Generac Power Systems RS801 User manual

SAVE THIS MANUAL FOR FUTURE REFERENCE
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(1-888-436-3722)
Installation Manual
Generac SnapRS™
010050
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
Register your Generac product at:
https://register.generac.com/
1-888-GENERAC
(888-436-3722)
Para español, visita: http://www.generac.com/service-support/product-support-lookup
Pour le français, visiter: http://www.generac.com/service-support/product-support-lookup

ii Installation Manual for SnapRS
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.

Installation Manual for SnapRS iii
Section 1: Introduction and Safety
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
Safety Rules .........................................................1
How to Obtain Service .................................................1
General Hazards ..................................................2
PVRSE Warning ...................................................2
Electrical Hazards ................................................3
Safety Shutdown ..................................................3
Section 2: General Information
Specifications ......................................................5
Serial Number Location ......................................5
Unit Dimensions .................................................5
About PV Link Optimizer .....................................5
PVRSS Information ..............................................6
Component Locations .........................................6
Section 3: Installation and Enabling
Instructions
Installing SnapRS Devices .................................7
Enabling Generac SnapRS Devices ...........................8
Section 4: Troubleshooting
DMM Red to SnapRS +, DMM Black to SnapRS – .....9
DMM Red to SnapRS –, DMM Black to SnapRS + .....9

iv Installation Manual for SnapRS
This page intentionally left blank.

Introduction and Safety
Installation Manual for SnapRS 1
Section 1: Introduction and Safety
Introduction
Thank you for purchasing Generac SnapRS™. SnapRS
devices are solid-state switches designed to safely
interrupt a circuit of solar photovoltaic (PV) modules in
the event of a rapid shutdown command from a Generac
PWRcell™ Inverter.
This manual provides instructions for installing SnapRS.
Commissioning instructions are provided in the Generac
PV Link™ Installation Manual. Consult the installation
and operation manuals for other Generac PWRcell
system components, as applicable.
The information in this manual is accurate based on
products produced at the time of publication. The
manufacturer reserves the right to make technical
updates, corrections, and product revisions at any time
without notice.
Read This Manual Thoroughly
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
If any section of this manual is not understood, contact
the nearest Independent Authorized Service Dealer
(IASD) or Generac Customer Service at 1-888-436-3722
(1-888-GENERAC), or visit www.generac.com for assis-
tance. The owner is responsible for correct maintenance
and safe use of the unit.
This manual must be used in conjunction with all other
supporting product documentation supplied with the
product.
SAVE THESE INSTRUCTIONS for future reference. This
manual contains important instructions that must be fol-
lowed during placement, operation, and maintenance of
the unit and its components. Always supply this manual
to any individual that will use this unit, and instruct them
on how to correctly start, operate, and stop the unit in
case of emergency.
Safety Rules
The manufacturer cannot anticipate every possible cir-
cumstance that might involve a hazard. The alerts in this
manual, and on tags and decals affixed to the unit, are
not all inclusive. If using a procedure, work method, or
operating technique that the manufacturer does not spe-
cifically recommend, verify that it is safe for others and
does not render the equipment unsafe.
Throughout this publication, and on tags and decals
affixed to the unit, DANGER, WARNING, CAUTION, and
NOTE blocks are used to alert personnel to special
instructions about a particular operation that may be
hazardous if performed incorrectly or carelessly. Observe
them carefully. Alert definitions are as follows:
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that
they indicate. Common sense and strict compliance with
the special instructions while performing the action or
service are essential to preventing accidents.
How to Obtain Service
For assistance, contact the nearest Independent Autho-
rized Service Dealer (IASD) or Generac Customer Ser-
vice at 1-888-GENERAC (1-888-436-3722), or visit
www.generac.com.
When contacting Generac Customer Service about parts
and service, always supply the complete model and
serial number of the unit as given on its data decal
located on the unit.

