FrontLine RGSS58 User manual

www.frontlinefall.com
INTRODUCTION:- debris, rot, decay, cracking, and hazardous materials.
Thank you for purchasing a Frontline RGSS58 This manual must 4. Installation, set-up, and use of Lifeline system must be done
be read and understood in its entirety, and used as part of an under the supervision of a Qualified Person.
employee training program as required by OSHA or any applicable
state agency. Installation and Use
This and any other included instructions must be made available to 1. Eliminate all risk of lower end and termination. Either ensure
the user of the equipment. The user must understand how to safely Vertical Lifeline Assembly(VLA) will prevent user from striking
and effectively use the RGSS58, and all fall safety equipment next lower level and that there is always adequate fall clearance,
used in combination with the RGSS58. or that VLA will not reach the leading edge of any fall hazard
when used at its full length. NEVER tie knot in lifeline, except
Applicable Safety Standards at extreme bottom of lifeline in order to prevent Fall Arrest from
When used according to instruction specifications, this product
2. Eliminate or minimize all risk of swing fall.
meets or exceeds ANSI Z359.1-2007 standards for fall protection.
Applicable standards and regulations depend on the type of work
3. Attach snap hook with integrated Shock Pack to compatible
being done, and also might include state-specific regulations.
anchorage connector.
Consult regulatory agencies for more information on personal fall
4. Attach snap hook with integrated Fall Arrest to applicable
arrest systems and associated components.
harness D-ring.
Worker Classifications
5. To move along lifeline, compress and hold Fall Arrest handle.
Qualified Person: A person with an accredited degree or
ALWAYS adjust Fall Arrest to reduce slack in the system as
certification, and with extensive experience or sufficient
much as possible. When attached to a Fall Arrest and moving
professional standing, who is considered proficient in planning and
along work surface, ALWAYS do so by moving Fall Arrester
reviewing the conformity of fall protection and rescue systems
along rope, and NEVER by moving only the rope itself. For
example, if moving from a roof edge to the roof peak, engage
Competent Person: A highly trained and experienced person who
is ASSIGNED BY THE EMPLOYER to be responsible for all
handle of fall Arrester and move it up the Vertical Lifeline Assembly
elements of a fall safety program, including, but not limited to, its
(VLA) while walking to peak. DO NOT move up to roof peak by
regulation, management, and application. A person who is
moving VLA and keep Fall Arrest stationary; doing so can create
proficient in identifying existing and predictable fall hazards, and
free fall in excess of levels permitted by system.
who has the authority to stop work in order to eliminate hazards.
6. To restrict Fall Arrest movement along lifeline, release Fall
Authorized Person: A person who is assigned by their employer to
Arrest handle.
work around or be subject to potential or existing fall hazards
7. Fall Arrester RGSS58 comes with an anti-panic feature which
automatically acts in case the user holds the fall arrester and
It is the responsibility of a Qualified or Competent person to
grasps it too tightly. However, care must be taken that never
supervise the job site and ensure all applicable safety
grab fall arrester in the event of fall.
regulations are complied with.
8. NEVER work above the Fall Arrester unless free fall is limited to
IMPORTANT BEFORE INSTALLATION AND USE :-
6' or less.
Prior to use, plan your system:
WARNING: One connection per Vertical Lifeline Assembly(VLA).
1. Ensure all PFAS equipment is selected and deemed
NEVER attempt to remove components from VLA.
compatible by a Competent Person.
2. Eliminate or minimize all risk of swing fall.
Do not alter & misuse the equipment.
3. Determine desired location for Lifeline; ensure location is free of
Applicable to : RGSS58
Manufacturer :
Certification Body : SATRA Technology Centre Kettering, Northants, UK
(Notified Body 0321)
Ongoing Assessment Body : SGS United Kingdom Ltd., Unit 202B, Worle Parkway,
Weston-super-Mare, BS22 6WA, UNITED KINGDOM.
