FLORABEST FTS 1100 C3 Owner's manual

SCHMUTZWASSER-TAUCHPUMPE
Originalbetriebsanleitung
PONORNÉ ČERPADLO
Překlad originálního provozního návodu
PONORNÉ ČERPADLO NA ZNEČISTENÚ VODU
Preklad originá lneho návodu na obsluhu
DIRTY WATER SUBMERSIBLE PUMP
Translation of original operation manual
POTOPNA ČRPALKA ZA UMAZANO VODO
Prevod originalnega navodila za uporabo
IAN 102797
DIRTY WATER SUBMERSIBLE PUMP FTS 1100 C3
®
102797_flo_Schmutzwassertauchpumpe_cover_SI_CZ_SK.indd 2 19.09.14 11:18

GB Translation of original operation manual Page 4
SI Prevod originalnega navodila za uporabo Stran 15
CZ Překlad originálního provozního návodu Strana 25
SK Preklad originálneho návodu na obsluhu Strana 36
DE / AT / CH Originalbetriebsanleitung Seite 47
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.
Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi přístroje.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
102797_flo_Schmutzwassertauchpumpe_cover_SI_CZ_SK.indd 3 19.09.14 11:18

1
2
3
3
10
4
4
4a
5
2
6
7
8
11
10
9
9
5






4
GB
This appliance can be used by chil-
dren aged from 8 years and above
and persons with reduced physi-
cal, sensory or mental capabilities
or lack of experience and knowl-
edge if they have been given su-
pervision or instruction concerning
use of the appliance in a safe way
and understand the hazards in-
volved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
Introduction
Congratulations on the purchase of your
new device. With it, you have chosen a
high quality product.
During production, this equipment has
been checked for quality and subjected
to a nal inspection. The functionality of
your equipment is therefore guaranteed. It
cannot be ruled out that residual quantities
of water or lubricants will remain on or in
the equipment/hose lines in isolated cases.
This is not a fault or defect and it repre-
sents no cause for concern.
The operating instructions constitute
part of this product. They contain
important information on safety, use
and disposal.
Before using the product, familiarise
yourself with all of the operating
and safety instructions. Use the
product only as described and for
the applications specied.
Keep this manual safely and in the
event that the product is passed on,
hand over all documents to the third
party.
Content
Introduction .................................4
Areas of Application ....................5
General Description......................5
Scope of Delivery............................5
Functional description......................5
Overview.......................................5
Technical Data..............................6
Performance data............................6
Notes on Safety ...........................6
Symbols in the manual.....................6
Symbols on the equipment ...............6
General notes on safety...................7
Initial Operation...........................8
Positioning/Hanging .......................8
Mains Connection...........................9
Connecting the Pressure Line.............9
Adjustment of the oat switch ..........9
Operational start-up ......................10
Cleaning/Maintenance/Storage..10
General cleaning instructions..........10
Cleaning the Fan Wheel ................11
Storage........................................11
Waste Disposal/Environmental Pro-
tection........................................11
Guarantee .................................12
Repair Service............................13
Service-Center............................13
Importer ....................................13
Troubleshooting .........................14
Replacement parts/Accessories ..14
Translation of the original EC
declaration of conformity........... 59

5
GB
General Description
The diagram of the most impor-
tant functional elements can be
found on the foldout side.
Scope of Delivery
Carefully unpack the appliance and check
that it is complete. Dispose of the packag-
ing material correctly.
- Fully assembled dirty water
submersible pump
- Angle adapter
- Reducer
- 8 m nylon cord
- Instruction Manual
Functional description
The dirty water submersible pump has a
stainless steel casing, a stable suction foot
and a non-corrosive motor shaft. The pump
is tted with a oat switch, which automati-
cally switches the equipment on or off.
The motor is protected from overload by a
thermal safety switch.
Please refer to the following descriptions
for the function of the operating parts.
Overview
1 Round handle
2 Pump housing
3 Pump outlet
4 Floor plate
5 Foot part
6 Mains connection cable
7 Float switch
8 Float switch grating
9 Reducer
10 Angle adapter
11 8 m nylon cord
Areas of Application
The dirty water submersible pump is a
drainage pump and designed for trans-
porting water and sewage water (max.
particle size 35 mm) up to a temperature
of max. 35°C.
It is suitable e.g. for pumping around and
pumping out basins and containers, for
pumping out ooded cellars, and for ex-
tracting water from wells and shafts.
This equipment is not suitable for industrial
use. Industrial use will invalidate the guar-
antee.
Any other use, not expressly authorised in
these instructions, may cause damage to
the equipment and represent a serious risk
for the user.
The pump is not suitable for continuous
operation. Continuous operation reduces
the durability and shortens the guarantee
period.
The operator or user is responsible for ac-
cidents or damage to other people or their
property.
The manufacturer shall not be liable for
damages caused by use other than for
which the equipment is intended or by in-
correct operation.

