ReliaGear™lighting panelboards
Panneaux d’éclairages ReliaGear™
Pro-Stock™Spectra RMS™G frame single- and
three-phase circuit breaker kits, 240 and 480 Vac
Kits de disjoncteurs Spectra RMS™G frame Pro-Stock™
à phase simple et trois phases, 240 et 480 Vca
Introduction
These instructions describe the installation of a Pro-Stock
Spectra RMS G frame single- and three-phase main circuit
breaker kit into a ReliaGear lighting panelboard. These kits are
not for use in standard, factory-assembled panelboards.
The catalog numbers for the single-phase kits are MB332,
MB332WB, MB335WB and MB336WB (circuit breaker included) and
the lists of parts are found in Tables 1 and 2. The catalog numbers
for the three-phase kits are MB333, MB333WB, MB331WB and
MB334WB (circuit breaker included) and the lists of parts are
found in Tables 3 and 4.
Table 1. Parts list for the 240 and 480 Vac Spectra RMS
G frame single-phase circuit breaker installation kit, catalog
number MB332.
Item # Description Part # Qty.
1Shield insert, 240 Vac 1 0081 1 32P2 6 1
Shield insert, 480 Vac 1 0081 1 32P2 5 1
1
Shield insert, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Shield insert, 480 Vac,
ReliaGear 10081132 P32 1
2 Nut, 5/16-18 N269P23B6 2
3 Screw, #1 0-32 x 3/8 N7 22 EP16006B6 6
4 Screw, #10-32 x 3-3/4 N37P 16060B6 2
5Lock washer N405P40B6 2
6Flat washer 41 52 2
7 Cap screw, 1/2-13 x 7/8 N17 0P2 9 01 4B6 2
8 Washer, belleville, 1 /2 75A105503P103 2
10 Connection strap 10 083059P2 4
12 B-Phase Barrier 569B701G1 1
15 Label, “MAIN” 315A7337P 1 1
16 139C5473P63 1
Introduction
Ces instructions décrivent l’installation d’un kit de disjoncteur
principal Spectra RMS G frame à phase simple et trois phases
dans un panneau d’éclairage ReliaGear. Ces kits ne doivent pas
être utilisés sur des panneaux standards fabriqués en usine.
Les numéros de catalogue pour les kits à phase simple sont
MB332, MB332WB, MB335WB et MB336WB (disjoncteur inclus) et
les listes des pièces se trouvent aux Tables 1 et 2. Les numéros de
catalogue pour les kits à trois phases sont MB333, MB333WB,
MB331WB et MB334WB (disjoncteur inclus) et les listes des pièces
se trouvent aux Tables 3 et 4.
Table 1. Liste des pièces pour kit d’installation de disjoncteur
Spectra RMS G frame à phase simple, 240 et 480 Vca, numéro de
catalogue MB332.
Item # Description Pièce # Qté.
1Rajout du garde, 240 Vca 1 0081 1 32P2 6 1
Rajout du garde, 480 Vca 1 0081 1 32P2 5 1
1
Rajout du garde, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Rajout du garde, 480 Vac,
ReliaGear 10081132 P32 1
2 Écrou, 5/16-1 8 N269P23B6 2
3 Vis, #1 0-32 x 3/8 N722 EP16006B6 6
4 Vis, #10-32 x 3-3/4 N37P 16060B6 2
5Rondelle de retenue N405P40B6 2
6Rondelle plate 41 52 2
7 Vis ‡ chapeau, 1 /2-13 x 7/8 N17 0P2 9 01 4B6 2
8Rondelle, belleville, 1/2 75A105503P1 03 2
10 Courroie de connexion 10 083059P2 4
12 Barrière de phase B 569B701G1 1
15 Étiquette “MAIN” 315A7337P 1 1
16 139C5473P63 1
17
Mounting bracket
110086929P11 1171
110086929P11
12 B-Phase Barrier 569B701G1 12 Barrière dephase B 1569B701G1
B-Phase Barrier
Insulator SG600A
Mounting bracket
Isolateur SG600A

