MARATHON 3000(R)
General Purpose Centrifuge
Operation Manual
Model 3000 3L Ventilated Centrifuge
Cat. No. 04-977-3000 -- 120 VAC, 60 Hz
Cat. No. 04-977-3001 -- 220, 230, 240 VAC, 50/60 Hz
Model 3000R 3L Refrigerated Centrifuge
Cat. No. 04-977-3000R -- 120 VAC, 60 Hz
Cat. No. 04-977-30001R -- 220, 230, 240 VAC, 50 Hz
Cat. No. 04-977-30002R -- 230 VAC, 60 Hz
PartNo.04-977-3000M Rev.4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents
Section 1 - Introduction Page
1.1 General Product Description...............................................................................................4
1.2 About This Manual.............................................................................................................5
1.3 Warnings, Cautions and Notes............................................................................................6
Section 2 - Installation
2.1 Receiving the Unit ..............................................................................................................7
2.2 Site Preparation...................................................................................................................7
2.3 Power Configuration............................................................................................................9
2.4 Moving the Unit.................................................................................................................10
2.5 The Front Panel (Keys and Displays)................................................................................11
Section 3 - Operation
3.1 Rotor and Accessories .......................................................................................................15
3.2 Starting and Stopping a Run..............................................................................................18
3.3 Stored Programs................................................................................................................19
3.4 Rotor Recognition System.................................................................................................21
3.5 3000R Refrigeration..........................................................................................................22
3.6 Diagnostic Messages and Error Codes..............................................................................23
Section 4 - Applications
4.1 Introduction.......................................................................................................................26
4.2 Speed and Force Tables....................................................................................................28
4.3 Derating Tables.................................................................................................................31
4.4 Chemical Resistance Tables..............................................................................................33
4.5 Decontamination Table.....................................................................................................34
4.6 RCF Nomograph...............................................................................................................35
Section 5 - Maintenance
5.1 Introduction.......................................................................................................................36
5.2 Care and Cleaning.............................................................................................................36
5.3 Cover Interlock Bypass.....................................................................................................39
5.4 Fuses Not Replaceable By Operator..................................................................................39
5.5 Condition of Returned Equipment ....................................................................................40
5.6 Warranty ...........................................................................................................................40
Section 6 - Specifications
MARATHON Series Operation Manual
2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Copyright ©, 1998
Fisher Scientific
Printed in the USA
MARATHON Series Operation Manual
3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 Introduction
1.1 General Product Description
Marathon series units are low-speed, general purpose
centrifuges, used in medical, industrial, and scientific
applications.
The Marathon 3000 Series is available in two models:
ventilated (3000) and refrigerated (3000R). Sections of
this manual that apply to the refrigerated version will be
designated 3000R or refrigerated only.
Both models accommodate swinging bucket style rotors of
either 4 x 750 mL or 6 x 250 mL. They can process a
variety of tubes, bottles, and microsample tubes. The 4 x
750 mL rotor can process both standard and deepwell
microplates. Also available are pear shape and short form
conical oil tube rotors.
Each centrifuge has an easy to use front panel that provides
two modes of operation: Manual and Programmed.
Manual mode is used for entering temperature (3000R
only), speed/force, and time values for individual runs.
Program mode allows you to define and save a maximum
of ninety-nine specific sets of run parameters, to recall and
reuse.
MARATHON Series Operation Manual
4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

The Marathon Series features a maintenance-free, brushless
motor, and an easy-to-use front panel, which provides three
versatile timing modes: automatic timed run, short spin
(momentary), and hold (continuous mode). Acceleration
and brake rates may be controlled, to optimize runs: rapid
for fast separations or slow for delicate samples. Repeat
runs, with the same speed and time settings, may be
achieved at the touch of a key.
A fail-safe cover interlock insures that the cover is closed,
before a run can begin, and keeps the cover closed, until the
rotor has reached a safe low speed (below 100 rpm), even
in the event of a power failure.
The rugged steel cabinet and rigid construction provide
quiet operation and long term reliability.
1.2 About This Manual
The Operations Manual contains all of the information
needed to install, operate, and maintain a Marathon Series
centrifuge. Refrigerated and ventilated models operate
similarly, and any differences are highlighted and noted,
throughout this manual. This manual, also, contains speed
and force, derating, chemical resistance, and
decontamination tables. The last chapter lists the units’
specifications.