6
GB
Technical Data
Rated voltage ..................230 V~, 50 Hz
Rated power input/
Power consumption ................... 1100 W
Max. discharge rate (Q max) .. 20000 l/h
Max. discharge head (H max)........... 9 m
Max. depth of immersion .................. 7 m
Max. water temperature (T max) ..... 35°C
Hose connection .............. 1“, 1¼ “, 1½ “
Max. foreign body size.................35 mm
Switching point level:
ON...........................approx. 520 mm
OFF...........................approx. 230 mm
Mains cable .................................. 10 m
Weight (incl. accessories)............ 6.18 kg
Safety class ..........................................I
Degree of protection.........................IPX8
Technical and optical changes can be
carried out in the course of further devel-
opment without notice. All dimensions,
references and information of this instruc-
tion manual are without guarantee. Legal
claims, which are made on the basis of the
instruction manual, cannot thus be consid-
ered as valid.
The maximum performance data are meas-
ured with a straight, direct outlet ow.
The angle piece and backow valve may
reduce performance.
Performance data
(l/h)
(m)
Notes on Safety
This section deals with the general safety
regulations for working with the equip-
ment.
Symbols in the manual
Warning symbols with in-
formation on damage and
injury prevention.
Instruction symbols (the instruction is
explained at the place of the excla-
mation mark) with information on
preventing damage.
Help symbols with information on
improving tool handling.
Symbols on the equipment
Caution! Not suitable for water
with a high sand content!
Before beginning work, familiarise
yourself thoroughly with all the op-
erating elements, particularly with
how they function and operate. Ask
a specialist if necessary.
Read and follow the operating in-
structions provided for the device!
Attention: Remove the plug from the
socket as soon as the power lead is
damaged or cut.
7 m
Greatest possible operating immer-
sion depth.
Electric appliances should not be
disposed of in the domestic gar-
bage.

7
GB
General notes on safety
Working with the equipment:
Caution: to avoid accidents and
injuries:
• People who are unfamiliar with the
operating instructions are not permitted
to use the equipment. Local regulations
or bylaws may determine the minimum
age for using the device.
• Wear sturdy footwear to protect
against electric shock.
• Should there be people in the water,
do not operate the equipment. Risk of
electric shock!
• Take appropriate measures to keep
children away from the equipment
whilst it is running. There is a risk of
injury!
• Do not use the equipment in the vicinity
of ammable liquids or gases. Non-
observance will result in a risk of re
or explosion.
• Store the equipment in a dry place and
out of reach of children.
Caution! To avoid damage to the
equipment and any possible person
injury resulting from this:
• The transportation of aggressive, abra-
sive (grinding effect, e.g. sandwater),
corrosive, combustible (e.g. motor
fuels) or explosive liquids, salt water,
cleaning agents and foodstuffs is not
permitted. The temperature of the liq-
uid being transported must not exceed
35°C. Non-observance can lead to
device damage and create a risk for
the user.
• Do not work with damaged or incom-
plete equipment, or with equipment
that has been converted without the
approval of the manufacturer. Before
initial operation, have a specialist
check that the required electrical pro-
tection measures are in place.
• Monitor the equipment during opera-
tion (particularly in residential spaces,
in order to detect automatic switching
off or dry running of the pumps in time.
Regularly check the function of the oat
switch (see chapter “initial operation“).
Non-observance will invalidate all
guarantee and liability claims.
• Please note that the pump is not suit-
able for continuous operation (e.g. for
watercourses in garden ponds). Check
the equipment regularly for correct
functioning.
• Note that the lubricants used in the
equipment may cause damage or con-
tamination if they escape. Do not use
the pump in garden ponds with sh
stocks or valuable plants.
• Do not carry or x the equipment by
the cable or pressure line.
• Protect the equipment from frost and
from running dry.
• Use only original accessories and do
not carry out conversion work on the
equipment.
• Please read the notes in the operating
instructions on the topic of “mainte-
nance and cleaning”. Any measures
above and beyond these, particularly
opening the equipment, are to be car-
ried out by an electrician. In the case
of repairs, always contact our service
centre.
Electrical safety:
Caution: to avoid accidents and
injuries from electric shocks:

8
GB
• The equipment is not to be operated if
there are people in the water. There is
a risk of electric shock.
• After erection, the mains plug must be
freely accessible when the equipment
is in operation.
• Before operating your new pump,
have a specialist check:
- The earthing, the protective multiple
earthing; the residual current circuit
breaking must be compliant with
the safety regulations of the energy
supply company and function with-
out fault,
- The protection of the electrical plug
connections from the wet.
- If there is a risk of ooding, x the
plug connections in an area that is
safe from ooding.
• Ensure that the mains voltage matches
the specications on the rating plate.
• The electrical installation shall be ac-
cording to national wiring rules.
• Connect the appliance to a power
socket with a residual current circuit
breaker of rated residual current no
more than 30 mA; minimum fuse 6 am-
peres.
• Before each use, check the equipment,
cable and plug for damage. Defec-
tive cables are not to be repaired, but
rather replaced by new ones. Have
damage on your equipment repaired
by an authorised specialist.
• If the power cable for this equipment is
damaged, it must be replaced by the
manufacturer, a customer service agent
of the same or a similarly qualied
person in order to prevent hazards.
• Do not pull the plug from the socket by
the cable. Protect the cable from heat,
oil and sharp edges.
• Do not carry or x the equipment by
the cable.
• Use only extension cables that are pro-
tected from spray water and designed
for outdoor use. Always fully unroll a
cable drum before use. Check the ca-
ble for damage.
• Disconnect the mains plug from the
socket before all work on the equip-
ment, in case of leaks in the water
system, during work breaks, and when
not in use.
• The cross-section of mains connection
lines must be no smaller than rub-
ber hose lines with the designation
H07RN8-F. The line must be 10 m long.
The exible lead cross-section of the
extension cord must at least 2.5 mm2.
Initial Operation
Positioning/Hanging
• The dimensions of the pump shaft must
be not less than 40 x 40 x 50 cm, in
order that the oat switch ( 7) can
move freely.
• The pump can be suspended by the
round handle ( 1) or placed on the
shaft oor.
The pump can be suspended and/or
removed using the nylon cord ( 11)
provided.
To hang up safely, loop the nylon cord
around both of the cable holders that
are pointing downwards and pull it up-
wards through the round handle.
Never suspend the pump by the hose.
Ensure that the equipment is
not hung up or held by the
mains cable. There is a risk
of electric shock from dam-
aged mains cables.

9
GB
Note that, over time, dirt and sand
may collect on the bottom of the
shaft, which could damage the
pump.
We recommend standing the pump
on a brick.
If the water level is too low, the silt
in the shaft can quickly dry out and
impede the pump when warming
up.
Mains Connection
The pump you have purchases is already
tted with an earthed plug. The equipment
is designed for connection to an earthed
wall socket with a residual current operat-
ed device (RCD switch) at 230 V ~ 50Hz.
Connecting the Pressure Line
The pump is installed
- Either with a xed pipeline
- Or with a exible hose line.
1. Screw the bracket adapter (10)
onto the pump outlet (3).
2. Fit the hose over the reducer (9)
and secure it with a hose clamp.
Or use a screw connection at
the bracket adapter (10) or the
reducer (9).
Outlet with a 1½” internal thread on
the pump for connection of the angle
adapter (10) or for direct connection
of a hose with a 1½” external thread;
Outlet with 1½“ external thread at the
bracket adapter (10) for connection of
the reducer (9) or a 1½“ screw con-
nection;
Outlet on reducer (9) for connection of
a 1¼” or 1½” hose as a compression
joint (xing with a hose clamp);
Outlet with 1“ external thread at the re-
ducer (9) for connection of a 1“ screw
connection;
Outlet with 1½“ thread at the reducer
(9) for connection of a 1“hose as
clamp connection (xing with a hose
clamp).
Note that the particle size may
be max. 19 mm if the reducer
(Ø19.3mm) is used, otherwise
the reducer and hose can become
blocked.
Adjustment of the oat
switch
The oat switch ( 7) is adjusted so that
it can be started up immediately.
In the case of stationary installation, check
regularly (no less then once every three
months) that the oat switch is working.
The ON and OFF switching point of the
oat switch can be adjusted by changing
the position of the oat switch in the oat
switch grating. Please check the following
points before start of operation.
• The oat switch must be attached so
that the switching point ON level and
the switching point OFF level can be
reached easily and with little expendi-
ture of energy. Check this by placing
the pump into a vessel lled with water
and lift the oat switch carefully by
hand and then lower it again. In this
case, you can see whether the pump
switches on and off.
• Also ensure that the separation dis-
tance between the oat switch head
and the oat switch latching mecha-
nism ( 8) is not too small. In the
case of a separation distance which is
too small, trouble-free functioning can-

10
GB
not be guaranteed.
• During the adjustment of the oat
switch, ensure that the oat switch
does not contact the oor before the
pump switches off.
There is a risk of dry running if the
oat switch cable is selected to be
too long
Operational start-up
• Check that the pump is standing
rmly on the bottom of the shaft
or hung up safely.
• Check whether the pressure line
has been attached correctly and
the unused pump outlet is fully
closed.
• Avoid that the pump runs dry.
Regularly check the function
of the oat switch. In case of
non-observance or if the pump
runs dry, guarantee and liability
claims are invalidated.
• Check that the electrical connec-
tion is 230V ~50Hz
• Check the proper status of the
electrical plug socket and make
sure that the plug socket is suf-
ciently fused (at least 6 A, RCD
switch). Insert the pump plug into
the plug socket and the pump is
ready for operation.
• Make sure that moisture or water
never come in contact with the
mains connection. There is a risk
of electrocution.
Cleaning/Maintenance/
Storage
Clean and maintain your equipment regu-
larly. This will guarantee its performance
and long durability.
Ask our service centre to carry out
any work that is not described in
these instructions. Use only original
parts.
This will prevent damage to the
equipment and any resulting per-
sonal injury.
Pull out the power plug before
every maintenance operation. There
is a risk of electrocution or of injury
from moving parts.
General cleaning instructions
• In case of transport for utilization in
different locations, the pump must be
cleaned with clear water after every
use.
• In case of stationary installation, the
function of the oat switch ( 7) is
to be checked regularly (at the latest
every three months).
• With a water jet, remove uff and
brous particles which are possibly
present in the pump casing.
• Regularly remove sludge from the pit
base and also clean the shaft walls.
• Clean precipitation from the oat
switch with clear water.
• In the case of a long period of non-use,
the pump must be thoroughly cleaned
after the last use and before the new
use, since difculties in start-up can
arise due to precipitation and residues.

