Generac Power Systems MLT3080KV User manual

LIGHT TOWER
MLT3060MV • MLT3060KV
00120
MLT3080KV
OPERATING MANUAL
www.discount-equipment.com
Discount-Equipment.com

Discount-Equipment.com is your online resource for commercial and industrial
quality parts and equipment sales.
Locations:
Florida (West Palm Beach): 561-964-4949
Outside Florida TOLL FREE: 877-690-3101
Need parts? Check out our website at www.discount-equipment.com
Can’t find what you need?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and fill out
the request form.
Please have the machine model and serial number available in order to help us get
you the correct parts. One of our experienced staff members will get back to you with
a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone,
Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,
Chicago Pneumatic, Allmand Brothers, Essick, Miller Spreader, Skyjack, Lull, Skytrak,
Tsurumi, Husquvarna/Target, Whiteman-Concrete/Mortar, Stow-Concrete/Mortar, Baldor,
Wacker, Sakai, Snorkel, Upright, Mi-T-M, Sullair, Neal, Basic, Dynapac, MBW, Weber,
Bartell, Bennar Newman, Haulotte, Ditch Runner, Blaw-Knox, Himoinsa, Best, Buddy,
Crown, Edco, Wyco, Bomag, Laymor, Terremite, Barreto, EZ Trench, Takeuchi, Basic, Bil-
Jax, Curtis, Gehl, Heli, Honda, ICS/PowerGrit, Puckett, Waldon, ASV, IHI, Partner, Imer,
Clipper, MMD, Koshin, Rice, Gorman Rupp, CH&E, Cat Pumps, Comet, General Pump,
Giant,AMida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,
Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, Small Line, Wanco, Yanmar
Discount-Equipment.com

2
INTRODUCTION
This manual provides information and procedures to safely operate and maintain the Generac Mobile Products unit.
For your own safety and protection from physical injury, carefully read, understand, and observe the safety
instructions described in this manual. Keep a copy of this manual with the unit at all times. The information
contained in this manual was based on machines in production at the time of publication. Generac Mobile Products
reserves the right to change any portion of this information without notice.
Read all of the manuals included with the unit. Each manual details specific information regarding items such as
setup, use and service requirements. An engine operator’s manual provides detailed operation and maintenance
procedures for the engine.
DO NOT MODIFY or use this equipment for any application other than which it was designed for.
Generac Mobile Products recommends that a trained and licensed professional perform all electrical wiring and
testing functions. Any wiring should be in compliance with the National Electrical Code (NEC), state and local codes
and Occupational Safety and Health Association (OSHA) guidelines.
Engine Make:__________________________________________
Engine Serial Number:___________________________________
Engine Model Number: __________________________________
Generator Make: _______________________________________
Generator Model Number: ________________________________
Generator Serial Number: ________________________________
Unit Model Number:_____________________________________
Unit Serial Number: _____________________________________
WARNING
CALIFORNIA PROPOSITION 65 WARNING: Diesel engine exhaust and some of its
constituents are known to the state of California to cause cancer, birth defects and
other reproductive harm.
Discount-Equipment.com

