TX2550 M4 Operating Manual
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.
High safety use
This product has been designed and manufactured to be used in commercial
and/or industrial areas as a server.
When used as visual display workplace, it must not be placed in the direct field
of view to avoid incommoding reflections (applies only to TX server systems).
The device has not been designed or manufactured for uses which demand an
extremely high level of safety and carry a direct and serious risk of life or body
if such safety cannot be assured.

Operating Manual TX2550 M4
These uses include control of nuclear reactions innuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance
control in weapons systems (hereafter, "high safety use"). Customers should
not use this product for high safety use unless measures are in place for
ensuring the level of safety demanded of such use. Please consult the sales
staff of Fujitsu if intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. Toprevent a momentary voltage drop, use of an AC
uninterruptible power supply isrecommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for Japan:
About SATAHDDs
The SATAversion of this server supports HDDs with SATA / BC-SATAstorage
interfaces. Please note that the usage and operation conditions differ
depending on the type of HDD used.
For more information on the usage and operation conditions of each available
type of HDD, see the following internet address:
http://jp.fujitsu.com/platform/server/primergy/harddisk/

TX2550 M4 Betriebsanleitung
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups for this manual . . . . . . . . . . 9
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 11
2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 13
2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 22
3 Installation steps, overview . . . . . . . . . . . . . . . . . . 31
4 Important information . . . . . . . . . . . . . . . . . . . . . 33
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 43
4.4 Environmental protection . . . . . . . . . . . . . . . . . . . 44
5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 47
5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 48
5.2 Setting up the floorstand model . . . . . . . . . . . . . . . . 49
5.3 Installing/removing the server in/from the rack . . . . . . . 50
5.4 Connecting devices to the server . . . . . . . . . . . . . . . 51
5.5 Connecting the server to the mains . . . . . . . . . . . . . . 55
5.5.1 Using the cable clamp . . . . . . . . . . . . . . . . . . . . . . 56
5.6 Notes on connecting/disconnecting cables . . . . . . . . . 57

Betriebsanleitung TX2550 M4
Contents
6 Starting up and operation . . . . . . . . . . . . . . . . . . . . 59
6.1 Access to the drives (floorstand model) . . . . . . . . . . . . 59
6.1.1 Enabling access to the accessible drives . . . . . . . . . . . . . 59
6.1.2 Access to the HDD modules (floorstand model) . . . . . . . . . 60
6.2 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 61
6.2.1 Server front . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.2.1.1 Controls on the front panel . . . . . . . . . . . . . . . . . . 61
6.2.1.2 Indicators on the front panel . . . . . . . . . . . . . . . . . . 62
6.2.1.3 Indicator on the ODD . . . . . . . . . . . . . . . . . . . . . 65
6.2.1.4 Indicators on the hot-plug HDD/SSD module . . . . . . . . . 66
6.2.2 Server rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.2.2.1 Indicators on the I/O panel . . . . . . . . . . . . . . . . . . 67
6.2.2.2 Indicators on PSUs (slide-in units) . . . . . . . . . . . . . . 71
6.3 ID card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
6.4 Switching the server on and off . . . . . . . . . . . . . . . . 73
6.5 Configuring the server . . . . . . . . . . . . . . . . . . . . . 76
6.5.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 76
6.5.2 Configuring the SAS/SATA RAID controller . . . . . . . . . . . . 77
6.5.3 Configuring the server and installing the operating system
with the ServerView Installation Manager . . . . . . . . . . . . . 78
6.5.4 Configuring the server and installing the operating system
without the ServerView Installation Manager . . . . . . . . . . . 79
6.6 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 80
7 Property and data protection . . . . . . . . . . . . . . . . . . 81
7.1 BIOS setup security functions . . . . . . . . . . . . . . . . . 81
8 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 83
8.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 83
8.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 84
8.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 84
8.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 85
8.5 No screen display or display drifts . . . . . . . . . . . . . . . 85

