FMS EMGZ310 User manual

Operating Instructions
EMGZ310
Compact digital measuring amplifier
EMGZ310.ComACT
Digital Tension Measuring Amplifier with Optional Operation
via FMS-comACT App
Document version 2.32 10/2020 NS
Firmware EMGZ310 V 1.14
Firmware EMGZ310.ComACT V2.10
EMGZ310 EMGZ310.ComACT
Diese Bedienungsanleitung ist auch in Deutsch erhältlich.
Bitte kontaktieren Sie Ihre lokale FMS Vertretung.
© by FMS Force Measuring Systems AG, CH-8154 Oberglatt – All rights reserved.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 2
1Table of Contents
1TABLE OF CONTENTS ............................................................................................................................. 2
2SAFETY INFORMATION ........................................................................................................................... 3
2.1 Presentation of Safety Information..................................................................................................... 3
2.1.1 Danger that Could Result in Minor or Moderate Injuries ............................................................... 3
2.1.2 Note Regarding Proper Function ................................................................................................... 3
2.2 General Safety Information ................................................................................................................ 4
2.3 Regulatory Notices............................................................................................................................. 4
2.4 Notes Réglementaires........................................................................................................................ 6
3PRODUCT DESCRIPTION ........................................................................................................................ 7
3.1 Block Diagram.................................................................................................................................... 7
3.2 Product Description............................................................................................................................ 7
3.3 Scope of Delivery ............................................................................................................................... 7
4QUICK GUIDE/QUICK START .................................................................................................................. 8
4.1 Preparations for Parameterization ..................................................................................................... 8
4.2 Mounting Sequence ........................................................................................................................... 8
4.3 Installation and Electrical Connections .............................................................................................. 8
4.4 Force sensor installation .................................................................................................................... 9
4.5 Electrical Connections........................................................................................................................ 9
5OPERATION AND CONFIGURATION .................................................................................................... 11
5.1 Power up the EMGZ 310.................................................................................................................. 11
5.2 Operating panel and controls........................................................................................................... 11
6CALIBRATION OF THE MEASURING SYSTEM.................................................................................... 13
6.1 Offset Compensation ....................................................................................................................... 13
6.2 Calibration (Adjusting the Gain Factor)............................................................................................ 13
6.2.1 Calibrating in force mode............................................................................................................. 14
6.2.2 Calibrating in voltage mode ......................................................................................................... 14
7PARAMETER LIST .................................................................................................................................. 16
8FMS COMACT APPTM.............................................................................................................................. 19
8.1 Configuration via the App................................................................................................................. 19
8.2 Data recording.................................................................................................................................. 21
9DIMENSIONS ........................................................................................................................................... 23
10 TECHNICAL DATA .................................................................................................................................. 24

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 3
2Safety Information
All safety information, operating and installation regulations listed here ensure proper
function of the device. Safe operation of the systems requires compliance at all times.
Noncompliance with the safety information or using the device outside of the specified
performance data can endanger the safety and health of persons.
Work with respect to operation, maintenance, retrofit, repair, or setting the device
described here must only be performed by expert personnel.
2.1 Presentation of Safety Information
2.1.1 Danger that Could Result in Minor or Moderate Injuries
Danger, warning, caution
Type of danger and its source
Possible consequences of nonobservance
Measure for danger prevention
2.1.2 Note Regarding Proper Function
Note
Note regarding proper operation
Simplification of operation
Ensuring function