3
TABLE OF CONTENTS
Page
INTRODUCTION ................................................................................................................................ 2
SAFETY NOTES ................................................................................................................................ 4
OPERATING SAFETY ....................................................................................................................... 4
ENGINE SAFETY............................................................................................................................... 5
SERVICE SAFETY............................................................................................................................. 6
TOWING SAFETY.............................................................................................................................. 6
REPORTING TRAILER SAFETY DEFECTS ..................................................................................... 7
SAFETY SYMBOL SUMMARY .......................................................................................................... 8
SPECIFICATIONS - MLT3060MV, MLT3060KV................................................................................ 9
SPECIFICATIONS - MLT3080KV .................................................................................................... 10
UNIT DIMENSIONS ........................................................................................................................ 11
UNIT SERIAL NUMBER LOCATIONS ............................................................................................ 12
COMPONENT LOCATIONS ............................................................................................................ 13
LIGHT TOWER SET UP................................................................................................................... 14
RAISING THE MAST........................................................................................................................ 15
MAIN CONTROL PANEL - MLT3060MV, MLT3060KV ................................................................... 16
MAIN CONTROL PANEL - MLT3080KV .......................................................................................... 17
PRESTART CHECKLIST ................................................................................................................. 18
STARTING THE UNIT...................................................................................................................... 18
AUTOMATIC SHUTDOWN ..............................................................................................................19
LIGHT OPERATION......................................................................................................................... 19
DERATING FOR ALTITUDE ............................................................................................................ 19
WET STACKING .............................................................................................................................. 20
CONTROL PANEL RECEPTACLES................................................................................................ 20
SHUTTING DOWN THE UNIT ......................................................................................................... 20
LOWERING THE MAST................................................................................................................... 21
REMOVING THE LIGHTS FOR TRANSPORTATION ..................................................................... 22
TOWING THE UNIT ......................................................................................................................... 22
LIFTING THE UNIT .......................................................................................................................... 23
GENERAL MAINTENANCE ............................................................................................................24
BASIC MAINTENANCE SCHEDULE - MITSUBISHI ENGINE ........................................................ 25
BASIC MAINTENANCE SCHEDULE - KUBOTA ENGINE .............................................................. 26
WINCH USE, OPERATION & MAINTENANCE ............................................................................... 27
JACK MAINTENANCE ..................................................................................................................... 27
TRAILER WHEEL BEARINGS ......................................................................................................... 28
LOWER RADIATOR HOSE HEATER OPTION - USE AND MAINTENANCE................................. 28
TROUBLESHOOTING THE LIGHTS ............................................................................................... 29
MAST LIGHT CONNECTIONS ........................................................................................................ 30
AC WIRING DIAGRAM .................................................................................................................... 31
DC WIRING DIAGRAM - MITSUBISHI ENGINE.............................................................................. 32
DC WIRING DIAGRAM - KUBOTA ENGINE ................................................................................... 33
DC WIRING DIAGRAM - ELECTRIC WINCH .................................................................................. 34
DC WIRING DIAGRAMS FOR OPTIONAL EQUIPMENT................................................................ 35
TRAILER LIGHTS WIRING DIAGRAM ............................................................................................ 36
SERVICE LOG ................................................................................................................................. 37
NOTES ............................................................................................................................................. 38
Discount-Equipment.com

4
SAFETY NOTES
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
This manual contains DANGERS, WARNINGS, CAUTIONS, NOTICES and NOTES which must be
followed to prevent the possibility of improper service, damage to the equipment, personal injury or death.
The following formatting options will apply when calling the readers attention to the DANGERS, WARN-
INGS, CAUTIONS, NOTICES and NOTES.
DANGER
INDICATES A HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, WILL RESULT IN
DEATH OR SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Indicates a hazardous situation which, if not avoided, could result in property or equipment
damage.
Note: Notes contain additional information important to a procedure and will be found within the regular text body
of this manual.
OPERATING SAFETY
Before using the unit be sure to read and understand all of the instructions provided with the unit. This
equipment was designed for specific applications; DO NOT modify or use this equipment for any application
other than which it was designed for. Equipment operated improperly or by untrained personnel can be
dangerous.
Read the operating instructions and familiarize yourself with the location and proper use of all instruments
and controls. Inexperienced operators should receive instruction from someone familiar with the equipment
before being allowed to operate or set up the unit. The following points should be practiced at all times:
• The area immediately surrounding the unit should be dry, clean, and free of debris.
• Position and operate the unit on a firm, level surface.
•NEVER start a unit in need of repair.
•ALWAYS lower the mast when not in use, or if high winds or electrical storms are expected in the area.
• Make certain the unit is well grounded and securely fastened to a good earthen ground. Follow any
local, state or National Electrical Code (NEC) guidelines.
• The mast extends up to 25 ft (7.6 m). ALWAYS make sure the area above the unit is open and clear
of overhead wires and obstructions.
• Keep area around the mast clear of people while raising and lowering the mast.
• Keep all body parts, clothing and other loose items clear of the winch, cables and pulleys during
operation.
• Bulbs become extremely hot during use. Allow them to cool 10-15 minutes before handling.
•NEVER raise or lower the mast while lights are in operation.
Discount-Equipment.com