2
RELIAGEAR LIGHTING PANELBOARDS - PRO-STOCK SPECTRA RMS G FRAME CIRCUIT BREAKER KITS
Table 2. Parts list for the 240 and 480 Vac Spectra RMS G frame
single-phase circuit breaker installation kit with circuit breaker
included, catalog number MB332WB, MB335WB and MB336WB.
Item # Description Part # Qty.
1Shield insert, 240 Vac 1 0081 1 32P2 6 1
Shield insert, 480 Vac 1 0081 1 32P2 5 1
1
Shield insert, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Shield insert, 480 Vac,
ReliaGear 10081132 P32 1
2 Nut, 5/16-18 N269P23B6 2
3 Screw, #1 0-32 x 3/8 N7 22 EP16006B6 6
7 Cap screw, 1/2-13 x 7/8 N17 0P2 9 01 4B6 2
8 Washer, belleville, 1 /2 75A105503P103 2
10 Connection strap 10 083059P2 4
1
13 Breaker - 1
14 Lug kit TCLK265 1
15 Label, “MAIN” 315A7337P 1 1
16 Mounting bracket 139C5473P63 1
Table 3. Parts list for the 240 and 480 Vac Spectra RMS G frame
three-phase circuit breaker installation kit, catalog number
MB333.
Item # Description Part # Qty.
1Shield insert, 240 Vac 1 0081 1 32P2 6 1
Shield insert, 480 Vac 1 0081 1 32P2 5 1
1
Shield insert, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Shield insert, 480 Vac,
ReliaGear 10081132 P32 1
2 Nut, 5/16-18 N269P23B6 3
3 Screw, #1 0-32 x 3/8 N7 22 EP16006B6 6
4 Screw, #10-32 x 3-3/4 N37P 16060B6 2
5Lock washer N405P40B6 2
6Flat washer 41 52 2
7 Cap screw, 1/2-13 x 7/8 N17 0P2 9 01 4B6 3
8 Washer, belleville, 1 /2 75A105503P103 3
10 Connection strap 10 083059P2 6
15 Label, “MAIN” 315A7337P 1 1
16 Mounting bracket 139C5473P63 1
17 Insulator SG600A brk 1 008692 9P1 1 1
Table 2. Liste des pièces pour kit d’installation de disjoncteur
à phase simple Spectra RMS G frame 240 et 480 Vca avec
disjoncteur inclus, numéro de catalogue MB332WB,
MB335WB et MB336WB.
Item # Description Pièce # Qté.
1Rajout du garde, 240 Vca 1 0081 1 32P2 6 1
Rajout du garde, 480 Vca 1 0081 1 32P2 5 1
1
Rajout du garde, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Rajout du garde, 480 Vac,
ReliaGear 10081132 P32 1
2 Écrou, 5/16-1 8 N269P23B6 2
3 Vis, #1 0-32 x 3/8 N722 EP16006B6 6
7 Vis ‡ chapeau, 1 /2-13 x 7/8 N17 0P2 9 01 4B6 2
8Rondelle, belleville, 1/2 75A105503P1 03 2
10 Courroie de connexion 10 083059P2 4
12 1
13 Briseur - 1
14 Kit díattache TCLK265 1
15 Étiquette “MAIN” 315A7337P 1 1
16 Mounting bracket 139C5473P63 1
Table 3. Liste des pièces pour kit d’installation de disjoncteur
Spectra RMS G frame trois phases 240 et 480 Vca, numéro de
catalogue MB333.
Item # Description Pièce # Qté.
1Rajout du garde, 240 Vca 1 0081 1 32P2 6 1
Rajout du garde, 480 Vca 1 0081 1 32P2 5 1
1
Rajout du garde, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Rajout du garde, 480 Vac,
ReliaGear 10081132 P32 1
2 Écrou, 5/16-1 8 N269P23B6 3
3 Vis, #1 0-32 x 3/8 N722 EP16006B6 6
4 Vis, #10-32 x 3-3/4 N37P 16060B6 2
5Rondelle de retenue N405P40B6 2
6Rondelle plate 41 52 2
7 Vis ‡ chapeau, 1 /2-13 x 7/8 N17 0P2 9 01 4B6 3
8Rondelle, belleville, 1/2 75A105503P1 03 3
10 Courroie de connexion 10 083059P2 6
15 Étiquette “MAIN” 315A7337P 1 1
16 Mounting bracket 139C5473P63 1
17 Insulator SG600A brk 1 008692 9P1 1 1
12 B-Phase Barrier 569B701G1 Barrière de phase B 569B701G1
17110086929P11 1171
110086929P11
Insulator SG600A Insulator SG600A
1
12 B-Phase Barrier 569B701G1 12 1
Barrière de phase B 569B701G1

