Front Runner RTTENT101 User manual

1
FEATHER-LITE ROOF TOP TENT
SET-UP GUIDE RTTENT101
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER RACKS AND ACCESSORIES BE PROPERLY AND
SECURELY ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN
AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR TO
OTHERS. YOU ARE RESPONSIBLE FOR SECURING THE RACKS AND ACCESSORIES TO YOUR CAR,
CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS
FOR ADJUSTMENT, WEAR, AND DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF
THE INSTRUCTIONS AND CAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS,
OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE
INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL
INSTALLER SUCH AS A QUALIFIED GARAGE OR AUTO BODY SHOP.
For more info and pics of this product, visit
INSTALL TIME: 30 minutes
1GET ORGANIZED
you will need:
Your Tent
The Ladder (in a separate box)
Power Drill w/ Phillips screw bit
A solid, scratch free surface large enough to hold the tent.
(you can use the cardboard that the tent shipped in , or a blanket
or furnie pad on the ground)
A 10mm wrench/socket
A 13mm wrench/socket
A friend for step 4, 6 and 7 (10 minutes)
if mounting to open over the rear of the vehicle, you will also need:
Hack Saw or similar (only needed for mounting the tent to
open to the rear)
Sharpie or suitable instrument for marking metal

1
...CONT’D
US

2
1
1
1
Here's what you're looking at:
Your new Feather-Lite tent, folded over, secured with velcro straps
2 aluminum mounting channels
Hardware and fasteners (8 6mmx40 bolts, 8 6mm nuts, 8 washers, 8 8mm bolts, 8 slide
plate washers, 4 mounting channel end caps, 4 self drilling sheet metal screws.)
The PVC zip cover
The ladder hinges and 2 bolts/nuts
Ladder
OPTIONAL Front Runner Slimline Rack Tent Mount Kit. (purchased separately)
AND 6 fly sheet rods (not pictured, secured inside the tent for shipping)
GET ORGANIZED
...CONT’D
1A)Carefully remove the tent from the box and set it upside down
(the 4 holes facing up) on your clean, dry work surface. Lay out all
the parts nearby.

3
1MAKE A CHOICE
Sometimes in life you have to ask yourself the difficult questions. Now is one of those times.
WHICH WAY DO YOU WANT YOUR TENT TO OPEN? Over the side of the vehicle, with
the ladder supporting the tent on the side of the vehicle? Or over the rear of the vehicle, with the
ladder supporting the tent behind the vehicle?
Since your Feather-Lite roof top tent is delivered to you with the option to be mounted to open
out over the rear or to open over either side, you will need to decide which direction suits your
vehicle and your preference.
CONSIDER THIS:
How will you be accessing the inside of the vehicle when camping?
Will you be using the optional Annex?
On some vehicles it’s not physically possible to open out over the rear. Some rear hatch doors
and windows open taller than the roof line and may interfere with the tent if it is oriented to open
out over the rear of the vehicle.
If the tent opens over the rear there will be a shelter from the sun and rain covering the back area
where you access the most cargo. This is especially nice if you use your tailgate as a kitchen, or
with the optional annex as a changing room for easy access to luggage.
If you open over the side you still may be able to position the shelter of the tent and/or the annex
to cover a side door. This too is handy to access luggage for changing or supplies for food prep.
Your tent can open either over the driver’s side or passenger side.
If you’d like to position your roof tent on the rack towards the front of the vehicle (because you’d
like to use the back of the rack for other gear), the tent will need to open over the sides. While it
is possible to have the tent open over the hood of the vehicle, the ladder will need to be modified
to attach either to bull bars or the hood of the vehicle.
The lowest wind resistance when driving is achieved with the roof tent opening out over the rear
of the vehicle. This is because the ladder is stored on top of the tent front to rear.
If you choose to install the tent to open over the rear of the vehicle there is an extra step in the
installation procedure -- you will need to shorten the aluminum extrusions by cutting them with a
hack saw.
DECIDE NOW!
If your tent is going to open out over the side, SKIP STEP 3!!!
2
1
B) HOW WILL YOU BE MOUNTING YOUR TENT TO YOUR VEHICLE?
If you have a roof rack that is a basket with raised edges that rise 2 “ or higher
than the floor of the rack, it is likely that you won’t be able to use that rack to
mount your tent without some major modifications.
If you’re using the Front Runner Slimline Roof Rack or Load Bars, make sure
you have the Tent Mount Kit (FRTENT16) or Quick Release Tent Mount Kit
(FRTENT 102).
The roof tent is supplied with sufficient brackets and hardware to allow
mounting to roof bars/load bars that are up to 2” wide x 1.25” high.