5
•ALWAYS extend the outriggers and level the unit before raising the mast. DO NOT retract the outriggers
while the mast is up.
• If for any reason any part of the mast hangs up or the winch cable develops slack while raising or
lowering the mast, STOP immediately and contact an authorized service representative.
•NEVER use the unit if insulation on the electrical cord is cut or worn through.
•NEVER operate the lights without protective lens covers in place or with a lens cover that is cracked
or damaged.
• Only use mild soap and water to clean the lens covers. Other chemicals may have an adverse effect
on the glass.
•NEVER operate a unit while tired, distracted, or under the influence of drugs or alcohol.
ENGINE SAFETY
Internal combustion engines present special hazards during operation and fueling. Failure to follow the
safety guidelines described below could result in severe injury or death. Also read and follow all safety
warnings described in the engine operator's manual. A copy of this manual was supplied with unit when
it was shipped from the factory.
•DO NOT run engine indoors or in an area with poor ventilation unless exhaust hoses are used. Diesel
engine exhaust contains carbon monoxide, a deadly, odorless and colorless gas which, if inhaled,
can cause nausea, fainting or death. Make sure engine exhaust cannot seep into closed rooms or
ventilation equipment.
•DO NOT operate the unit on a combustible surface.
•DO NOT fill fuel tank near an open flame, while smoking, or while engine is running. DO NOT fill tank
in an enclosed area with poor ventilation.
•DO NOT operate with the fuel tank cap loose or missing.
•DO NOT touch or lean against hot exhaust pipes or engine cylinders.
•DO NOT clean air filter with gasoline or other types of low flash point solvents.
•DO NOT remove engine coolant cap while engine is hot.
•DO NOT operate the unit without a functional exhaust system. Prolonged exposure to sound levels
in excess of 85 dB(A) can cause permanent hearing loss. Wear hearing protection when working
around a running engine.
• Keep area around exhaust pipes and air ducts free of debris to reduce the chance of an accidental fire.
• Batteries contain sulfuric acid which can cause severe injury or death. Sulfuric acid can cause eye
damage, burn flesh or eat holes in clothing. Protective eye wear and clothing are necessary when
working on or around the battery. Always disconnect the negative (-) battery cable from the
corresponding terminal before performing any service on the engine or other components.
• Shut the engine down if any of the following conditions exist during operation:
1. Noticeable change in engine speed.
2. Loss of electrical output.
3. Equipment connected to the generator overheats.
4. Sparking occurs.
5. Engine misfires or there is excessive engine/generator vibration.
6. Protective covers are loose or missing.
7. If the ambient air temperature is above 120°F (49°C).
Discount-Equipment.com

6
SERVICE SAFETY
This unit uses high voltage circuits capable of causing serious injury or death. Only a qualified electri-
cian should troubleshoot or repair electrical problems occurring in this equipment.
• Before servicing, make sure the Engine Start switch is turned to OFF, circuit breakers are open (off)
and the negative terminal on the battery is disconnected. NEVER perform even routine service (oil/
filter changes, cleaning, etc.) unless all electrical components are shut down.
•NEVER allow water to accumulate around the base of the unit. If water is present, DO NOT service.
•NEVER service electrical components if clothing or skin is wet. If the unit is stored outside, check the
engine and generator for any moisture and dry the unit before use.
•NEVER wash the unit with a power washer or high pressure hose.
• Open the main circuit breaker before disconnecting battery cables.
• Keep all body parts, clothing, and other loose items away from moving parts on the unit.
• Wear heavy leather gloves when handling winch cables. Never let cables slip through bare hands.
• Make sure slings, chains, hooks, ramps, jacks, and other types of lifting devices are attached securely
and have enough weight-bearing capacity to lift or hold the unit safely. Always remain aware of the
position of other people around when lifting the unit.
TOWING SAFETY
Towing a trailer requires care. Both the trailer and vehicle must be in good condition and securely fastened
to each other to reduce the possibility of an accident. Some states require that large trailers be registered
and licensed, contact your local Department of Transportation office to check on license requirements for
your particular unit.
• Check that the hitch and coupling on the towing vehicle are rated equal to, or greater than, the trailer's
Gross Vehicle Weight Rating (GVWR).
• Check tires on trailer for tread wear, inflation, and condition.
•NEVER tow trailer using defective parts. Inspect the hitch and coupling for wear or damage.
• Make sure the trailer hitch and the coupling are compatible. Make sure the coupling is securely fastened
to the vehicle.
• Connect safety chains in a crossing pattern under the tongue and ATTACH THE BREAKAWAY
CABLE TO THE REAR BUMPER OF THE TOWING VEHICLE. Do not attach the cable to the trailer
hitch.
• Make sure directional and brake lights on the trailer are connected and working properly.
• Check that all lug nuts holding wheels on are tight and none are missing.
• Maximum recommended speed for highway towing is 45 mph (72 km/h). Recommended off-road
towing speed is not to exceed 10 mph (16 km/h) or less, depending on terrain.
• When towing, maintain extra space between vehicles and avoid soft shoulders, curbs and sudden
lane changes. If you have not pulled a trailer before, practice turning, stopping, and backing up in an
area away from heavy traffic.
Discount-Equipment.com

7
REPORTING TRAILER SAFETY DEFECTS
If you believe your trailer has a defect which could cause a crash or could cause injury or death, you should immediately
inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Generac Mobile Products.
If NHTSA receives similar complaints, it may open an investigation; and if it finds that a safety defect exists in a
group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in an
individual problem between you, your dealer, or Generac Mobile Products.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-888-327-4236 (TTY:1-800-424-9153),
go to http://www.safercar.gov; or write to:
Administrator
NHTSA
1200 New Jersey Avenue S.E.
Washington, DC 20590
You can also obtain other information about motor vehicle safety from http://www.safercar.gov.
Discount-Equipment.com

