Frico PA2500 User manual

PA2500
Original instructions
.... 21
SE .... 26 GB .... 30
DE .... 35 ES .... 40 FR
.... 45
IT .... 50 NL .... 55 NO .... 60 PL .... 65 RU
Тел. [phone]
e-mail: [email protected]
www.moscowclimate.ru

Introduktionssidorna består huvudsakligen av bilder. För översättning av de
engelska texter som används, se respektive språksidor.
SE
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the respective language pages.
GB
Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de
engelske tekstene, se de respektive språksidene
NO
Les pages de présentation contiennent principalement des images. Consulter
la page correspondant à la langue souhaitée.
FR
Die Einleitungsseiten bestehen hauptsächlich aus Bildern. Für die Übersetzung
der verwendetenTexte in englischer Sprache, siehe die entsprechenden
Sprachseiten.
DE
Las páginas introductorias contienen básicamente imágenes. Consulte la
traducción de los textos en inglés que las acompañan en las páginas del
idioma correspondiente.
ES
De inleidende pagina's bevatten hoofdzakelijk afbeeldingen. Voor een vertaling
van de gebruikte Engelse teksten, zie de pagina's van de resp. taal.
NL
Le pagine introduttive contengono prevalentemente immagini. Per le
traduzioni dei testi scritti in inglese, vedere le pagine nelle diverse lingue.
IT
Początkowe strony zawierają głównie rysunki. Tłumaczenie wykorzystanych
tekstów angielskich znajduje się na odpowiednich stronach językowych.
PL
PA2500
2
RU Страницы в начале Инструкции состоят в основном из рисунков, схем и
таблиц. Перевод встречающегося там текста приведен в разделе RU.

PA2500
3
2 m
345
min 500
min 500 min 500
157
157157
90,5
10
20
40
22
210
165
184
1026 / 1536 / 2026
1050 / 1560 / 2050
Cu ø1
5
53
71 40
min 500 min 500 157157
345
min 500
min 500 min 500
157
157157
90,5
10
20
40
22
210
165
184
1026 / 1536 / 2026
1050 / 1560 / 2050
Cu ø15
53
71 40
min 500 min 500 157157
345
min 500
min 500 min 500
157
157157
90,5
10
20
40
22
210
165
184
1026 / 1536 / 2026
1050 / 1560 / 2050
Cu ø15
53
71 40
min 500 min 500 157157
1PA2500A 2 PA2500W
3PA2500E
PA2500

PA2500
4
ø17, 5ø17,5
ø32,5
ø25,5
ø20,5
ø17, 5
Gland
Knock-out
Knock-out
Knock-out
Gland
Fig.2
Gland

PA2500
5
Fig.3: Open the unit.
AB
C
TX20
Fig.4: Minimum distance.
min 60

PA2500
6
min 500 mm
Fig. 6: Mounting with wall brackets
Mounting with wall brackets
AB
C
PA2510 2 pcs
PA2515 2 pcs
PA2520 3 pcs
D
203575
210
33
ø8 (3x)
ø5
ø10
162

Accessories
PA2500
7
PA34TR PA2P
PA2PF PAMLK
PA34TR15 PA2510, PA2515, 1 m
PA34TR20 PA2520, 1 m
PA2P15 PA2510, PA2515, 1 m
PA2P20 PA2520, 1 m
PA2PF15 PA2510, PA2515
PA2PF20 PA2520
PAMLK PA2500
PA2EF10 PA2510
PA2EF15 PA2515
PA2EF20 PA2520
PA2EF
Type E-nr
(SE)
RSK-nr
(SE)
NRF-nr
(NO)
PA34TR15 87 505 32 673 90 94
PA34TR20 87 505 34 673 90 95
PA2P15 87 505 28 673 90 92
PA2P20 87 505 30 673 90 93
PA2PF15 87 505 02 673 90 90
PA2PF20 87 505 03 673 90 91
PAMLK
PA2EF10 673 90 86 85 024 73
PA2EF15 673 90 87 85 024 74
PA2EF20 673 90 88 85 024 75

