance and the risk levels as
described below:
3) The claim which is out of the quality guarantee published by the Manufacturer is out of Manufacturer’s
responsibility.
4) The damage which is from unexpected fault or damage of user by Acts of God is out of Manufacturer’s
responsibility.
Symbols Meaning
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Ignoring this warning could cause serious injury or even death.
Ignoring this caution could cause injury or property damage.
Ignoring this notice could cause operational problems.

Thermo Scientific Hotplate Stirrer iii
Preface
Do You Need Information or Assistance on
Thermo Scientific Products?
If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:
1-740-373-4763 Direct
1-800-438-4851 Toll Free, U.S. and Canada
1-877-213-8051 FAX
http://www.thermoscientific.com Internet Worldwide Web Home Page
[e-mail] Tech Support Email Address
Certified Service Web Page
Thermo Fisher Scientific
401 Millcreek Road, Box 649
Marietta, OH 45750
Our staff can provide information on pricing and give you quotations. We can
take your order and provide delivery information on major equipment items or make
arrangements to have your local sales representative contact you. Our products are listed on the
Internet and we can be contacted through our Internet home page.
Our staff can supply technical information about proper setup, operation or
troubleshooting of your equipment. We can fill your needs for spare or replacement parts or
provide you with on-site service. We can also provide you with a quotation on our Extended
Warranty for your Thermo Scientific products.
Whatever Thermo Scientific products you need or use, we will be happy to discuss your
applications. If you are experiencing technical problems, working together, we will help you
locate the problem and, chances are, correct it yourself...over the telephone without a service
call.
When more extensive service is necessary, we will assist you with direct factory trained
technicians or a qualified service organization for on-the-spot repair. If your service need is
covered by the warranty, we will arrange for the unit to be repaired at our expense and to your
satisfaction.
Regardless of your needs, our professional telephone technicians are available to assist you
Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by
telephone or fax. If you wish to write, our mailing address is:
International customers, please contact your local Thermo Scientific distributor.
Sales Support
Service Support
www.unitylabservices.com

Hotplate Stirrer ivThermo Scientific
Table of Contents
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Ease of Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Durability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Unpacking and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Installation Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Connecting to Main Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Location Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Heater Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Stirrer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Cleaning Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Relocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Keeping Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
Support Rod Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
Transparent Shield & Heating Bath Assy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
Disposing of the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
Section 1
Section 2
Section 3
Section 4
Section 5
Section 6
Section 8
Section 7
Section 9

Hotplate Stirrer 1-1Thermo Scientific
Section 1 Warnings and Cautions
Ignoring the following warnings could cause serious injuries or even fatal
accidents.
Always wear proper protective gear (such as goggles, gloves, masks or an
apron) when using this instrument.
Never install or use this instrument in explosive atmospheres.
Never use the instrument to heat flammable liquids.
Never install this instrument near to hazardous or flammable substances.
Never immerse this instrument in water or operate it under water
Never reach for this instrument if it has fallen into water.
Check electrical requirements described in this operation manual or on the
ID plate of this instrument before use. Connect this instrument to a
dedicated power outlet nearby.
Make sure to connect this instrument only to properly grounded power
outlets to protect you and your instrument. Do not ground to gas
pipes or water pipes.
Do not install this instrument closer than 30 cm (12 inches) to a wall of
combustible material. And observe the minimum distances (in general,
30 cm) from other devices.
If you observe a strange smoke, odor or noise from the instrument, unplug
the power cord immediately and turn off the main power switch. After
the smoke or odor disappears, contact your dealer or Thermo Scientific
if any repair is required.
Do not disassemble, repair, or modify this instrument on your own. Doing
so will void your warranty and may result in injuries or product
damages.

1-2 Hotplate Stirrer Thermo Scientific
Section 1
Section title
Ignoring the following cautions could cause injuries or property damages..
Do not touch the top plate or any object near it even when the heater is
turned off. You may get burned due to residual heat.
After using this equipment, make sure to turn off the main power switch
and also to disconnect the power cord from the power outlet for the
safety of other users.
Do not place heavy objects, including this equipment, on top of the
power cord and do not strip, scratch, bend, twist, pull, or heat the
power cord. A damaged power cord is a fire and electrical shock hazard.
Do not allow moisture or water to get into the instrument. Fire or electri-
cal shock may result.
Beware of the effects of the magnetic field generated by this instrument.
Magnetic field can affect certain devices such as cardiac pacemaker, data
storage media, and so on.
Make sure to set up your instrument on a flat, stable, clean, non-slip, dry,
and fireproof surface inside a lab with proper safety measures.
Do not place any device which can be affected by the motor vibrations
near this equipment.
Do not touch the power outlet, power socket, or power cord with wet
hands. And make sure to connect the power cord directly and firmly to
the power outlet and power socket.
Do not put or insert any objects (especially if conductive or flammable)
inside this equipment.
Beware that mechanical shock or vibration can damage this equipment
and pay extra attention while moving it. Damages caused by mechanical
shock or vibration may result in injury or fire.
Do not impact the heat sink. You can damage the equipment or get
injured.
Do not install this equipment near any device that generates high fre-
quency noise such as high frequency welding machines, high frequency
sewing machines, or SCR power controllers.
Before cleaning, make sure to unplug the power cord to avoid electric
shock or fire.
Do not use chlorine bleach, ammonia-based cleaners, abrasives, ammonia,
or metal scouring pads. Wipe with a soft damped cloth or a sponge
soaked in water or diluted neutral detergent.