11
GB
Cleaning the Fan Wheel
In case of soiling or blockage of the impel-
ler, this can be cleaned via the pump outlet
(3) or by removing the oor plate (4):
1. Unscrew the bracket adapter
(10) from the pump outlet
(3).
2. Remove the 3 screws on the bot-
tom of the base (5) and take off
the base plate (4).
3. Clean the fan wheel using clean
water.
4. To re-assemble, reverse this order.
Any measures above and beyond these,
particularly opening the equipment, are
to be carried out by an electrician. In the
case of repairs, always contact our service
centre.
Storage
• Keep the equipment clean, dry and out
of the reach of children.
• Unscrew the bracket adapter ( 10)
for storage.
Waste Disposal/Envi-
ronmental Protection
Be environmentally friendly. Return the
tool, accessories and packaging to a recy-
cling centre when you have nished with
them.
Do not dispose of electrical appli-
ances as unsorted municipal waste,
use separate collection facilities.
Hand over the device at an utilization loca-
tion. The plastic and metal parts employed
can be separated out and thus recycled
use can be implemented. Ask our Service-
Center for details.
Defective units returned to us will be dis-
posed of for free.

12
GB
Guarantee
Dear Customer,
This equipment is provided with a 3-year
guarantee from the date of purchase.
In case of defects, you have statutory rights
against the seller of the product. These
statutory rights are not restricted by our
guarantee presented below.
Terms of Guarantee
The term of the guarantee begins on the
date of purchase. Please retain the original
receipt. This document is required as proof
of purchase.
If a material or manufacturing defect occurs
within three years of the date of purchase
of this product, we will repair or replace –
at our choice – the product for you free of
charge. This guarantee requires the defec-
tive equipment and proof of purchase to be
presented within the three-year period with
a brief written description of what consti-
tutes the defect and when it occurred. If the
defect is covered by our guarantee, you will
receive either the repaired product or a new
product. No new guarantee period begins
on repair or replacement of the product.
Guarantee Period and Statutory
Claims for Defects
The guarantee period is not extended by
the guarantee service. This also applies for
replaced or repaired parts. Any damages
and defects already present at the time of
purchase must be reported immediately af-
ter unpacking. Repairs arising after expiry
of the guarantee period are chargeable.
Guarantee Cover
The equipment has been carefully pro-
duced in accordance with strict quality
guidelines and conscientiously checked
prior to delivery.
The guarantee applies for all material and
manufacturing defects. This guarantee
does not extend to cover product parts that
are subject to normal wear and may there-
fore be considered as wearing parts (e.g.
lters or attachments) or to cover damage
to breakable parts (e.g. switches, batteries,
or parts made of glass).
This guarantee shall be invalid if the prod-
uct has been damaged, used incorrectly or
not maintained. Precise adherence to all of
the instructions specied in the operating
manual is required for proper use of the
product. Intended uses and actions against
which the operating manual advises or
warns must be categorically avoided.
The product is designed only for private
and not commercial use. The guarantee
will be invalidated in case of misuse or
improper handling, use of force, or inter-
ventions not undertaken by our authorised
service branch.
In the case of pumping water contain-
ing sand or aggressive liquids or other
incorrect, non-design-appropriate use, as
well as in case of non-observance of the
operating manual, application of force in
use or inappropriate or insufcient main-
tenance, no guarantee claim exists, since
seals, impeller wheel, motor or other parts
are damaged by this. Also, sewage water
pumps are not suitable for the pumping of
abrasive materials (sand, stone).
Note: submersible pumps are drainage
pumps. This kind of pump is constructed
with the purpose of transporting or remov-
ing a certain volume of water – depending
on its output category – as quickly as pos-
sible. Submersible pumps are not intended
as irrigation (for example, in garden ir-
rigation systems) or as constant water-ow
pumps (such as in articial streams or or-
namental fountains). Inappropriate use will