Type E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
NRF-nr
(NO)
Dimensions Length
SIReB
87 510 21 673 09 57 54 911 22 85 023 18
SIReAC
87 510 29 673 09 64 54 911 23 85 023 22
SIReAA
87 510 31 673 09 66 54 911 24 85 023 23
SIReRTX
87 510 12
673 09 22
54 910 01 85 022 94
70x33x23 mm
SIReUR
87 510 11
673 09 21
49 325 00 85 022 93
114x70x50 mm
SIReWTA
673 09 69
SIReCJ4
87 510 33 673 09 70 54 910 02
SIReCJ6
87 510 34 673 09 71
SIReCC603
87 510 13
673 09 23
54 329 01 85 022 95
3 m
SIReCC605
87 510 14
673 09 24
54 329 02 85 022 96
5 m
SIReCC610
87 510 15
673 09 25
54 329 03 85 022 97
10 m
SIReCC615
87 510 16
673 09 26
54 329 04 85 022 98
15 m
SIReCC403
87 510 17
673 09 27
54 329 05 85 022 99
30 m
SIReCC405
87 510 18
673 09 28
54 329 06 85 023 01
50 m
SIReCC410
87 510 19
673 09 29
54 329 07 85 023 02
10 m
SIReCC415
87 510 20
673 09 30
54 329 08 85 023 03
15
PA2500
8
Type RSK-nr
(SE)
NRF-nr
(NO)
Ø
VMO15LF
673 09 47 DN15
VMO15NF 673 09 48 DN15
VMO20 673 09 49 DN20
VMO25 673 09 50 DN25
VMOP15LF 673 09 51 DN15
VMOP15NF 673 09 52 DN15
VMOP20 673 09 53 DN20
VMOP25 673 09 54 DN25
VOS15LF 673 09 35 DN15
VOS15NF 673 09 36 DN15
VOS20 673 09 37 85 023 31 DN20
VOS25 673 09 38 85 023 32 DN25
VOSP15 LF 673 09 43 DN15
VOSP15NF 673 09 44 DN15
VOSP20 673 09 45 DN20
VOSP25 673 09 46 DN25
VOT15 673 61 93 DN15
VOT20 673 61 94 DN20
VOT25 673 61 95 DN25
VMT15 DN15
VMT20 DN20
VMT25 DN25
VAT 482 98 30
Accessories
C
SIReB SIReAC/SIReAA SIReRTX SIReUR SIReWTA SIReCCSIReCJ4/SIReCJ6
VOS VOSP
VMO VMOP
VOT
VAT
VMT

PA2510E05 / PA2515E08 / PA2520E10
C2
Over heat cut-out
°C
C1
LNPE
NNF1 F2 F3H1 H2
HeatingMotor/trafo
ID. pot.
C1 = low power
C2 = high power
L2 PE
L1 LN
L3
400V 3N~
ACTUATOR
SUPPLY
ROOMC1C2
Internal sensor
Motor protection
SIReB2
Over heat
°C
cut-out
PA 2510E05 PA 2515E08 PA 2520E10 C4
C3
C1 = low power
C2 = high power
L2 PE
L1
L3
400V3~
M
Blue
Black
Brown
C°
~
Right motor
M
Blue
Black
Brown
C°
~
C3
Run
C2 Lo
C1
Mid
Left motor
Only 2 m version
C3
Run
C2 Lo
C1
Mid
PA2500
9

PA2510E08 / PA2515E12 / PA2520E16
C2
Over heat cut-out
°C
C1
LNPE
NNF1 F2 F3H1 H2
Heating Motor/trafo
ID. pot.
C1 = low power C2 = high power
L2 PE
L1 LN
L3
400V 3N~
ACTUATOR
SUPPLY
ROOMC1C2
Internal sensor
Motor protection
SIReB2
Over heat
°C
cut-out
PA 2510E08 PA 2515E12 PA 2520E16 C4
C3
L2 PE
L1
L3
400V 3~
C1 = low power C2 = high power
M
Blue
Black
Brown
C°
~
Right motor
M
Blue
Black
Brown
C°
~
C3
Run
C2 Lo
C1
Mid
Left motor
Only 2 m version
C3
Run
C2 Lo
C1
Mid
PA2500
10