8
SAFETY SYMBOL SUMMARY
This equipment has been supplied with numerous safety and operating decals. These decals provide important
operating instructions and warn of dangers and hazards. Replace any missing or hard-to-read decals and use care
when washing or cleaning the unit. Decal placement and part numbers can be found in the parts manual. Below is
a summary of the intended meanings for the symbols used on the decals.
UV
Hot surface(s) nearby.
Fire/explosion hazard; keep
open flames away from unit.
Read and understand the
supplied operator’s manual
before operating unit.
Ultraviolet radiation hazard;
operate only with lens intact.
Use clean diesel fuel only.
Unit electrical ground.
Anchor/tie down point.
Lift here only.
Asphyxiation hazard; operate
in well ventilated area.
Dangerous voltage may be
present.
Crush hazard; keep body parts
clear of this area.
Burn/scald hazard;
pressurized steam.
Fan hazard; keep body parts
clear of this area. Forklift here only.
Belt/entanglement hazard; keep
body parts clear of this area.
Safety alert symbol; used to
alert you to potential personal
injury hazards.
Stop engine before fueling.
00198
Discount-Equipment.com

9
SPECIFICATIONS - MLT3060MV, MLT3060KV
GENERAC MODEL MLT3060MV MLT3060KV
Engine
Make/Brand................................................................... Mitsubishi .....................................Kubota
Model ............................................................................ L3E-W461ML................................D1005-E3BG1-MGM-1
EPA Tier ........................................................................ 4f...................................................4f
Type .............................................................................. Diesel, liquid cooled, 4-stroke.......Diesel, liquid cooled, 4-stroke
Horsepower - prime hp (kW) ....................................... 10.5 (7.8) ......................................11.7 (8.7)
Horsepower - standby hp (kW) .................................... 12.2 (9.1) ......................................13.1 (9.8)
Operating Speed rpm .................................................. 1800..............................................1800
Displacement in3(L) .................................................... 57.97 (0.95) ..................................61.08 (1.00)
Cylinders - qty ............................................................... 3....................................................3
Fuel Consumption - 100% prime gph (Lph) ................ 0.47 (1.78) ....................................0.50 (1.89)
Battery Type - Group Number ....................................... 24..................................................24
Battery Voltage (Quantity per Unit) ............................... 12V (1) ..........................................12V (1)
Battery Rating ............................................................... 440 CCA .......................................440 CCA
Generator
Make/Brand................................................................... Marathon Electric..........................Marathon Electric
Model ............................................................................ 201CSA5411.................................201CSA5411
Type, Insulation ............................................................. Brushless, F..................................Brushless, F
Generator Set (Engine/Generator)
Output kW (kVA) .......................................................... 6.0 (6.0) ........................................6.0 (6.0)
Output Voltage V.......................................................... 120/240, single phase...................120/240, single phase
Output Amperes 120V (240V) A .................................. 50 (25) ..........................................50 (25)
Frequency Hz ............................................................... 60..................................................60
Power Factor................................................................. 1 (1Ø)............................................1 (1Ø)
Weights
Dry Weight lbs (kg) ...................................................... 1694 (768) ....................................1707 (774)
Operating Weight lbs (kg) ........................................... 1910 (866) ....................................1923 (872)
Capacities
Fuel Tank Volume gal (L) ............................................. 30 (114).........................................30 (114)
Usable Fuel Volume gal (L) ......................................... 30 (114).........................................30 (114)
Coolant (incl. engine) qt (L) .......................................... 4.5 (4.3) ........................................4.8 (4.5)
Oil (incl. filter) qt (L) ...................................................... 3.8 (3.6) ........................................5.4 (5.1)
Maximum Run Time hrs .............................................. 64..................................................60
Lighting
Lighting Type................................................................. Metal Halide..................................Metal Halide
Ballast Type................................................................... Coil & Core ...................................Coil & Core
Lumens ......................................................................... 440,000.........................................440,000
Coverage acres (m2).................................................... 5 - 7 (20,234 - 28,328) ..................5 - 7 (20,234 - 28,328)
AC Distribution
Circuit Breaker Size ...................................................... 30..................................................30
Voltage Regulation ........................................................ Capacitor +/-6% ............................Capacitor +/-6%
Voltages Available 1Ø ................................................... 120, 240........................................120, 240
Trailer
Number of Axles............................................................ 1....................................................1
Capacity - Axle Rating lbs (kg) .................................... 2200 (998) ....................................2200 (998)
Tire Size in ................................................................... 13..................................................13
Hitch - Standard ............................................................ 2" Ball............................................2" Ball
Maximum Tire Pressure psi ......................................... 50..................................................50
Specifications are subject to change without notice.
Discount-Equipment.com

