Generac Power Systems MAGNUM MLT4250 User manual

Owner’s Manual
Light Tower
MLT4250
SAVE THIS MANUAL FOR FUTURE REFERENCE
www.discount-equipment.com
Discount-Equipment.com

Discount-Equipment.com is your online resource for commercial and industrial
quality parts and equipment sales.
Locations:
Florida (West Palm Beach): 561-964-4949
Outside Florida TOLL FREE: 877-690-3101
Need parts? Check out our website at www.discount-equipment.com
Can’t find what you need?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and fill out
the request form.
Please have the machine model and serial number available in order to help us get
you the correct parts. One of our experienced staff members will get back to you with
a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone,
Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,
Chicago Pneumatic, Allmand Brothers, Essick, Miller Spreader, Skyjack, Lull, Skytrak,
Tsurumi, Husquvarna/Target, Whiteman-Concrete/Mortar, Stow-Concrete/Mortar, Baldor,
Wacker, Sakai, Snorkel, Upright, Mi-T-M, Sullair, Neal, Basic, Dynapac, MBW, Weber,
Bartell, Bennar Newman, Haulotte, Ditch Runner, Blaw-Knox, Himoinsa, Best, Buddy,
Crown, Edco, Wyco, Bomag, Laymor, Terremite, Barreto, EZ Trench, Takeuchi, Basic, Bil-
Jax, Curtis, Gehl, Heli, Honda, ICS/PowerGrit, Puckett, Waldon, ASV, IHI, Partner, Imer,
Clipper, MMD, Koshin, Rice, Gorman Rupp, CH&E, Cat Pumps, Comet, General Pump,
Giant,AMida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,
Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, Small Line, Wanco, Yanmar
Discount-Equipment.com

ii Owner’s Manual for MLT Light Tower
Use this page to record important information about your Light Tower
Record the information found on your unit data label on
this page. See unit serial number location (Unit Serial
Number Locations). The label plate is affixed to the
inside partition, to the left of the control panel console.
Engine and generator serial numbers are located on
separate data plates affixed to the engine and generator
respectively.
When contacting an Generac Mobile Products
Authorized Service Dealer about parts and service,
always supply the complete model number and serial
number of the unit.
Operation and Maintenance: Proper maintenance and
care of the Light Tower ensures a minimum number of
problems and keeps operating expenses at a minimum. It
is the operator’s responsibility to perform all safety
checks, to verify that all maintenance for safe operation is
performed promptly, and to have the equipment checked
periodically by a Generac Mobile Products Authorized
Service Dealer. Normal maintenance, service and
replacement of parts are the responsibility of the owner
or operator and, as such, are not considered defects in
materials or workmanship within the terms of the
warranty. Individual operating habits and usage may
contribute to the need for additional maintenance or
service.
Unit Model Number
Unit Serial Number
Engine Model
Number
Engine Serial
Number
Generator Model
Number
Generator Serial
Number
(000005)
WARNING
California Proposition 65. This product contains or
emits chemicals known to the state of California to
cause cancer, birth defects, and other reproductive
harm.
(000004)
WARNING
California Proposition 65. Engine exhaust and some
of its constituents are known to the state of California
to cause cancer, birth defects, and other reproductive
harm.
Discount-Equipment.com