4
1
3
For the majority of roof racks and load bars, the aluminum channels will face front to back
on the vehicle, parallel with the sides of your vehicle. So -- if you face the tent opening off
the rear, the tips of the channels will face the opening and if your tent opens off the side, the
opening of the tent will run parallel with the aluminum channels.
Here’s how to tell which way your tent opens when it’s all folded up --
The nylon and velcro latches are on the sides of the tent.
Look for the 4 holes pre-drilled on one side of the tent floor. This is where the extrusions
will attach that mount to your rack or load bars. This is the bottom of the tent.
With the 4 holes facing the ground, the top/opening will fold up and away from the velcro
straps. There are 2 pairs of pre-drilled holes along the extrusion on the edge of the tent.
This is where the ladder will mount. That is the opening of the tent.
WARNING! - You do not have to cut the aluminum extrusions if you are mounting the
tent to open up over the side of your vehicle! The tracks are pre-cut to work as is!!
A) If mounting the channels front to rear so the tent will open over the
back of the vehicle, you will need to cut the channels to fit the base of
the tent.
C) Cut all 4 ends! Use a hack saw or
other tool of choice for cutting through
aluminum.
HINT
B)Measure 35mm/1.37” from
each end of EACH CHANNEL.
Mark a straight line with the
sharpie.
CUT THE CHANNELS?? * SKIP THIS STEP if you are
mounting the tent to open off of the side of your vehicle!
*

5
INSTALL CHANNELS
1
4
•FYI• The bolt
heads will protrude
slightly from the floor
of the tent, but you’ll
never notice since
they will be under
the mattress.
A) Now that you know which way you want your tent to open, it’s time to attach
the channels to the tent base.
The channels will run front to back on the tent floor if your tent will be opening over
the back of the vehicle. The channels will run side to side on the tent floor if your
tent is opening over the side of the vehicle.
The roof tent base is pre-drilled with 4 holes which align with holes in the channels.
Insert the 6 x 40mm bolts through the washers and push them through the 4 holes
from the INSIDE of the tent.
B) Slide 2 6mm nuts into each channel.
Line up the channels in the direction determined by your tent
orientation. Insert bolts into nuts and tighten.
You will have to open the tent and reach deep into the tent to access
the heads of the back bolts. You may need a hand for this step, as the
nut in the channel and bolt must line up.
C) Use a power drill to set the self-
drilling screws at each end of the
channels – these must screw into the
aluminum outer edge section.

6
1
6
B) Fit the plastic end caps on each end of the mounting channels (it may
be necessary to use the rubber mallet to tap them into place).
INSTALL LADDER AND COVER
1
A) Grab your helper friend and turn your tent over with the channels facing the
ground. Be careful with the protruding bolts. You may need to prop up the tent
using the channels.
5
A) Determine your roof carrier mounting points.
• If you are mounting your tent to an old fashioned steel
rack, or oval/rectangular rails and load bars that are no
larger than 2” wide x 1.25” high, use the included bracket
plates. Insert the included bolts through the 8 slide plates,
and insert 4 slide plates per channel.
INSTALL RACK MOUNTING POINTS
• If you are mounting your tent on a Front Runner Slimline Rack, you have 2 choices:
1) For the standard Tent Mount Kit (FRUN16) - use the 8 8mm bolts included with the tent
mount kit and insert the bolts into all 8 slide plates, then slide 4 plates into each channel.
(You can discard the 8mm bolts that came with the tent).
2) For the Quick Release Tent Mount kit, use the 4 8mm bolts included with the Quick Release
Kit and slide 2 plates in each channel.
B) Line up the hinge plates to the the predrilled holes along the aluminum extrusion.
Use the 4 remaining 6 x 40mm bolts to mount the 2 hinge plates. Insert the bolts from
inside the tent with the nuts on the outside. Tighten.

7
1
7
C) Bolt on ladder, with ladder hinge plate on
the inside.
D) INSTALL VINYL (PVC) COVER
Slide blue retaining edge into sliding channel of
tent base. Pull through until cover lines up with
tent. Fold cover over tent and out of the way for
placement of tent on the vehicle.
MOUNT TENT ON VEHICLE
If you’re using the Slimline Rack with the FRONT RUNNER SLIMLINE RACK TENT MOUNT
KIT (FRTENT16), see TENT MOUNT KIT INSTALLATION GUIDE and mount your feet first.
If you’re using the the QUICK RELEASE TENT MOUNT KIT (FRTENT102), see the QUICK
RELEASE TENT MOUNT KIT INSTALLATION GUIDE to mount the quick release system first.
Grab your helper friend to lift the tent on to your roof mounting system.
TIP: Be careful not to scratch the vehicle with the bolts hanging out of the slide plates.
For all other load bars, rails, racks -- after you set the tent on your roof carrier, slide the plates
and adjust the bolts to straddle the rail/bar and tighten the bracket plate until secure.
...CONT’D