RELIAGEAR LIGHTING PANELBOARDS - PRO-STOCK SPECTRA RMS G FRAME CIRCUIT BREAKER KITS
3
Installation
Use the following procedure to install a Pro-Stock Spectra RMS G
frame circuit breaker kit into a ReliaGear 400 A or 600 A lighting
panelboard. Call-out numbers in the illustrations and numbers in
brackets in the text refer to the Item Numbers in Tables 1, 2, 3,
and 4.
Installation of MB332 or MB332WB kit into a new lighting panel-
board is illustrated in Figure 1. Installation of MB333 or MB333WB
kit into a new lighting panelboard is illustrated in Figure 2.
WARNING: Before attempting to install this kit, remove
all power from the panelboard.
1. Remove the interior assembly from its packaging and verify
that all parts are present, as given in the packing list.
2. Remove the eight screws securing the shield to the panel-
board interior. Lift off the shield and place it and the screws
aside.
3. Remove the circuit breaker kit from its packaging and verify
that all parts are present, as given in the packing list.
If installing an MB332 or MB333 kit, perform all of the
following steps. If installing an MB332WB, MB333WB,
MB335WB, MB336WB, MB331WB or MB334WB kit, skip
to Step 5.
Installation
Utiliser la procédure suivante pour procéder à l’installation d’un
kit de disjoncteur Spectra RMS G frame Pro-Stock dans un
panneau d’éclairage vieux ReliaGear 400 A ou 600 A. Les numéros
des illustrations et les numéros entre parenthèses dans le texte
réfèrent aux numéros des items aux Tables 1, 2, 3, et 4.
L’installation un kit de MB332 ou de MB332WB dans la nouvelle
panneau d’éclairage est illustrée sur la Figure 1. L’installation un kit
de MB333 ou de MB333WB dans la nouvelle panneau d’éclairage
est illustrée sur la Figure 2.
AVERTISSEMENT: Avant de procéder à l’installation de
ce kit, débrancher tout courant électrique du panneau.
1. Retirer l’assemblage de l’intérieur de son emballage et vérifier
que toutes les pièces y sont, telles que données sur la liste
d’emballage.
2. Retirer les huit vis fixant le garde à l’intérieur du panneau.
Soulever le garde et le mettre de côté avec les vis.
3. Retirer le kit de disjoncteur de son emballage et vérifier
que toutes les pièces y sont, telles que données sur la liste
d’emballage.
Si vous installez un kit MB332 ou MB333, exécutez toutes les
étapes suivantes. Si vous installez un kit MB332WB, MB333WB,
MB335WB, MB336WB, MB331WB ou MB334WB sautez à l’étape
5.
Table 4. Parts list for the 240 and 480 Vac Spectra RMS G frame
three-phase circuit breaker installation kit with circuit breaker
included, catalog number MB333WB, MB331WB and MB334WB.
Item # Description Part # Qty.
1Shield insert, 240 Vac 1 0081 1 32P2 6 1
Shield insert, 480 Vac 1 0081 1 32P2 5 1
1
Shield insert, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Shield insert, 480 Vac,
ReliaGear 10081132 P32 1
2 Nut, 5/16-18 N269P23B6 3
3 Screw, #1 0-32 x 3/8 N7 22 EP16006B6 6
7 Cap screw, 1/2-13 x 7/8 N17 0P2 9 01 4B6 3
8 Washer, belleville, 1 /2 75A105503P103 3
10 Connection strap 10 083059P2 6
12
13 1
14 Lug kit TCLK365 1
15 Label, “MAIN” 315A7337P 1 1
16 Mounting bracket 139C5473P63 1
17 Insulator SG600A brk 1 008692 9P1 1 1
Table 4. Liste des pièces pour kit d’installation de disjoncteur
Spectra RMS G frame trois phases 240 et 480 Vca avec
disjoncteur inclus, numéro de catalogue MB333WB, MB331WB
et MB334WB.
Item # Description Pièce # Qté.
1Rajout du garde, 240 Vca 1 0081 1 32P2 6 1
Rajout du garde, 480 Vca 1 0081 1 32P2 5 1
1
Rajout du garde, 240 Vac,
ReliaGear 1 0081 1 32 P31 1
Rajout du garde, 480 Vac,
ReliaGear 10081132 P32 1
2 Écrou, 5/16-1 8 N269P23B6 3
3 Vis, #1 0-32 x 3/8 N722 EP16006B6 6
7 Vis ‡ chapeau, 1 /2-13 x 7/8 N17 0P2 9 01 4B6 3
8Rondelle, belleville, 1/2 75A105503P1 03 3
10 Courroie de connexion 10 083059P2 6
12 1
13 1
14 Kit díattache TCLK365 1
15 Étiquette “MAIN” 315A7337P 1 1
16 Mounting bracket 139C5473P63 1
17 Insulator SG600A brk 1 008692 9P1 1 1
B-Phase Barrier 569B701G1
Barrière de phase B 569B701G1
Breaker -
Briseur -
1