Owner’s Manual for MLT Light Tower iii
Section 1: Introduction and Safety
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
How to Obtain Service .................................................1
Safety Rules .........................................................1
General Hazards ..................................................2
Explosion and Fire Hazards ................................2
Trailer Hazards .....................................................2
Electrical Hazards ................................................3
Battery Hazards ...................................................3
Fuel Hazards ........................................................4
Engine Safety .......................................................4
Operating Safety ..................................................4
Positioning the Unit .....................................................4
Starting the Unit ...........................................................4
Raising and Lowering the Mast ...................................5
Service Safety ......................................................5
Towing Safety ......................................................6
Hitch and Coupling ......................................................6
Running Lights ............................................................6
Wheels and Tires ........................................................6
Safe Towing Techniques .............................................6
Reporting Trailer Safety Defects ........................6
Section 2: General Information
Specifications ......................................................7
Unit Serial Number Locations ............................9
Component Locations .......................................10
Main Control Panel ............................................11
Section 3:Operation
Light Tower Setup .............................................13
Raising the Mast ................................................14
Magnum Digital Controller (MDC) Features and
Functions ............................................................15
Generator Monitoring ........................................15
Engine Monitoring .............................................16
MDC Fault Reset ................................................17
MDC Operational Status ................................... 17
MDC Alarm Management .................................. 17
MDC List of Alarms ........................................... 18
MDC History ....................................................... 19
Adjusting the Backlighting ............................... 19
Generator Output Connection Lugs ................ 19
Voltage Selector Switch .................................... 20
Emergency Stop Switch ................................... 20
Prestart Checklist .............................................. 21
Starting the Unit—Manually ............................. 21
Starting the Unit—Auto/Remote ...................... 23
Automatic Shutdown ........................................ 23
Light Operation .................................................. 23
Auxiliary Outlets ................................................ 24
Wet Stacking ...................................................... 24
Voltage Regulator .............................................. 24
Engine Derating ................................................. 24
Main Circuit Breaker ......................................... 24
Remote Start Terminal Block ........................... 25
Transfer Switch ................................................. 25
Auto Exercise Time ........................................... 26
Fine Voltage Adjustment .................................. 26
Shutting Down the Unit ..................................... 26
Lowering the Mast ............................................. 27
Removing the Lights for Transportation ......... 27
Towing the Unit ................................................. 28
Lifting the Unit ................................................... 28
Section 4:Maintenance
Emissions Information ...................................... 31
Daily Walk-Around Inspection ......................... 31
General Maintenance ........................................ 31
Preparing for Service .................................................31
Cleaning the Unit .......................................................31
Inspecting the Unit .....................................................31
Basic Maintenance Schedule ........................... 32
Resetting the “Time to Service” Reminder ..... 33
Table of Contents
Discount-Equipment.com

iv Owner’s Manual for MLT Light Tower
Winch Use, Operation and Maintenance .........34
Prior to Use ............................................................... 34
Operation .................................................................. 34
Maintenance ............................................................. 34
Optional Lower Radiator Hose Heater Use and
Maintenance .......................................................34
Trailer Wheel Bearings ......................................34
Jack Maintenance ..............................................35
Section 5:Troubleshooting
General Troubleshooting ..................................37
Troubleshooting the Lights ..............................38
Section 6:Wiring Diagrams
Mast Junction Box Wiring and Light
Connections .......................................................39
AC Wiring Diagram ............................................40
AC Wiring Diagram—Receptacle Panel ...........41
AC Wiring Diagram—Receptacle Panel
Options (1 of 2) ..................................................42
AC Wiring Diagram—Receptacle Panel
Options (2 of 2) ..................................................43
DC Wiring Diagram ............................................44
DC Wiring Diagram—Optional Equipment .....45
Trailer Lights Wiring ..........................................46
Discount-Equipment.com