8
Set up the tent once, and you’ll never have to think about it again!
OPEN YOUR TENT AND ADJUST THE LADDER
8
A) POP THE TENT
If your PVC cover is on, loosen the black nylon straps and velcro corner tabs and then unzip
around 3 edges. The cover can then be folded over and out of the way OR removed
completely by sliding it out of the sliding track.
2. Slide the ladder out until the locking pins engage in the holes
3. Use the ladder as a lever to pull down and open the tent. The tent will just pop up into
shape.
B) Determine the ideal angle for the ladder. You want the entire sleeping platform to be
level and straight.
The ladder is pre-drilled to lock into place at the longest safe position.
If you level the platform out and find that the angle of the ladder is too great – you can
straighten the ladder as desired and drill 2 new holes for the pins to lock in to. (this may
be the case on shorter vehicles)
Loosen the pins and adjust it to the desired angle. Mark the position of the ladder legs
and using a 7mm bit, drill the 2 additional holes for the pins to lock in to.
WARNING: The locking pins can be twisted and locked in the open position, so
ensure that the pins are unlocked and engaged in the holes. Always make sure that
the pins are in the closed position before attempting to climb the ladder!

9
C) Insert the 6 steel rods to support the fly sheet.
The 2 longer rods are for the windows on each side. The 4 shorter front and rear rods
mount into holes in the outer edge. Locate the eyelets in the Flysheet (in the middle of
the sides, and on the corners of the front and back).
The two center rods on each side slide into the tongue and groove aluminum extrusion
between the floor boards. Practice inserting the rods by using two hands to create a
curve and thus making it easier to insert into the slots. The 4 rods for the front and rear
fit into the holes near the ends of the aluminum extrusion on the base of the tent. The
holes are angled, and once again, you will want to use 2 hands to maneuver the rods
into the slot.
Note: The window rods will retain some curve after the first use - no worries! This is
normal.
...CONT’D
To close the tent – reverse the above procedures. Store the fly sheet rods in their bag, in
the tent underneath the mattress.
You have some room inside the tent to set out your sleeping bag, even your pillows (if
they’re not overstuffed California King Size!) Or you can tuck fitted sheets around the
mattress and throw on a comforter. Toss in your teddy bear and close the tent back up.
When you arrive at your destination, pop the tent open and you’ll already be set for the
best camp sleep of your life!
YOU DID IT! Now make your bed.
YOU MADE YOUR BED. NOW SLEEP IN IT.
A) After your first adventure, check the
tension on all the bolts and screws and re-
tighten where needed. You'll find a small
amount of settling has happened.
B) Go on many more adventures.
Periodically check the bolts - it's always wise
to double check your fasteners every once
and a while.
10
11
WARNING! READ ME! NEVER EXTEND THE LADDER BEYOND THE PRE-DRILLED
HOLES AND FACTORY LOCKING POSITION. UNDER NO CIRCUMSTANCES SHOULD YOU
DRILL NEW HOLES PAST THE CURRENT HOLES. THE LADDER IS NOT SAFE EXTENDED
ANY TALLER. If a longer ladder is needed for extremely tall vehicles, please order a Ladder
Extension -- Part No: FRTENT15

10
THE FINE PRINT: Now that your Front Runner Feather-Lite Roof Top Tent is installed, please be safe when getting in
and out of the tent. Take your time when backing out and make sure you have a firm footing on the ladder.
And always remember- you've raised the height of your vehicle and changed the center of gravity - so use caution when
entering parking structures and driving under other low hanging obstacles. Also use caution when taking tight turns - as
you have altered your center of gravity because you have added weight to your roof top.
For the safety of the tent system and your vehicle, please obey all traffic laws and adjust speed accordingly to the load
being carried and the conditions of the road.
Cargo will affect the vehicles handling.
Modifying your vehicle involves some risks and may void certain aspects of your vehicle’s warranty.
You'll get many years of enjoyment out of your Front Runner Feather-Lite Roof Top Tent if you use common load carrying
sense.
©2010 Front Runner Outfitters, Inc
version 3-10
TENT CARE - READ ME!!
12
Do not over tighten the black nylon retaining straps – these should NOT be used
to force the bases together or damage will result. Only apply enough tension to
prevent the cover from flapping in transit.
Do not store the tent longer than 2-3 days when wet. Open the tent to dry as
soon as possible.
If the tent is to be stored for long periods – open the tent and windows
occasionally to allow it to air and make sure it is ALWAYS stored in a dry location.
Do not store directly on a concrete floor as moisture will penetrate the tent.
Do not drag the tent over hard surfaces or damage will result.
Do not drill the ladder locating holes below the existing holes. If a longer ladder is
needed for extremely tall vehicles, please order the correct Ladder Extension --
Part No: FRTENT15
WARNING! READ ME AGAIN! NEVER EXTEND THE LADDER BEYOND THE PRE-
DRILLED HOLES AND FACTORY LOCKING POSITION. UNDER NO CIRCUMSTANCES
SHOULD YOU DRILL NEW HOLES PAST THE CURRENT HOLES. THE LADDER IS NOT
SAFE EXTENDED BEYOND THIS POINT.
