Gemini Gemini BioReader User manual

Control NAPCO’s Gemini alarm systems
with the touch of a finger – or use the
built-in relay outputs to integrate with any
brand of alarm system or for standalone
alarm and garage door access control
NAPCO introduces our indoor/outdoor digital keypad with a highly-advanced
and accurate optical biometric fingerprint reader for integrated control of any
Gemini security system or as state-of-the-art standalone access control use for
alarm systems, garage door operator control, lighting, etc. with relay activation.
Increases the security of the system
Biometric ambush feature sends silent alarms.
Use pre-selected and enrolled finger to silently call
the police during push ins and robberies
Eliminates code pass-along. With children or
employee-turnover – you can’t pass along a
fingerprint!
Tamper-proof. Alarm is tripped if the reader is
ripped from the building
Feature-rich, flexible and convenient
External device control. To control garage doors,
lighting and more
Rugged & durable. Metal keypad is weather and
vandal-resistant
Convenient. No keys or cards to carry, no codes to
memorize and remember
Single finger use. One touch of a finger arms/
disarms the system and/or activates relay groups.
Send a silent alarm in ambush/duress situation simply
using a different finger.
www.napcosecurity.com • 1-800-645-9445
Residential alarm and garage door control
Only users enrolled in the reader can operate the
electric garage door, alarm and lighting system.
Ideal for walking around the neighborhood and
not having to carry a house key. Your finger is
the key!
Perfect for commercial
applications such as:
• gate control and parking
lot access
• restricted access to
sensitive pharmaceuticals,
weapons, supplies and
more.
New innovative indoor/outdoor Gemini bio reader keypad by NAPCO
No lost keys by children
No code pass-along, or
other children looking over
the child’s shoulders and
memorizing their code
Perfect for the elderly
No codes to remember, no
fumbling with keys
™

Standalone or with an alarm system,
outstanding biometric reliability for
greater security for residential &
commercial accounts
3-Way “live” finger detection
High-security verification thwarts use by imposters using photocopies
and rubber impression fake fingers
Easy, fast, accurate fingerprint enrollment
Enrolls at keypad in approximately 5-seconds. (Also easy user deletions.)
Secure processing and storage on-board
All processing is done and stored securely within the unit. Includes
anti-substitution which prevents hacking or unauthorized keypad
replacement by retaining its own master code, enrolled in the panel
upon installation.
Audible and visual status indicators
Piezo sounder prompts/feedback. Traditional keypad armed/alarm and
ready LEDs plus bio-feedback indicator
Stealth/Blanking Mode for no-show alarm status LEDs
Status is hidden after use, displayed only with an authorized user’s
fingerprint or code
Removable bio-optic reader privacy shield
Shield covers durable scratch-resistant optic glass, disguises operation
Superior 99% accurate false acceptance and false rejection
Bioreader has exceptional biometric reliability and accuracy to ensure
reliable use – even by those with fingerprints traditionally considered
hard to read, such as consumers with finer (poor quality) prints, or
people whose fingerprints are dry or worn such as people who garden,
manual laborers, elderly, etc. FAR (False Acceptance Rate) from .001 to
0% and FRR (False Rejection Rate) selectable 1.1 to 5.8% .
Alarm System Integration:
Works with Napco Gemini (all panels, 3- and 4-wire bus, not intended to
be sole keypad) and Express systems
All digital user code info (3 to 6 digit codes) passes through
Gem-BioReader to the Gemini System (does not change panel
programming.)
Unit performs arm, disarm, ambush, bypass alarm functions and
energize relay outputs (or relay groups in panels which support them,
ie., P3200 through X255)
Keypad includes Stay/Away K-Series functionality and programmable
one-button relay control
Also works on most brands of panels with a keyswitch or similar input
www.napcosecurity.com • 1-800-645-9445
NASDAQ: NSSC
Preliminary specifications subject to change. 7/09 A584
PATS (2) Pending Copyright 2009, Napco Security Technologies.
Ordering Info
GEM-BIOREADER/MS Metallic Silver indoor/outdoor metal keypad
with advanced bio-optic ngerprint reader and integral Form C Relay,
rated 1A/24VDC
GEM-BIOREADER/MB As above, in metallic bronze nish (right)
WI819 Instruction manual for GEM-BIOREADER
WI829 Installation mounting guide for GEM-BIOREADER
OI363 User Guide for GEM-BIOREADER
Users Supports up to 100 biometric
fingerprints/digital code user IDs
Current draw requirements 65mA @12VDC
Form C Relay Outputs Rated at 1A/24VDC; programmable
activation duration (1 to 255 sec.)
Mounting Tamper supervised wall mount or
single gang box mount
LFD Live Finger Detection
Temporary Lockout Mode After 4 unsuccessful attempts to
activate system
CPU ARM Based 32Bit RISC
CPU Clock Up to 200MHz
Processing Speed 2-4 Seconds. Even with system at
maximum user capacity
Flash Memory 1M Byte
SDRAM 8M Byte
Auto Sensing Human Touch Sensor
Capture Type Optical, 500dpi
Sensing Area 15 x 17 mm
FRR/ FAR / Verification time 01.% / 0.001% / <1sec
Operating Temperature 14° to 122°F, -10° to 50°C
Finishes Metallic Silver or Metallic Bronze
™
Integrated control of ALL Napco Gemini Panels,
including 3- and 4-wire bus models
What security dealers like best about the Bioreader:
“Customers’ fingers are their keys or codes. Nothing to carry, lose or
memorize. It’s great with latchkey kids coming home or elderly clients.”
“5-second fingerprint enrollment right at Bioreader is so quick and easy”
“Stealth mode – Reveals alarm status only to authorized user without
arming/disarming first.”
“Also, alarm in memory is automatically displayed with LED indicator as a
precautionary warning to returning users before they enter.”
“Other-finger” ambush/silent alarm activation is very handy, whether it’s
their ring finger or index finger or their left hand vs. their right hand they
use for ambush -- they can’t leave home without it.”
“With one-touch of a finger my accounts can disarm their alarm and open
their electric garage door opener.”