(Notified Body 0120)
USER INSTRUCTIONS
Do not skip this instruction manual. Read the instruction manual carefully before using the equipment. If failed in doing so
it may cause serious Injury or Death.
Page 1 of 4
RGSS58
Loosen the
Nut for Opening
the Fall Arrester
Flange
Direction of Usege
Press the
safety clip
of the Fall
Arrester
Direction of Usege
Direction of Usege
Rope
Fall Arrester
Follow these steps to install the Fall Arrester
detaching.

RGSS58
NOTE:- ØEquipment that fails inspection in any way must immediately be
removed from use, or repaired by an entity approved by the
ØWorkplace conditions, including, but not limited to, flame, manufacturer.
corrosive chemicals, electrical shock, sharp objects,
machinery, abrasive substances, weather conditions, and ØNo on-site repair of equipment unless explicitly permitted by the
uneven surfaces, must be assessed by a Competent Person manufacturer.
before fall protection equipment is selected.
ØEquipment subjected to forces of fall arrest must immediately
ØThe analysis of the workplace must anticipate where workers be removed from use. Snap hooks, carabiners, and other
will be performing their duties, the routes they will take to reach connectors must be selected and applied in a compatible
their work, and the potential and existing fall hazards they may fashion. All risk of disengagement must be eliminated. All snap
be exposed to. Fall protection equipment must be chosen by a hooks and carabiners must be self-locking and self-closing, and
Competent Person. Selections must account for all potential must never be connected to each other.
hazardous workplace conditions. All fall protection equipment
should be purchased new and in an unused condition. ØAge, fitness, and health conditions can seriously affect the
worker should a fall occur. Consult a doctor if there is any
ØFall protection systems must be selected and installed under reason to doubt a user's ability to withstand and safely absorb
the supervision of a Competent Person, and used in a fall arrest forces or perform set-up of equipment.
compliant manner.
ØPregnant women and minors must not use this equipment.
ØFall protection systems must be designed in a manner Physical harm may still occur even if fall safety equipment
compliant with all federal, state, and safety regulations. functions correctly. Sustained post-fall suspension may result in
serious injury or death. Use trauma relief straps to reduce the
ØForces applied to anchors must be calculated by a Competent effects of suspension trauma. Allowable individual worker
Person. weight limit (including all equipment), unless explicitly stated
otherwise, is 40-100 kgs..
ØHarnesses and connectors selected must be compliant with
manufacturer's instructions, and must be of compatible size MAINTENANCE, CLEANING, AND STORAGE
and configuration.
Ø
ØA pre-planned rescue procedure in the case of a fall is required.
The rescue plan must be project specific. The rescue plan must
Repairs to RGSS58 can only be made by an entity authorized by the
allow for employees to rescue themselves, or provide an
manufacturer. A RGSS58 fails inspection in any way, immediately
alternative means for their prompt rescue.
ØCleaning after use is important for maintaining the safety and
ØStore rescue equipment in an easily accessible and clearly
longevity of RGSS58.
marked area.
ØRemove all dirt, corrosives, and contaminants from RGSS58
ØTraining of Authorized Persons to correctly erect, disassemble,
before and after each use. If RGSS58 cannot be cleaned with
inspect, maintain, store, and use equipment must be provided
plain water, use mild soap and water, then rinse and wipe dry.
by a Competent Person.
NEVER clean RGSS58 with corrosive substances.
ØTraining must include the ability to recognize fall hazards,
ØWhen not in use, store equipment where it will not be affected by
minimize the likelihood of fall hazards, and the correct use of
heat, light, excessive moisture, chemicals, or other degrading
personal fall arrest systems.
elements.
ØNEVER use fall protection equipment of any kind to hang, lift,
LIMITATIONS
support, or hoist tools or equipment, unless explicitly certified
for such use. Fall Clearance: There must be sufficient clearance below the
anchorage connector to arrest a fall before the user strikes the
ØMaintenance of equipment must be done according to
ground or an obstruction. When calculating fall clearance, account
manufacturer's instructions. Equipment instructions must be
for a MINIMUM 3' safety factor, deceleration distance, user height,
retained for reference.
length of lanyard/SRL, and all other applicable factors.