This manual is written for centrifuge operators. In addition
to operation information, it contains a few basic
troubleshooting techniques, and a chapter on maintenance.
This Operation Manual is not a guide for servicing
centrifuge units.
MARATHON Series Operation Manual
5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1.3 Warnings, Cautions, and Notes
The terms warning, caution, and note have specific
meanings in this manual.
•A Warning advises against certain actions or situations
that could result in personal injury.
•A Caution advises against actions or situations that
could damage equipment, produce inaccurate data, or
invalidate a procedure.
•A Note provides useful information regarding an
operation, function, or procedure.
MARATHON Series Operation Manual
6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2 Installation
2.1 Receiving the Unit
Fisher Scientific ships the centrifuge in a carton that
protects it from shipping hazards. Follow the unpacking
instructions on the carton. Be sure to complete and return
the postage-paid warranty card.
2.2 Site Preparation
The unit normally resides on a bench top. The 3000
(ventilated model) can be placed in a cold room (no colder
than 4°C), for processing temperature-sensitive samples.
When you remove the centrifuge from a cold environment,
do not operate for a minimum of two hours, so that any
condensation will evaporate.
Note: When used in a cold room environment, some
bearing noise may become evident. The bearing lubricant
thickens at low temperatures. As the centrifuge speeds up,
it is thinned and distributed more evenly. Once this occurs,
any noise should subside.
MARATHON Series Operation Manual
7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

The following table lists the physical dimensions for the
3000 and 3000R:
3000R 3000
Sample Loading Height
14.7” (37.3 cm) 14.7” (37.3 cm)
Cover Closed Height
16.5” (41.9 cm) 16.5” (41.9 cm)
Cover Open Height
41” (104.1 cm) 41” (104.1 cm)
Width
30” (76.2 cm) 23.3” (59.1 cm)
Depth
25.8” (65.4 cm) 25.8” (65.4 cm)
A clearance of 8 cm (3 inches) should be provided on each
side of the unit, to ensure proper ventilation. Place the
centrifuge on a clean, dry surface, to make certain that the
suction feet at the bottom grip the surface firmly. Keep the
area beneath the unit free of debris and loose materials.
The resting surface must be level, to ensure quiet,
vibration-free operation. A rigid and stable location is
important. An improperly loaded centrifuge may vibrate or
move.
Warning: International Electrotechnical Commission
standard 1010 part 2-20 limits the permitted movement
of a laboratory centrifuge to 300 mm (12 in) in the unlikely
event of a disruption. Laboratory management procedures
should require that no person or any hazardous materials
enter within this boundary while the centrifuge operates.
MARATHON Series Operation Manual
8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2.3 Power Configuration
The Marathon Series uses AC power in different
configurations, appropriate for use throughout the world.
Please check the catalog number of the model that you
have purchased, to ensure that the machine you have is the
proper power configuration. For best results, the
refrigerated centrifuge, 3000R, should be used on a
dedicated line. Variations in line voltage or frequency
affect the unit’s speed and other characteristics. Less than
nominal line voltage may prevent the centrifuge from
reaching maximum published specifications of speed
and/or temperature. Power line voltage, at some locations,
may sag, when the refrigeration system turns on.
Power Cord The unit requires a grounded power supply (3 prong
outlet). If your facility does not have grounded power
outlets, arrange for a proper grounding. The power cord
plugs in on the left side of the unit.
Warning: Do not remove the grounding pin from the centrifuge
power cord. Do not use the bare wired power cord to attach a
power plug that does not have a grounding pin.
The power cord provided with the unit is correctly rated for the
highest current demand. This power cord should not be
interchanged with cords from equipment with lower current
demand. Exchange of power cords between equipment may
create a fire hazard.
Main Power Switch The main power switch is located on the left side of the
centrifuge, next to the power cord. Press this rocker switch
to power the unit on or off according to the picture below:
OFF ON
MARATHON Series Operation Manual
9
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Circuit Breaker The system provides an automatic circuit breaker, for
emergency situations, such as power surges, that could
damage the unit.
If the circuit breaker trips:
1. Unplug the unit.
2. Press the white button, on the left side of the unit.
3. Plug the unit back in.
2.4 Moving the Unit
Suction cups, at the bottom of the unit, keep it anchored to
the work surface. Keeping the unit stationary is a safety
feature.
To move the unit to a new location:
Caution: The unit can weigh up to 145 lb. (65.8 kg). Use
precaution when moving to avoid any injury.
