Floe P1200 User manual

SHEET 1 OF 12
FLOE ANCHORING SYSTEM
P1200, PWC1300, P1600, V1600 PWC
ASSEMBLY INSTRUCTIONS
KIT P/N 512-00054-00
TOOLS REQUIRED
-(2) 9/16” SOCKETS/WRENCHES
-1-1/8” SOCKET (6 POINT ONLY)
-1/2” DRIVE RATCHET
-TORQUE WRENCH
-TAPE MEASURE
INSTRUCTION P/N: 612
-
00054
-
00
RELEASED 04/27/20
© Manufactured by:
Floe International Inc.
48473 State Hwy. 65
McGregor, MN 55760
www.floeintl.com
*LIFT NOT
INCLUDED
STORAGE
DISCLAIMER
WHEN STORING THE ANCHORING SYSTEM, THE MAIN TUBE WITH AUGER
MUST BE CLEANED THOUROUGHLY OF ANY DEBRIS (MUD, SAND, ETC.) AND
PLACED UPSIDE DOWN (AUGER POINTING UPWARDS).
I
MPORTANT
DO NOT USE AN IMPACT
OR CORDLESS DRILL TO
INSTALL LIFT ANCHORS.

SHEET 2 OF 12
BILL OF MATERIALS/EXPLODED VIEW
P/N 512-00054-00 ANCHORING SYSTEM, PIVOT LIFTS & V1600
NUMBER PART NUMBER QTY. DESCRIPTION
1 001-70107-00 2 HHCS, 3/8-16 x 1 ¼” 18-8 SS
2 001-70113-00 4 HHCS, 3/8-16 x 2-1/2” 18-8 SS
3 001-70114-00 4 HHCS, 3/8-16 x 2-3/4” 18-8 SS
4* 001-70117-00 4 HHCS, 3/8-16 x 3-1/2” 18-8 SS
5* 001-70118-00 4 HHCS, 3/8-16 x 3-3/4” 18-8 SS
6 001-76071-00 8 NUT, NYLOCK 3/8-16 ALUM.
7 002-00198-00 2 SET COLLAR, ANCHORING SYSTEM
8 002-00265-00 4 PLATE, PIVOT ANCHOR POCKET MOUNTING
9 111-00509-00 2 ASS’Y, ANCHOR POCKET PIVOT & V1600
10 111-00510-00 2 ASS’Y, BOAT LIFT ANCHOR PIVOT AND V1600
*USED ON P1600 INSTALLATIONS

SHEET 3 OF 12
INSTALLATION NOTE
IF A WHEEL KIT IS INSTALLED OR TO BE INSTALLED, POSITION ANCHORING SYSTEM BRACKETS:
- 9” MINIMUM FROM THE WHEEL KIT BRACKET ON V1600 PWC LIFTS
- 12” MINIMUM FROM THE WHEEL KIT BRACKET ON PIVOT LIFTS

SHEET 4 OF 12
STEP 1
ANCHORS WILL BE PLACED ON SIDE BEAMS BETWEEN CORNER POSTS “A” & “B” AND CORNER
POSTS “C” & “D” (FIGURE 1.1).
FIGURE 1.1

SHEET 5 OF 12
ATTACH PLATES AND POCKET WELDMENT ONTO FRAME BEAM AS SHOWN IN FIGURE 1.2. FOR
V1600, P1200, AND PWC 1300 LIFTS, USE (2) 3/8” X 2-1/2 BOLTS FOR THE LOWER HOLES AND (2)
3/8” X 2-3/4” BOLTS FOR THE UPPER HOLES. FOR P1600 LIFTS, USE (2) 3/8” X 3-1/2” BOLTS FOR THE
LOWER HOLES AND (2) 3/8” X 3-3/4” BOLTS FOR THE UPPER HOLES. PLACE POCKET AT THE
APPROPRIATE DIMENSION FOR YOUR LIFT AS SHOWN IN FIGURE 1.3. MEASURE FROM THE INSIDE
OF THE CORNER POST ON THE WINCH END OF THE LIFT TO THE CLAMP. FOR PWC1300 LIFTS,
PLACE AT 26” FROM THE CORNER POST. FOR P1200 & P1600 LIFTS, PLACE AT 41” FROM THE
CORNER POST. FOR V1600 LIFTS, PLACE AT 29” FROM THE CORNER POST.
2X
FIGURE 1.2
FIGURE 1.3
2X
*
**
*TOP HOLE
- PIVOT LIFTS
**BOTTOM HOLE
- V1600

SHEET 6 OF 12
ONCE PLACEMENT IS FINALIZED, TORQUE TO 35 FT-LBS (FIGURE 1.4).
IMPORTANT NOTE: POCKET PLACEMENT MAY HAVE
TO BE ADJUSTED BASED UPON POSSIBLE
OBSTRUCTIONS ON LAKE BOTTOM OR ABILITY TO
DRIVE AUGER TO FULL DEPTH.
FIGURE 1.6
2X
FIGURE 1.4
2X

