Front Runner LALD005 User manual

LALD005_REV_A00 © 2019 FRONT RUNNER VEHICLE OUTFITTERS
front runner
LALD005
ENG
1
Thank you for purchasing a Front Runner Land Rover Defender 90 / 110 Ladder.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
LAND ROVER DEFENDER 90 / 110
LADDER

LALD005_REV_A00 © 2019 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
FIGURE 1.1
GET ORGANIZED
1
2794
4685
1.0m
0.5m
5cm
Scale: 1:25 All measurements in millimeters.
IN THE BOX
1 1 X Land Rover Defender Ladder
2 2 X M6 Flat Washer
3 2 X M6 Spring Washer
4 2 X M6 x 60 Cap Srew
5 2 X M8 Nyloc Nut
6 2 X M8 Flat Washer
7 4 X M8 PVC Flat Washer
8 2 X M8 Flat Washer
9 2 X M8 x 35 Hex Bolt
10 2 X M8 Nut Cap
11 2 X M10 Nyloc Nut
12 3 X M10 x 30 x 3 SS Flat Washer
13 1 X Spacer
14 1 X M10 Flat Washer
15 1 X Bottom Step
16 1 X M10 x 80 Hex Bolt
17 1 X M10 x 100 Hex Bolt
1 2
3
4
7
7
6
5
8
10
9
13
12
11
14
15
12
16
17
13mm
17mm 6mm
8.5mm
13mm
17mm
4mm
MARKER

2794
4685
1.0m
0.5m
5cm
Scale: 1:25 All measurements in millimeters.
2021
1790
1992
2
3
4
LALD005_REV_A00 © 2019 FRONT RUNNER VEHICLE OUTFITTERS
3
FIT AND SECURE2
2.1
2.2
2.3
Remove the M6 Flat Washers, M6 Spring
Washers and M6 x 60 Cap Screws
(Item 2,3 & 4) from the Ladder (Item 1).
Swing open the Ladder's Top Clamp for
fitment and place in vehicle's gutter.
Inside the vehicle, remove the rear left
window cover and speaker box.
Place the Ladder onto the vehicle's gutter
and line up as shown in 2.2.
Check door clearance and make sure the
ladder is aligned straight with the door.
Mark the bottom two holes of the Ladder on
the vehicle's body and remove the Ladder.
Using a drill machine and a 6mm drill bit,
drill two pilot holes on your markings.
Change to a 8.5mm drill bit and drill the
holes to 8.5mm.
Place the ladder back onto the vehicle and
line up the holes in the bottom of the Ladder
with the holes drilled in 2.2.
Insert two M8 x 35 Hex Bolts and two M8
Flat washers (Item 9 & 8) through the
holes in the Ladder. Place two M8 PVC Flat
Washers (Item 7) over each bolt between the
vehicle and the Ladder. Secure on the inside
of the vehicle using two M8 Flat Washers
and two M8 Nyloc Nuts (Item 6 & 5).
Insert fixings removed earlier in 2.1 and fully
fasten.
Refit rear left window cover and speaker
box.
2794
4685
1.0m
0.5m
5cm
Scale: 1:25 All measurements in millimeters.
1
5
6
7
7
8
9
10
4mm
4mm
6mm
8.5mm
13mm
13mm

1790
1992
LALD005_REV _A00 © 2019 FRONT RUNNER VEHICLE OUTFITTERS 4
2021
1790
1992
FIT AND SECURE3
3.1
3.2
3.3
Remove the two orginal bolts from
the bumper and place the Bottom step
(Item 15) against the body, and align with
the two holes in the bumper as shown.
Refer to 3.1 & 3.2 and insert the M10 x 100
Hex Bolt with a M10 x 30 x 3 Flat Washer
(Item 17 & 12) into the right hole marked
"A". Behind the bumper insert the Spacer
(Item 13) between the bumper and the "Tab"
attached to the body/bumper. Guide the Hex
Bolt through the Spacer and loosely fasten
using a M10 x 30 x 3 Flat Washer and M10
Nyloc Nut (Item 12 &11).
For the left side marked "B", insert the
M10 x 80 Hex Bolt and M10 x 30 x 3 Flat
Washer (Item 16 & 12) and loosely fasten
using a M10 Flat Washer and M10 Nyloc Nut
(Item 14 & 11)
Align the Bottom step and Fully tighten all
bolts. To complete the job fit two M8 Nut
Caps (Item 10).
17
12
15
13
12
11
16
14
17mm
17mm
17mm
17mm
BA

INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
FINISH
3
Congratulations! You did it. Take a step back and admire your work!