4RELIAGEAR LIGHTING PANELBOARDS - PRO-STOCK SPECTRA RMS G FRAME CIRCUIT BREAKER KITS
WARNING: Hazardous voltage will cause serious injury
or death. The phase barrier must be installed before
energizing the panel.
6. Place the phase barrier [12] around the B-phase bus bar and it
will fit between the bus support and the circuit breaker
7. For a panel with MB332WB, MB333WB, MB335WB, MB336WB,
MB331WB or MB334WB – Mount [16] on the interior rails with
#10-32 x 3/8 screws [3]. Tighten to
27–36 in-lb.
8. Place the insulator SG600A [17] under the circuit breaker
between the mounting bracket [16], align the holes closer to
the edge of the insulator with the ones on the mounting
bracket.
9. Place two connection straps [10] on A and C phase of the load
side of the circuit breaker for MB322, MB322WB, MB335WB or
MB336WB and on all the three poles for MB333, MB333WB,
MB331WB or MB334WB with screw [7] and belleville washer [8].
The hole on the other end of the strap should sit over the
studs on the interior bus bars. Tighten [7] to 100–120 in-lb.
10. Place two or three 5/16-18 nuts [2] on the studs over the
connection straps and tighten to 100–120 in-lb.
11. Place the appropriate shield insert [1] over the shield, lining up
the four same-size holes. Secure with four #10-32 x 3/8 screws
[3] tightened to 27–36 in-lb. Attach the MAIN label [15] to the
front of the shield insert.
12. Reattach the shield to the interior with the eight screws
removed in Step 2. Tighten the screws to 27–36 in-lb.
4. Placez le support [16] sur les rails intérieurs avec vis de deux
#10-32 x 3/8 [3]. Placer quatre vis #10-32 x 3-3/4 [4],
deux rondelles de retenue #10 [5], et deux rondelles plates
#10 [6] dans les ouvertures au haut du disjoncteur. Fixez le briseur
sur les trous dedans [16 ] avec [4]. Resserrer les vis à 27–36 po-lb.
AVERTISSEMENT: Voltage dangereux, il y a risque de
blessure grave ou de mort. La barrière de phase doit
être installée avant de mettre le panneau sous tension.
6. Placez la barrière de phase [12] autour de la barre omnibus de
phase B et elle se placera entre le support de bus et le
disjoncteur.
7. Pour un panneau avec MB332WB, MB333WB , MB335WB,
MB336WB, MB331WB or MB334WB – Montez [16] sur les rails
intérieurs avec des vis de #10-32 x 3/8 [3]. Resserrer à 27–36 po-
lb.
8. Placer l’isolant SG600A [17] sous le disjoncteur entre le support
de montage [16] aligner les trous les plus proches du bord de
l’isolateur avec ceux du support de monage.
9. Placez deux courroies de raccordement avec [10] la phase de A
et de C du côté de charge du briseur pour MB322,
MB322WB,MB335WB ou MB336WB et sur tous les trois poteaux
pour MB333, MB333WB, MB331WB ou MB334WB la vis [7] et la
rondelle de belleville [8]. Le trou sur l’autre fin de la courroie
devrait se reposer au-dessus des goujons sur les barres
omnibus intérieures. Resserrer à 100–120 po-lb.
10. Placer deux ou trois écrous 5/16-18 [2] sur les goujons
par dessus les courroies de connexion et resserrer à
100–120 po-lb.
11. Placer le rajout du garde approprié [1] par dessus le garde, en
alignant les quatre ouvertures de mêmes dimensions. Fixer avec
quatre vis #10-32 x 3/8 [3] resserrées à 27–36 po-lb. Attacher
l’étiquette MAIN [15] au devant du rajout d garde.
12. Rattacher le garde à l’intérieur avec les huit vis retirées à l’étape
2. Resserrer les vis à 27–36 po-lb.
4. Place the mounting bracket [16] on the interior rails with two
#10-32 x 3/8 screws [3]. Place two #10-32 x 3-3/4 screws [4], two #10
lock washers [5], and two #10 flat washers [6] into the holes in the top
of the circuit breaker. Secure the circuit breaker on the holes in
[16] with [4]. Tighten to 27–36 in-lb.
5. For an MB332WB, MB333WB, MB335WB, MB336WB, MB331WB or
MB334WB kit, insert the lugs [14] into the ine side of the circuit
breaker.
5. Pour un kit MB332WB, MB333WB , MB335WB, MB336WB,
MB331WB or MB334WB, insérer les attaches [14] dans le côté
réseau du disjoncteur.

