Freescale Semiconductor Motorola MMDS0508 User manual

MMDS0508OM/D
MMDS
MODULAR DEVELOPMENT SYSTEM
for 68HC05 and 68HC08
MICROCONTROLLERS
OPERATIONS MANUAL
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MMDS0508OM/D
MOTOROLA 3
MMDS0508
Motorola Modular Development System
Operations Manual
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MMDS0508OM/D
4 MOTOROLA
Motorola reserves the right to make changes without further notice to any products herein to
improve reliability, function, or design. Motorola does not assume any liability arising out of the
application or use of any product or circuit described herein; neither does it convey any license
under its patent rights nor the rights of others. Motorola products are not designed, intended, or
authorizedforuseascomponentsinsystemsintendedforsurgicalimplantintothebody,orother
application in which the failure of the Motorola product could create a situation where personal
injury or death may occur. Should Buyer purchase or use Motorola products for any such
unintended or unauthorized application, Buyer shall indemnify and hold Motorola and its officers,
employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages,
and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of
personalinjuryordeathassociatedwithsuchunintendedorunauthorizeduse,evenifsuchclaim
alleges that Motorola was negligent regarding the design or manufacture of the part.
Motorola and the Motorola logo are registered trademarks of Motorola Inc.
Motorola Inc. is an Equal Opportunity/Affirmative Action Employer
MS-DOS is a registered trademark of Microsoft Corporation. IBM is a registered trademark of
IBM Corporation.
MMEVS05 software is P & E Microcomputer Systems, Inc.*, 1995; All Rights Reserved.
Portions of the software are Borland International, 1987. Portions of the software are 
TurboPower Software, 1988.
_______
* P & E Microcomputer Systems, Inc.
P.O. Box 2044
Woburn, MA 01888-2044
[phone]
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Revision History
MMDS0508OM/D
MOTOROLA 5
Revision History
This table summarizes differences between this revision and the
previous revision of this emulation module user’s manual.
Previous
Revision None
Current
Revision Original release
Date 08/96
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Revision History
MMDS0508OM/D
6 MOTOROLA
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MMDS0508OM/D
MOTOROLA Table of Contents 7
Table of Contents
General
Description Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
System Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Host Computer Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Acronyms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Installation Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Configuring the Platform Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Factory Test Header (J1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Port Voltage Control Headers (J2–J4) . . . . . . . . . . . . . . . . . . . . . .24
Installing the EM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Removing the EM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Making System Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Host Computer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Bus State Analyzer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Target Cable Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Reset Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Serial Connector and Cable Information . . . . . . . . . . . . . . . . . . . . . . .28
Serial RS232 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Logic Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Power Supply Fuse Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Table of Contents
MMDS0508OM/D
8 Table of Contents MOTOROLA
Loading and
Initialization Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Software Distribution Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Installing MMDS Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Personality Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Using MMDS Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Running MMDS05 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Running MMDS08 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
MMDS Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
User Screens Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Main Window Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Status Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
CPU Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Source/Code F2 Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Code F2 Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Source Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Variables F8 Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Memory F3 Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Debug F10 Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Pop-Up Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Stack Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Set Memory Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Baud Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Emulator Clock Frequency Window . . . . . . . . . . . . . . . . . . . . . . . .54
Other Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Mouse Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Changing Screen Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Operation
Fundamentals Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
System Initialization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Setting CommunicationsBaud Rate . . . . . . . . . . . . . . . . . . . . . . . .61
Standard Memory Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Table of Contents
MMDS0508OM/D
MOTOROLA Table of Contents 9
Custom Memory Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Initializing the Clock Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Loading User Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Initializing Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Initializing Assembly Language . . . . . . . . . . . . . . . . . . . . . . . . .64
Initializing Memory Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
System Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Script Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Information Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Log File Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Debug Screen Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Exit the Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Debug Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Setting CPU Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Memory Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Reset Control of the Emulation System . . . . . . . . . . . . . . . . . . . . .72
Using Breakpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Tracing Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Execution Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Bus State Analyzer Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Configuring the Analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Capturing Analyzer Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Viewing Analyzer Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Bus State Analysis Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Operating the Bus Analyzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Defining Events (Terms) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Selecting the Trigger Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Selecting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Collecting Bus Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Viewing Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Searching the Trace Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Using the Time-Tag Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Table of Contents
MMDS0508OM/D
10 Table of Contents MOTOROLA
Command-Line
Commands Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Command Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Command Explanations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
S-Record
Information Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199
S-Record Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200
S-Record Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
S-Record Creation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202
S-Record Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202
Index Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MMDS0508OM/D
MOTOROLA General Description 11
General Description
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
System Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Host Computer Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Acronyms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Introduction
The M68MMDS05/08 Motorola Modular Development System (MMDS)
is a tool for developing embedded systems based on an MC68HC05 or
MC68HC08 microcontroller unit (MCU). The MMDS is a modular
emulation system that, when connected to a user’s target system, gives
the user interactive control of a microcontroller application.
