Fri-Jado STG User manual

WWW.FRIJADO.COM Service Manual STG8 I form 9123548 rev. 05/2007
MODELS
Programmable controls STG8 I
Versions:
Solid Back
Pass-Through with rotor button
SERVICE MANUAL
STG ROTISSERIE OVEN MODELS
Model STG8 I
- NOTICE -
This manual is prepared for the use of trained Service Technicians and
should not be used by those not properly qualified. If you have attended
a trianing for this product, you may be qualified to perform all the proce-
dures in this manual.
This manual is not intended to be all encompassing. If you have not
attended a training for this product, you should read, in its entirety,
the repair procedure you wish to perform to determine if you have the
necessary tools, instruments and skills required to perform the procedure.
Procedures for which you do not have the necessary tools, instruments
and skills should be performed by a trained technician.
Reproduction or other use of this Manual, without the express written
consent of Fri-Jado, is prohibited.

Page 2 Service Manual STG8 I form 9123548 rev. 05/2007

Page 3
TABLE OF CONTENTS
Service Manual STG8 I form 9123548 rev. 05/2007
Index ............................................................................................................................... 3
General technical data .................................................................................................... 4
Technical data .............................................................................................................................4
Programming instructions for the STG8 I ......................................................................... 5
Default parameters .....................................................................................................................9
Removal and replacement of parts for the STG8 I ......................................................... 19
Right or left side panel ...............................................................................................................19
Top cover ..................................................................................................................................19
Glass operation panel with back plate ........................................................................................20
CPU board and display (Central Processor Unit) .........................................................................20
Keypad .....................................................................................................................................21
Electric panel ............................................................................................................................21
Ceramic element .......................................................................................................................22
Halogen lamp (holder) ..............................................................................................................22
Electronic transformer ................................................................................................................23
Power and I/O board ................................................................................................................23
High limit thermostat .................................................................................................................24
Contactor .................................................................................................................................25
Blower motor ............................................................................................................................25
Blower motor bottom rotisserie (stacked STG8 I) .........................................................................26
PT1000 sensor ..........................................................................................................................26
Heating element .......................................................................................................................27
Drive motor ..............................................................................................................................27
Door adjustment (left side) .........................................................................................................28
Door glass inside ......................................................................................................................28
Door glass outside ....................................................................................................................29
Electrical tests and service procedures ........................................................................... 30
Programming with FIPS ..............................................................................................................30
PT1000 Sensor test ....................................................................................................................35
Heating element test ..................................................................................................................35
Keypad test ...............................................................................................................................36
Control location ........................................................................................................................36
Part 1: General troubleshooting list ............................................................................... 37
Troubleshooting the STG8 I rotisserie ..........................................................................................37
Part 2: Analytic troubleshooting list ............................................................................... 38
Servicing and repairing of the STG8 I rotisserie ...........................................................................38
Exploded views & partlists ............................................................................................. 42
Electrical diagrams ........................................................................................................ 57
INDEX

Page 4
GENERAL TECHNICAL DATA
Service Manual STG8 I form 9123548 rev. 05/2007
GENERAL TECHNICAL DATA
Thismanual covers the STG8 I series rotisserie ovens. Ovens will also be delivered in stacked versi-
ons.
• STG8 I - Oven with eight spits ( 32 to 40 chickens )
All of the information, illustrations and specifications contained in this manual are based on the
latest product information available at the time of printing.
Type STG8 I Pass-Through STG8 I Solid Back
Power 10.500W 10.500W
Fuses needed with power connection
400 V, 3N ~ 50...60 Hz
(3 phases with zero)
3 x 16 A 3 x 16 A
Fuses needed with power connection
200 or 230 V, 3 ~ 50...60 Hz
(3 phases without zero)
3 x 32 A 3 x 32 A
Power connection 400/230V, 3N ~ 50...60 Hz
Standard plug from factory CEE-form 5-pole 16 A 16 A
Net weight 181 kg 181 kg
Gross weight 217 kg 217 kg
Height 1015 mm 1015 mm
Width 985 mm 985 mm
Depth 865 mm 850 mm
Tools
• Standard set of tools.
• Metric wrenches, sockets and hex socket key wrenches.
• Multi meter and AC current clamp meter..
• Temperature tester.
• Insulation value tester (Megger).
• Field Service Grounding Kit.
TECHNICAL DATA

