Front Runner Slimline II KRVA002T User manual

ENG
KRVA002T_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
1
Don’t be a hero and muscle through this installation without reading these fitting instructions first! Improper installation of this gear may void certain
aspects of your warranty.
Before you begin, take a moment and open all your Front Runner rack kit boxes and gather the assembly instructions for the various components.
A complete kit will contain:
1. A Front Runner Mounting System specific to your vehicle
2. A Front Runner Rack Tray or Load Bar Slats
This document will guide you through the assembly of the mounting system and assist you in fitting the roof rack tray or load bars to your specific
vehicle.
Please refer to the next page for a list of all the components, quantities and tools required.
KRVA002T
READ ME FIRST
START HERE!
front runner VOLKSWAGEN ATLAS (2018-CURRENT)
SLIMLINE II ROOF RAIL RACK KIT
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.

KRVA002T_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 2
FIGURE 1.1
IN THE BOX
1 1 X Slimline II Tray - 1255mm(W) X 1560mm(L)
2 1 X Spacer Set
3 2 X Grab On Foot Set
4 2 X Inner Grip Set
5 2 X Outer Grip Set
1GET ORGANIZED
TOOLS NEEDED
2
3
4
1
5
3mm
5mm 13mm

© 2021 FRONT RUNNER VEHICLE OUTFITTERS
3 KRVA002T_REV_A00
FIT AND SECURE
2
2.1
2.2
2.3
Assemble your Slimline II Tray, referring to
the RRSTUNI fitment guide.
Flip the Tray so that the bottom of the Tray
faces up.
Insert four M8x16 Hex Bolts into the Slat
machined slots as shown.
Insert four M8x30 Hex Bolts into the Slat
machined slots as shown.
Loosely assemble the two Grab On Foot Sets
(Item 3) onto the slats indicated in 2.2 as
shown using M8 Flat Washers and M8 Nyloc
Nuts.
Note the Spacers must be used on the rear
feet.
B
B
A
3
3
2
A

Inner Grip
Outer Grip
© 2021 FRONT RUNNER VEHICLE OUTFITTERS
4 KRVA002T_REV_A00
FIT AND SECURE
2
2.4
2.5
Refer to GOFR001 fitment guide.
Remove the Front Covers from all the Base
Feet by loosening the two M5x10 Button
Head Screws.
Loosen and remove the M5 Cap Screw, M5
Spring Washer and Cap Screw Washer.
Loosley fit one Inner Grip and one Outer Grip
to each Grab On Foot using a M5 Cap Screw,
M5 Spring Washer and M5 Cap Screw
Washer removed.
FIT AND SECURE
3
Make sure that the wind deflector is
installed before you proceed to the next
step.
3.1

© 2021 FRONT RUNNER VEHICLE OUTFITTERS
5 KRVA002T_REV_A00
COMPLETION
4
4.1
Congratulations! You did it. Take a step back and admire your work!
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
5
Now's the time to visit your favorite Front Runner Dealer in person or online.
IMPORTANT!
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
FRONT RUNNER RACK KITS OFTEN HAVE A HIGHER LOAD RATING THAN THE VEHICLES THEY ARE MOUNTED TO. PLEASE REFER TO YOUR SPECIFIC VEHICLE MANUFACTURER
FOR A RECOMMENDED ROOF RATING. FRONT RUNNER CANNOT BE RESPONSIBLE FOR IMPROPER LOADING BEYOND THE VEHICLE MANUFACTURER'S STATED LOAD CAPACITY.
150mm
FIT AND SECURE
3
2.2
3.2
3.3
Center the rack and tighten fully. Finish off by placing M8 Nut Caps over the M8 Nyloc Nuts.
13mm
Place your Tray on the vehicle positioning
all the feet so that they rest on top of the
roof rails.
Measure 150mm on the front of the roof rail
as shown and position the LH and RH front
Grab On Feet.
Fully tighten all the M6x50 Cap Screws to
secure the Tray onto the rails.
Refit the Front Cover Plates.
3mm
5mm
Tightening Torque 6Nm
Make sure there are no movement on
the rack after fully tightening all the
fasteners.