Introduction and Safety
2 Installation Manual for SnapRS
General Hazards
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000191)
DANGER
WARNING
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to
service this equipment and could result in death or
serious injury. (000215)
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
(000662)
WARNING
Electric Shock. Consult installation documentation for all
other REbus™ devices on the system. Failure to do so
could result in death, serious injury, and equipment or
property damage.
(000182a)
WARNING
Equipment damage. Only qualified service personnel may
install, operate, and maintain this equipment. Failure to
follow proper installation requirements could result in death,
serious injury, and equipment or property damage.
WARNING
Risk of Burn. Use protective gloves when
handling hot parts. Failure to do so could
result in serious injury.
(000386)
(000667)
Equipment damage. Never open a Generac SnapRS device.
Generac SnapRS devices are factory-sealed and contain
no field-servicable parts. Opening a Generac SnapRS device
could result in equipment damage.
CAUTION
(000665)
Equipment damage. Connect to REbus-compatible PV
optimizers only. Generac SnapRS devices are for use with
ungrounded PV arrays only. Connecting to other equipment
could result in equipment damage.
CAUTION
•Connecting Generac PWRcell to the electric utility
grid must only be done after receiving prior
approval from the utility company.
•Only competent, qualified personnel should install,
operate, and service this equipment. Strictly com-
ply to local, state, and national electrical and build-
ing codes. When using this equipment, comply with
regulations established by the National Electrical
Code (NEC), CSA Standard; the Occupational
Safety and Health Administration (OSHA), or the
local agency for workplace health and safety.
•Protection against lightning surges in accordance
with local electric codes is the responsibility of the
installer.
•If working on this equipment while standing on
metal or concrete, place insulative mats over a dry
wood platform. Work on this equipment only while
standing on such insulative mats.
•Never work on this equipment while physically or
mentally fatigued.
•Any voltage measurements should be performed
with a meter that meets UL3111 safety standards,
and meets or exceeds overvoltage class CAT III.
PVRSE Warning
This Photovotaic Rapid Shutdown Equipment (PVRSE)
does not perform all of the functions of a complete
Photovoltaic Rapid Shutdown System (PVRSS). This
PVRSE must be installed with other equipment to form a
complete PVRSS that meets the requirements of NEC
(NFPA 70) section 690.12 for controlled conductors
within and outside the array. SnapRS devices are for
conductors within the array. Other equipment installed in
or on this PV system may adversely affect the operation
of the PVRSS. It is the responsibility of the installer to
ensure that the completed PV system meets the rapid
shutdown functional requirements.
This equipment must be installed according to the
manufacturer’s installation instructions.

Introduction and Safety
Installation Manual for SnapRS 3
Electrical Hazards
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000599)
DANGER
Electrocution. Turn battery disconnect OFF and
de-energize REbus before touching terminals..
Failure to do so will result in death, serious injury,
equipment and property damage.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000187)
WARNING
Electrocution. Potentially lethal voltages are generated
by this equipment. Render the equipment safe before
attempting repairs or maintenance. Failure to do so
could result in death or serious injury.
(000668)
WARNING
Electric Shock. Cover PV modules in opaque material
before connecting or disconnecting the Generac SnapRS
devices. Failure to do so could result in death or serious
injury.
(000155a
)
WARNING
Electric shock. Only a trained and licensed electrician
should perform wiring and connections to unit. Failure
to follow proper installation requirements could result in
death, serious injury, and equipment or property damage.
(000666)
WARNING
Electric Shock. Avoid contact with DC conductors. DC
conductors of this photovoltaic system are ungrounded and
may be energized regardless of sun exposure. Contact with
conductors could result in death or serious injury.
Safety Shutdown
(000600)
DANGER
Electrocution. Initiate a system-wide safety shutdown
and turn PWRcell Disconnect Switch OFF on all
connected batteries before performing service. Failure
to do so will result in death, serious injury, equipment
and property damage.
NOTE: A loss of grid power will not de-energize REbus
in a system configured to island or provide backup power.
See Figure 1-1. Shutdown button (A) on the Generac
PWRcell Inverter control panel activates Safety
Shutdown. Safety Shutdown signals connected devices
to shutdown and limit output voltage to a safe level. An
external shutdown button may also be installed, given
appropriate labeling. See the Generac PWRcell Inverter
Installation Manual for more information.
To enter Safety Shutdown, press and hold Shutdown (A).
Safety shutdown LED (B) will illuminate and LCD screen
(C) will indicate Safety Shutdown has been initiated.
REbus Inverter
Internet
Shutdown
(hold)
009918
A
C
B
Figure 1-1. Safety Shutdown Button (Located on
Inverter Control Panel)
Upon entering Safety Shutdown, a shutdown signal will
be transmitted to all devices connected to REbus. In
Safety Shutdown:
•Generac PWRcell Inverter will disconnect from the
grid.
•Generac PWRcell Inverter will stop sourcing power
to REbus, and immediately disable all sources on
REbus by sending a global shutdown signal.
•All Generac PV Link Optimizers will disconnect
their output.
•Safety Shutdown LED (B) will be illuminated to
show that the inverter has entered safety shut-
down. REbus DC bus voltage will be displayed on
the inverter screen.