The RAPID software provides an integrated development environment
and includes an editor, assembler, and a user interface to the MMDS
system. The environment allows for source-level debugging and
simplifies writing and debugging code for an embedded MCU system.
These features significantly reduce development time.
A complete MMDS system contains the station module
(M68MMDS0508), an emulation module (EM), and a target cable
assembly. An EM completes MMDS functionality for a particular MCU or
MCU family. To accommodate emulation of the numerous MCUs
available, the MMDS uses a variety of different EMs. Refer to Motorola’s
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
MMDS0508OM/D
12 General Description MOTOROLA
Development Tool Selector Guide , order number SG173/D, for a
complete list of available emulator modules and the appropriate user's
manual for EM installation instructions. For connection to a target
system, a separately purchased target cable with the appropriate target
head also is needed.
To use the MMDS, an IBM (or compatible) host computer is needed. A
9-pin RS-232 serial cable also is provided with the MMDS.
About this Manual
This manual covers MMDS software, hardware, and reference
information as follows:
•Installation on page 19 explains M68MMDS0508 hardware.
•Loading and Initialization on page 35 explains how to load and
initialize the MMDS system software.
•User Screens on page 41 explains the window screens, as well
as how to use a mouse.
•Operation Fundamentals on page 59 describes command
usages.
•Bus State Analysis on page 77 details the built-in state analyzer
features.
•Command-Line Commands on page 99 explains MMDS
command syntax.
•S-Record Information on page 199 gives reference information
about Motorola S-records.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
System Features
MMDS0508OM/D
MOTOROLA General Description 13
System Features
The MMDS is a full-featured development system that provides in-circuit
emulation. Its features include:
• Real-time, non-intrusive, in-circuit emulation
• Real-time bus state analysis
• MC68HC11K1 system controller for fast command transfer
• Meets ECC92 European electromagnetic compatibility standards
• Fourcomplex databreakpoints; adatabreakpointcan be qualified
by an address, an address range, data, or externally connected
logic clips.
• 32 variables or real-time variables, plus a 32-byte block of
real-time memory, mappable anywhere within a 1 Kbyte window
over the 64-K HC05/HC08 memory map.
• 64 Kbytes of emulation memory to accommodate the largest
available ROM size of current HC05/HC08 MCUs.
• 64 hardware instruction breakpoints over the 64-K memory map
• A DOS personality file for each EM. Each personality file provides
a memory-map definition.
• 64K bytes of emulation memory, to accommodate the largest
available ROM size of current HC05/HC8 MCUs.
• Latch-up resistant design (47-Ωseries resistor on I/O connections
to the target system) to make power-up sequencing unimportant.
• Built-in bus state analyzer:
– 8K x 64 real-time trace buffer
– Four hardware triggers for controlling real-time bus analysis
and to provide breakpoints
– Nine triggering modes
– Display of real-time trace data as raw data, disassembled
instructions, raw data and disassembled instructions, or
assembly-language source code
– As many as 8190 pre- or post-trigger points
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
MMDS0508OM/D
14 General Description MOTOROLA
– Trace buffer can be filled while single-stepping through user
software
– 16-bit time tag, or an optional 24-bit time tag that sacrifices
eight logic clips
– Eight software selections for the time tag clock source,
permitting wide time variance between analyzer events
– 16 general-purpose logic clips, five of which can be used to
trigger the bus state analyzer sequencer
• Four software-selectable internally generated oscillator clock
sources
• Built-in power supply with 85 to 264 VAC input
• Command and response logging to disk files
• SCRIPT command for automatic execution of a sequence of
MMDS commands
• Assembly-language source-level debugging
• RS-232 operation speeds as high as 57600 baud
• On-screen,context-sensitivehelpvia pop-up menus and windows
• CHIPINFO command for memory-map, vectors, register, and
pin-out information pertaining to the device being emulated
• Emulation that allows multiple types of reset:
– RESET command resets target
– RESETGO command resets target and begins execution
– WAIT4RESET command resets target via target hardware
assertion of the RESET signal
• Mouse or keyboard control of host software
• Status line that displays such information as emulator state,
communications port, and communications rate
• Compact size: 15.38 inches (390.6 mm) deep, 10.19 inches
(258.83 mm) wide, and 2.75 inches (69.85 mm) high. The station
module weighs 6.0 pounds (2.72 kg).
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
System Components
MMDS0508OM/D
MOTOROLA General Description 15
Connections, configuration, and other related information is explained in
the installation section of this document. For similar information with
regard to EMs, see the corresponding EM user's manual.
System Components
The following items are included with the MMDS:
•Station module: the MMDS enclosure, containing the platform
board and the internal power supply. The sliding panel in the
enclosure top lets you insert an EM easily.
•9-pin RS-232 serial cable: The cable that connects the station
module to the host computer RS-232 port.