1. Check that the new site meets the criteria in Section 2.2
before moving the unit.
2. Position a flat object, such as a tongue depressor, near a
suction cup at the bottom of the unit.
3. Lift up an edge of the cup, and insert the flat object far
enough to break the vacuum seal.
4. When all four cups are disengaged, lift the unit from the
work surface.
Caution: When the unit is in its new location, ensure that
the suction cups adhere correctly to the work surface.
MARATHON Series Operation Manual
10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2.5 The Front Panel
The Front Control Panel
(3000R Model Shown)
The control panel contains numeric displays for RPM/RCF
(Speed/Force), Time, program, and Temperature
(Refrigerated only). These displays have two states or
modes: Actual (bright display) and Set (dim display).
In Actual mode (bright display), they indicate current run
conditions, such as:
•rotor speed or force
•elapsed time of, or time remaining in, the run
•actual temperature (Refrigerated only)
•program number
In Set mode (dim display), the display indicates the desired
settings for the run. Set mode is activated when:
•SPEED, TIME, TEMP., or PROGRAM are pressed
•briefly, at the start of a run
•briefly, after the unit is switched ON
The numeric displays can, also, display warning or error
messages (see Section 3.5). Descriptions of the displays
appear on the following pages.
MARATHON Series Operation Manual
11
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

SPEED Speed Key: Pressing the SPEED key switches the display
from Actual to Set mode. Select the desired speed using the
numeric keypad, and then press ENTER. A selection must
begin before 5 seconds elapse or the display will revert to
the Actual reading.
RPM
RCF Speed/Force key and display: The number in the
speed/force display represents the rotor speed in RPM or
force in RCF. Press this key to toggle between RPM and
RCF. When RPM is selected, the display indicates
revolutions per minute. When RCF is selected, the display
indicates relative centrifugal force. Use the numeric keys
to change the set speed or force. Select speed in increments
of 50 RPM, from 500 through 3,600 RPM (depending on
the max. allowable speed limit for the particular rotor).
Select RCF from 500 - 3,000 xg (depending on the max.
allowable RCF limit for the particular rotor) in increments
of 50 xg.
Rotor Radius SPEED & RPM/RCF: Pressing these keys together
allows the user to change the radius of rotation. Select the
radius using the numeric keypad, and then press ENTER.
Also see Section 3.4 Rotor Recognition System.
TIME
HOLD
SHORT
SPIN
Time key: Pressing the TIME key switches the display
from Actual to Set mode. Select the desired time using the
numeric keypad, and then press ENTER. A selection must
begin before 5 seconds elapse or the display will revert to
the Actual reading.
Time display: The number in the display indicates time.
Time is displayed as minutes:seconds up to 99 minutes.
The timer begins counting at the start of a run, i.e. when
START is pressed. In manual mode, the timer counts
down from the set point. In time HOLD or SHORT SPIN
modes,the timer counts up.
Hold display: The hold feature is used to initiate an
indefinite spin. Press the HOLD key so that HOLD
appears in the display. Pressing START will then begin a
run at the set parameters. The timer will count up, and the
run will not end until the STOP key is pressed.
Short Spin: The short spin is used for quick separations.
Pressing SHORT SPIN will begin a run at the set
parameters. The timer will count up, and the run will not
end until the SHORT SPIN key is released.
MARATHON Series Operation Manual
12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

TEMP
(3000R only) Temperature key: Pressing the TEMP key switches the
display from Actual to Set mode. Select the desired
temperature using the numeric keypad, and then press
ENTER. A selection must begin before 5 seconds elapse or
the display will revert to the Actual reading.
Temperature display: The number in the display
represents temperature in degrees Celsius, from −9 °C
through +40 °C.
Note: If the Actual rotor chamber differs by more than 5°C
from a selected set point temperature, the °C display will
switch between the actual and set/programmed
temperatures, until the two temperatures come within 5°C.
PROGRAM
SAVE
MANUAL
Program key: Pressing the PROGRAM key switches the
display from Manual to Program mode.
Save key: This key saves the currently displayed desired
settings as stored programs 1 through 99 (see Section 3.3).
The numeric display shows the stored program number and
mode of operation (see Section 3.2).
Manual key: The manual returns the unit to manual
operation from Program mode.