10
SPECIFICATIONS - MLT3080KV
GENERAC MODEL MLT3080KV
Engine
Make/Brand..........................................................................................................................Kubota
Model ...................................................................................................................................D1105-E3BG
EPA Tier ...............................................................................................................................4f
Type .....................................................................................................................................Diesel, liquid cooled, 4-stroke
Horsepower - prime hp (kW) ..............................................................................................13.5 (10.1)
Horsepower - standby hp (kW) ...........................................................................................15.4 (11.5)
Operating Speed rpm .........................................................................................................1800
Displacement in3(L) ............................................................................................................68.53 (1.12)
Cylinders - qty ......................................................................................................................3
Fuel Consumption - 100% prime gph (Lph) .......................................................................0.70 (2.65)
Battery Type - Group Number ..............................................................................................24
Battery Voltage (Quantity per Unit) ......................................................................................12V (1)
Battery Rating ......................................................................................................................440 CCA
Generator
Make/Brand..........................................................................................................................Marathon Electric
Model (Capacitor Regulated) ...............................................................................................201CSA5412
Type, Insulation ....................................................................................................................Brushless, F
Generator Set (Engine/Generator)
Output kW (kVA) .................................................................................................................8.0 (8.0)
Output Voltage V.................................................................................................................120/240, single phase
Output Amperes 120V (240V) A .........................................................................................66 (33)
Frequency Hz ......................................................................................................................60
Power Factor........................................................................................................................1 (1Ø)
Weights
Dry Weight lbs (kg) .............................................................................................................1729 (784)
Operating Weight lbs (kg) ..................................................................................................1945 (882)
Capacities
Fuel Tank Volume gal (L) ....................................................................................................30 (114)
Usable Fuel Volume gal (L) ................................................................................................30 (114)
Coolant (incl. engine) qt (L) .................................................................................................4.8 (4.5)
Oil (incl. filter) qt (L) .............................................................................................................5.4 (5.1)
Maximum Run Time hrs .....................................................................................................43
Lighting
Lighting Type........................................................................................................................Metal Halide
Ballast Type..........................................................................................................................Coil & Core
Lumens ................................................................................................................................440,000
Coverage acres (m2)...........................................................................................................5 - 7 (20,234 - 28,328)
AC Distribution
Circuit Breaker Size .............................................................................................................40
Voltage Regulation ...............................................................................................................Capacitor +/-6%
Voltages Available 1Ø ..........................................................................................................120, 240
Trailer
Number of Axles...................................................................................................................1
Capacity - Axle Rating lbs (kg) ...........................................................................................2200 (998)
Tire Size in ..........................................................................................................................13
Hitch - Standard ...................................................................................................................2" Ball
Maximum Tire Pressure psi ................................................................................................50
Specifications are subject to change without notice.
Discount-Equipment.com

11
UNIT DIMENSIONS
Specifications are subject to change without notice.
ABCDE
MLT3060MV/KV,
MLT3080KV
117 in
(3 m)
111 in
(2.8 m)
25 ft
(7.6 m)
58 in
(1.5 m)
98 in
(2.5 m)
A
B
D
00212
E
C
Discount-Equipment.com

12
UNIT SERIAL NUMBER LOCATIONS
Refer to the illustration to locate the unit ID tag and Vehicle Identification Number (VIN) tag on the unit. Important
information, such as the unit serial number, model number, VIN and tire loading information are found on these tags.
Record the information from these tags so it is available if the tags are lost or damaged. When ordering parts or
requesting assistance, you may be asked to provide this information.
Unit ID Tag
Located on inside
of front panel
Serial Number
V
A
Model
KVA
FOR ELECTRICAL
EQUIPMENT ONLY.
POUR MATERIAL
ELECTRIQUE SEULEMENT.
Mfg. Code
Skidded WT (lbs/kg) rpm/freq
1 ph. 1.0PF 3 ph. .8PF 3 ph. 1.0PF
insul. class
RATING
KW
®
MAGNUM POWER PRODUCTS LLC
Manufactured by
A wholly owned subsidiary of
Generac Power Systems, Inc.
215 Power Drive • Berlin, WI 54923
1-800-926-9768
VIN Tag
TIRE AND LOADING INFORMATION
RENSEIGNEMENTS SUR LES
PNEUS ET LE CHARGEMENT
SEE OWNER’S
MANUAL FOR
ADDITIONAL
INFORMATION
VOIR LE
MANUEL DE
L’USAGER
POUR
PLUS DE
RENSEIGNEMENTS
MANUFACTURED BY/FABRIQUE PAR: Magnum Power Products LLC DATE: 00/0000
GVWR/PNBV: 000KG (0000LBS) COLD INF. PRESS./
PRESS. DE
V.I.N./N.I.V.:
00000000000000000
TYPE: TRAILER
MODEL: XXX000
GAWR / PNBE TIRE / PNEU RIM / JANTE GONF A FROID - KPA(PSI/LPC) SGL / DUAL
EACH
AXLE
THIS VEHICLE CONFORMS TOALL APPLICABLE STANDARDS PRESCRIBED UNDER THE U.S. FEDERAL MOTOR VEHICLE SAFETY STANDARDS(FMVSS)AND CANADIAN
MOTOR VEHICLE SAFETY REGULATIONSIN EFFECT ON THE DATE OF MANUFACTURE.
CE VEHICULE EST CONFORMEA TOUTES LES NORMES QUI LUI SONT APPLICABLES EN VERTU DU REGLEMENT SUR LASECURITE DES VEHICULES AUTOMOBILES DU CANADA EN VIGUEUR A LADATE SA
FABRICATION.
The weight of cargo should never exceed 0000KG (0000LBS)
Le poids du chargement ne doit jamais depasser 0000KG (0000LBS)
00223
Discount-Equipment.com