PA2510A / PA2515A / PA2520A
PA2510W / PA2515W / PA2520W
LNPE
NNF1 F2 F3H1 H2
Heating Motor/trafo
ID. pot.
ACTUATOR
SUPPLY
ROOM C1 C 2
Internal sensor
Motor protection
SIReB2
PA 2510WA PA 2515WA PA 2520WA
M
Blue
Black
Brown
C°
~
Right motor
M
Blue
Black
Brown
C°
~
C3
Run
C2 Lo
C1
Mid
Left motor
Only 2 m version
C3
Run
C2 Lo
C1
Mid
PA2500
11

PA2510E05YD / PA2515E08YD
C2
Over heat cut-out
°C
C1
LNPE
NNF1 F2 F3H1 H2
Heating Motor/trafo
ID. pot.
L2 PE
L1 LN
L3
400V 3N~
ACTUATOR
SUPPLY
ROOM C1 C 2
Internal sensor
Motor protection
SIReB2
PA 2510E05YD PA 2515E08YD
L2 PE
L1 LN
L3
230V 3~
230V 3~
400V 3~
a1 a2 b2 c2 c1 b1 a1 a2 b2 c2 c1 b1
M
Blue
Black
Brown
C°
~
Right motor
C3
Run
C2 Lo
C1
Mid
PA2500
12

PA2520E10YD
C2
Over heat cut-out
°C
C1
LNPE
NNF1 F2 F3H1 H2
Heating Motor/trafo
ID. pot.
L2 PE
L1 LN
L3
400V 3N~
ACTUATOR
SUPPLY
ROOM C1 C 2
Internal sensor
Motor protection
SIReB2
Over heat
°C
cut-out
PA 2520E10YD
L2 PE
L1 LN
L3
230V 3~
230V 3~
400V 3~
a1 a2 b2 c2 c1 b1 a1 a2 b2 c2 c1 b1
M
Blue
Black
Brown
C°
~
Right motor
C3
Run
C2 Lo
C1
Mid
C2
C1
L2 PE
L1
L3
400V 3~
230V 3~
400V 3~
a1 a2 b2 c2 c1 b1 a1 a2 b2 c2 c1 b1
M
Blue
Black
Brown
C°
~
C3
Run
C2 Lo
C1
Mid
Left motor
L2 PE
L1
L3
230V 3~
PA2500
13

PA2500
14
PAMLK, motor alarm board
M
C°
~
M
Blue
Black
Brown
C°
~
Lo
Mid
Run
Right motor
LNPE
NNF1 F2 F3H1 H2
Heating Motor/trafo
ID. pot.
ACTUATOR
SUPPLY
ROOM C1 C 2
Internal sensor
Motor protection
SIReB2
NF1F2F3
OUT PAMLK
CNC NO
M
Blue
Black
Brown
C°
~
Lo
Mid
Run
Left motor
Only 2 m version

SIReB Basic
PA2500 E
SIReB Basic - Parallel connection
Wiring diagrams for SIReAC Competent and SIReAA Advanced, see manuals for SIRe.
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE NL
PE
ACTUATOR SUPPLY
SIReB2 SIReUB1
SIReRTX
(optional)
230V~ 230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE NL
PE
ACTUATORSUPPLY
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE NL
PE
ACTUATORSUPPLY
SIReB2 SIReB2 SIReRTX
(optional)
SIReUB1
PA2500
15

SIReB Basic
PA2500 W
C
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE NL
PE
ACTUATOR SUPPLY
230V~
SIReB2
SD230 SIReRTx
(optional)
SIReUB1
PA2500
16

SIReB Basic - Parallel connection
PA2500 W/A
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE
NL
PE
ACTUATOR SUPPLY
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE NL
PE
ACTUATOR SUPPLY
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID
N L
PE NL
PE
ACTUATOR SUPPLY
230V~
230V~
230V~
SIReB2
SD230 (W)
SIReB2
SIReB2
SD230 (W)
SD230 (W) SIReRTX
(optional)
SIReUB1
PA2500
17

