FUFU & GAGA KF200198-01 User manual

ersion:05/27/2022
Shoe Cabinet
V1/11

please read the entire manual before starting to assemble
and/or using this product.follow the manual thoroughly and
keep it for further reference.
IMPORTANT INFORMATION!
It is important that any product which is assembled using any kind of screw is re-tightened
2 weeks after assembly,and once every 3 months - in order to assure stability through-out
the lifespan of the product.
For regular maintenance and cleaning of the product, for the frame, please use a rag dipped
in neutral detergent to fully wipe it, and then dry it with a clean rag.For glass materials, wipe
with a rag dampened with water glass cleaner, and then dry with a dry rag.
Do not use an electric screwdriver, and do not use too much force when installing, because
the board is easy to break.
IMPORTANT !
Overturned furniture can cause serious or fatal crush injuries. To prevent tipping over, be sure
to use the wall attachment, if not included with this product. Please purchase the wall
attachment that fit your wall. If unsure, seek professional advice. Please read and follow each
step of the instructions carefully.
ANTI-TOPPLE WARNING !
Try to find a partner to install
with you, which can speed up
the installation efficiency and
shorten the time.
IMPROVE EFFICIENCY !
In order to avoid scratching this
furnuture should be assembled
on a soft layer-could be a rug.
AVOID SCRATCHES!
2/11

6 x 30 mm
When installing, please carefully confirm whether
each screw corresponds to the manual, accessories
with similar shapes can be distinguished by size
Please prepare the following tools
3/11
A x 4
4 x 40 mm
B x 17 C1 x 6 C2 x 6
C3 x 6
3.5 x 14 mm
D x 36
4 x 10 mm
E x 6
4 x 20 mm
F x 6
G x 3 J1 x 1
2.5 x 14 mm
I x 10
L x 3 R x 3
1.5mm
6 x 30 mm4 x 12 mm
H x 4
J2 x 1 J3 x 1

4/11
x3
5
2
9
77
8
5
1
3
4
6

D x 6
3.5 x 14 mm
2
5/11
D x 24 F x 6 G x 3 L x 3 R x 3
3.5 x 14 mm 4 x 20 mm
1
ED
3.5 x 14 mm 4 x 10 mm
D
L
D
R
8
D
D
L
Fix plastic part(L&R)to panel 8 using screw(D)as shown.
Attach panel 7 to the assembled part using
screw(D)slightly to tighten, as shown.
D
Attach this part to panel 6 using screw(D)to corresponding holes as shown.
Fix handle(G)to panel 6 using screw(F).
x3
R
L
F
F
G
D
D
D
D
D
R
8
6
x3
LD
D
R
6
7

C1 x 6 C2 x 6
A x 2 B x 8 J1 x 1 J2 x 1
6 x 30 mm 4 x 40 mm 4 x 12 mm
C1
C1
C1
C1
C1
C1
C2
C2
C2
C2
C2
C2
2
3
A
A
B
B
B
B
B
B
B
B
B
13
5
9
5
J1
J2
J2
C2
C1
6/11
3
4
Knock part(C1,C2)slightly
into the holes in panel 2&3
as shown.
Fix part(J1)to panel 1 using screw(J2). Connect panel
1 with panel 3 using wooden dowel(A)at first. Then
use screw(B)to tighten, as shown.
Attach panel 5 and 9 to panel 3 using screw(B)
as shown.
3

7/11
A x 2 B x 8
6 x 30 mm 4 x 40 mm
1.5 mm
5
H x 4 I x 10
6
2.5 x 14 mm
A
A
B
B
B
B
B
B
B
B
1
2
3
5
9
5
B
H
H
H
H
I
I
I
I
I
I
I
II
3
2
4
I
I
1
Attach panel 2 to assembled part in step 4,
using screw(B)and wooden dowel(A)
Fix panel 4 to the back of assembled unit
using screw(I)as shown.
Knock part(H)into the bottom.
as shown.
2

B x 1 J3 x 1
4 x 40 mm 6 x 30 mm
wall
1
B
7
8/11
WALL
WALL
J3
Install anti-tipping device with part(J3) and screw(B)
as shown.

C3 x 6
4 x 10 mm
E D
3.5 x 14 mm
4 x 10 mm
8
9/11
E x 6
Fix the plastic part(L&R)to panel 2&
3 by using (C3)slightly.
Then screw(E)to tighten as shown.
wall
2
L
3
C3 E
R
C3
E
L
C3 E
R
C3
E
L
C3 E
R
C3
E
6
C3
E
6
6

9
10/11
Insert panel 7 to the middle of drawers
wall
7
7
7

D x 6
3.5 x 14 mm
10
11/11
Using screw(D)to fix panel 7 to both
side plastic part as shown.
wall
7
7
7
D
D
L
R
D
D
L
R
D
D
L
R
D
ED
3.5 x 14 mm 4 x 10 mm