Introduction and Safety
4 Installation Manual for SnapRS
This page intentionally left blank.

Installation Manual for SnapRS 5
General Information
Section 2: General Information
Specifications
Description Units RS801
PV module maximum VOC V 75
Maximum PV Modules per String - 10
Efficiency % 99.8*
Maximum input current A 13
Shutdown time sec < 10
Enclosure rating - NEMA 6P
Operating temperature range ºF (ºC) -40 (-40) to 158 (70)
Certifications - UL 1741
Weight oz (g) 3.5 (100)
*Used with a 50 V PV Panel
Specifications are subject to change without notice. Refer to the product specification sheet for complete list.
Serial Number Location
Refer to Figure 2-1 to locate the unit serial number and
date of manufacture (A). Record the information from this
tag in the PV Link Important Information table located on
the inside front cover of the Generac PV Link Installation
Manual. When requesting assistance, you may be asked
to provide this information.
009954
A
Figure 2-1. Serial Number Location
Unit Dimensions
009955
A
C
B
010051
Figure 2-2. Unit Dimensions
A
B
C
About PV Link Optimizer
Generac SnapRS devices are designed to connect PV
modules within a string array to achieve 2017 and 2020
NEC 690.12 compliance with PV rapid shutdown system
(PVRSS) requirements. When used with Generac PV
Link™, Generac SnapRS devices allow all controlled
conductors within an array’s 1 ft (305 mm) boundary to
be limited to 80 VDC or less within 30 seconds of rapid
shutdown initiation.
SnapRS devices install to the negative (-) whip of each
PV module in the array using MC4 PV connectors. Each
PV module must have exactly one SnapRS device.
During a shutdown event, SnapRS devices isolate PV
modules to satisfy NEC 2017/2020 array conductor
voltage requirements.
NOTE: Generac SnapRS devices are not compatible
with existing Pika S2501 PV Links. If an existing PV array
must be brought into 2017 or 2020 NEC compliance,
Generac S2502 or newer model PV Links are required.
1 in (25.4 mm)
7 in (152.4 mm)
1 in (25.4 mm)

6 Installation Manual for SnapRS
General Information
PVRSS Information
PVRSS requirements have evolved over time and are
defined by the National Electrical Code (NEC) in
conjunction with UL 1741. The 2017 and 2020 NEC
added to the PVRSS requirement by mandating the need
to reduce voltages of controlled conductors to less than
80 VDC within the array. NEC Article 690.12(C) contains
all of the requirements for the type and location of the
PVRSS initiation device. SnapRS is a PV rapid shutdown
system equipment (PVRSE) component within a PVRSS.
Component Locations
010050
A
B
Figure 2-3. Component Locations
TABLE 1. Component Locations
APositive PV Connector
BNegative PV Connector