PA2500
18
Type E-nr
(SE)
Output
steps
[kW]
Airflow*1
[m3/h]
∆t*3
[°C]
Sound
level*2
[dB(A)]
Voltage
motor
[V]
Amp.
motor
[A]
Voltage [V]
Amp. [A]
(heat)
Length
[mm]
Weight
[kg]
PA2510E05 87 505 15 1,7/3,3/5 900/1450 17/10,5 42/51 230V~ 0,5 400V3~/7,2 1050 19
PA2510E08 87 505 16 3/5/8 900/1450 27/16,5 42/51 230V~ 0,5 400V3~/11,5 1050 20
PA2515E08 87 505 17 2,7/5,4/8 1400/2200 17,5/11 40/52 230V~ 0,7 400V3~/11,5 1560 30
PA2515E12 87 505 24 3,9/8/12 1400/2200 26/16,5 40/52 230V~ 0,7 400V3~/17,3 1560 32
PA2520E10 87 505 25 3,4/6,7/10 1800/2900 17/10,5 43/53 230V~ 1,0 400V3~/14,4 2050 36
PA2520E16 87 505 27 6/10/16 1800/2900 27/16,5 43/53 230V~ 1,0 400V3~/23,1 2050 40
Type RSK-nr
(SE)
NRF-nr
(NO)
Output*4
[kW]
Airflow*1
[m3/h]
∆t*3,4
[°C]
Water
volume
[l]
Sound
level*2
[dB(A)]
Voltage
motor
[V]
Amp.
motor
[A]
Length
[mm]
Weight
[kg]
PA2510W 673 57 93 85 023 79 4,7 900/1300 12/11 0,71 42/53 230V~ 0,45 1050 1 7, 5
PA2515W 673 57 94 85 023 81 9,2 1250/2100 16/13 1,09 41/54 230V~ 0,6 1560 26
PA2520W 673 57 95 85 023 82 11,5 1800/2600 15/13 1,42 43/55 230V~ 0,9 2050 35
3Electrical heat - PA2500 E
2Water heat - PA2500 W
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
3Electrical heat - PA2500 E
Type C1 Mid
[mF]
C2 Low
[mF]
C2 Run
[mF]
PA2510E05 10 6 4
PA2510E08 10 6 4
PA2515E08 12 8 4
PA2515E12 12 8 4
PA2520E10 10 6 4
PA2520E16 10 6 4
Type E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
NRF-nr
(NO)
Output
[kW]
Airflow*1
[m3/h]
Sound
level*2
[dB(A)]
Voltage
motor
[V]
Amp.
motor
[A]
Length
[mm]
Weight
[kg]
PA2510A 87 506 05 673 69 97 49 308 01 85 024 34 0 900/1300 43/53 230V~ 0,5 1050 16
PA2515A 87 506 06 673 69 98 49 308 02 85 024 35 0 1250/2100 44/54 230V~ 0,7 1560 23,5
PA2520A 87 506 07 673 69 99 49 308 03 85 024 36 0 1800/2600 44/55 230V~ 1,0 2050 32
1Ambient, no heat - PA2500 A
Type C1 Mid
[mF]
C2 Low
[mF]
C2 Run
[mF]
PA2510A/W 10 6 4
PA2515A/W 14 10 4
PA2520A/W 10 6 4
PA2510E05YD 10 6 4
PA2515E08YD 12 8 4
PA2520E10YD 10 6 4
Technical specifications
Type EL-nr
(NO)
Output*
[kW]
Airflow*1
[m3/h]
∆t*3
[°C]
Sound
level*2
[dB(A)]
Voltage
motor
[V]
Amp.
motor
[A]
Voltage
heat
[V]
Amperage
heat
[A]
Weight
[kg]
PA2510E05YD 49 320 29 1,7/3,3/5 900/1450 17/10,5 42/51 230V~ 0,5 230V3~/400V3~ 12,6/7,2 19
PA2515E08YD 49 320 30 2,7/5,4/8 1400/2200 17,5/11 40/52 230V~ 0,7 230V3~/400V3~ 20,1/11,5 30
PA2520E10YD 49 320 31 3,4/6,7/10 1800/2900 17/10,5 43/53 230V~ 1,0 230V3~/400V3~ 25,1/14,4 36
*1) Lowest/highest airflow of totally 3 fan steps.
*2) Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area: 200 m². At lowest/highest
airflow.
*3) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*4) Applicable at water temperature 60/40 °C, air temperature, in +18 °C.