TX2550 M4 Betriebsanleitung
Contents
8.6 No mouse pointer displayed on screen . . . . . . . . . . . . 85
8.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . 86
8.8 System will not boot . . . . . . . . . . . . . . . . . . . . . . 86
8.9 HDD error messages at system boot . . . . . . . . . . . . . 86
8.10 Added drive is reported as defective . . . . . . . . . . . . . 87
8.11 Error message on screen . . . . . . . . . . . . . . . . . . . 87
8.12 Expansion cards or onboard devices not recognized . . . . 87
8.13 Temperature warning . . . . . . . . . . . . . . . . . . . . . . 88
8.14 No effect of keyboard or mouse . . . . . . . . . . . . . . . . 88
8.15 ODD cannot read data . . . . . . . . . . . . . . . . . . . . . 88

Betriebsanleitung TX2550 M4
Contents

TX2550 M4 Operating Manual 9
1 Introduction
PRIMERGY TX2550 M4 floorstand model
The PRIMERGY TX2550 M4 is a no compromise floorstand model with
maximum levels of performance, expandability and availability.
The new modular concept supports excellent expandability with up to 32 2.5-
inch HDDs or up to 12 3.5-inch HDDs, up to 10 PCIe Gen 3 cards and up to
1536 GB memory. Moreover the 2 hot-plug PSUs with up to 94% efficiency and
the new power management, will result in lower operational costs. Thanks to the
upgrade kits as well as the cost-saving LAN options, the TX2550 M4 is
prepared for future requirements. TX2550 M4 is ideal for database,
consolidation or high performance computing scenarios.
PRIMERGY TX2550 M4 rack model
The PRIMERGY TX2550 M4 rack model is a 4U rack server with maximum
levels of performance, expandability and availability.
The new modular concept supports excellent expandability with up to 32 2.5-
inch HDDs or up to 12 3.5-inch HDDs, up to 10 PCIe Gen 3 cards and up to
1536 GB memory. Moreover the 2 hot-plug PSUs with up to 94% efficiency and
the new power management, will result in lower operational costs. Thanks to the
upgrade kits as well as the cost-saving LAN options, the TX2550 M4 is
prepared for future requirements. TX2550 M4 is ideal for database,
consolidation or high performance computing scenarios.
The floorstand model can be converted to a rack model using an optional
conversion kit.
1.1 Concept and target groups for this manual
This operating manual describes how to install, set up and operate your server.
This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the
information you need to put your PRIMERGY TX2550 M4 into operation.
To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.

10 Operating Manual TX2550 M4
Introduction
1.2 Documentation overview
More information on your PRIMERGY TX2550 M4 can be found in the following
documents:
– "Quick Start Hardware - FUJITSU Server TX2550 M4" leaflet
– ServerView Quick Start Guide
– "Safety Notes and Regulations" manual
"安全上のご注意 " for Japan
– "Warranty" manual
"保証書 " for Japan
– "ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual and "Service Desk" leaflet
"サポート＆サービス " for Japan
– "FUJITSU Server PRIMERGY TX2550 M4 Server Upgrade and
Maintenance Manual"
– "D3386 BIOS Setup Utility for FUJITSU Server PRIMERGY TX2550 M4
Reference Manual"
– "iRMC S5 - Concepts and Interfaces" user guide
– "iRMC S5 - Configuration and Maintenance" user guide
– "iRMC S5 - Web Interface" user guide
– "ServerView embedded Lifecycle Management (eLCM)" user guide
– "Integrated RAID for SAS User Guide"
– "LSI MegaRAID - SAS Software User Guide"
– "Modular RAID Controller / Modular SAS HBA Installation Guide"