Page 5
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
ON�-�OFF
ON�-�OFF
°C�-�°F
IN�MAIN�MENU's
IN�SUBMENU's
Navigate�by
arrows�up�and�down�or�the�dial.
Change�value�by
left�or�right�arrow.
Entering�Submenu�(>)�by
"right"�arrow�or�"OK"�button
Navigate�by
left�or�right�arrow
Change�value�by
up�or�down�arrow
or�the�dial
Confirm�and�leave�menu
with�"OK"�button
Leave�menu�without�change
with�"CANCEL"�button.
SETTINGS�MENU
MANAGER��MENU���---->
SERVICE��MENU ---->
PROGRAMMING INSTRUCTIONS FOR THE STG8 I

Page 6
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
MANAGER��MENU
NO�-�1x�- YES
NO�- TIME
24HR�- AM/PM
DMY -�MDY
YES�-�NO
-30°C�...�+30°C�or�-54°F�...�+54°F
-50°C�....�+50°C�or�-90°F�...�+90°F

Page 7
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
SERVICE��MENU access�code�4878
MULTI�-�M�BAKE�-�STGi
1�....�10
YES�-�NO
YES�-�NO
INPUT�/�OUTPUT�TEST ---->

Page 8
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
INPUT�/�OUTPUT�TEST
FRONTPANEL
Allows�a�function�test�of�all�keys.
MFMC�INPUTS
Shows�the�electronic�board
temperature�and�the�dipswitch
settings.
MFMB�INPUTS
Shows�the�values�of�the�actual
inputs�on�the�"Power�and�I/O"
board.
MFMB�OUTPUTS
Allows�an�output�test�on�the
outputs�connected�to�the�"Power
and�I/O"�board.
MFS1�INPUTS
Shows�the�values�of�the�actual
inputs�on�the�"Extension�I/O"
board.
MFS1�OUTPUTS
Allows�an�output�test�on�the
outputs�connected�to�the
"Extension"�I/O�board.

Page 9
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
INPUT�/�OUTPUT�TEST
FRONTPANEL
Allows�a�function�test�of�all�keys.
MFMC�INPUTS
Shows�the�electronic�board
temperature�and�the�dipswitch
settings.
MFMB�INPUTS
Shows�the�values�of�the�actual
inputs�on�the�"Power�and�I/O"
board.
MFMB�OUTPUTS
Allows�an�output�test�on�the
outputs�connected�to�the�"Power
and�I/O"�board.
MFS1�INPUTS
Shows�the�values�of�the�actual
inputs�on�the�"Extension�I/O"
board.
MFS1�OUTPUTS
Allows�an�output�test�on�the
outputs�connected�to�the
"Extension"�I/O�board.
SETTINGS MENU Default Possibilities
Light on on - off
Alarm signal on on - off
Temperature °C °C - °F
Set time Dutch time
Set date Actual date
Set contrast 75 0….120
Information softw. version
Manager ---> MANAGER MENU
Change pincode 0000
Preheat mode no no - 1x - yes
Preheat delta 0°C -50°C…+50°C or -0°F…+90°F
Auto-correct no no - time
Time format 24hr 24hr - am/pm
Date format DMY DMY - MDY
Set language English various
Irda interface no yes - no
Nafem option no no - “password”
Pulse times --> t1 - 0,1….10
t2 - 1….10
t3 - 0,1….1
Alarm delays --> t4 - 1….17
t5 - 1….60
Heater delta - -30°C…+30°C or -4°F…+54°F
Service ---> SERVICE MENU
Device type STG-i Multi - M-bake - MultiM - Bake-i
- STG-b - STG-i
Correct factor 4x 1….10
auto off (t6) 120 min. no….240
clean times --> Adding clnr (t1) - 0 10
Dry soak (t2) - 0….30
Wet soak (t3) -0….60
Rinsing (t4) - 0….10
Drying (t5) - 0….60
Debug RS 232 no yes - no
Demo mode no yes - no
I/O test - -
DEFAULT PARAMETERS

Page 10
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
DISPLAY AND KEYS
SETTING THE STG8 I
Start / Stop key
OK / Enter key
On / Off key
Turning knob
Cancel key
Rotor rotation key
Display
Selection keys (3x)
Press and hold the On/Off key during
2 seconds. The display lights up and the
rotisserie is ON.

Page 11
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
ADD A PROGRAM
Press program key.
Note: when a pin code has been set, first enter
the pin code and confirm with OK.
Go to add program with turning knob and con-
firm with OK.
Edit the program name with turning knob and
confirm with 2x OK.

Page 12
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
ADD A PROGRAM
Select time table with turning knob and confirm
with OK. Set the time of the grilling step and
confirm with OK.
Select temperature table with turning knob and
confirm with OK. Set the temp. of the grilling
step and confirm with OK.
Program next grilling step if necessary.
Program temperature HOLD if necessary. Select
next time table and set this on HOLD with tur-
ning knob and confirm with OK.
Select temperature table with turning knob and
confirm with OK.
Go to save program and confirm with OK.
PROGRAM START
Press operate key.
Select program with the turning knob and con-
firm with OK.
When no pre heating is activated, process starts
and is indicated by means of a heating diagram.

