Front Runner RRAC242 User manual

ENG
RRAC242_REV_A00 © 2023 FRONT RUNNER VEHICLE OUTFITTERS
1
Don’t be a hero and muscle through this installation without reading these fitting instructions first! Improper installation of this gear may void certain
aspects of your warranty.
Before you begin, take a moment and open all your Front Runner rack kit boxes and gather the assembly instructions for the various components.
A complete kit will contain:
1. A Front Runner Mounting System specific to your vehicle
2. A Front Runner Rack Tray or Load Bar Slats
This document will guide you through the assembly of the mounting system and assist you in fitting the roof rack tray or load bars to your specific
vehicle.
Please refer to the next page for a list of all the components, quantities and tools required.
RRAC242
READ ME FIRST
START HERE!
front runner Polaris Ranger (2018-Current)
Slimsport Rack 40"Light Bar Wind Fairing
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.

3
RRAC242_REV_A00 © 2023 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
CHECK ONLINE FOR LATEST FITMENT GUIDE WWW.FRONTRUNNEROUTFITTERS.COM
GET ORGANIZED
1
IN THE BOX
1 1 X Light Bar Wind Fairing
2 1 X Wind Fairing Support outer LHS
3 1 X Wind Fairing Support Center
4 1 X Wind Fairing Support Outer RHS
5 1 X Light Bar Bracket LHS
2
6 1 X Light Bar Bracket RHS
7 2 X Light Bar Bracket 01
8 9 X M6 x 16 Button Head Flange Bolt
9 3 X M8 x 16 x 1.6 Flat Washer
10 3 X M8 Nyloc Nut
11 3 X M8 x 20 Hex Bolt
12 3 X M8 Nut Cap
13 1 X Wind Fairing Rubber (1050mm LONG)
1
8
7
5
9
10
12
11
4
6
13
Torx
T30 Cordless
Driver 13mm

© 2023 FRONT RUNNER VEHICLE OUTFITTERS
3 RRAC242_REV_A00
FIT AND SECURE
2
2.1
2.2
2.3
Loosen and remove the front slat.
Slide The M8 x 20 Hex Bolt (Item 11) in the
the Slat that was removed in 2.1 at the
bottom and the top as shown.
Place the Wind Fairing Center support
Bracket (Item 3) on the M8 x 20 Hex Bolt
(Item 11) at the bottom of the Slat together
with the M8 Flat Washer, M8 Nyloc Nut and
M8 Nut Cap (Item 9, 10 & 12)
Centralize the Support Bracket and tighten
the M8 Nyloc nut and place the M8 Nut Cap
on the Nyloc nut.
Assemble the Light Bar Bracket L/H & R/H
(Item 5 & 7) on to the M8 x 20 Hex bolt (Item
11) together with the M8 Flat washer, M8
Nyloc Nut and M8 Nut Cap (Item 9, 10 & 12)
Refit The Front Salt that Was Removed into
the lower holes of the Foot Rail As Shown.
Assemble the Wind Fairing Outer Support
Bracket on the L/H and R/H (Item 2 & 4)side
as shown with the M6 Button Head Flange
Bolts (Item 8).
Slide The Light Bar Brackets to desired
position and fully Tighten,
Keep screws to one side to use later.
3
12
7
5
9
10
11
8
2
Torx
T30
Cordless
Driver
Torx
T30
Cordless
Driver
Torx
T30
Cordless
Driver
13mm

COMPLETION
3
3.1
Congratulations! You did it. Take a step back and admire your work!
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner dealer in person or online.
IMPORTANT!
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
FRONT RUNNER RACK KITS OFTEN HAVE A HIGHER LOAD RATING THAN THE VEHICLES THEY ARE MOUNTED TO. PLEASE REFER TO YOUR SPECIFIC VEHICLE MANUFACTURER
FOR A RECOMMENDED ROOF RATING. FRONT RUNNER CANNOT BE RESPONSIBLE FOR IMPROPER LOADING BEYOND THE VEHICLE MANUFACTURER'S STATED LOAD CAPACITY.
© 2023 FRONT RUNNER VEHICLE OUTFITTERS
4 RRAC242_REV_A00
FIT AND SECURE
2
2.4
Assemble the Wind Fairing (item 1) The the
Wind Fairinf Support Brackets (Item 2, 3 & 4)
using the M6 Button Head Flange Bolts (Item
8) as shown.
1
8
2
3
4
Torx
T30
Cordless
Driver