RELIAGEAR LIGHTING PANELBOARDS - PRO-STOCK SPECTRA RMS G FRAME CIRCUIT BREAKER KITS
7
Figure 1. Installation of a Pro-Stock Spectra RMS G frame circuit breaker kit, catalog number
MB332, MB335WB, MB336WB or MB332WB, as a main breaker into a new 400 A or 600 A
lighting panelboard.
Figure 1. Installation d’un kit de disjoncteur Spectra RMS G frame, Pro-Stock, numéro de
catalogue MB332, MB335WB, MB336WB or MB332WB, comme disjoncteur principal dans un
panneau d’éclairage nouvelle 400 A ou 600 A.

8
RELIAGEAR LIGHTING PANELBOARDS - PRO-STOCK SPECTRA RMS G FRAME CIRCUIT BREAKER KITS
Figure 2. Installation of a Pro-Stock Spectra RMS G frame circuit breaker kit, catalog
number MB333, MB331WB, MB334WB or MB333WB, as a main breaker into a new 400 A or
600 A lighting panelboard.
Figure 2. Installation d’un kit de disjoncteur Spectra RMS G frame, Pro-Stock, numéro de
catalogue MB333, MB331WB, MB334WB ou MB333WB, comme disjoncteur principal dans un
panneau d’éclairage nouvelle 400 A ou 600 A.
1TQC213000Z0011,DEH40190,APR2021
—
ABB Inc.
305 Gregson Drive
Cary, NC 27511
©Copyright 2021 ABB. All rights reserved.
Information provided is subject to change without notice. Please verify all details with ABB. All values are design or typical
values when measured under laboratory conditions, and ABB makes no warranty or guarantee, express or implied, that such
performance will be obtained under end-use conditions.
Pro-Stock, Spectra RMS and ReliaGear are trademarks of ABB Inc.
GE is a registered trademark used under license from General Electric company.
electrification.us.abb.com
This manual suits for next models
1
Table of contents
Other GE Lighting Equipment manuals

GE
GE 62191 User manual

GE
GE LED G90 8L Lawn Stakes User manual

GE
GE Evolve Guide

GE
GE StreetDreams Pendant User manual

GE
GE Tetra PowerStrip DS User manual

GE
GE Current Tetra miniMax User manual

GE
GE NHL Tree 23136LO User manual

GE
GE Current Tetra Slim EdgeStrip Series User manual

GE
GE 78937 User manual

GE
GE Tetra PowerMAX GEPM71-W1 User manual
