GDS 450P I Manual

Installation and Maintenance
Manual
Sliding Gate Operators
Inbuilt Models: GDS 450P I & 630P I Range
Made in Australia from Australian & quality imported components
MOVITRAC B
ABN    
March 

2
N14870
Abbreviated Installation Instructions
(For those who don't have time!)
S l i d i n g G a t e O p e r at o r s
PLC 450, 630 Range
Made in Australia from Australian & quality imported components
MOVITRAC B
Place operator in correct position (Pinion wheel to be
parallel to the gate and stepped out to allow for width of
rack once it is mounted onto the gate frame). Mark out
fixings and fix operator to the concrete pad.
Fix rack to the gate frame keeping 1mm-2mm clearance
between the rack teeth and Pinion wheel
Once the rack is fixed move the gate and sight the rack
moving over the pinion wheel, check that most of the
pinion wheel meshes with the rack. Make sure rack runs
freely over the pinion wheel, any tights spots should be
corrected by adjusting the rack height. Check the operator
is firmly bolted down to the concrete pad.
Ensure stops are installed on the gate for the fully closed
and fully open positions.
Connect Power supply (If not done already). Turn on
Power.
To commission the gate, move the gate approximately
1m from the fully open position and tighten the
knurled wheel (Clockwise) engaging the clutch
assembly