13
GB
invalidate the warranty.
In particular, the guarantee is likewise void
in the case of employment of the sewage
water pumps without base plate or (this
applies for all pumps) in case of damages
which are caused by supporting on or sus-
pending from the mains cable. The pumps
must not be run dry or exposed to frost.
Processing in Case of Guarantee
To ensure efcient handling of your query,
please follow the directions below:
• Please have the receipt and identica-
tion number (IAN 102797) ready as
proof of purchase for all enquiries.
• Please nd the item number on the rat-
ing plate.
• Should functional errors or other de-
fects occur, please initially contact the
service department specied below by
telephone or by e-mail. You will then
receive further information on the pro-
cessing of your complaint.
• After consultation with our customer
service, a product recorded as defec-
tive can be sent postage paid to the
service address communicated to you,
with the proof of purchase (receipt)
and specication of what constitutes
the defect and when it occurred. In or-
der to avoid acceptance problems and
additional costs, please be sure to use
only the address communicated to you.
Ensure that the consignment is not sent
carriage forward or by bulky goods,
express or other special freight. Please
send the equipment inc. all accessories
supplied at the time of purchase and
ensure adequate, safe transport pack-
aging.
Repair Service
For a charge, repairs not covered by the
guarantee can be carried out by our ser-
vice branch, which will be happy to issue
a cost estimate for you.
We can handle only equipment that has
been sent with adequate packaging and
postage.
Attention: Please send your equipment to
our service branch in clean condition and
with an indication of the defect.
Equipment sent carriage forward or by
bulky goods, express or other special
freight will not be accepted.
We will dispose of your defective devices
free of charge when you send them to us.
Service-Center
Service Great Britain
Tel.: [phone]
(£ 0.10/Min.)
E-Mail: [email protected]
IAN 102797
Importer
Please note that the following address is
not a service address. Please initially con-
tact the service centre specied above.
Grizzly Tools GmbH & Co. KG
Stockstädter Straße 20
63762 Großostheim
Germany
www.grizzly-service.eu
GB

14
GB
Troubleshooting
Faults Causes Remedies
Pump does not start
Mains voltage is not applied Check mains voltage
Float switch ( 7) does not
switch
Bring oat switch into higher
position
Pumps has no dis-
charge
Buckled pressure hose Repair point at which the line
is bent
Trapped air in the pump cas-
ing Tip the pump underwater until the air escapes
Pump does not switch
off Float switch ( 7) cannot
drop
Set up pumps correctly on the
pit base
Flow rate insufcient
Reduces pump performance,
through severely contami-
nated water and additions in
the water which produce a
grinding effect
Clean pumps and replace
wear parts
Pump switches off after
a short period
Motor contactor disconnects
the pumps because of water
pollution that is too severe.
Pull out power plug and clean
the pump as well as shaft
Water temperature too high,
motor contactor breaks Note maximum water tem- perature of 35°C!
Replacement parts/Accessories
Spare parts and accessories can be obtained at
www.grizzly-service.eu
If you do not have internet access, please contact the Service Centre via telephone (see
“Service-Center” Page 13). Please have the order number mentioned below ready.
Item Description Product No.
4 Floor plate 91103470
4a Screw set for oor plate 91103471
9/10 Connector set (reducer, sealing ring, angle adapter) 91103472
11 8 m nylon cord 91103473

SI
15
To napravo lahko uporabljajo otro-
ci, stari 8 let ali več, ter osebe z
omejenimi zičnimi, senzoričnimi
ali mentalnimi sposobnostmi ali
osebe s pomanjkanjem znanja in
izkušenj, če so nadzorovani ali so
bili poučeni o varni uporabi napra-
ve in razumejo morebitne nevarno-
sti. Otroci se z napravo ne smejo
igrati. Otroci ne smejo čistiti ali
vzdrževati naprave brez nadzora.
Predgovor
Čestitke ob nakupu vaše nove naprave.
Odločili ste se za visokokakovosten izde-
lek.
Kakovost naprave je bila preverjena med
postopkom proizvodnje in pri končnem
preverjanju, s čimer je zagotovljeno pravil-
no delovanje vaše naprave. Kljub temu ni
mogoče izključiti, da so v posameznih pri-
merih v napravi oz. v ceveh ostanki vode
ali maziv. To ni napaka ali pomanjkljivost
in ni vzrok za skrb.
Izdelku so priložena navodila za
uporabo. Vsebujejo pomembna
navodila glede varnosti uporabe in
odstranitve. Pred uporabo izdelka
se seznanite z navodili za uporabo
in varnostnimi navodili. Izdelek
uporabljajte zgolj na opisani način
in v naštete namene.
Navodila skrbno shranite in pri
predaji naprave tretji osebi priložite
tudi vso dokumentacijo.
Kazalo
Predgovor..................................15
Namen uporabe ........................16
Splošen opis ..............................16
Obseg dobave.............................16
Funkcijski opis..............................16
Pregled .......................................16
Tehnični podatki.........................16
Podatki o zmogljivosti ...................17
Varnostna navodila ...................17
Simboli v navodilih.......................17
Simboli na napravi .......................17
Splošna varnostna navodila...........17
Pred uporabo.............................19
Postavitev/obešanje......................19
Priklop na električno omrežje .........19
Priključitev cevi.............................19
Preverjanje funkcije plavajočega
stikala.........................................20
Preverjanje pred zagonom.............20
Čiščenje/vzdrževanje/
shranjevanje..............................21
Splošna čistilna opravila ...............21
Čiščenje krilatega kolesa...............21
Shranjevanje................................21
Odstranjevanje/ varstvo okolja .21
Odpravljanje napak...................22
Nadomestni deli/Pribor .............22
Garancijski list ...........................23
Prevod originalne izjave o
skladnosti CE .............................59