Introduction and Safety
Owner’s Manual for MLT Light Tower 1
Section 1: Introduction and Safety
Introduction
Thank you for purchasing a Generac Mobile Products LLC
product. This unit has been designed to provide high
performance, efficient operation, and years of use when
maintained properly.
The information in this manual is accurate based on
products produced at the time of publication. The
manufacturer reserves the right to make technical updates,
corrections, and product revisions at any time without
notice.
Read This Manual Thoroughly
The owner is responsible for proper maintenance and safe
use of the equipment. Comply with regulations the
Occupational Safety and Health Administration (OSHA)
has established, or with equivalent standards. Also, verify
that the unit is applied, used, and maintained in accordance
with the manufacturer's instructions and recommendations.
Do nothing that might alter safe application/usage and
render the unit in noncompliance with the aforementioned
codes, standards, laws, and regulations .
Save these instructions for future reference. This manual
contains important instructions for the unit that should be
followed during setup, operation and maintenance of the
unit and battery.ALWAYS supply this manual to any
individual that will use this machine.
How to Obtain Service
When the unit requires servicing or repairs, contact a
Generac Mobile Products Authorized Dealer for assistance.
Service technicians are factory-trained and are capable of
handling all service needs.
Safety Rules
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings in
this manual, and on tags and decals affixed to the unit are,
therefore, not all inclusive. If using a procedure, work
method or operating technique that the manufacturer does
not specifically recommend, verify that it is safe for others.
Also make sure the procedure, work method or operating
technique utilized does not render the equipment unsafe.
Throughout this publication, and on tags and decals affixed
to the unit, DANGER, WARNING, CAUTION and NOTE
blocks are used to alert personnel to special instructions
about a particular operation that may be hazardous if
performed incorrectly or carelessly. Observe them
carefully. Their definitions are as follows:
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that they
indicate. Common sense and strict compliance with the
special instructions while performing the action or service
are essential to preventing accidents.
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Discount-Equipment.com

Introduction and Safety
2Owner’s Manual for MLT Light Tower
General Hazards Explosion and Fire Hazards
Trailer Hazards
Asphyxiation. Running engines produce
carbon monoxide, a colorless, odorless,
poisonous gas. Carbon monoxide, if not
avoided, will result in death or serious injury.
(000103)
DANGER
(000107)
WARNING
Hearing Loss. Hearing protection is
recommended when using this machine.
Failure to wear hearing protection could
result in permanant hearing loss.
(000111)
WARNING
Moving Parts. Keep clothing, hair, and
appendages away from moving parts. Failure
to do so could result in death or serious injury.
(000108)
WARNING
Hot Surfaces. When operating machine, do not
touch hot surfaces. Keep machine away from
combustibles during use. Hot surfaces could
result in severe burns or fire.
WARNING
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to service
this equipment and could result in death or serious
injury. (000215)
(000139)
WARNING
Risk of burns. Allow engine to cool before
draining oil or coolant. Failure to do so could
result in death or serious injury.
(000105)
DANGER
Explosion and Fire. Fuel and vapors are
extremely flammable and explosive. Add fuel
in a well ventilated area. Keep fire and spark
away. Failure to do so will result in death
or serious injury.
(000147)
WARNING
Risk of Fire. Unit must be positioned in a
manner that prevents combustible material
accumulation underneath. Failure to do so
could result in death or serious injury.
(000110)
WARNING
Risk of Fire. Hot surfaces could ignite
combustibles, resulting in fire. Fire could
result in death or serious injury.
WARNING
Trailer must be securely coupled to the hitch and the
chains correctly attached. Uncoupled or unchained
towing could result in death or serious injury.
(000233)
WARNING
Do not operate this unit while transporting. Doing so
could result in death or serious injury.
(000231)
(000234a)
WARNING
Crushing hazard. Verify unit is properly secured and
on level ground. An unsecured unit can suddenly roll
or move, causing death or serious injury.
WARNING
Property or Equipment Damage. Tighten wheel lug
nuts after first 50 miles to factory specifications.
Failure to do so could result in death, serious injury,
property or equipment damage. (000235)
Discount-Equipment.com

Introduction and Safety
Owner’s Manual for MLT Light Tower 3
Electrical Hazards Battery Hazards
Always recycle batteries in accordance with local laws and
regulations. Contact your local solid waste collection site
or recycling facility to obtain information on local recycling
processes. For more information on battery recycling, visit
the Battery Council International website at: http://
batterycouncil.org
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000144)
DANGER
Electrocution. Contact with bare wires,
terminals, and connections while generator
is running will result in death or serious injury.
(000152)
DANGER
Electrocution. Verify electrical system is
properly grounded before applying power.
Failure to do so will result in death or serious
injury.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000137a)
WARNING
Explosion. Batteries emit explosive gases while charging.
Keep fire and spark away. Wear protective gear when
working with batteries. Failure to do so could result in
death or serious injury.
(000162)
WARNING
Explosion. Do not dispose of batteries in a fire. Batteries
are explosive. Electrolyte solution can cause burns and
blindness. If electrolyte contacts skin or eyes, flush with water
and seek immediate medical attention.
(000163a)
WARNING
Risk of burn. Do not open or mutilate batteries.
Batteries contain electrolyte solution which can
cause burns and blindness. If electrolyte contacts
skin or eyes, flush with water and seek immediate
medical attention.
WARNING
Environmental Hazard. Always recycle batteries at an
official recycling center in accordance with all local
laws and regulations. Failure to do so could result in
environmental damage, death or serious injury.
(000228)
Discount-Equipment.com

