FUFU & GAGA KF180131-01 User manual

Dining Set
KF180131-01
1/24

2/24

Ax8 Bx8 Cx8 Dx8
Ex8 Fx8 Gx8 Hx4
Jx2 Kx8 Lx32
5 x 31 mm 15 x 11 mm
3 x 12 mm
Mx8
3.5x14mm
Nx2
6 x 37 mm
7 x 34 mm
6 x 12 mm
3/24

1
2
3
4
4
4
4
5
5
6
6
6
6
1
7
11
8
12
10
x4
4/24

1Mx8 Jx2
3
J
J
M
J
3 3
M
M
Fix telescopic slide rail(J) to part 3
using screw(M) as shown.
Please pay attention the holes where
screws in.
3.5 x 14 mm
M
M
M
M
M
M
MMM
5/24

2
1
1
Connect two plate 1 together at first.
6/24

3Ex8
E
E
E
E
1
1
3
E
EE
E
E
EE
E
Attach part 3 to plate 1 by
fixing slid rail using screw(E)
as shown.
3 x 12 mm
7/24

Ax8
4
Ax2
Ax2
Ax2
Ax2
Ax2
3
1
1
Insert quickfit screw(A) into two plate 1
with a screwdriver as shown.
5 x 31 mm
8/24

5Bx8
4
4
4
B
3
1
1
B4
B
B
B
B
B
B
B
9/22
Attach plate 4 to two plate 1 at first.
Put cam lock(B) into holes in plate 4,
and turn clockwise to tighten as shown.
15 x 11 mm
9/24

Fx8
6Gx8
F
F
G
G
5
5
5
4
4
4
4
G
G
G
G
G
G
F
F
F
F
FF
F
F
Insert nut(G) into holes in plate 4 at first.
Fix plate 5 to plate 4 using screw(F) as shown.
10/24

D
D
6
6
6
6
x4
3
1
1D
D
Fix leg 6 to four corners of part 3
using screw(D) as shown.
7 x 34 mm
DX8
11/24

Hx4
8
H
H
H
H
6
6
6
6
3
1
1
Fix part(H) to leg 6 as shown.
12/24

9
1
1
Pressing the switch in slide rail(J) will
not be able to pull out plate 1.
13/24

2
10 Nx2
N
N
N
14/24

11
1
1
3
Lifting the switch in slide rail(J)
will be able to pull out plate 1.
15/24

12
2
Cx8
C
1
1
Put plate 2 in the middle, and connect
with plate 1.
Use sticker(C) to cover cam lock holes.
16/24

13
1
1
2
Pressing the switch in slide rail(J)
will not be able to pull out plate 1 and 2.
17/24

14
2
2
1
1
1
1
Take out plate 2 and put it on plate 5,
then push plate 1 inward.
18/24

15
2
2
1
1
1
1
19/24

Kx8
16
11
7
8
K
K
x4
Fix leg component 7 and 11 with plate 8
using screw(K) as shown.
Please do not tighten the screws completely,
just 75%.
6 x 37 mm
20/24