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 4
2.2 General Safety Information
The function of the measuring amplifier is only ensured with the
components in the specified layout to one another. Otherwise, severe
malfunctions may occur. Thus, observe the mounting information on
the following pages.
Observe the local installation regulations.
Improper handling of the electronics module can lead to damage to
the sensitive electronics!
Do not work with a blunt tool (screw driver, pliers, etc.) on the
housing!
Use suitable grounding (grounding wrist strap, etc.) when working on
the electronics.
The devices should have a distance of at least 15 mm to one another
in the control cabinet for proper cooling.
2.3 Regulatory Notices
NOTE:
This device complies with Part 15 of the FCC Rules and with Industry Canada licence-
exempt RSS standard(s).
Operation is subject to the following two conditions:
-this device may not cause harmful interference, and
-this device must accept any interference received, including interference that may
cause undesired operation.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 5
Figure 1: FCC Labeling on device FCC_Label_EMGZ310ComACT..ai
NOTE:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.+
NOTE:
Changes or modifications made to this equipment not expressly approved by FMS Force
Measuring Systems AG may void the FCC authorization to operate this equipment.
Radiofrequency radiation exposure Information:
This equipment complies with FCC and IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance of [50] cm between the radiator and your body.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 6
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2.4 Notes Réglementaires
NOTE:
Cet équipement est conforme à la section 15 du règlement de la Commission fédérale
américaine des communications (FCC) et au(x) Cahier(s) des charges sur les normes
radioélectriques (CNR) d’Industrie Canada exemptes de licence.
Son utilisation est soumise aux deux conditions ci-dessous :
-cet équipement ne peut pas causer d’interférences nuisibles, et
-cet équipement doit accepter toutes les interférences, y compris celles qui
pourraient provoquer un fonctionnement indésirable.
NOTE:
Cet équipement a été testé et déclaré conforme aux limites applicables aux appareils
numériques de classe A, selon la section 15 du règlement FCC. Ces limites visent à
garantir une protection raisonnable contre les interférences nuisibles lorsque
l’équipement est utilisé dans un environnement commercial.
Cet équipement produit, utilise et peut émettre une énergie de fréquence radio et, s’il
n’est pas installé ni utilisé conformément au manuel d’instruction, il peut générer des
interférences affectant les communications radio. L’utilisation de cet équipement dans
une zone résidentielle peut causer des interférences nuisibles, auquel cas l’utilisateur
sera tenu d’y remédier à ses frais.
NOTE:
Des changements ou modifications apportés à cet équipement sans l’autorisation
expresse de FMS Force Measuring Systems AG peuvent invalider l’agrément d’utilisation
de cet équipement accordé par la FCC.
Informations sur l’exposition aux rayonnements radioélectriques
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies
pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un
minimum de
[50] cm de distance entre la source de rayonnement et votre corps.
Ce transmetteur ne doit pas etre place au meme endroit ou utilise simultanement avec
un autre transmetteur ou antenne. “

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 7
3Product Description
3.1 Block Diagram
Figure 2: block diagram EMGZ310 EMGZ310_BA_Manual.ai
3.2 Product Description
The digital tension measuring amplifier EMGZ310.ComACT is suitable for tension
measurement with all FMS force sensors. This versatile product includes the latest
technology and can substitute for all single channel amplifiers (1 measuring point, 1 or
2 force sensors). Amplifier configuration is straightforward with the parameters being
set using either three easily accessible keys or your smartphone/tablet. The free FMS-
ComACT app is available for download for IOS and Android devices, and makes
parameter setting and value reading as efficient and comfortable as never before.
3.3 Scope of Delivery
The following is included in the scope of delivery
-Measuring amplifier
The following is not included in the scope of delivery
-AC/DC power supply, minimum requirement: EMC immunity specifications
EN61000-4-2, 3, 4, 5; EN55024 light industry level, criteria A, e.g., TRAKO TXL 035-
0524D
-Cable for power supply
The following is not included in the scope of delivery, but are available as accessories
from FMS
-Sensor cable for the connection of force sensor and measuring amplifier

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 8
4Quick Guide/Quick Start
In these operating instructions, commissioning of the measuring amplifier is limited to
the description of the installation procedure, offset compensation, and system
calibration.
4.1 Preparations for Parameterization
-Read the operating instructions of the selected force sensor carefully.
-Check your requirements on the system, such as:
oUsed units in the system
oUsed outputs (current or power)
-Filter settings for actual force value and analog output
-Create the connection diagram for your specific system layout (see chapter
“Electrical Connection”)
4.2 Mounting Sequence
-Mount the force sensors (mounting details can be obtained from the mounting
instructions of the force sensors)
-Connect the force sensors to the amplifier
-Connect the amplifier to the supply voltage. The voltage supply must be in the range
of 18 to 36 VDC
-Perform offset compensation and calibration
-Change the parameter settings as needed
4.3 Installation and Electrical Connections
Warning
To improve natural convection and keep heating of the amplifiers as
low as possible, the devices installed in a cabinet should have a
minimum distance of 15 mm.
Warning
The function of the measuring amplifier is only ensured with the
components in the specified layout to one another. Otherwise,
severe malfunctions may occur. Thus, the mounting information on
the following pages must be followed
Warning
The local installation regulations ensure the safety of electrical
systems. They are not considered in these operating instructions.
However, they must be met.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 9
4.4 Force sensor installation
The force sensors are mounted in line with the mounting instructions of the respective
products. The mounting instructions are included with the force sensors.
4.5 Electrical Connections
One or two force sensors can be connected to the amplifier. When two sensors are used,
they are connected in parallel internally. The force sensors and amplifier are connected
using a 2 x 2 x 0.25 mm2[AWG 23] shielded, twisted cable.
Figure 3: electrical connections EMGZ310_BA_Manual.ai