Introduction and Safety
4Owner’s Manual for MLT Light Tower
Fuel Hazards
•DO NOT fill fuel tank near an open flame, while
smoking, or while engine is running. DO NOT fill
tank in an enclosed area with poor ventilation.
•DO NOT operate with the fuel tank cap loose or
missing.
Engine Safety
Internal combustion engines present special hazards
during operation and fueling. Failure to follow the safety
guidelines described below could result in severe injury or
death. Read and follow all safety alerts described in the
engine operator's manual. A copy of this manual was
supplied with the unit when it was shipped from the factory.
•DO NOT run engine indoors or in an area with poor
ventilation. Make sure engine exhaust cannot seep
into closed rooms or ventilation equipment.
•DO NOT clean air filter with gasoline or other types
of low flash point solvents.
•DO NOT operate the unit without a functional
exhaust system.
•Shut the engine down if any of the following
conditions exist during operation:
• Noticeable change in engine speed.
• Loss of electrical output.
• Equipment connected to the unit overheats.
• Sparking occurs.
• Engine misfires or there is excessive engine/
generator vibration.
• Protective covers are loose or missing.
• Ambient air temperature is above 120°F (49°C).
Operating Safety
Positioning the Unit
•The area immediately surrounding the unit should
be dry, clean, and free of debris.
•Position and operate the unit on a firm, level
surface.
•If the unit is equipped with a frame grounding stud,
follow the National Electrical Code (NEC), state,
and local regulations when connecting.
Starting the Unit
(000192)
DANGER
Explosion and fire.Fuel and vapors are extremely
flammable and explosive. No leakage of fuel is
permitted. Keep fire and spark away. Failure to do
so will result in death or serious injury.
(000174)
DANGER
Risk of fire. Allow fuel spills to completely dry
before starting engine. Failure to do so will
result in death or serious injury.
(000260a)
High Voltage. Verify area above unit is clear
of overhead wires and obstructions. Contact
with high-voltage power lines will result in
death or serious injury.
DANGER
(000277)
WARNING
Burn hazard. Never operate lights with a
damaged or missing lens cover. Lamps are
hot and pressurized while in use. Unprotected
lamps can shatter, causing severe injury.
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)
CAUTION
(000291)
Equipment damage. Do not attempt to start or operate
a unit in need of repair or scheduled maintenance.
Doing so could result in serious injury, death, or
equipment failure or damage.
WARNING
Discount-Equipment.com