Installation and Enabling Instructions
Installation Manual for SnapRS 7
Section 3: Installation and Enabling Instructions
Installing SnapRS Devices
NOTE: Before installing SnapRS devices, consult the
Generac PV Link Installation Manual for information on
installing and grounding the PV Link.
When installing SnapRS devices consider the following:
•Each PV Link can control a series-connected string
of two to nine standard PV modules of 60–420
VDC.
•One (1) SnapRS device must be installed to the
negative (-) lead of each PV module in the array.
•PV modules require Staubli (Multi-Contact) MC4
connectors. Brands other than Staubli (Multi-
Contact) MC4 connectors are not recommended.
•See Figure 3-1. PV modules are installed in series
with SnapRS devices connected inline between
each module.
•See Figure 3-2. High-voltage modules can be
configured in parallel strings. See the Generac PV
Link Installation Manual for details.
To install SnapRS devices:
1. See Figure 3-1. Connect one SnapRS device (C)
to the negative (-) whip of each PV module (D).
2. Connect the modules in series with the SnapRS
devices installed inline between modules by con-
necting the positive lead of each module to the
SnapRS device already installed on the negative
lead of the next PV module in the series.
3. Connect the PV string positive lead to PV Link (B)
at the location marked PV Substring Input + (F).
See the Generac PV Link Installation Manual for
more information.
4. Connect the PV string negative lead with its con-
nected SnapRS device to PV Link (B) at the loca-
tion marked PV Substring Input - (E). See the
Generac PV Link Installation Manual for more
information.
5. Secure the SnapRS devices to the racking or mod-
ule frame using zip ties or similar fasteners
AGenerac PWRcell Inverter
BGenerac PV Link
CSnapRS Device
DPV module
EPV Substring Input -
FPV Substring Input +
010028
B
CCCC
C
D
D
D
D
D
DD
D
A
E
F
Figure 3-1. Single-String PV Array with Generac SnapRS™ Devices
NOTE: Figure 3-2. If dual strings are connected in paral-
lel, each string must have the same number of the same
type of PV modules, and there must be one SnapRS
device for each module in each array.
AGenerac PWRcell Inverter
BGenerac PV Link
CSnapRS Device
DPV Module
E MC4 Y Splitter
C
010029
C
ECCC
C
CC
B
A
DD
D
D
D
DD
D
C
Figure 3-2. Parallel-Input PV Array with Generac SnapRS™ Devices

Installation and Enabling Instructions
8 Installation Manual for SnapRS
Enabling Generac SnapRS Devices
Generac SnapRS devices are controlled by Generac PV
Link. See the Generac PV Link Installation Manual for
information on commissioning Generac SnapRS devices.

Installation Manual for SnapRS 9
Troubleshooting
Section 4: Troubleshooting
(000667)
Equipment damage. Never open a Generac SnapRS device.
Generac SnapRS devices are factory-sealed and contain
no field-servicable parts. Opening a Generac SnapRS device
could result in equipment damage.
CAUTION
There are no functional tests that can be performed on
SnapRS devices in the field. However, some simple
digital multimeter (DMM) checks can confirm the general
health of a SnapRS device.
DMM Red to SnapRS +, DMM Black to SnapRS –
Resistance reads ~ 300 kΩ to 350 kΩ
Diode check reads ~ 0.50 V to 0.55 V
DMM Red to SnapRS –, DMM Black to SnapRS +
Resistance reads ~ 12 MΩ

10 Installation Manual for SnapRS
Troubleshooting
This page intentionally left blank.

Part No. DMAN00021 Rev. A 09/30/19
©2019 Generac Power Systems, Inc.
All rights reserved.
Specifications are subject to change without notice.
No reproduction allowed in any form without prior written
consent from Generac Power Systems, Inc.
Generac Power Systems, Inc.
S45 W29290 Hwy. 59
Waukesha, WI 53189
1-888-GENERAC (1-888-436-3722)
www.generac.com
®