•Serial adapter: DB9M to DB25F RS-232 adapter for connecting
to a 25-pin serial port on a host system.
•System software: RAPID integrated development environment
featuring editor, assembler, and assembly source level debugger
(3.5-inch diskettes)
•RAPID documentation: A
RAPID Integrated Development
Environment User’s Manual
•MMDS documentation: An MMDS0508 Operations Manual
(MMDS0508OM/D – this manual).
• Software Release Guide: Documentation on the current release
of system software.
•Two logic clip cable assemblies: twisted-pair cables that
connect the station module to your target system, a test fixture, a
clock, an oscillator, or any other circuitry useful for evaluation or
analysis. One end of each cable assembly has a molded
connector, which fits into pod A or pod B of the station module.
Leads at the other end of each cable terminate in female probe
tips. Ball clips come with the cables.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
MMDS0508OM/D
16 General Description MOTOROLA
Separately purchased Motorola personality products include:
•An emulation module (EM): One of many printed circuit boards
that complete MMDS functionality for one or more particular
MCUs. The two DIN connectors on the bottom of the EM fit into
connectors on the top of the MMDS0508 platform board for power
and signal connections. The EM also has a connector for the
target cable. EMs are purchased separately from the platform
board and are shipped with a user’s manual containing
information specific to the module.
•Optional target cable: A separately purchased target cable that
is part of a cable assembly, used to connect the target system to
the MMDS system
•Optional target head adapter: A separately purchased target
head adapter that is part of a cable assembly, used to connect the
target system to the MMDS system
User supplied components include:
•Host computer: For further information refer to Host Computer
Requirements
Host Computer Requirements
The host computer for the MMDS must be hardware and software
compatiblewithIBMAT or PS/2 computers. The host computer must run
DOS 5.0 or later versions. The host software requires approximately
512 Kbytes.
An asynchronous communications port, configured as COM1, COM2,
COM3, or COM4, is required for communications between the MMDS
and the host computer.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
Acronyms
MMDS0508OM/D
MOTOROLA General Description 17
For improved product performance, additional system enhancements
can be added. These are: 80386- or 80486-based systems, a hard disk
drive, and a high-resolution color monitor with either an EGA or VGA
graphics adapter card. The MMDS system software also supports a
Microsoft, Logitech, or IBM mouse. Other mice may be compatible, but
Motorola does not guarantee their satisfactory performance with MMDS
software.
Acronyms
Table 1 provides definitions for the acronyms used throughout this
manual.
Table 1. Acronym Definitions
Term Description
M68MMDS0508 The station module where common hardware for all M68HC05
and M68HC08 emulation resides.
EM An emulation module that connects to the platform board to
customize the MMDS for a particular MCU or family of
MCUs.
RAPID An integrated development environment that includes an editor
and allows applications such as assemblers and debuggers
to be blended into a single environment.
MMDS Motorola Modular Evaluation System. A generic term that
describes a two-board evaluation system consisting of the
platform board, one of many emulation modules, and system
software (RAPID integrated development environment,
CASM assembler and MMDS debugger).
CASM Cross assembler that assembles M68HC05 (CASM05) or
M68HC08 (CASM08) code.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

General Description
MMDS0508OM/D
18 General Description MOTOROLA
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MMDS0508OM/D
MOTOROLA Installation 19
Installation
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Configuring the Platform Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Factory Test Header (J1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Port Voltage Control Headers (J2–J4) . . . . . . . . . . . . . . . . . . . . . .24
Installing the EM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Removing the EM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Making System Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Host Computer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Bus State Analyzer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Target Cable Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Reset Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Serial Connector and Cable Information . . . . . . . . . . . . . . . . . . . . . . .28
Serial RS232 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Logic Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Power Supply Fuse Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Installation
MMDS0508OM/D
20 Installation MOTOROLA
Introduction
Complete MMDS installation consists of configuring the platform board,
configuring and installing the appropriate emulation module (EM), and
making system cable connections. Consult the system components
section on page 9 for a list of all the system parts, including a separately
purchased EM. Note that EM configuration is specific to a particular EM;
follow the guidance of the specific EM user's manual. Follow the
guidance given in this section to complete the MMDS installation.
Figure 1 shows the right side of the MMDS station module, with the
access panel open. The recessed reset switch and power LED are on
the front of the station module. The logic cable A and B connectors (pod
A and pod B) are on the right (as you face the station module). When
using the logic clip cables, always attach the black clip to ground.
Figure 2 shows the left side of the station module, with the access panel
closed. The power cord socket, the power switch, and the 9-pin RS-232
serial connector are on the left as you face the station module. The
circular +5 V out connector, also on the left side of the station module,
is reserved for future features. A spacer covers the final enclosure
cutout, for a future conenctor.)
NOTE: This manual uses the words left and right as you face the front of the
station module.
Follow the guidance of this chapter to complete the installation of your
MMDS.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...