TX2550 M4 Operating Manual 11
Introduction
IAll documentation on PRIMERGY hardware and ServerView software is
available online from the Fujitsu manuals server at:
http://manuals.ts.fujitsu.com
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy/manual/
The complete PRIMERGY documentation set can also be downloaded
as a DVD ISO image at:
ftp://ftp.ts.fujitsu.com/images/serverview/manuals
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy/downloads/
Further sources of information:
– ServerView Suite Glossary
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system
1.3 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

12 Operating Manual TX2550 M4
Introduction

TX2550 M4 Operating Manual 13
2 Functional overview
This section provides information on the features and technical data of the
PRIMERGY TX2550 M4 server. For information on key characteristics and
layout of the system board, see the "FUJITSU Server PRIMERGY TX2550 M4
Server Upgrade and Maintenance Manual".
2.1 Features
Customer Self Service (CSS)
The PRIMERGY Customer Self Service (CSS) concept enables you to identify
and replace the affected component yourself in the case of certain error
scenarios.
In the CSS concept, you can replace the following components yourself in the
event of an error:
– Hot-plug HDD/SSD modules
– Hot-plug PSUs
– Memory modules
– System fans
– Expansion cards
For information on replacing these components, see the "FUJITSU Server
PRIMERGY TX2550 M4 Upgrade and Maintenance Manual".
CSS indicators on the control panel and on the back of the PRIMERGY server
provide you with information if a CSS event arises.
In addition, CSS errors are displayed in the ServerView Operations Manager,
the server management software from Fujitsu.
In the event of errors, the ServerView Operations Manager refers you directly
to the affected component and its order information in the Illustrated Spares
catalog of the server in question. (This feature is not available for Japan.)
IFurther information on the CSS concept is provided in the "PRIMERGY
ServerView Suite Local Service Concept - LSC" manual on the Fujitsu
manuals server.

14 Operating Manual TX2550 M4
Functional overview
For the latest information on optional products provided for the
TX2550 M4 see the configurator of the server:
http://ts.fujitsu.com/products/standard_servers/index.html
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy/
System board
The features of the system board are described in the "FUJITSU Server
PRIMERGY TX2550 M4 Upgrade and Maintenance Manual", the setup
possibilities are described in the "D3386 BIOS Setup Utility for FUJITSU Server
PRIMERGY TX2550 M4 Reference Manual".
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the BIOS system (for more information, refer to the
“D3386 BIOS Setup Utility for FUJITSU Server PRIMERGY TX2550 M4
Reference Manual").
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.

TX2550 M4 Operating Manual 15
Functional overview
Slots for expansion cards
The server can be flexibly expanded via six full hight PCIe Gen3 low profile
adapters (3 PCIe x8, 3 PCIe x16).
One horizontal chassis slot is occupied by the OCP module.
For more information on the OCP module, see the associated documentation.
HDDs/SSDs
The server is shipped with one of the following drive cages:
– For up to twelve 3.5-inch SAS/SATA HDDs:
Up to twelve SAS HDD modules can be used in the drive cage. Each HDD
module can accommodate a SAS HDD with a maximum height of 1 inch.
The module is connected to the SAS backplane wirelessly. This allows
HDD/SSD modules to be plugged in and pulled out easily.
Optionally, you can also install a HDD expansion box (Multibay 2, see also
section "Accessible drives / components" on page 16) (with up to four 3.5-
inch SAS/SATA HDD modules). The HDD in this expansion box are
controlled by a SAS expansion card or by a second 8-Port RAID Controller.
– For up to thirty-two 2.5-inch SAS HDDs/SSDs:
Up to thirty-two SAS HDD/SSD modules can be used in the drive cage. Each
HDD/SSD module can accommodate an SAS HDD/SSD with a 2.5-inch
format. The module is connected to the SAS backplane wirelessly. This
allows HDD/SSD modules to be plugged in or pulled out easily.
Optionally, you can also install a HDD expansion box (with up to eight 2.5-
inch SAS HDD/SSD modules). An additional SAS controller must be
installed in order to control the HDDs in this expansion box. The HDDs in this
expansion box are controlled by a SAS expansion card or by a second 8-
Port RAID Controller.
IHybrid configurations of SAS and SATA HDD/SSD modules are not
supported.