SI
16
Funkcijski opis
Črpalka za umazano vodo ima ohišje iz
nerjavečega jekla, stabilno sesalno nogo
in nerjavečo motorno gred. Črpalka ima
plavajoče stikalo, ki glede na višino vode
napravo samodejno vklopi ali izklopi.
Termično zaščitno stikalo ščiti motor pred
preobremenitvijo. Funkcije elementov za
upravljanje so opisane v naslednjih opisih.
Pregled
1 Okrogel ročaj
2 Ohišje črpalke
3 Izhod črpalke
4 Osnovna plošča
5 Podnožje
6 Priključni električni kabel
7 Plavajoče stikalo
8 Držalo plavajočega stikala
9 Reducirni nastavek
10 Kotni adapter
11 8 m najlonska vlečna vrv
Tehnični podatki
Nazivna napetost.............230 V~, 50 Hz
Nazivna moč (Priključna moč) .... 1100 W
Maksimalen pretok (Qmax) ......20000 l/h
Maksimalna dobavna višina (Hmax)... 9 m
Maksimalna potopna globina............ 7 m
Maks. temperatura vode (Tmax)...... 35 °C
Cevni priključek ............... 1“, 1¼ “, 1½ “
Maksimalna velikost zrn ...............35 mm
Preklopna višina za vklop...... ca. 520 mm
Preklopna višina za izklop..... ca. 230 mm
Dolžina priključnega kabla ............. 10 m
Teža (vključno s priborom)........... 6,18 kg
Razred zaščite...................................... I
Stopnja zaščite ................................IPX8
Pridržujemo si pravico do tehničnih in
oblikovnih sprememb, ki so povezane z
Namen uporabe
Črpalka za umazano vodo je namenjena
odvajanju ter izčrpavanju čiste in umazane
vode (maks. velikost delcev 35 mm) s tem-
peraturo do največ 35 °C.
Črpalka je primerna npr. za prečrpavanje
in izčrpavanje bazenov in korit, za izčrpa-
vanje poplavljenih kleti in za odstranjeva-
nje vode iz vodnjakov in jaškov.
Naprava ni primerna za profesionalno
uporabo. Veljavnost garancije preneha,
če napravo uporabljate v profesionalne
namene.
Kakršnakoli druga raba, ki v teh navodilih
ni pisno dovoljena lahko poškoduje na-
pravo in predstavlja resno nevarnost za
uporabnika.
Črpalka ni primerna za trajno obratova-
nje. Trajno obratovanje skrajša življenjsko
dobo in garancijsko dobo.
Uporabnik je odgovoren za nezgode ali
poškodbe drugih ljudi ali njihove lastnine.
Proizvajalec ne jamči za škodo, nastalo
zaradi nenamenske ali napačne uporabe.
Splošen opis
Sliko pomembnih obratovalnih
delov poiščite na zložljivi strani.
Obseg dobave
Orodje vzemite iz embalaže in preverite,
ali je popolno.
Embalažo odstranite v skladu s predpisi.
- Sestavljena črpalka za umazano vodo
- Kotni adapter
- Reducirni nastavek
- 8 m najlonska vlečna vrv
- Navodila za uporabo

SI
17
nadaljnjim razvojem, brez predhodnega
obvestila. Vse mere, navodila in podatki
v teh navodilih za uporabo so zato brez
jamstva. Garancijskih zahtevkov na podlagi
vsebine navodil za uporabo zato ni mogo-
če uveljavljati.
Merjenje maksimalne zmogljivosti je bilo
opravljeno pri ravnem in neposrednem
izhodu. Kotni adapter lahko zmanjša zmo-
gljivost črpalke.
Podatki o zmogljivosti
(l/h)
(m)
Varnostna navodila
Ta poglavje obravnava varnostne predpise
pri delu z napravo.
Simboli v navodilih
Znaki za nevarnost z napotki
za preprečevanje osebne in
materialne škode.
Znaki za navodilo (namesto klicaja
sledi razlaga navodila) z napotki
za preprečevanje škode.
Znaki za napotek z informacijami o
primernem rokovanju z napravo.
Simboli na napravi
Pozor!
Naprave ne uporabljajte za čisto
vodo s peskom!
Pred prvo uporabo se dobro sezna-
nite z vsemi upravljalnimi elementi,
funkcijami in načini delovanja
naprave. Po potrebi prosite strokov-
njaka za razlago.
Preberite in upoštevajte navodila za
uporabo naprave!
Pozor! V primeru, da se priključni
kabel med delom poškoduje ali
prereže, ga nemudoma izvlecite iz
vtičnice.
7 m
Maksimalna potopna globina.
Električne naprave ne spadajo med
gospodinjske odpadke.
Splošna varnostna navodila
Delo z napravo:
Opozorilo: Za preprečevanje ne-
sreč in poškodb:
• Osebe, ki ne poznajo navodil za upo-
rabo, ne smejo uporabljati naprave.
Spodnja starostna meja za uporabnike
je odvisna od lokalnih predpisov.
• Za zaščito pred električnim udarom
nosite ustrezno obutev.
• Naredite vse potrebno, da otrokom
preprečite dostop do delujoče napra-
ve. Nevarnost poškodb!
• Naprave ne uporabljajte v bližini gor-
ljivih tekočin ali plinov. V primeru neu-
poštevanja opozoril obstaja nevarnost