13
COMPONENT LOCATIONS
LEFT SIDE
RIGHT SIDE
Engine
Exhaust
Control
Box
Central
Lift Point
Mast
Switch
Forklift
Pockets
Battery
Engine
Access Fuel Fill
Outriggers
Mast
Rotation
Knob
Radiator
Access
00108
Discount-Equipment.com

14
LIGHT TOWER SET UP
1. For maximum light coverage, locate the unit at ground level or in a spot higher than the area being illuminated
by the lamps.
WARNING
The mast extends up to 25 ft (7.6 m). Make sure area above the unit is open and clear
of overhead wires and obstructions.
2. Place the unit on firm ground that is relatively flat, then block the wheels to keep it from moving (A). This will
make it easier to level the unit.
3. Pull the locking pin on the tongue jack and rotate the jack 90°. Replace the locking pin (B). Turn the jack handle
clockwise to raise the trailer tongue off of the towing vehicle.
4. Connect a good earthen ground to the grounding stud on the frame of the trailer near the trailer tongue (C).
Note: Consult local codes for proper grounding requirements.
5. Pull the locking pin (D) on the outrigger (E) and pull each outrigger out until the spring loaded locking pin snaps
back into place. Pull the locking pin on the outrigger jack and rotate each 90° so the jack pad is facing down and
the spring loaded pin snaps back into place.
6. Pull the locking pin on the rear jack (F) and rotate the jack 90° until the spring loaded pin snaps back into place.
Turn the jack handle clockwise to start leveling the trailer. Adjust all four jacks by turning their handles clockwise
until they are firmly in contact with the ground and the trailer is as level as possible (G).
7. Before raising the mast, it may be necessary to adjust the lamps. The lamps may be adjusted up, down, left or
right by loosening the wing nuts on the trunnion (H) and aiming them in the desired direction. Tighten the hardware
completely and make sure the lamps are connected to the junction box (J).
DETAIL C
DETAIL D
DETAIL G
DETAIL H
D
B
G
F
H
A
D
C
J
E
00155
Discount-Equipment.com

15
RAISING THE MAST
1. Set up and level the unit. Refer to “Light Tower Set
Up” on page 14.
WARNING
The unit must be leveled with the
outriggers extended before raising the
mast. The outriggers must remain
extended while the mast is up. Failure
to level the unit or extend the
outriggers will severely reduce
stability and could allow the unit to tip
and fall.
2. Check the mast cables for excessive wear or dam-
age. Make sure the cables are properly centered in
each pulley (A). Check the electrical cord for damage.
WARNING
Do not start the unit if insulation on the
electrical cord is cut or worn through.
Bare wires in contact with the mast or
frame may energize the unit and cause
electrocution. Repair or replace a
damaged cord.
3. Press and hold the winch control toggle switch (B)
upward to telescope the mast to the desired height.
Extend the mast slowly, making sure that the coiled
electrical cord is extending at the top sections of the
mast. If, for any reason, the winch cable begins to
develop slack or any of the mast sections get stuck,
STOP IMMEDIATELY and contact an authorized
service center.
CAUTION
Do not extend the mast beyond the
colored mark on top of the lower mast
section (C).A limit switch on the main mast
section will disconnect power to prevent
overextending the mast.
4. The mast can be rotated by loosening the mast rotation knob at the bottom of the mast (D). Turn the mast until
the lights face in the desired direction and then tighten the knob.
WARNING
Never raise or lower the mast while the unit is operating.
D
C
B
A
STOP
DETAIL C
DETAIL B
00182
Discount-Equipment.com