PA2500
19
Output charts water
*1) Recommended outlet air temperature for good comfort and optimized output.
*2) Nominal output at given supply and return water temperature.
Supply water temperature:80 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 80/60 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water
temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510W Max 1300 7, 4 52,0 0,07 1,4 8,8 38,0 0,11 3,4
Min 900 5,2 47,0 0,04 0,6 7, 0 41,0 0,09 2,3
PA2515W Max 2100 12,0 44,0 0,08 3,0 16,3 40,8 0,20 14,1
Min 1250 7, 3 38,0 0,04 1,0 11,7 45,6 0,14 7, 8
PA2520W Max 2600 15,2 44,0 0,10 5,5 20,1 40,8 0,25 25,0
Min 1800 10,4 38,0 0,06 2,2 16,0 44,1 0,20 16,5
Supply water temperature:90 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 90/70 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water
temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510W Max 1300 7, 4 50,0 0,04 0,7 10,8 42,5 0,13 4,8
Min 900 5,2 46,0 0,03 0,4 8,7 46,3 0,11 3,2
PA2515W Max 2100 12,5 43,0 0,07 1,9 19,8 45,8 0,24 19,6
Min 1250 7, 2 36,0 0,03 0,6 14,3 51,5 0,18 10,8
PA2520W Max 2600 15,1 41,0 0,08 3,1 24,4 45,6 0,30 34,6
Min 1800 10,6 36,0 0,05 1,5 19,3 49,6 0,24 22,8
Supply water temperature:110 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 110/80 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water
temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510W Max 1300 7, 4 47,0 0,03 0,3 13,3 48,1 0,11 3,3
Min 900 5,3 46,0 0,02 0,2 10,6 52,8 0,09 2,2
PA2515W Max 2100 12,5 39,0 0,04 0,9 24,4 52,2 0,20 13,3
Min 1250 7, 4 34,0 0,02 0,3 1 7, 6 59,4 0,15 7, 4
PA2520W Max 2600 15,0 36,0 0,05 1,5 30,1 52,0 0,25 23,6
Min 1800 10,2 32,0 0,03 0,7 23,9 57,0 0,20 15,6
Supply water temperature:70 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 70/50 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water
temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510W Max 1300 7, 4 54,0 0,11 3,7 6,8 33,4 0,08 2,2
Min 900 5,3 49,0 0,06 1,3 5,4 35,7 0,07 1,5
PA2515W Max 2100 12,0 47,0 0,13 6,7 12,8 35,9 0,16 9,3
Min 1250 7, 3 41,0 0,06 1,8 9,2 39,6 0,11 5,2
PA2520W Max 2600 15,0 47,0 0,16 12,1 15,8 35,9 0,19 16,7
Min 1800 10,3 41,0 0,09 4,1 12,6 38,5 0,15 11,1

PA2500
20
Supply water temperature: 60 °C
Room temperature: +18 °C
Outlet air temperature: +32 °C
Water temperature: 60/40 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water
temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510W Max 1300 6,4 50,0 0,16 7, 1 4,7 28,6 0,06 1,2
Min 900 4,5 45,0 0,07 1,8 3,7 30,0 0,05 0,8
PA2515W Max 2100 10,5 45,0 0,17 11,3 9,2 30,8 0,11 5,4
Min 1250 6,6 40,0 0,08 3,0 6,6 33,5 0,08 3,0
PA2520W Max 2600 13,1 45,0 0,21 20,3 11,5 31,0 0,14 9,8
Min 1800 9,1 40,0 0,11 6,5 9,1 32,9 0,11 6,5
See www.frico.se for additional calculations.
*1) Recommended outlet air temperature for good comfort and optimized output.
*2) Nominal output at given supply and return water temperature.
Supply water temperature: 55°C
Room temperature: +18 °C
Outlet air temperature: +29 °C
Water temperature: 55/35°C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water
temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510W Max 1300 6,4 50,0 0,34 29,3 3,5 25,9 0,04 0,7
Min 900 4,2 44,0 0,09 2,7 2,6 26,6 0,03 0,5
PA2515W Max 2100 10,3 46,0 0,28 27,5 7, 3 28,2 0,09 3,7
Min 1250 6,1 39,0 0,09 4,1 5,2 30,3 0,06 2,1
PA2520W Max 2600 12,7 46,0 0,34 48,7 9,3 28,5 0,11 6,9
Min 1800 8,5 39,0 0,13 8,8 7, 4 30,0 0,09 4,6
Output charts water