Numeric Key Pad: The numeric key pad is used to change
the Set parameters for Speed/Force, Time, Temperature
(Refrigerated only) Rotor/Radius, or Program. When any
of the mode keys such as the SPEED, TIME, TEMP or
PROGRAM key is pressed, the numeric display switches
from Actual readings to Set parameters, without changing
them. The numeric key pad may be used to change the
parameter value. A selection must begin before 5 seconds
elapse or the display will revert to the Actual reading.
The CE key is used to clear a selection that has not yet
been entered to memory.
The 0/- key may be used to select a negative temperature.
Note: Temperature control range is specified from +4 °C
to ambient at maximum rated speed. Lower temperatures
can be achieved at less than maximum speed.
The ENTER key must be pressed after each parameter
selection to enter the value into memory.
MARATHON Series Operation Manual
13
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Acceleration and Braking Gentle acceleration and braking can be selected, when
centrifuging delicate samples. The gentle settings avoid
mixing of density gradients or breakup of pellets.
ACCEL Acceleration key: The Acceleration key controls rotor
acceleration up to 400 RPM. Press this key to toggle
between fast and slow acceleration.
•Fast acceleration is selected when the indicator above
the is lit.
•Slow acceleration is selected when the indicator above
the is lit.
Slow acceleration takes from 15 to 35 seconds to achieve
400 RPM, depending on the rotor and its contents. After
400 RPM, full acceleration is applied, until the set speed is
reached.
DECEL Deceleration key: The Deceleration key controls rotor
braking. Press this key to toggle between fast, slow, and
no brake.
•Fast braking is selected when the indicator above the
is lit.
•Slow braking is selected when the indicator above the
is lit.
•When no indicators are lit, coast (no brake) is selected.
The rotor will coast from operating speed to a stop.
START The Start key starts a run. A run is governed by the Set
parameters (manual or programmed). The green indicator
light blinks, until the rotor reaches 95% of the set run
speed. The light stays on until the end of the run.
STOP/LID This Stop/Lid key stops a run or unlocks the cover when
the unit is not running. (A run will also stop automatically
when the set time has elapsed or the start key is released, in
the Short Spin mode.) The red indicator light flashes to
indicate the rotor is still slowing down (braking or
coasting). When the run ends, the red light stays on,
indicating that the rotor has stopped.
MARATHON Series Operation Manual
14
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3 Operation
3.1 Rotor and Accessories
A balanced load is essential for all centrifuges. An
unbalanced load produces vibration, and can damage the
unit. A 2 gram load imbalance, at a speed of 4600 RPM,
imparts force equivalent to 9.1 kg (20 pounds) at rest.
Always ensure that the rotor is loaded symmetrically, with
a full complement of accessories, and a full (or paired) set
of tubes. Tube adapters should also be installed
symmetrically.
The rotors are dynamically balanced at the factory. The
manufacturer matches removable parts (trunnion rings,
shields, buckets, and carriers) to within 1 gram, and stamps
the weight on each piece. Check these markings, whenever
you interchange parts, to ensure that opposite parts are
matched. Ensure that the total weight of samples and
removable parts, loaded in opposing positions, are equal in
weight, to within 1 gram. The position numbers, present on
many rotors and adapters, identify opposing tube positions.
To obtain good dynamic balance, opposite loads must not
only be equal in mass, but must, also, have the same
centers of gravity. Opposing containers must be alike in
shape, thickness, and distribution of glass or plastic. This
is especially important for large containers.
MARATHON Series Operation Manual
15
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Tubes loaded into swinging bucket rotors must be
symmetric, around the axis of rotation. Verify this by
rotating the entire rotor 180°, by hand. The loads should be
in the same apparent positions (not mirror images). In
addition, the loads within each bucket must, also, be
symmetric around the bucket’s pivot axis. Verify this by
ensuring that each bucket is loaded so that it does not tilt
from the vertical, when the rotor is at rest. Maintaining
balance within each bucket ensures that the bucket and the
tubes swing out to horizontal, when the rotor reaches
operating speed, applying centrifugal force toward the
bottom of the tubes. Failure to achieve full swing-out
causes vibration and premature wear of the rotor and the
motor.
Samples of like (similar) specific gravities may be
processed in the same run, provided that the samples of the
same type are balanced around the rotor, as though they
were the only pairs in the rotor.
Caution: Do not exceed maximum rated speed for each
rotor/accessory combination. Maximum rated speeds can
be found in Section 4.2 - Speed And Force Tables.
Rotor Balance
Load tubes in the following manner:
1. Load two tubes at positions:
9 and 18.