Introduction and Safety
Owner’s Manual for MLT Light Tower 5
Raising and Lowering the Mast
•Keep area around the unit clear of people while
raising and lowering the mast.
•ALWAYS lower the mast when not in use.
•The tower extends up to 30 ft (9.14 m). Make sure
area above trailer is open and clear of overhead
wires and obstructions.
•If for any reason any part of mast hangs up or
winch cable develops slack while raising or
lowering tower, STOP immediately! Contact a
Generac Mobile Products Authorized Service
Dealer.
•NEVER remove safety pin or pull mast locking pin
while tower is up.
Service Safety
This unit uses high voltage circuits capable of causing
serious injury or death. Only a qualified and licensed
electrician should troubleshoot or repair problems
occurring in this equipment.
• Before servicing the unit, verify the Control Power
switch and circuit breakers are in the OFF (O)
position, and the negative (-) terminal on the battery
is disconnected.
DO NOT perform even routine
service (oil/filter changes, cleaning, etc.) unless all
electrical components are shut down.
• ALWAYS use extreme caution when servicing this
unit in damp conditions. Do not service the unit if your
skin or clothing is wet. Do not allow water to collect
around the base of the unit.
• DO NOT wash the unit with high pressure hoses,
power washers, or steam cleaners. Water may
collect in the unit, causing damage to electrical parts.
• Replace all missing and hard to read decals. Decals
provide important operating instructions and warn of
dangers and hazards.
• Wear heavy leather gloves when handling winch
cables. Never let cables slip through bare hands.
• Only use mild soap and water to clean the lens covers.
Other chemicals may damage the lens covers.
• Make sure slings, chains, hooks, ramps, jacks and
other types of lifting devices are attached securely
and have enough weight-bearing capacity to lift or
hold the equipment safely. Always remain aware of
the position of other people around you when lifting
the equipment.
WARNING
Electrocution. Do not set up or operate
this unit if severe weather is expected.
Lightning strikes can kill or cause severe injury
even if you are not touching the unit. (000296)
WARNING
(000297)
> 60 mph> 60 mph Do not set up the unit if high winds
are expected. High winds can cause the
unit to tip or fall, causing severe injury
or machine damage.
(000279)
Personal injury or equipment damage. Do not raise
or lower the mast while the unit is operating.
Doing so can break the lenses and cause the
lamps to shatter.
WARNING
WARNING
Personal Injury. Stop immediately if the mast hangs
up or the winch cable develops slack. Excess slack
could cause the mast to collapse, resulting in personal
injury or equipment damage. (000265)
WARNING
Tipping hazard. Extend the outriggers and level the unit
before raising the mast. Keep the outriggers extended
while the mast is up. Failure to do so could cause the unit
to tip and fall and could result in death or serious injury.
(000266)
(000278)
WARNING
Burn hazard. Lamps become extremely hot
while in use. Allow 10–15 minutes for cooling
before handling or lowering mast. Touching a
hot lens or fixture can cause severe burns.
Discount-Equipment.com

Introduction and Safety
6Owner’s Manual for MLT Light Tower
Towing Safety
Towing a trailer requires care. Both the trailer and vehicle
must be in good condition and securely fastened to each
other to reduce the possibility of an accident. Some states
require that large trailers be registered and licensed.
Contact your local Department of Transportation office to
check on license requirements for your particular unit.
Hitch and Coupling
•Verify the hitch and coupling on the towing vehicle
are rated equal to, or greater than, the trailer's
Gross Vehicle Weight Rating (GVWR).
•Verify the trailer hitch and the coupling are
compatible. Make sure the coupling is securely
fastened to the vehicle.
•DO NOT tow trailer using defective parts. Inspect
the hitch and coupling for wear or damage.
•Connect safety chains in a crossing pattern under
the tongue.
•Before towing the trailer, verify that the weight of
the trailer is equal across all tires. On trailers with
adjustable height hitches, adjust the angle of the
trailer tongue to keep the trailer as level as
possible.
•Attach the breakaway cable to the rear bumper of
the towing vehicle.
Running Lights
Verify directional and brake lights on the trailer are
connected and working properly
Wheels and Tires
•Check trailer tires for wear and proper inflation.
•Verify wheel lug nuts are present and tightened to
the specified torque.
Safe Towing Techniques
•Practice turning, stopping and backing up in an
area away from heavy traffic prior to transporting
the unit.
•Maximum recommended speed for highway towing
is 45 mph (72 km/h). Recommended off-road
towing speed is 10 mph (16 km/h) or less,
depending on terrain.
•When towing, maintain extra space between
vehicles and avoid soft shoulders, curbs and
sudden lane changes.
Reporting Trailer Safety Defects
If you believe your trailer has a defect which could cause
a crash or could cause injury or death, you should
immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying Generac
Mobile Products LLC.
If NHTSA receives similar complaints, it may open an
investigation; and if it finds that a safety defect exists in a
group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in
an individual problem between you, your dealer, or
Generac Mobile Products LLC.
To contact NHTSA, you may either call the Auto Safety
Hotline toll-free at 1-888-327-4236 (TTY:1-800-424-9153),
go to http://www.safercar.gov; or write to:
Administrator
NHTSA
1200 New Jersey Avenue S.E.
Washington, DC 20590
You can also obtain other information about motor vehicle
safety from http://www.safercar.gov.
Discount-Equipment.com