ØPrior to EACH use, all equipment in a fall protection system
Swing Falls: Prior to installation or use, make considerations for
must be inspected for any potential or existing deficiencies that
eliminating or minimizing all swing fall hazards. Swing fall occurs
may result in its failure or reduced functionality. IMMEDIATELY
when the anchor is not directly above the location where a fall
remove equipment from service if any deficiencies are found.
occurs. Always work close or in line with anchor point as possible.
Swing falls significantly increase the likelihood of serious injury or
ØEquipment must be inspected by a Competent Person at least
death in the event of a fall.
every six months. These inspections must be documented in
equipment instruction manual and on equipment inspection
Compatibility: When making connections with RGSS58,
grid label.
eliminate all possibility of roll-out. Roll out occurs when interference
ØEquipment must be inspected for defects, including, but not
limited to, the absence of required labels or
closing and self-locking and withstand minimum load of 3600 lbs.
markings, improper form/fit/function, evidence of cracks, sharp
edges, deformation, corrosion, excessive heating, alteration,
Vertical Lifeline Assembly (VLA): Specific Applications
excessive wear, fraying, knotting, abrasion, and absence of
parts.
Page 2 of 4
Direction of Usege
Close the flange and
Tighten the screw nut
Direction of Usege
Now, Connect The
System with your
Harness using a
carabiner and the
System is ready for
use
Now Install the Rope
Into The Fall Arrester
Direction of Usege
remove it from service, and contact manufacturer to inquire about
its return or repair.
between a hook and the attachment point causes the hook gate to
unintentionally open and release. All connector gates must be self

RGSS58
WARNING: Use of equipment in unintended applications may Personal Fall Arrest: RGSS58 may be used to support a
result in serious injury or death. Maximum 1 attachment per MAXIMUM 1 Personal Fall Arrest Systems (PFAS) for use in Fall
connection point. Arrest applications. Structure must withstand loads applied in the
directions permitted by the system of at least 15kN.
Personal Fall Arrest: RGSS58 may be used in Personal Fall Arrest
applications to support a MAXIMUM 1 Personal Fall Arrest System Restraint: RGSS58 may be used in Restraint applications.
(PFAS). Structure must withstand loads applied in the directions Restraint systems prevent workers from reaching the leading edge
permitted by the system of at least 5,000 lbs. of a fall hazard. Always account for fully deployed length of
lanyard/SRL. Structure must withstand loads applied in the
Restraint: VLA may be used in Restraint applications. Restraint directions permitted by the system of at least 15kN. No free fall is
systems prevent workers from reaching the leading edge of a fall permitted.
hazard. Always account for fully deployed length of lanyard/ VLA.
Structure must withstand loads applied in the directions permitted. For all applications: worker weight capacity range (including
Restraint system may only be used on surfaces with slopes up to all clothing, tools, and equipment) is 310 lbs.
4/12 (vertical horizontal). Applicable D-rings: NEVER for simultaneous use in Fall Arrest and Restraint
For all applications: worker weight capacity range (including all Swing Falls: Prior to installation or use, make considerations for
clothing, tools, and equipment) is 130-310 lbs. eliminating or minimizing all swing fall hazards. Swing falls occur
VLA: Inspection when the anchor is not directly above the location where a fall
occurs. Always work as close to in line with the anchor point as
KEEP INSTRUCTIONS AVAILABLE FOR REFERENCE. possible. Swing falls significantly increase the likelihood of serious
injury or death in the event of a fall.
Record date of first use
Compatibility: When making connections with RGSS58,
Prior to each use, inspect the VLA for deficiencies, including, but not eliminate all possibility of roll-out. Roll-out occurs when interference
limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp between a hook and the attachment point causes the hook gate to
edges, cracking, rust, paint buildup, excessive heating, alteration, unintentionally open and release. All connections must be selected
broken stitching, fraying, bird caging, and missing or illegible labels. and deemed compatible with RGSS58 by a Competent Person.