2. Load four tubes at positions:
1, 5 and 10, 14
or
7, 3 and 16, 12
3. Load six tubes at positions:
1, 9, 5 and 14, 18, 10
or
7, 9, 3 and 12, 18, 16
4. Loading an odd number of tubes is not
recommended.
MARATHON Series Operation Manual
16
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Vibration All centrifuges have critical speeds, at which vibration
occurs. As the speed increases, beyond the critical speed,
vibration will cease. This inherent condition, also, occurs
during deceleration. An imbalanced load intensifies these
critical vibrations. Do not continuously operate this
centrifuge at observed critical speeds.
Rotor Installation To install the rotor:
1. Place the rotor (with recognition ring facing down, and
all printing facing up) onto the shaft.
2. Using the wrench provided, tighten the locking nut.
Slide the wrench handle to one side in order to utilize
maximum torque. Remove the wrench.
Note: There are two styles of locking nuts. One is
removable, as shown in Figure 1, and one is
captive (not removable), as shown in Figure 2.
Wrench
Captive Nut
Removable Nut
Recognition Ring
Recognition
Rin
g
Figure 1: Removable Locking Nut Figure 2: Captive Locking Nut
Rotor Removal To remove the rotor:
1. Using the wrench provided, loosen the rotor locking
nut. Remove the wrench.
2. Remove the locking nut completely, if removable,
otherwise lift up captive nut to free rotor.
MARATHON Series Operation Manual
17
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3. Lift the rotor off the shaft.
3.2 Starting and Stopping a Run
Read Section 2.5, for a general description of the front
panel. The settings displayed on the front panel always
govern the operation of the unit. The display above the
Program key shows the unit’s operating mode. It is
important that the unit be in the correct mode for the
desired operation.
The PROGRAM display can be one of the following:
•blank The unit is in manual operation.
•1-99 The unit is under control of the displayed
stored program number.
The rest of the display indicates the last parameters
selected.
Manual Operation For manual operation, press the MANUAL key so that the
program display is blank. Select the desired temperature
(3000R only), speed/g-force, run time, acceleration mode,
and braking mode. Press START, to start the spin.
The rotor will accelerate to 100 - 200 rpm and then coast
for a few seconds while the rotor recognition system
verifies the rotor and set parameters.
The time display counts down, and displays the time
remaining in the current spin, during manual operation.
The specified run time begins when the START key is
pressed. Braking begins when the set time elapses. Run
time does not include braking time.
The spin will stop automatically, at the end of the desired
interval. A run can, also, be stopped, at any time, by
pressing the STOP key.
The settings can be changed during a manual run. These
changes affect the run in progress. If the time setting is
changed, during a run, the unit adjusts the count-down
timer, to display the revised setting as the total time of the
run. If the new time selected is less than the elapsed time,
the run will end.
MARATHON Series Operation Manual
18
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

The unit’s mode (settings) cannot be changed during a
program mode spin.
3.3 Stored Programs
The Marathon Series has an internal memory capable of
holding 99 sets of run parameters. Each set, or program, is
stored and can be recalled by selecting a program number
(from 1-99). Programs are retained in memory, even if the
power is turned off. When necessary, a program can be
modified for a particular run or changed permanently. You
cannot change the unit's program, rotor/radius, or timing
modes, during a spin.
Add/Change Program Press PROGRAM to enter Program mode.
Select a program number with the numeric key pad. The
current program parameters will appear on the display.
Modify the desired parameter, including speed/RCF, time,
and temperature (if a refrigerated unit), using the numeric
key pad or modify the ACCEL or BRAKE modes.
Additionally, a radius value may be stored explicitly in the
program. The program number will flash, indicating that
the program was changed and has not yet been saved.
Make the changes permanent by pressing the SAVE key.
The program number will stop flashing, and the new
program settings will be displayed. The program will
remain in memory until further changes are made.
Because the Marathon 3000(R) has a fully automatic rotor
recognition system, the very first rotor that is spun using a
particular program will be identified and have its identity
automatically stored in the program. If a radius value was
not explicitly set by the user, the default radius (or
maximum allowable radius) for that rotor will be stored
with the program as well. If the user attempts to run a rotor
other than the one whose identity is stored in the program,
a “CH HD” (check head) message will appear.
If the user wishes to clear the rotor and its radius from the
memory banks of the program, he or she need only press
the SAVE button. The very first rotor spun after SAVE is
pressed will have its identity stored in the program,
MARATHON Series Operation Manual
19
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