General Information
Owner’s Manual for MLT Light Tower 7
Section 2: General Information
Specifications
DESCRIPTION UNITS MLT4250
Engine
Make/Brand — Isuzu
Model — 4LE1NYGV-03 / 4LE1NYGV-03E
EPA Tier — 4i
Type Diesel, liquid cooled, 4-stroke
Horsepower - prime hp (kW) 31.5 (23.5)
Horsepower - standby hp (kW) 34.5 (25.7)
Operating Speed rpm 1800
Displacement in3 (L) 134.25 (2.20)
Cylinders qty 4
Fuel Consumption—100% Prime gph (Lph) 1.80 (6.81)
Battery Type—Group Number — 24
Battery Voltage quantity per unit 12V (1)
Battery Rating CCA-hour 720
Generator
Make/Brand — Marathon Electric
Model — 282NSL1505
Type, Insulation — Brushless, H
3Ø - Standby kW (kVA) 20.0 (25)
Amps - 3Ø Standby -480V (208V) A 30 (69)
3Ø - Prime kW (kVA) 18 (23)
Amps - 3Ø Prime - 480V (208V) A 28 (64)
1Ø - Standby kW (kVA) 16.0 (16.0)
Amps - 1Ø Standby - 240V A67
1Ø - Prime kW (kVA) 15.0 (15.0)
Amps - 1Ø Prime - 240V A63
Frequency Hz Hertz 60
Power Factor — 1 (1Ø), 0.8 (3Ø)
Sound (23 ft at prime) dB (A) 70
Weights
Dry Weight lbs (kg) 2158 (979)
Operating Weight lbs (kg) 2556 (1159)
Capacities
Fuel Tank Volume gal (L) 56 (212)
Usable Fuel Volume gal (L) 56 (212)
Coolant (including engine) qt (L) 11.6 (11.0)
Oil (including filter) qt (L) 8.6 (8.1)
Maximum Run Time hours 31
AC Distribution
Circuit Breaker Size amperes 90
Voltage Selection 3 Position Switch (lockable)
Voltage Regulation — +/-1%
Voltages Available 1Ø — 120, 139, 208, 220, 240, 277
Voltages Available 3Ø 208, 220, 440, 480
Lighting
Lighting Type — Metal Halide
Ballast Type — Coil & Core
Lumens — 440,000-462,000
Coverage acres (m2)5 - 7 (20,234 - 28,328)
Trailer
Number of Axles 1
Capacity - Axle Rating lbs (kg) 3000 (1361)
Tire Size in 15
Hitch—Standard — 2" Ball
Maximum Tire Pressure psi 50
Specifications are subject to change without notice.
Discount-Equipment.com

General Information
8Owner’s Manual for MLT Light Tower
Unit Dimensions
Figure 2-1. Unit Dimensions
Specifications are subject to change without notice.
ABCDE
MLT4250 170 in
(4.32 m)
70 in
(1.78 m)
30 ft
(9.14 m)
68 in
(1.73 m)
140 in
(3.56 m)
E
C
D
B
A
004647
Discount-Equipment.com