SHEET 7 OF 12
STEP 2
NOTE: INNER LEG HEIGHT MUST BE SET BEFORE ANCHORS ARE INSTALLED (BOTTOM OF INNER
LEG TO BOTTOM OF CORNER POST). SLIDE COLLAR OVER ANCHOR TUBE (FIGURE 2.1). SET
HEIGHT OF COLLAR BY TAKING THE MEASUREMENT FROM THE BOTTOM OF COLLAR TO THE TIP OF
THE AUGER (FIGURE 2.2). SEE TABLE ON SHEETS 8 FOR COLLAR HEIGHT MEASUREMENTS.
FIGURE 2
.1
FIGURE 2.2
2X
2X

SHEET 8 OF 12
TO DETERMINE COLLAR HEIGHT, THE FOLLOWING TABLE IS USED. REFER TO FIGURE 2.2 ON SHEET
7 ON HOW TO MEASURE FOR COLLAR HEIGHT. INNER LEGS ON INSTALLATIONS HAVE A TRAVEL OF
24 INCHES.
COLLAR HEIGHT SETUP
EXTENDED LEG LENGTH (INCHES) 1 2 3 4
COLLAR HEIGHT (INCHES)
25 26 27 28
EXTENDED LEG LENGTH (INCHES) 5 6 7 8
COLLAR HEIGHT (INCHES)
29 30 31 32
EXTENDED LEG LENGTH (INCHES) 9 10 11 12
COLLAR HEIGHT (INCHES)
33 34 35 36
EXTENDED LEG LENGTH (INCHES) 13 14 15 16
COLLAR HEIGHT (INCHES)
37 38 39 40
EXTENDED LEG LENGTH (INCHES) 17 18 19 20
COLLAR HEIGHT (INCHES)
41 42 43 44
EXTENDED LEG LENGTH (INCHES) 21 22 23 24
COLLAR HEIGHT (INCHES)
45 46 47 48
EXTENDED LEG LENGTH (INCHES) 25
COLLAR HEIGHT (INCHES)
49
FOR EXAMPLE, AN EXTENDED LEG LENGTH OF 12 INCHES WOULD RESULT
IN A COLLAR HEIGHT OF 36 INCHES.

SHEET 9 OF 12
ONCE POSITION IS SET, SECURE COLLAR TO HEX TUBE USING (1) 3/8” X 1-¼” BOLT (FIGURE 2.3)
AND TORQUE TO 20 FT-LBS (FIGURE 2.4).
FIGURE 2.3
FIGURE 2.4
2X
2X

SHEET 10 OF 12
BRING ANCHOR ASSEMBLY TOWARDS LIFT UNTIL AUGER TOUCHES FRAME BEAM (FIGURE 2.5). LIFT
THE ANCHOR ASSEMBLY AND STOP WHEN THE AUGER HELIX TOUCHES THE BOTTOM OF THE
FRAME BEAM (FIGURE 2.6).
FIGURE 2.5
2X
FIGURE 2.6
2X

SHEET 11 OF 12
SLIDE THE ANCHOR ASSEMBLY TOWARDS THE POCKET. NOTE THAT ONLY THE AUGER SHAFT WILL
SLIDE INTO THE POCKET, THE HEX SHAFT WILL NOT (FIGURE 2.7). LOWER THE ANCHOR INTO
POCKET UNTIL AUGER TOUCHES LAKE BOTTOM (FIGURE 2.8).
FIGURE 2.7
2X
FIGURE 2.8
2X

SHEET 12 OF 12
IF ADDITIONAL ADJUSTMENT IS REQUIRED, LOOSEN 3/8” NUTS AND SLIDE POCKETS
ON FRAME BEAM WITH ANCHOR ASSEMBLIES UNTIL DESIRED POSITION IS FOUND.
ONCE POSITION IS SET, RE-TORQUE NUTS TO 35 FT-LBS (FIGURE 2.9).
DRIVE ANCHOR ASSEMBLY INTO LAKE BOTTOM USING 1-1/8” 6 POINT SOCKET & 1/2” DRIVE
RATCHET UNTIL COLLAR TOUCHES TOP OF ANCHOR POCKET (FIGURE 2.10).
FIGURE 2.9
2X
2X
FIGURE 2.10
IMPORTANT NOTE:
ONLY USE A 6
POINT SOCKET.
12 POINT SOCKETS
MAY CAUSE
DAMAGE TO HEX
SHAFT.
6 POINT SOCKET
12
POINT SOCKET
DO NOT USE
IMPORTANT
DO NOT
USE AN
IMPACT OR
CORDLESS
DRILL TO
INSTALL
LIFT
ANCHORS.
