Flexispot H2B User manual

What is Not Covered?
Our limited warranty does not cover any problem that is caused by:
1. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
2. Conditions, malfunctions or damage resulting from normal wear and tear, improper
installation, improper maintenance, misuse, abuse, negligence, accident or alteration.
3. Accessories, connected materials and products, or related products not manufactured by
FlexiSpot.
4. Conditions, malfunctions or damage resulting from failure to follow the instructions and
guidelines relating to the product's intended use.
Our limited warranty is void if a product is returned with removed, damaged or tampered labels
or any alterations (including removal of any component or external cover).
How to File a Claim?
In order to receive the benefit of our limited warranty, you need to process your claim in
compliance with the terms of this limited warranty and follow proper return procedure. To
request warranty service, please contact customer service via email at [e-mail]
or toll free at 855-421-2808. You will need to provide the sales receipt or other evidence of the
date and place of purchase for your FlexiSpot product.
Implied Warranties and Limitation of Damages
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES
(INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE) SHALL BE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY,
AND SHALL NOT BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR FLEXISPOT
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PROFITS OR
REVENUE, RESULTING FROM ANY BREACH OF EXPRESS OR IMPLIED WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, EVEN IF HAS BEEN FLEXISPOT
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some jurisdictions do not allow
limitations on the duration of an implied warranty or the exclusion or limitation of special,
indirect, incidental or consequential damages, so the above limitations or exclusions may not
apply to you.
Governing Law
This Warranty shall be governed by the laws of the State of California, USA, without giving
effect to any conflict of laws principles that may provide the application of the law of another
jurisdiction.
How State Law Applies
This Warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
FlexiSpot Limited Warranty
Item No. H2B/H2S
Installation Guide
Website: www.flexispot.com
Tel: [phone]

1
2
3
4
6
5
7
8
10 9
Specifications
Accessory Package
Parts Included
Step 1
01 02
Pitch Quantity 2
Max. Weight Capacity
Adjustable Height
Wide expand 43.3" - 70.9" (1100 - 1800mm)
A B C D E
x2
M5 x 8 mm
F
x1
5x5 Square
gasket
x6 x8
Figures shown are for reference only. Please contact customer service if there are any accessories or
tools missing.
Diagram of Components
NO. Parts Qty
Step 2
176 Ibs (80 kg)
28.3" - 48.4" (720 - 1230mm)
G H
x1
4x4
x1
3x3 M8 x 16 mm
Bolt
x8 x24
St4.8 x 20 mm
Screw
M8 x 35 mm
Bolt
Screw
NO. Parts Qty
1 2
3 4
5 6
7 8
910
2
1
1
1
11
11
11
Turn the legs (2,3) upside down. Attach the feet (1) to the bottom of the legs using 8pcs M8x16mm
bolts (F) and tighten with 5x5 hex key (A).
A
F
2
A
F
Gx4
A
5x5
1
G
A
B
4x4
2
Attach the legs (3) to the cross bar (4) using 4pcs of the M8x35mm bolts (G). Use the 5x5 hex key
to lock bolts firmly in place. Then, using the 4x4 hex key (B), adjust the 8 screws on the bottom of the
cross bar (4) so that they will accommodate the actual size of your work surface.
Loosen
Stretch
Tighten
3
1
4
3

9
Step 3
Step 4
Step 5
Using the hex key (A), connect both the left and right side brackets (6, 7) to the bottom legs
using 4 bolts (G).
Please note:
Do not misplace the two brackets (6, 7).
The crank handle can be installed for either left-hand or right-hand orientation simply by reversing
its position as in the following figure.
Option 1: installing for right-hand orientation Option2: installing for left-hand orientation
1. Insert the crank shaft (8) into the right leg which has a shaft hole.
2. Use 2pcs bolts (D) and lock firmly with hex key (C).
3. Then insert crank handle (9) into crank shaft (8).
4. The crank handle(9) can be adjusted depending on your preference.
03 04
1
2
Loosen
Insert
Tighten
Adjust the drive
shaft to fit the slot.
Insert the assembled
drive shaft into the slots that
located at the top of each leg.
Loosen
Tighten
Stretch the hex
G
A
1
2
3
4
8
D
Dx2
C
3x3
C
3x3
C
A
Remove the Bearing block
from the crank shaft (8),
change its postion as in
figure, install it for left-hand
using.
B
A8
6
7
7

Step 6
Step 7
Attach the crank handle holder (10) to the underside of the table top using 2 screws (H). Ensure
that the crank handle will properly settle onto the holder when pushed in before screwing crank
handle holder (10) to surface.
attach the work surface to the side brackets (6, 7) using screws (H). Tighten screws firmly with a drill
or screwdriver.
Place the crank here
after you use.
10
H
Warning
·The packaging materials of this product could be dangerous to young children. Please keep all
plastic bags, screws, tools and other small or potentially hazardous materials away from young
children as they may present a choking risk.
·This Flexispot desk should not be used by children. To avoid potential danger, keep children and
people with cognitive impairments away from this height-adjustable desk, its control unit.
The manufacturer is not responsible for unintended use of this equipment.
·Before using this product, please read the instructions carefully and make sure you fully
understand all the product's functions and settings. If you have any questions, please contact us.
05 06
H
E
Hx22
Use the gaskets (E) while
screw the cross bar (4).
The quantity of gaskets (E) and screws
depends on the length of your desktop.
FlexiSpot Limited Warranty
This limited warranty offered by FlexiSpot covers defects in material or workmanship in new
FlexiSpot products. This warranty extends to the original purchaser only and is non-transferable.
Only consumers purchasing FlexiSpot products from authorized FlexiSpot retailers or resellers
may benefit from our limited warranty.
What is Covered?
The FlexiSpot limited warranty covers our products against defects in material or workmanship
as follows:
·FlexiSpot Height Adjustable Desk Frames
All height-adjustable desks purchased on or after October 5, 2016 include a 5-year warranty for
the frame, and a 3-year warranty for the motor, controller and switch, electronics and other
mechanisms.
·FlexiSpot Sit-Stand Desktop Workstations
All standing desks purchased on or after October 5, 2016 include a 5-year warranty for the frame,
medium-fiber desktop and mechanisms.
·FlexiSpot Desk Bikes
All desk bikes purchased on or after October 5, 2016 include a 3-year warranty for the frame, and
a 1-year warranty for the electronics and other mechanisms.
·FlexiSpot Mini Steppers
All desk bikes purchased on or after October 5, 2016 include a 1-year warranty for the frame, and
other mechanisms.
·Accessories
All monitor mounts purchased on or after October 5, 2016 include a 5-year warranty for the arms,
3-year warranty for gas spring system and mechanisms.
What are your Remedies?
FlexiSpot will replace at no charge to the consumer the defective parts only or, at FlexiSpot's
option, replace any product or part of the product that is defective because of improper
workmanship and/or material, under normal installation, use, service and maintenance. If
FlexiSpot is unable to provide a replacement and repair is not practical or cannot be completed in
a timely fashion, FlexiSpot may elect to refund the purchase price in exchange for the return of
the product. In the rare event that your FlexiSpot product is defective, we will provide you with a
replacement item shipped at no cost to you within the continental United States. The shipping
method for replacement products is FedEx Ground, but expedited shipping is available if you
choose to pay the additional expense. In addition, you will need to pay the shipping costs if any
products need to be shipped to you at an address outside the continental United States.
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE
PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY
OF THE PURCHASER. NEITHER ASSUMES NOR AUTHORIZES ANY PERSON FLEXISPOT
TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS
PRODUCT.