Hotplate Stirrer 2-1Thermo Scientific
Section 2 General Description
Congratulations of your purchase of a Thermo Scientific hotplate which is
specially designed to provide maximum benefit for your investment with
respect to performance, safety, ease of use, and durability.
HPS RT2 Basic model boasts fast heat up time (with 600W heating
capacity), fast and precise stirring speed (up to 2000 rpm), and big stirring
capacity (up to 20 liter in case of water).
Item/Model HP RT2 Basic
Dimension (W x D x H, mm) 161 x 290 x 100
Top plate dimension (Ø) 140 mm (5.5”)
Maximum heating capacity 600W
Current consumption (230V) 3A
Current consumption (120V) 5A

2-2 Hotplate Stirrer Thermo Scientific
Section 2
General Description
Performance Features
• Virtually No Decoupling of Stir Bars - By adopting a special magnet
with exceptionally strong magnetic coupling power as well as smooth-
start stirring mechanism, you will experience virtually no decoupling of
magnetic stir bars even with viscous media or at high speeds.
• Quick Heat Up Time - High heat transfer rate of the tightly integrated
structure of heater and ceramic-coated aluminum alloy top plate allows
quick heat up (up to 350°C).
• Fast and precise stirring speed - Fast and precise stirring speed (up to
2,000 rpm) even at high temperatures is made possible thanks to the
combination of a powerful and precise brushless DC (BLDC) motor
and a special magnet with extremely strong magnetic coupling power.
• Big Stirring Capacity - The BLDC motor and the special magnet also
provide big stirring capacity (up to 20 liter in case of water).
• Constant Stirring Speed - The feedback control design of this
instrument allows you to have constant stirring speed even when the
viscosity of the media changes during operation.
• Instant Halt of the Stirring Operation - Due to the exceptionally fast
response characteristics of the BLDC motor, the stirring operation
stops instantly when the stirrer is turned off.
Safety Features
• High Temperature Safety Limit of the Heating Plate - The default
setting of the temperature limit of the heating plate is 350°C to protect
you and your media.
• Multiple Overheat Prevention Measures - Built-in overheat prevention
circuit will turn off the heater if the top plate temperature reaches
450°C for any reason. In addition, if the temperature of the main body
exceeds 85°C, the overheat prevention circuit stops heating to protect
the motor and the PCB.
• Hot Top Warning Indicator - The top plate temperature can remain
very hot for some time even after the heater is turned off. To prevent
injury or fire under such circumstances, this instrument has a hot top
warning indicator on the control panel. This indicator will illuminate if
the top plate temperature is over 50°C. Even so, do not rely on this
indicator alone for your safety.
Features

Safety Features (continued)
• Heating Bath (Patent Pending) (optional) - A specially designed non-
slip heating bath shown below is available as an option. To prevent
unintentional slips of the bath during operation, this bath has concavo-
convex bottom shown below so that it fits snugly on top of the top
plate.
• Transparent Shield (optional) - A transparent shield is also available to
allow you to monitor your operations more safely by shielding you
against decoupled stir bars or liquid splashes.
• Two large digital displays show top plate temperature, heating level,
stirring speed as well as the set time and the remaining time for the
timer operation.
• When setting the timer, stirring time and heating time can be set
independently or even together, if needed.
• With two separate knobs for heat and speed control, you can set
heating level and/or stirring speed fast and with ease.
• You can easily set your own temperature limit at any value between 50
and 350°C.
• Up to two support rods (optional) can be attached to hold various
kinds of devices such as temperature sensors, thermometers, laboratory
glassware, and so on.
Hotplate Stirrer 2-3Thermo Scientific
Section 2
General Description
Features (continued)
Ease of Use