16 Operating Manual TX2550 M4
Functional overview
Onboard SATA controller
One SATA controller is integrated on the system board; up to four SATA HDDs
can be connected to the controller. The LSI Embedded MegaRAID software
(Software RAID) supports RAID levels 0, 1 and 10.
For more information on configuring the controller, see section "Configuring the
onboard SATA controller" on page 76.
SAS/SATA RAID controller
The server is available with the following SAS/SATA RAID controllers for
operating the internal SAS/SATA HDDs:
– Modular RAID 0/1 controller with "MegaRAID functionality"
(SAS MegaRAID) for SAS1.0 and SAS2.0
RAID levels 0, 1 and 10 are supported for internal HDD configurations.
– Modular RAID 5/6 controller with "MegaRAID functionality"
(SAS MegaRAID) for SAS1.0 and SAS2.0
RAID levels 0, 1, 10, 5, 50, 6 and 60 are supported for internal HDD
configurations. As an option, a flash backup unit (FBU) can save the
memory content even if the power fails. Cache memory size of 1 Gbyte or
2 Gbyte is available.
IFor more information on configuring the controller, see section
"Configuring the SAS/SATA RAID controller" on page 77.
For more information on SAS/SATA RAID controllers, see the "Modular
RAID Controller Installation Guide" (on the Fujitsu manuals server under
x86 Servers - Expansion Cards - Storage Adapters - LSI SAS / SCSI RAID
Controllers).
For more information on other SAS/SATA RAID controllers (e.g. for
operating external SAS/SATA HDDs or tape drives), see the Fujitsu
manuals server under x86 Servers - Expansion Cards - Storage Adapters -
LSI SAS / SCSI RAID Controllers.
Accessible drives / components
With most configurations the TX2550 M4 offers 3 x 1.6-inch bay in the
accessible drives area located at the top of the floorstand model (or at the right
side of the rack) for various ODD and or backup drives.

TX2550 M4 Operating Manual 17
Functional overview
USB connectors
Two USB 3.0 connectors on the front of the device support activities carried out
by the service technician. The maximum length of the external cable is two
meters for the USB connectors on the front.
Another four USB connectors are available on the rear of the device
(4x USB 3.0).
Power supply unit (PSU)
The server can be equipped with up to two AC PSUs.
In its basic configuration, the server has one PSU that adjusts automatically to
any mains voltage in the range of 100 V - 240 V (AC PSUs Platinum) or
200 V - 240 V (AC PSU Titanium, 800 W). Besides the PSU, a second PSU can
be installed optionally to serve as a redundant power supply. If one PSU fails,
the second PSU in the redundant configuration ensures operation can continue
uninterrupted and the defective PSU can be replaced during operation (hot-
plug).
Advanced Thermal Design
The Advanced Thermal Design option allows you to operate the system with a
wider temperature range either of 5 °C to 40 °C or 5 °C to 45 °C, depending on
your system and configuration.
VCAUTION
In a system that is configured with Advanced Thermal Design, only
certain components which support the respectively increased higher
operating temperature range may be installed and used. For applicable
restrictions, please refer to the official configurator tool.
This option can only be ordered from the
manufacturer and is indicated by the respective
logo on the identification rating plate.