16
MAIN CONTROL PANEL - MLT3060MV, MLT3060KV
1. MAIN CIRCUIT BREAKER: This 240V (30A) breaker will disconnect power to the lights and control panel
receptacles.
2. LIGHT SWITCHES: One circuit breaker is supplied for each light.
3. BALLAST INDICATOR LIGHTS: Indicates power from the ballast to each light.
4. ENGINE START SWITCH: Keyed switch operates glow plugs, starts and stops engine.
5. GLOW PLUG INDICATOR: Indicates operation of the engine glow plugs (Mitsubishi engines only).
6. ENGINE HOUR METER: Keeps track of engine hours for service.
7. DC BREAKER: Circuit breaker (10A) for the engine electrical system.
8. 120V DUPLEX RECEPTACLE: This unit is equipped with one 120V (20A) GFCI receptacle to supply power for
accessories connected to the generator when the engine is running and the main circuit breaker is switched “ON/I”.
9. 240V TWIST-LOCK RECEPTACLE: This 240V (30A) receptacle supplies power for accessories connected to
the generator when the engine is running and the main circuit breaker is switched to the “ON/I” position.
10. 120V BREAKER: This 120V (20A) circuit breaker is supplied for the 120V GFCI duplex receptacle.
11. CIRCUIT BREAKER INDICATOR LIGHT: This light indicates that the main circuit breaker must be opened
(switched off) before starting the engine.
9
8
10
11
120V
240V
DC
BREAKER
TURN
MAIN
BREAKER
OFF
120V
BREAKER
MAIN
BREAKER
240V
BALLAST INDICATOR LIGHTS
MAST LIGHT SWITCHES
I
O
I
O
I
O
I
O
NEUTRAL BONDED TO FRAME
ON ON
ON ON ON ON
GLOW PLUG
INDICATOR
OFF
RUN
START
GLOW
PLUG
4
6
7
5
123
00165
Discount-Equipment.com

17
MAIN CONTROL PANEL - MLT3080KV
1. MAIN CIRCUIT BREAKER: This 240V (40A) breaker will disconnect power to the lights and control panel
receptacles.
2. LIGHT SWITCHES: One circuit breaker is supplied for each light.
3. BALLAST INDICATOR LIGHTS: Indicates power from the ballast to each light.
4. 240V BREAKER: This 240V (30A) circuit breaker is supplied for the 240V twist-lock receptacle.
5. ENGINE START SWITCH: Keyed switch operates glow plugs, starts and stops engine.
6. ENGINE HOUR METER: Keeps track of engine hours for service.
7. DC BREAKER: Circuit breaker (10A) for the engine electrical system.
8. 120V DUPLEX RECEPTACLES: This unit is equipped with two 120V (20A) GFCI receptacles to supply power
for accessories connected to the generator when the engine is running and the main circuit breaker is “ON/I”.
9. 240V TWIST- LOCK RECEPTACLE: This 240V (30A) receptacle supplies power for accessories connected to
the generator when the engine is running and both the main circuit breaker and 240V breaker are switched to
the “ON/I” position.
10. 120V BREAKERS: These 120V (20A) circuit breakers are supplied for the 120V GFCI duplex receptacles.
11. CIRCUIT BREAKER INDICATOR LIGHT: This light indicates that the main circuit breaker must be opened
(switched off) before starting the engine.
120V 120V
240V
DC
BREAKER
TURN
MAIN
BREAKER
OFF
120V
BREAKER
120V
BREAKER
MAIN
BREAKER
240V
BALLAST INDICATOR LIGHTS
MAST LIGHT SWITCHES
I
O
I
O
I
O
I
O
240V
BREAKER
NEUTRAL BONDED TO FRAME
I
O
ON ON
ON ON ON ON
ON ON
OFF
RUN
START
GLOW
PLUG
123
5
6
7
9
4
8
11
10
00166
Discount-Equipment.com