• The ceramic coated top plate boasts high heat and corrosion resistance
and its white color is optimal for monitoring color changes of the
media during operation.
• The BLDC motor inside this instrument has unusually long lifespan.
• Spill-proof design of the main body protects the inner parts of the
instrument and the elevated control panel reduces the chances of
contact with liquid spills or leakage.
2-4 Hotplate & Magenetic Stirrer Thermo Scientific
Section 2
General Description
Durability
(1) Ceramic-coated Top plate
(2) Heat Sink
(3) Heater Knob
(4) Control Panel (refer to Control Panel)
(5) Stirrer Knob
(6) Threaded Hole for Support Rod
(7) Main Power Switch
Construction

Construction
(continued)
Hotplate & Magenetic Stirrer 2-5Thermo Scientific
Section 2
General Description
(8) Power Socket
(9) Heating Bath (Optional)
(10) Support Rod (Optional)
(11) Transparent Shield (Optional)

Hotplate Stirrer 3-1Thermo Scientific
Section 3 Unpacking and Installation
Upon receiving the instrument, check to ensure that no damage has
occurred during shipment. It is important that any damage that occurred
during shipment must be detected before unpacking. If such damage is
found, notify the carrier immediately.
After unpacking, check to ensure that all the following parts and
accessories are included in the package. If not, contact your dealer or
Thermo Scientific immediately.
Installation
Environment
This instrument is designed for indoor use in laboratory environments and
to be operated only by properly trained staff knowledgeable in safe
laboratory practices. A suitable environment for installation is described
below.
• Avoid direct sunlight.
• Room temperature should be 5°C ~ 40°C
• Relative Humidity (RH%) should be less than 80%.
• Altitude should be less than 2,000m.
Item Figure Quantity Description
Main body 1--
Power cord 1--
Operation Manual 1--

3-2 Hotplate Stirrer Thermo Scientific
Section 3
Unpacking and Installation
Location Conditions
• Never install or use this equipment in explosive atmospheres.
• Never install or use this equipment with or near to hazardous or flammable
substances.
• Never operate this instrument under water, where water can get into the
instrument, or in an excessively wet environment.
• Set up your instrument on a flat, stable, clean, non-slip, dry, and fireproof
surface inside a lab with proper safety measures.
• Do not install this instrument closer than 20 cm (8 inches) to a wall of
combustible material.
• Observe the minimum distances (in general, 30 cm or 12 inches) from other
devices. In addition, any device which can be affected by the motor
vibrations should not be placed near this instrument.
• Do not install this instrument near any device that generates high frequency
noise.
When connecting power, use only the power cord that came with your
instrument. The power connection procedures are as follows:
(1) Before connecting the power cord, make sure that the main power
switch is turned off.
(2) Plug the power cord into the power socket at the back of your
instrument as shown in the diagram below.
(3) Plug the other end into a properly grounded and dedicated power
outlet nearby.
• Check electrical requirements in the operation manual or on the ID plate
attached to the bottom of this equipment before use.
• Make sure to connect this equipment only to properly grounded as well as
dedicated power outlets to protect you and your equipment.
• In order to prevent fire or power cord damage due to overloading, do not use
power strips or improper extension cords.
Connecting to Main
Power Supply
Main Power Switch
Power Socket

Hotplate Stirrer 4-1Thermo Scientific
Section 4 Control Panel
Thermo Scientific’s hotplate stirrers are equipped with a user-friendly
control panel which has two big knobs, three operational status LEDs, and
a hot top warning indicator.
A. Hot Top Warning Indicator
B. Heater LED
C. Stirrer LED
D. Power LED
E. Heater Knob
F. Stirrer Knob

• To avoid fires or injuries, make sure that the temperature is kept safely
below the flash point of the media to be heated.
• Be sure to wear proper protective gear (such as goggles, gloves, masks or
an apron) when using this instrument.
• This instrument can reach temperatures in excess of 350°C at the top plate
surface. Touching such hot surface will cause severe burns.
• Even if the instrument is turned off, the surface of the top plate and the
vessel on top of it will remain very hot for some time. Never leave your
instrument accessible to others while it is hot and never touch it unless you
are absolutely sure.
• Although this instrument has a hot top warning indicator, which is turned on
when the top plate temperature is over 50°C, do not rely on this indicator
alone for your safety.
EXTREME CAUTION IS REQUIRED AT ALL TIMES!
• To avoid overheating of the media, do not set the heating level too
high from the beginning. Gradual increase of the heating level is always
recommended.
The procedures of the heating operation are as follows:
(1) To activate the heater, turn the heater knob clockwise. With a ‘click’
sound, the heating starts immediately. Set the heater knob at the
desired position. (The heater LED will illuminate only when power is
supplied to the heater. However, if you set the knob at its maximum
position, then the heater LED will remain illuminated.)
Note that the hot top warning indicator will be turned on if the top
plate temperature rises over 50°C.
(2) If you want to turn off the heater, turn the heater knob counter-
clockwise until you hear the ‘click’ sound.
4-2 Digital Hotplate Thermo Scientific
Section 4
Operation
Heater Operation