18 Operating Manual TX2550 M4
Functional overview
High level of availability and data security
When memory data is accessed, 1-bit errors are identified in the main memory
and automatically corrected with the error correcting code (ECC) method. The
patented memory scrubbing function regularly starts up the EDC mechanism,
ensuring continuous data integrity.
The memory modules used support SDDC technology (Chipkill™), which
further increases the effectiveness of memory error monitoring and correction.
Support is likewise provided for hot-spare memory technology, in which a
memory bank is used like a replacement bank. If a memory module fails, the
bank with the defective memory is automatically deactivated and the
replacement bank is activated (provided it has been configured for appropriately
in the BIOS). The deactivated memory bank is no longer used and the faulty
memory module can be replaced at the next opportunity. In order to be able to
use the hot-spare memory function, all occupied memory banks should be
equipped with identical memory modules.
Memory modules can be protected against failure by mirroring (Memory
Mirroring). Memory Mirroring is roughly comparable to RAID level 1 for HDD
arrays. The basic configuration requires two identical memory modules in two
different banks.
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the event of an error and automatically "hides" the defective system
components.
The PDA (Prefailure Detection and Analysis) technology from Fujitsu analyzes
and monitors all components that are critical for system reliability.
The SAS/SATA RAID controller supports different RAID levels and increase the
availability and data security of the system.
iRMC S5 with integrated management LAN connector
The iRMC S5 (integrated Remote Management Controller) resides on the
system board with integrated management LAN connector and expanded
functionality. The iRMC S5 enables complete control of PRIMERGY servers,
regardless of system status, and thus particularly the control of PRIMERGY
servers that are in the "out-of-band" system status.
Major functions supported by the iRMC S5 include the following:
●Browser access via iRMC S5´s own Web server
●Secure communication (SSH, SSL)

TX2550 M4 Operating Manual 19
Functional overview
●Power Management for the managed server (depending on its system
status)
●Power Consumption Management
●Connecting virtual drives as remote storage
●Text-based and graphic console bypass (Advanced Video Redirection)
●Remote Storage
●Command Line Interface (CLI)
●Simple, interactive or script-based iRMC S5 configuration
●Customer Self Service (CSS)
●iRMC S5´s own user management
●Multi-computer, global iRMC S5 user administration using an LDAP
Directory Service
●Automatic network configuration via DNS / DHCP
●Power supply of the iRMC S5 via the system standby supply
●Full-coverage alarm management
●System Event Log (SEL) reading and processing
●IPMI support
●CIM / WS-MAN support
●Internal Event Log for user login / logout auditing
More information about the iRMC S5 can be found in the iRMC S5 user guides
(on the Fujitsu manuals server under x86 Servers - Software - ServerView Suite -
Out-Of-Band Management).
Server management
Server management is implemented using the ServerView Operations Manager
supplied and the PDA (Prefailure Detection and Analysis) technology from
Fujitsu. PDA reports the threat of a system error or overload at an early stage,
allowing preventive measures to be taken.
The ServerView Operations Manager enables the management of all
PRIMERGY servers in the network via a central console. The ServerView
Operations Manager supports the following functions:

20 Operating Manual TX2550 M4
Functional overview
●Round-the-clock monitoring, regardless of server status
●High-performance, graphical console bypass (AVR) protected by
HTTPS/SSL (128 bit)
●Remote storage via USB
●Remote power on
●Intrusion detection in the floorstand model
●Temperature monitoring of the CPU and the surrounding area
●Detailed status and error reports for CPUs and main memory
●Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event that memory modules or CPUs fail
●Power monitoring
●End-of-life monitoring of fans with prompt notification before failure
●Watchdog timer for monitoring the operating system with ASR&R
Further information on the ServerView Operations Manager is provided in the
associated documentation.
ServerView Installation Manager
You can configure the PRIMERGY server quickly and precisely with the
ServerView Installation Manager software provided. User-guided menus are
available for installing the server operating system (for further details see
section "Configuring the server" on page 76).
Service and support
PRIMERGY servers are easy to maintain and modular, thus enabling quick and
simple maintenance.
The handles and locks (touch points) used to exchange components are
colored green to ensure simple and immediate recognition.
In order to prevent the components from being damaged by incorrect handling
when they are being installed and removed, the areas of all components that
can be touched without damaging them are also marked green.
PRIMERGY diagnostic LEDs fitted on the system board indicate which
component (memory module, CPU, fan or expansion card) is not functioning
properly.