General Information
Owner’s Manual for MLT Light Tower 9
Unit Serial Number Locations
Refer to the illustration to locate the unit ID tag and
Vehicle Identification Number (VIN) tag on the unit.
Important information, such as the unit serial number,
model number, VIN and tire loading information are found
on these tags. Record the information from these tags so
it is available if the tags are lost or damaged. When
ordering parts or requesting assistance, you may be
asked to provide this information.
Figure 2-2. Serial Number Locations
VIN Tag
TIRE AND LOADING INFORMATION
RENSEIGNEMENTS SUR LES
PNEUS ET LE CHARGEMENT
SEE OWNER’S
MANUAL FOR
ADDITIONAL
INFORMATION
VOIR LE
MANUEL DE
L’USAGER
POUR
PLUS DE
RENSEIGNEMENTS
MANUFACTURED BY/FABRIQUE PAR: Generac Mobile Products LLC DATE: 00/0000
GVWR/PNBV: 000KG (0000LBS) COLD INF. PRESS./
PRESS. DE
V.I.N./N.I.V.:
00000000000000000
TYPE: TRAILER
MODEL:
XXX000
GAWR / PNBE TIRE / PNEU RIM / JANTE GONF A FROID - KPA(PSI/LPC) SGL / DUAL
EACH
AXLE
THIS VEHICLE CONFORMS TO ALLAPPLICABLE STANDARDS PRESCRIBED UNDER THE U.S. FEDERAL MOTOR VEHICLE SAFETY STANDARDS(FMVSS)AND CANADIAN
MOTOR VEHICLE SAFETY REGULATIONSIN EFFECT ON THE DATE OF MANUFACTURE.
CE VEHICULE EST CONFORMEA TOUTES LES NORMES QUI LUI SONT APPLICABLES EN VERTU DU REGLEMENT SUR LA SECURITE DES VEHICULESAUTOMOBILES DU CANADA EN VIGUEUR A LA DATESA
FABRICATION.
The weight of cargo should never exceed 0000KG (0000LBS)
Le poids du chargement ne doit jamais depasser 0000KG (0000LBS)
Unit ID Tag
Located on inside
of front panel
Serial Number
V
A
Model
KVA
Manufacturing Code
1 ph. 1.0PF 3 ph. .8PF 3 ph. 1.0PF
KW
Country of Origin
Weight (lbs/kg) RPM/Frequency
Rating
Ins. Class
FOR ELECTRICAL EQUIPMENT
ONLY.POUR MATERIAL
ELECTRIQUE SEULEMENT.
209649
Form: SFC626B
Manufactured by Generac Mobile Products, LLC.,
[phone] [phone]
004650
Discount-Equipment.com

General Information
10 Owner’s Manual for MLT Light Tower
Component Locations
Figure 2-3. Component Location
AMast rotation knob ELower Forklift pockets IUpper forklift pockets
BCentral lifting point FBattery JFuel fill
CEngine exhaust GControl box KOutriggers
DEmergency Stop Switch HRadiator box LEngine access
LEFT SIDE
RIGHT SIDE
004497
AB
C
D
E
F
G
H
J
I
K
L
Discount-Equipment.com

General Information
Owner’s Manual for MLT Light Tower 11
Main Control Panel
Figure 2-4. Control Panel
(A) Receptacle Panel Main Circuit Breaker (100A)
This breaker disconnects power to the receptacle panel.
(B) Individual Circuit Breaker
One breaker is supplied for each light.
(C) Ballast Indicator Lights
Indicates power from the ballast to each light .
(D) Engine Control Panel
Refer to Magnum Digital Controller (MDC) Features
and Functions.
(E) Lug Door Safety Switches
These switches will shut down the unit if the lug door is
opened when the unit is running.
(F) Voltage Selector Switch
This switch will change the generator output between
three phase and single phase power. For more
information, refer to Voltage Selector Switch.
(G) Cable Access
Allows for entry of load cables to the connection lugs with
the lug box door closed.
(H) Remote Start Terminal Block
Allows connections for remote starting of the unit.
(I) Generator Ground Connection Lug
This is for connecting a good earthen ground per the
National Electrical Code (NEC), state, and local
regulations before starting the unit.
(J) Generator Output Connection Lugs
These allow appropriate loads to be wired directly to the
generator.
(K) Main Circuit Breaker (90A)
This breaker will disconnect power to the connection
lugs.
004678
A
B
C
D
E
F
G
H
I
J
E
K
Discount-Equipment.com