SI
18
požara ali eksplozije.
• Napravo hranite na suhem mestu izven
dosega otrok.
Previdno! Na naslednji način boste
preprečili poškodbe naprave in mo-
rebitne telesne poškodbe:
• Črpanje agresivnih, abrazivnih/z
brusnim efektom (npr. voda, v kateri
je pesek), jedkih, vnetljivih (npr. mo-
torna goriva) ali eksplozivnih tekočin,
slane vode, čistil in živil ni dovoljeno.
Temperatura črpane tekočine ne sme
presegati 35 °C. Neupoštevanje navo-
dil lahko povzroči škodo na napravi in
predstavlja nevarnost za uporabnika.
• Ne delajte s poškodovano, nepopolno
ali brez dovoljenja proizvajalca spre-
menjeno napravo. Pred uporabo naj
strokovnjak preveri, da je zadoščeno
zahtevanim električnim varnostnim
ukrepom.
• Nadzorujte napravo med obrato-
vanjem (predvsem v stanovanjskem
prostoru), da pravočasno prepoznate
samodejni izklop črpalke ali delovanje
na suho. Redno preverjajte delovanje
plavajočih stikal (glejte poglavje „Pred
uporabo“). Ob neupoštevanju navodil
ne prevzemamo odgovornosti in ga-
rancija ne velja.
• Prosimo, da upoštevate, da črpalka ni
primerna za trajno obratovanje (npr.
za stalno cirkulacijo v vrtnih ribnikih).
Redno preverjajte, če naprava deluje
brezhibno.
• Upoštevajte, da v napravo lahko pride
uporabljeno mazivo, ki lahko včasih z
izlitjem povzroči škodo ali onesnaže-
nje. Črpalke ne uporabljajte v vrtnih
ribnikih z dragocenimi rastlinami ali
ribami.
• Naprave nikoli ne prenašajte in ne
pritrjujte tako, da jo držite za kabel ali
tlačni vod.
• Napravo zaščitite pred zmrzaljo in
obratovanjem na suho.
• Uporabljajte le originalni pribor in čr-
palke ne predelujte.
• Preberite napotke v poglavju „Vzdrže-
vanje in čiščenje“ v navodilih za upo-
rabo. Vse ostale ukrepe, zlasti odpira-
nje naprave, mora izvesti električar. V
primeru popravila se obrnite na našo
servisno službo.
Električna varnost:
Opozorilo: Na naslednji način pre-
prečite nesreče in poškodbe zaradi
električnega udara:
• Črpalke ne uporabljajte, če so v vodi
ljudje. Nevarnost zaradi električnega
udara.
• Po postavitvi in med obratovanjem na-
prave mora biti omogočen dostop do
vtiča.
• Pred zagonom vaše nove črpalke naj
strokovnjak preveri:
- ozemljitev, ničenje in zaščitno stikalo
okvarnega toka morajo ustrezati
varnostnim predpisom podjetja za
distribucijo električne energije in de-
lovati brezhibno,
- električne vtične spoje zaščite pred
vlago.
• Pri nevarnosti poplave prestavite vse
vtične spoje na suho, varno mesto.
• Bodite pozorni, da omrežna napetost
ustreza podatkom na tipski ploščici.
• Orodje priključite le na vtičnico z
zaščitno napravo okvarnega toka (di-
ferenčno stikalo) z nazivnim okvarnim
tokom največ 30 mA.
• Pred vsako uporabo preverite, da
naprava, kabel in stikalo niso poško-