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 10
For easy installation, the terminal blocks can be removed from the main body
Figure 4: Detachable terminal blocks: use a small slotted screwdriver as a lever
Warning
Poor grounding can result in electric shocks for persons,
malfunctions of the overall system or damage to the measuring
amplifier! Proper grounding must always be ensured.
Note
Cable shielding may only be connected to one side of the measuring
amplifier. On the side of the force sensor, shielding must remain
open.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 11
5Operation and configuration
5.1 Power up the EMGZ 310
-Connect the first force sensor
-Check whether applying a force in measuring direction (in the direction of the red
point) on the first sensor results in a positive output signal. If not, swap the two
signal wires of this force sensor
-If applicable, connect the second force sensor. Check whether applying a force in
measuring direction on the second sensor results in a positive output signal. If not,
swap the two signal lines of this force sensor.
5.2 Operating panel and controls
Figure 5: front view EMGZ310_BA_Manual.ai

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 12
Controls
Button Description
Change the selections, increase / decrease the values or choose
Scroll up or down the parameter lists
Enter
>0< + PARA > 3 Sec.
Start Offset compensation precedure
CAL + PARA > 3 Sec.
Start calibration procedure
PARA > 3 Sec.
Parameter setting
Table 1: controls

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 13
6Calibration of the Measuring System
6.1 Offset Compensation
Using offset compensation, the weight of the measuring roller is compensated and the
measuring system “zeroed”.
Offset compensation must always be executed prior to the actual calibration. The
measuring roller must not be loaded during the procedure.
-Press and hold the two buttons + (>0< + PARA) at the same time for
longer than 3 seconds. The value for offset compensation is calculated automatically
and stored in the amplifier.
6.2 Calibration (Adjusting the Gain Factor)
Calibration is used for matching the gain factor with the force sensors. After calibration,
the displayed force corresponds the effective material tension of the web / filament.
Two calibration methods are possible. The first calibration method described here uses
a defined weight. There is also a calculation method for the gain factor. The weight-
based calibration method is simple and delivers more accurate results as it replicates
the material profile (see the figure below) and considers the actual circumstances in the
machine.
Figure 6: Simulation of the material profile using a defined weight
Tension_Control_Solutions.ai

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 14
6.2.1 Calibrating in force mode
Note
If there is no input during 30 sec. while you perform the calibration
procedure, the display will automatically switch back to the initial
screen without saving the previous inputs.
-Insert a rope into the machine. Simulate the exact web path in the machine.
-Load the rope with a defined weight
-Press and hold the two buttons + (CAL + PARA) at the same time for
longer than 3 seconds.
-Enter the system force (Sys_F). The system force is made up of the nominal force of
the connected force sensors. If e.g. two force sensors with a nominal force of 500 N
each are connected, the system force is 2 x 500 N = 1000 N. The nominal force of
FMS force sensors is indicated on the type label.
-You can modify the value with .
-Save the changes with
-Enter the weight (GAIN) connected to the rope. Pay attention to the selected unit. 10
kg would require an input of 100 N if the system is set to N.
-You can modify the value with .
-Save the changes with
-The parameter F@mOut set the value of the indicated tension with maxium output
(10 VDC or 20 mA) on the display of the amplifier.
-You can modify the value with .
-Save the changes with
-The display will return to the main screen
-The calibration procedure is complete
6.2.2 Calibrating in voltage mode
Note
If there is no input during 30 sec. while you perform the calibration
procedure, the display will automatically switch back to the initial
screen without saving the previous inputs.
-Insert a rope into the machine. Simulate the exact web path in the machine.
-Load the rope with a defined weight
-Press and hold the two buttons + (CAL + PARA) at the same time for
longer than 3 seconds.
-Enter the weight (GAIN) connected to the rope. Pay attention as the unit is set to volt.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 15
-Modify the value with until the voltage output correlates with the weight.
-Save the changes with
-The display will return to the main screen
-The calibration procedure is complete