Digital Hotplate 4-3Thermo Scientific
Section 4
Operation
• Never place a cold glass vessel onto a hot top plate.
• There is a danger of liquid spills if containers are over-filled and stirred at
high speed. Always ramp up stirrer speed slowly and never stir more rapidly
than necessary.
The procedures of the stirring operation are as follows:
(1) Before activating the stirrer, check whether the stirrer knob is at the ’0’
position. If not at the ‘0’ position, turn the stirrer knob counter-
clockwise all the way until you hear the ‘click’ sound.
(2) To activate the stirrer, turn the stirrer knob clockwise. With a ‘click’
sound, the stirring starts immediately. To set the stirring speed, turn
the stirrer knob at the desired position. For your safety, it is highly
recommended to increase the stirring speed in a gradual fashion.
(3) If you want to turn off the stirrer, turn the stirrer knob counter-
clockwise all the way to the ‘0’ position until you hear the ‘click’
sound.
Stirrer Operation

Hotplate Stirrer 5-1Thermo Scientific
Section 5 Maintenance
• Never immerse this instrument in water or any other liquid!
• Do not allow any liquid or wet material to get inside the instrument when
cleaning.
• Do not reconnect this instrument to power outlets until all cleaned surfaces
have dried.
• Do not use chlorine bleach, ammonia-based cleaners, abrasives, ammonia,
or metal scouring pads when cleaning.
• During cleaning and general operation take care not to scratch the surface
of the ceramic coated top plate as this could result in subsequent thermal
breakage.
Item
Inspection Interval
Daily Weekly
Connection status of power cord or plug ●
Damages in power cord or plug ●
Damages or cleanliness of top plate ●
Cleanliness of main body and accessories ●
Damages in switches, buttons, LED’s, dial knobs ●
Heating capability check (up to 350℃)●
Stirring capability check (up to 2000 rpm) ●
Assembly status of all parts or accessories ●
Cleaning Product

5-2 Hotplate Stirrer Thermo Scientific
Section 5
Maintenance
Always make sure to keep top plate, main body, and accessories clean. Dirt
and other foreign substances can cause fire or electric shock. Before
attempting cleaning,
(1) Disconnect the power cord from the power outlet and ensure that the
instrument is cool enough,
(2) Wipe with a soft dry cloth first to remove any foreign matter and, if
not enough,
(3) Wipe with a soft damp cloth or a sponge soaked in water or diluted
neutral detergent when necessary.
Note that cleaning is made much easier if spills are attended to promptly.
If you need to move the instrument to another place,
(1) Disconnect the power cord from the power outlet,
(2) Pack the instrument and its accessories into the original packaging or
any other suitable container before moving.
• Pay attention to avoid mechanical shock or vibration while moving the
instrument. Damages caused by mechanical shock or vibration may result in
injury or fire.
If you know you will not use this unit for an extended period of time,
(1) Disconnect the power cord from the power outlet and
(2) Clean the instrument with soft cloth.
(3) Pack the instrument properly and make sure to store it in place.
Cleaning Product
(continued)
Relocation
Keeping Product

Section 6 Troubleshooting
Hotplate Stirrer 6-1Thermo Scientific
Electrical Trouble Causes Solution
No power Unsuitable power supply Meet the electrical requirements of this instrument
before use.
Power cut-off by a circuit breaker or
power blackout
Find out why blackout or cut-ff happened and restore
power. If there is a short circuit or leakage, trace the
source of the problem and fix it.
Loose power connection
Reconnect the power cord firmly
to the power outlet as well as to the power socket at the
back of the instrument.
Damages in power cords, power outlets,
or plugs, Replace the damaged part with a proper one
Internal circuit failure Contact Thermo Scientific for service.
Repetitive tripping of the circuit breaker
Electrical oveload
Disconnect all the appliances connected to the breaker
first and reconnect them one by one to find the reason for
the overload.
Internal circuit failure Contact Thermo Scientific for service.
No operation with power on
Power cut-off by built-in overheat pre-
vention circuit
If the temperature of the main body exceeds 75℃, the
built-in overheat prevention circuit stops heating to pro-
tect the instrument.
In such cases, let the instrument cool down for some time
before power reconnection.
Internal circuit failure Contact Thermo Scientific for service.
