Fri-Jado GO Combi User guide

Mounting instruction
Mounting the condensation hood
EN (Original Instruction) Revision 09/2023, SW: 0.7.9
GO Combi

2
GO Combi

3
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
General information 4
Target group....................................................................................... 4
Technical changes............................................................................... 4
More documentation.......................................................................... 4
Warranty ............................................................................................ 4
Permissions......................................................................................... 4
Safety information 5
Before replacement 6
Tools ............................................................................................. 6
Spare parts ......................................................................................... 6
Estimated working time...................................................................... 6
Condensation hood overview 7
Mounting the condensation hood 8
Mechanical installation ....................................................................... 8
Electrical installation ......................................................................... 11
Testing the condensation hood ......................................................... 13
Table of contents

4
GO Combi
General information
Target group
This document is aimed at service technicians who have been trained in installing and servicing the
oven. The oven must only be installed and serviced by qualified service technicians.
Technical changes
This document is subject to changes without notice.
More documentation
You find more documentation about the oven at our website.
Warranty
You find more information about warranty at our website.
Permissions
Log in as “Technician” (576021) to have the necessary rights to be able to change the oven setup,
use the test functions, update software, etc.

5
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
Safety information
Read this document before using, installing or servicing the product.
Installation and operation must comply with local regulations and accepted
codes of good practice.
Read the safety instructions in the user manual, installation manual and
service manual before you perform any work on the oven.
All maintenance and repair must be carried out by qualified installation and
service technicians only. Installation and/or service by others than qualified
service technicians may result in injury to the operator and/or damage to the
oven.

6
GO Combi
Before replacement
• Make sure the required tools are available.
• Unpack the spare parts and check if all parts are available.
• Make sure the working area is tidied up, clean and safe to prevent personal injury and damage
to the equipment.
Tools
• Drilling machine
• Ø5.7 drill
• M5 threaded tap
Spare parts
• Condensation hood, mounting kit.
Estimated working time
The estimated working time is 1 hour.

7
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
Condensation hood overview
Condensation hood for standard ovens
Condensation hood for PassThrough ovens
Condensation hood for Stackit PassThrough ovens
Condensation hood for Stacking kit ovens

1
2
8
GO Combi
Mounting the condensation
hood
Mechanical installation
IMPORTANT! The distance from the condensation to the ceiling must be
minimum 300 mm.
1. Drill out the centre marks in the oven roof in the marked areas using a Ø4.7 drill
and a M5 threaded tap.
The illustration only shows some of the markings on the right-hand side of the
oven. The same must be done on the left-hand side of the oven.
2. Place the the condensation hood on top of the oven.
IMPORTANT! Make sure that the pipes in the condensation hood fits on the
exhaust pipe and air intake pipe on the oven.
IMPORTANT!
In case of a Stacking kit oven, make sure that the pipes in the
condensation hood fits on the exhaust pipe and air intake
pipe on the upper oven as well as the exhaust pipe for the
bottom oven.

3
4
5
6
9
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
3. Remove the front.
4. Remove the six M5x10 screws on the left-hand side.
5. Remove the side plate on the left-hand side.
6. Remove the six M5x10 screws on the right-hand side.

8
8
8
7
10
GO Combi
8. Fasten the condensation hood with four M5x10 screws.
7. Remove the side plate on the right-hand side.

1
5
11
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
9. Remount the side plates and fasten them with six screws.
10. Remount the front.
Electrical installation
1. Lead the wire for the IO board through the cable gland.
2. Lead the wire down the back side of the oven.
3. Fasten the wire with cable ties.
4. Remove the side plate.
5. Lead the wire under the oven and up through the hole for Ethernet connection.

6
Requirements
This installation requires
Adobe Acrobat Reader
7.0 or Adobe Acrobat 7.0
You must install one of
these products before
installation ofthe plug-in.
Adobe products are able
on Adobe web site:
www.adobe.com
Default
View 1
Connection of gas burners
IO board LEDs
7
12
GO Combi
6. Lead the wire to the IO board on the front panel.
7. Connect the wire to the IO board on J1.
8. Put the three-pin plug into the socket.
9. Switch on power.
8

13
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
1
Testing the condensation hood
1. Go to “Settings” in the home screen menu.
2. Log in as “Technician”.
2
2
3. Touch “Oven setup”
5

14
GO Combi
5
4
4. Touch “Test functions”.
5. Touch “Other tests”.
6. Touch “Main contactor”.
7. Touch “External vent”.
7
6

15
GO Combi
GO Combi mounting instruction, revision 09/2023, SW: 0.7.9