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 16
7Parameter list
Parameter
Name Description
Output This parameter determines the current output signal of
the amplifier. The voltage output (± 10 V) is also available
in parallel
Selection 0 to 20 mA; 4 to 20 mA
Default 4 to 20 mA
Filter The amplifier provides a low
-
pass filter to prevent noise
overlaying the output signal. The parameter Filter stores
the cut off frequency of the filter. The lower the cut off
frequency, the more sluggish will the output as well as
the display be. The filter stabilizes the output signal in
case of highly fluctuating tension values. A correctly
tuned filter will "straighten" the displayed value.
Unit Hz
Min. 0,1
Max. 999,9
Default 10,0
Unit This parameter determines the unit used in the system.
The label on the force sensor shows always the nominal
force in N.
NOTE: By changing the unit to lb (pounds) the entire
system will change from metric to imperial units.
NOTE: If the system is set to voltage mode [VoltGauge],
this parameter is disabled
Selection N; kN; lb; g; kg
Default N

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 17
Sys_F The system force indicates which measuring force
capacity is installed in the measuring roller. E.g., if two
500 N force sensors are installed in the roller, 1‘000 N
must be entered. In the case of a one-sided
measurement, hence is one 500 N force sensor is used,
500 N must be entered. If force measuring rollers with
pulleys are used (e.g., RMGZ series), the nominal force of
the force measuring roller must be specified (in the
example 500 N as well)
NOTE: For force values larger than the available 9’999
please change the unit. E.g. for a system force of
12’000N change the unit to kN and enter 12kN as
system force.
NOTE: If the system is set to voltage mode [VoltGauge],
this parameter is disabled
Unit N; kN; lb; g; kg (selected in "unit")
Min. 1
Max. 9999
Default 1000
F@mOut This parameter determines the tension value (N, kN, lb, g,
kg) that is indicated at the maximum output of the
amplifier (10 V or 20mA).
NOTE: If lb (pound) is selected, the system switches from
metric to imperial measuring units.
Selection N; kN; lb; g; kg (selected in "unit"
Min. 1
Max. 100000
Default 1000
Offset The values determined with the “Offset Compensation”
procedure are stored in the form of a digital value in this
parameter. The value is used for compensating for the
roller weight.
Min. -9999
Max. 9999
Default 0
Gain The values determined with the “Calibration” procedure
are stored in the form of a digital value in this parameter.
Min. 0.001
Max. 20.000
Specified value 1.000

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 18
Mode The Device Mode determines the functionality of the
amplifier. If set to Volt Gauge, force values will be
displayed only in Volt (V) or mA. Force units will not be
available anymore.
Selection kgkNN; V
Default kgkNN

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 19
8FMS ComACT AppTM
If you have purchased an EMGZ310.ComACT measuring amplifier you are able to
display actual readings and configure the amplifier via the FMS-ComACT app.
You can identify the type of amp on the type label. The EMGZ310.ComACT has also the
last 4 digits of its serial number printed on the front housing.
Figure 7: EMGZ310.ComACT with serial number EMGZ310_Typenschild.jpg
Only a single mobile device at a time can connect to an amplifier.
As soon as the connection between amp and mobile device is setup, the display of the
amp will start flashing.
The FMS-ComACT app is meant as an operation aid to display actual readings and to
help configure the amplifier. The settings are only stored in the amplifier and not in the
mobile device.
8.1 Configuration via the App
The procedures of offset compensation and calibration are always identical to an
amplifier without Bluetooth connectivity. Instead of using the operating panel of the
amplifier, you can use here any mobile device for input and configuration.

Operating Instruction EMGZ310, EMGZ310.ComACT
21.10.2020 20
Download FMS
ComACTTM app
Google Play
Store (Android);
iTunes (IOS)
Overview with all
amplifiers within
the transmitting
range.
Display of actual
readings with the
selected settings
(unit, gain, output,
etc.)
Input signal from
force sensors
Start record
“Configure”
requires a
password.
The password is
preset to “3231”
and it cannot be
modified.
„Calibration“ leads
you to the offset
and gain menu.
Button for the
export of the
parameter
settings
You can perform
an offset without
any further input.
Make sure that
there is no web
applied to the
roller.
Successful input
and operations
are confirmed
Before you
perform the
calibration, you
have to enter the
value for the
corresponding
force that you
have applied to
the measuring
roller.
Table 2: Screenshots App (Android) - configuration
Export of parameter settings
The export will create a .txt file that you can send via any channel or
store as required.
This can be of help to document the settings.