Page 13
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
PRE HEATING
When pre heating step is activated in manager
menu, the oven will start up with pre heat pro-
gram after the program start. After reaching the
pre heat temperature the display will indicate:
load products.
LOADING WITH PRODUCTS
Press rotor key to start turning the rotor
Press rotor key again to stop
Load the rotisserie with products
Close the door and press the start key

Page 14
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
PROGRAM STOP
Press cancel key.
Select yes with turning knob and confirm with
OK.

Page 15
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
INTERRUPTING ACTIVE PROGRAM
Press start/stop key. Heating, blowers and rota-
tion stops.
Press start/stop key again to resume.
OPTIONAL SETTINGS
- Interrupting active program.
- Editing a program.
- Deleting of a program.
- Running in test program.
- Demo mode.
EDIT A PROGRAM
Press program key.
Note: when a pin code has been set, first enter
the pin code and confirm with OK.
Go to edit program with turning knob and con-
firm with OK.
Now change the name if necessary and confirm
with OK.
Now change time and temperature if necessary.
Then go to save program and confirm with OK.

Page 16
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
DELETE A PROGRAM
Press program key.
Note: when a pin code has been set, first enter
the pin code and confirm with OK.
Go to delete program with turning knob and
confirm with OK.
Now select the program to delete and confirm
with OK.
Select yes with turning knob and confirm with
OK.
TEST PROGRAM
In test program you can run a program and you
have the possibility to change time and tempera-
ture during the process.
Press program key.
Note: when a pin code has been set, first enter
the pin code and confirm with OK.
Go to test program with the turning knob and
confirm with OK.
Now select the program and confirm with OK.
If you press the OK key during the program you
can change the settings.
Go to save program and confirm with OK. New
settings are now saved.

Page 17
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
DEMO MODE
In the demo mode you can simulate a cooking
cycle. This is used for exhibitions and runs just
on 1 phase (L1).
Go to the service menu and activate the access
code 4878.
Go to demo mode with the turning knoband
adjust this on yes.
Go to operate and select a program with the
turning knob and confirm with OK.
Start the program and now on the display the
program is simulated by means of a heating
diagram.

Page 18
PROGRAMMING INSTRUCTIONS
Service Manual STG8 I form 9123548 rev. 05/2007
SWITCHING THE ROTISSERIE OFF
Press and hold both keys On/Off and settings
until the display light goes out and the rotisserie
is OFF

Page 19
Service Manual STG8 I form 9123548 rev. 05/2007
REMOVAL AND REPLACEMENT OF PARTS
WARNING: Disconnect the electrical power to the machine at
the main circuit box. Place a tag on the circuit box indicating the
circuit is being serviced.
1. Remove the screws that secure the panel
to the frame.
2. Remove the panel.
3. Reverse the procedure to install.
1. Remove the left side panel according
prior procedure.
2. Remove the screws securing both large
and small top covers.
3. Remove the top cover. (Lift at left side and
remove to the left).
4. Reverse the procedure to install.
REMOVAL AND REPLACEMENT OF PARTS FOR THE STG8 I
RIGHT OR LEFT SIDE PANEL
TOP COVER

Page 20 Service Manual STG8 I form 9123548 rev. 05/2007
REMOVAL AND REPLACEMENT OF PARTS
1. Remove the right side panel according prior
procedure.
2. Remove the screws that secure the small top
cover plate and remove the cover plate.
3. Remove the 2 nuts on the backside of the
operating panel.
4. Remove the nut from the earth wire on the
main board and remove the earth wire.
5. Remove the grey flat cable from the main
board.
6. Lift the operating panel out of the locking
slots and remove the panel.
7. Remove the flat cables on the main board.
8. Remove the 4 nuts that secure the main
board and remove the board.
9. Reverse the procedure to install.
Note: On a stacked unit both operation panels
are located on the top oven.
Before changing the CPU board be sure to
download or write down the grilling programs.
1. Remove the right side panel according prior
procedure.
2. Disconnect the wiring and flat cables on the
board.
3. Remove the 4 nuts that secure the main
board and remove the board.
4. Remove the connectors of the display on the
board and remove the ty-rap.
5. Remove the 4 screws and nuts that secure the
display and remove display.
6. Reverse the procedure to install.
Note: When installing a new CPU board, check
all settings in the manager and service menu and
load the programs.
GLASS OPERATION PANEL WITH BACK PLATE
CPU BOARD AND DISPLAY (CENTRAL PROCESSOR UNIT)
