Front Runner TRCA008 User manual

ENG
Universal Track
TRCA008_REV_A02 © COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS
1
IMPORTANT WARNING!
Don’t be a hero and muscle through this without first reading these fitting instructions! Improper installation of this gear may void certain aspects of
your warranty.
Before you begin, take a moment and open all your Front Runner rack kit boxes and gather the assembly instructions for the various components.
A complete kit will contain:
1. A Front Runner Universal Mounting System
2. A Front Runner Rack Tray or Load Bar Slats
This document will guide you through the assembly of the mounting system and assist you in fitting the roof rack tray or load bars to your specific
vehicle.
Please refer to the next page for a list of all the components, quantities and tools required.
TRCA008
READ ME FIRST
START HERE!
FRONT RUNNER CAN NOT RECOMMEND A MAXIMUM LOAD CARRYING CAPACITY. PLEASE REFER TO YOUR VEHICLE MANUFACTURER'S RECOMMENDATIONS. IT IS CRITICAL
THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN
AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS
TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND DAMAGE. THEREFORE YOU
MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO INSTALLATION OR USE. IF YOU
DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE
INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

TRCA008_REV_A02 © COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS 2
IN THE BOX
FIGURE 1.1
1 4 X M6 x 30 Button Head Bolt
2 4 X M6 x 20 Button Head Bolt
3 4 X M6x12x1 Stainless Steel Flat Washer
4 4 X Track End Cap
5 2 X Track
6 2 X Protective Trim
7 4 X M6x30x1 Flat Washer
8 4 X M6 Nyloc Hex Nut
9 4 X M6 Nut Cap
10 4 X M8 x 12 Button Head Bolt
IN THE BOX TOOLS NEEDED
10 mm 4mm
5mm
Measuring
Tape
IN THE BOX
1
2
2
3
4
1
34
5
6
7
8
9
9
8
7
6
5
10
1GET ORGANIZED
Here is what you are looking at for TRCA008
Sealant Marker
6.5mm
4mm
Utility
Knife

© COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS
3 TRCA008_REV_A02
2.1
Remove the Canopy / Cap roof rails if fitted. Determine the best possible position for mounting the
tracks. Take care not to drill into or through any reinforcements.
FIT AND SECURE
2
2.6
Fit and secure the tracks with a
combination of items 1/2, 6, 7, 8.
Depending on the thickness of the
material you are bolting trough you can
use either item 1 (M6x20 Button Head)
or item 2 (M6x30 Button Head). The bolt
needs to go through the
Nyloc Nut (item 8).
Install the end-caps (Item 4) before you
do the final fitment of the tracks.
The track and protective trim (item 3 &
5) must be used on the roof and the
M6x30x1 Flat Washer (item 6) must be
used inside.
Check that all the fasteners are fully
tightened.
Place M6 nut caps (item 9) on all the M6
Nyloc Nuts (item 8) to finish of the
fitment .
10mm
2.3
Once you are happy with the placement of the track, mark all the holes using a suitable marking pen.
2.4
Drill a 4mm pilot hole on all the marks you have made. Open the pilot holes to 6.5mm.
2.2
Measure and trim the tracks to the desired length.
2.5
Apply a bead of suitable sealant to each hole drilled in step 2.4.
4mm
1
2
3
4
5
6
7
8
9
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or Online.
Roof
Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
COMPLETION
3
Congratulations. You did it. Take a step back and admire your work!