18
PRESTART CHECKLIST
Before starting the unit, all items in the prestart checklist must be completed.
Read and understand ALL safety sections at the beginning of this manual.
Ensure all maintenance procedures are up to date. For more information, refer to “General
Maintenance ” on page 24 and Basic Maintenance Schedules beginning on page 25.
The unit must be level.
The unit must be dry. Check for any water inside, on, or near the unit, dry if needed.
Ensure the unit is properly grounded to a good earthen ground. Installation should be in compliance
with the National Electrical Code (NEC), as well as any state and local codes or regulations.
Switch the “CONTROL ON/OFF” toggle switch to “OFF/O”.
Switch all circuit breakers to “OFF/O”.
Inspect all electrical cords; repair or replace any that are cut, worn, or bare.
Ensure all winch cables are in good condition and centered on each pulley. Do not use if cables are
kinked or beginning to unravel.
Check oil, coolant, and fuel levels. For more information, refer to “General Maintenance ” on page 24.
Ensure engine battery connections are secure.
Turn the battery disconnect switch on, if equipped.
STARTING THE UNIT
1. Check that the main circuit breaker and individual
circuit breakers for each of the lights are in the “OFF/
O” position.
Note: When the red “TURN MAIN BREAKER OFF” light
is illuminated, the main circuit breaker must be turned
“OFF/O”.
2. Turn the key on the Engine Start switch to the left
“GLOW PLUG” position and hold the key in place for
five seconds, or until the glow plug indicator turns
red. (Kubota units do not have a glow plug indicator.)
As soon as it is glowing, turn the key to the right “START” position and hold it until the engine cranks and starts
running. Release the key, it will move to the “RUN” position.
Note: For cold weather conditions, refer to the engine operator’s manual for appropriate glow plug interval.
Do not crank the engine longer than 10 seconds at a time. If the engine will not start, wait
30 seconds to allow the starter motor to cool and then repeat the starting procedure.
Excessive cranking will cause damage to the starter.
Note: If oil pressure is not obtained within 15 seconds after the key is switched to the “RUN” position, the low oil
automatic shutdown will turn off the fuel supply, stopping the engine. Check the oil level and turn the key to the “OFF”
position to reset the oil pressure timer before attempting to restart the engine.
3. Once the engine is running, allow it to reach normal operating temperature before switching on any loads.
I
O
I
O
I
O
I
O
CIRCUIT BREAKERS
00202
GLOW
PLUG
OFF
RUN
START
RELEASE KEY
GLOW
PLUG
OFF
RUN
START
A
CTIVATE GLOW PLUG
GLOW
PLUG
OFF
RUN
START
CRANK ENGINE TO START
00203
Discount-Equipment.com

19
AUTOMATIC SHUTDOWN
This unit is equipped with a low oil pressure and high coolant temperature automatic shutdown system. This system
will automatically shut off the fuel supply to stop the engine if oil pressure drops too low or the engine exceeds normal
operating temperature. Return the switch to the “OFF” position to reset the unit after you have determined the cause
of the shutdown.
LIGHT OPERATION
WARNING
NEVER OPERATE THE LIGHTS WITHOUT THE PROTECTIVE LENS COVER, OR WITH
A LENS COVER THAT IS CRACKED OR DAMAGED. The bulbs in the light fixtures
produce high temperatures and operate under pressure. A broken or missing lens
cover could cause the bulbs to shatter, causing injury.
1. Once the engine is up to temperature and running
smoothly, switch the main circuit breaker (A) to the
“ON/I” position.
2. With the main circuit breaker on, switch each individ-
ual circuit breaker for the lights (B) to “ON/I”, one at
a time.
3. The ballast indicator lights (C) will come on and
continue to get brighter as the lights warm up, and
then remain on. This confirms that power is coming
from the ballasts to the lights.
4. If an indicator light does not come on, the ballast may
need to be serviced. If the indicator light comes on
and stays lit, but the related light is not illuminated,
check the bulb or the mast wiring. Refer to “Trouble-
shooting the Lights” on page 29.
5. The lights require a warm up period of 5-15 minutes before they reach full output. If the lights are shut down,
they require a cool down period of approximately 10 minutes before they can be switched on again.
6. The light tower uses four 1000W bulbs. When checking or replacing the bulbs, wipe them with a clean cloth to
avoid leaving any grease, oil residue or fingerprints on the glass. Any residue can create a hot spot on the bulb,
causing premature bulb failure.
CAUTION
Bulbs become extremely hot when in use. Allow bulb fixture to cool 10-15 minutes before
handling or lowering the mast.
DERATING FOR ALTITUDE
All units are subject to derating for altitude and temperature; this will reduce the available power for operating tools
and accessories connected to the receptacles. Typical reductions in performance are 2-4% for every 1000 ft (305
m) of elevation and 1% per 10ºF (5.6ºC) increase in ambient air temperature over 72ºF (22ºC).
120V
240V
DC
BREAKER
TURN
MAIN
BREAKER
OFF
120V
BREAKER
MAIN
BREAKER
240V
BALLAST INDICATOR LIGHTS
MAST LIGHT SWITCHES
I
O
I
O
I
O
I
O
NEUTRAL BONDED TO FRAME
ON ON
ON ON ON ON
GLOW PLUG
INDICATOR
OFF
RUN
START
GLOW
PLUG
ABC
00147
Discount-Equipment.com