SI
19
vlečna vrv okoli obeh navzdol obrnje-
nih nosilcev kablov in jo speljite prek
okroglega ročaja navzgor.
Naprave nikoli ne obešajte za cev.
Pazite, da naprava v nobe-
nem primeru ne bo pritrjena
ali obešena na priključni
kabel. Obstaja nevarnost
električnega udara zaradi
poškodovanega priključnega
kabla.
Pozor: na dnu jaška se lahko nabe-
re umazanija in pesek, kar lahko
poškoduje črpalko. Priporočamo,
da črpalko postavite na opečni
zidak. Pri prenizki vodni gladini se
lahko blato v jašku hitro izsuši in
ovira črpalko pri zagonu.
Priklop na električno
omrežje
Kupljena črpalka je opremljena z vtičem z
zaščitnim kontaktom.
Naprava je namenjena priklopu na vtič-
nico z zaščitnim kontaktom in napetostjo
z zaščitno napravo okvarnega toka (dife-
renčno stikalo) z 230 V ~ 50 Hz.
Priključitev cevi
Namestitev črpalke je lahko
- s togim cevovodom
- ali z gibkim cevovodom.
1 Privijte kotni adapter (10) na
izhod črpalke (3).
2. Potegnite cev preko reducirnega
nastavka (9) in jo pritrdite s cev-
no objemko.
Ali privijte kotni adapter (10) oz.
Reducirni nastavek (9).
dovani. Poškodovanih kablov ni dovo-
ljeno popravljati, ampak jih je treba
zamenjati. Škodo na vaši napravi naj
popravi pooblaščen strokovnjak.
• Če se poškoduje priključni kabel tega
orodja, naj ga zaradi varnostnih ra-
zlogov zamenja proizvajalec, njegova
servisna služba ali podobno ustrezno
usposobljen strokovnjak.
• Ne vlecite za kabel, da bi izvlekli vtič
iz vtičnice. Kabla ne izpostavljajte vro-
čini, olju ali ostrim robovom.
• Naprave nikoli ne prenašajte in ne pri-
trjujte tako, da jo držite za kabel.
• Uporabljajte le podaljške kablov, na-
menjene delu na prostem in zaščitene
pred škropljenjem vode. Pred uporabo
naprave vedno povsem odvijte kabel-
ski boben. Preverite, ali je kabel brez-
hiben.
• Pred vsemi deli na napravi, v primeru
netesnosti v vodnem sistemu, med
delovnimi odmori in ko naprave ne
uporabljate, izvlecite kabel iz vtičnice.
• Prerez električnega kabla ne sme biti
manjši od prereza gumijastih kablov z
oznako H07RN8-F. Priključni kabel mora
biti dolg 10 m. Presek električnega po-
daljška mora znašati najmanj 2,5 mm2.
Pred uporabo
Postavitev/obešanje
• Jašek črpalke mora meriti vsaj
40x40x50cm, da se lahko plavajo-
če stikalo (7) prosto premika.
• Napravo lahko obesite na okrogli
ročaj ( 1) ali postavite na dno
jaška.
Za obešenje in/ali izvlečenje črpalke
lahko uporabite najlonska vlečna vrv
(11), ki je v obsegu dobave.
Za varno namestitev ovijte najlonska

SI
20
Izhod z notranjim navojem dim. 1½«
na črpalki za namestitev kotnega adap-
terja (10) ali za neposredno priključitev
cevi z zunanjim navojem dim. 1½«.
Izhod z zunanjim navojem dimenzije
1½ “ na kotnem adapterju (10) za pri-
ključitev reducirnega nastavka (9) ali
vijačne zveze dimenzije 1½ “.
Izhod z reducirnim nastavkom (9) za
priključitev cevi dim. 1¼« ali 1½« s
pritrdilnim spojem (pritrditev s cevno
spojko).
Izhod z zunanjim navojem dimenzije
1“ na reducirnem nastavku (9) za pri-
ključitev vijačne zveze dimenzije 1“.
Izhod dimenzije 1“ na reducirnem na-
stavku (9) za priključitev cevi dimenzije
1“ s spojko (pritrditev s cevno spojko).
Bodite pozorni, da lahko velikost
delcev pri uporabi reducirnega na-
stavka (Ø 19,3 mm) znaša največ
19 mm, saj se lahko sicer reducirni
nastavek in cev zamašita.
Preverjanje funkcije
plavajočega stikala
Plavajoče stikalo ( 7) je nastavljeno
tako, da je napravo možno takoj zagnati.
Pri stacionarni instalaciji je treba funkcijo
plavajočega stikala redno preverjati (naj-
manj vsake tri mesece).
Točki vklopa in izklopa se da nastaviti s
spremembo položaja plavajočega stikala v
njegovem držalu ( 8).
• Položaj plavajočega stikala mora biti
tak, da lahko enostavno in brez sile
doseže višini za vklop in izklop. To
preverite tako, da črpalko postavite v
posodo, napolnjeno z vodo, in plava-
joče stikalo ročno pazljivo dvignete in
nato ponovno potopite. Pri tem lahko
vidite, ali se črpalka vklopi oziroma
izklopi.
• Pazite, da ni razmak med glavo pla-
vajočega stikala in njegovim držalom
premajhen. Pri premajhnem razmaku
brezhibno delovanje ni zagotovljeno.
• Pri nastavljanju pazite, da se plava-
joče stikalo ne dotakne dna še pred
izklopom črpalke.
Obstaja nevarnost delovanja na
suho, če izberete predolg kabel
plavajočega stikala.
Preverjanje pred zagonom
• Preverite, če črpalka stoji trdno
na tleh jaška ali če je varno obe-
šena.
• Preverite, če je tlačni vod pravil-
no pritrjen in če je neuporabljen
izhod črpalke trdno zaprt.
• Izogibajte se delovanju črpal-
ke na suho (pravilno nastavite
plavajoče stikalo). Ob neupošte-
vanju navodil ali delovanju na
suho ne prevzemamo odgovor-
nosti in pravica do uveljavljanja
garancije ugasne.
• Prepričajte se, da znaša na-
petost električnega omrežja
230 V ~ 50 Hz.
• Preverite stanje vtičnice in ali je
zadostno zavarovana (najmanj
6A-varovalka, (diferenčno stika-
lo).
• Poskrbite, da omrežni priključek
ne more priti v stik z vlago ali
vodo. Obstaja nevarnost električ-
nega udara.