IMMEDIATELY remove VLA from service if defects or damage are
found, or if exposed to forces of fall arrest.
Ensure that applicable work area is free of all damages, including,
but not limited to debris, rot, rust, decay, cracking, and hazardous
materials. Ensure that selected work area will support the
application–specific minimum loads set forth in this instruction
manual. Work area must be stable.
At least every 6 months, a competent person other than the user must
inspect VLAs. Competent Person inspection MUST be recorded in
instruction manual and on equipment inspection grid label. The
Competent Person must sign their initials in the box corresponding
to the month and year the inspection took place.
During inspection, consider all application
INSPECTION
ØKEEP INSTRUCTIONS AVAILABLE FOR REFERENCE.
Record Date of First Use
ØPrior to EACH use, inspect RGSS58 for deficiencies,
including, but not limited to, corrosion, deformation, pits, burrs,
rough surfaces, sharp edges, cracking, rust, paint buildup,
excessive heating, alteration, broken stitching, fraying, bird-
caging, and missing or illegible labels. IMMEDIATELY remove
RGSS58 from service if defects or damage are found, or if
exposed to forces of fall arrest.
ØEnsure that applicable work area is free of all damage,
including, but not limited to, debris, rot, rust, decay, cracking,
and hazardous materials. Ensure that selected work area will
support the application-specific minimum loads set forth in this
instruction manual. Work area MUST be stable.
ØAt least every 6 months, a Competent Person other than the
user must inspect RGSS58. Competent Person
inspections MUST be recorded in inspection log in
instruction manual and on equipment inspection grid
label. The Competent Person must sign their initials in the
box corresponding to the month and year the inspection
took place.
ØDuring inspection, consider all applications and hazards
RGSS58 have been subjected to.
PRODUCT SPECIFIC APPLICATIONS
WARNING: Use of equipment in unintended applications may
result in serious injury or death. Maximum 1 attachment per
connection point
Page 3 of 4
Markings
The Fall Arrester is marked with :
(i) Identification of the
manufacturer
(ii) Type or product code & Ref. No
(iii) Batch No / Year of Manufacture
(iv) Read the manufacturer's
instruction before use.
(v) Minimum Breaking Strength
UP
Ø16mm
(5/8" dia)
Polyester/PP
ANSI Z359.1-07
RGSS58

RGSS58
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.
INSPECTION LOG
User must inspect prior to EACH use. Competent Person other than user must complete formal inspection at least every 6 months.
Competent Person to inspect and fill the initial in the below inspections log.
Date of First Use: __________________. Product lifetime is 10 years from Date of First Use, or, if not recorded, from Date of Manufacture, as
long as it passes pre-use and Competent Person inspections.
DISCLAIMER- This information on the product is based upon technical data that Frontline obtained under laboratory conditions and believes
to be reliable. Frontline does not guarantee results and take no liability or obligation in connection with this information. As conditions of end
use are beyond our control it is the user's responsibility to determine the hazard levels and the use of proper personal protective equipment.
Persons having technical expertise should undertake evaluation under their own specific end-use conditions, at their own discretion and
risk. Please ensure that this information is only used to check that the product selected is suitable for the intended use. Any product that is
damaged, torn worn or punctured should be discontinued from usage immediately.
Page 4 of 4
EQUIPMENT RECORD
Product :
Model & type/Identification Trade Name Identification number
Manufacturer Address Tel, fax, email into use
Year of manufacture Purchase Date Date first put into use
Other relevant information (e.g. document number)
PERIODIC EXAMINATION AND REPAIR HISTORY
Date Reason for entry Defects noted, repairs Periodic examination
(periodic examination carried out and other
Name and signature
of competent person next due date
or repair) relevant information