Operation
Owner’s Manual for MLT Light Tower 13
Section 3: Operation
Light Tower Setup
Figure 3-1. Set Up Outriggers and Jacks
1. For maximum light coverage, position the unit at
ground level or in a spot higher than the area being
illuminated by the lamps.
NOTE: The mast extends up to 30 ft (9.14 m).
2. See Figure 3-1. Place the unit on firm ground that
is relatively flat (less than 5° slope), and then block
the wheels to keep it from moving (A).This will
make it easier to level the unit.
3. Pull the locking pin on the tongue jack and rotate
the jack 90° until the spring loaded pin snaps back
into place (B). Turn the jack handle clockwise to
raise the trailer tongue off of the towing vehicle.
4. A grounding stud (C) is located on the frame of the
trailer near the trailer tongue. For grounding
requirements, follow the National Electrical Code
(NEC), state, and local regulations.
5. Pull the locking pins (D) on the outriggers (E) and
pull each outrigger out until the spring loaded
locking pin snaps back into place. Pull the locking
pin on each outrigger jack and rotate each jack 90°
so the jack pad is facing down, and the spring
loaded pin snaps back into place.
6. Pull the locking pin on the rear jack (F) and rotate
the jack 90° until the spring loaded pin snaps back
DETAIL C
DETAIL D
DETAIL G
DETAIL H
004659
J
H
H
F
A
G
ED
C
B
D
E
(000260a)
High Voltage. Verify area above unit is clear
of overhead wires and obstructions. Contact
with high-voltage power lines will result in
death or serious injury.
DANGER
WARNING
(000297)
> 60 mph> 60 mph Do not set up the unit if high winds
are expected. High winds can cause the
unit to tip or fall, causing severe injury
or machine damage.
Discount-Equipment.com

Operation
14 Owner’s Manual for MLT Light Tower
into place. Turn the jack handle clockwise to start
leveling the trailer.
7. Rotate each jack handle clockwise to start leveling
the trailer. Adjust all four jacks by rotating their
handles clockwise until they are firmly in contact
with the ground (G).
8. Before raising the mast, it may be necessary to
adjust the lamps. The lamps may be adjusted up,
down, left or right by loosening the wing nuts on the
trunnion (H) and aiming the lamps in the desired
direction. Tighten the hardware completely and
make sure the lamps are connected to the junction
box (J).
Raising the Mast
1. Set up and level the unit. See Light Tower Setup.
2. See Figure 3-2. Remove mast cradle locking pin
from mast cradle (A).
3. Check mast cables for excessive wear or damage.
Verify the cables are properly centered in each
pulley (B). Check the electrical cord for damage.
4. Verify the area around the unit is clear before
raising the mast to vertical position.
5. Remove the safety pin from the mast lock bar (C).
Using the handle for the lower mast winch (D),
raise the mast until it is vertical and the tab on the
mast is positioned into the mast lock. The mast
lock bar should snap into place automatically.
Secure the lock with the safety pin (E).
6. After mast is up and locked into place, use upper
mast winch (F) to telescope the mast to the desired
height. Extend mast slowly, verifying the electrical
cord is extending at the top sections of the mast.
Do not extend past the colored mark (G).
IMPORTANT NOTE: Contact a Generac Mobile Prod-
ucts Authorized Service Dealer immediately if the
mast hangs up or the winch cable develops slack.
7. Rotate mast by loosening mast rotation knob at
bottom of mast (H). Turn mast until the lights face
in the desired direction and then tighten the knob.
Figure 3-2. Raising the Mast
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)
WARNING
Tipping hazard. Extend the outriggers and level the unit
before raising the mast. Keep the outriggers extended
while the mast is up. Failure to do so could cause the unit
to tip and fall and could result in death or serious injury.
(000266)
DETAIL C
STOP
DETAIL E
DETAIL G
DETAIL A
004660
B
B
H
A
E
C
F
D
B
WARNING
Tipping hazard. Do not extend the mast beyond the
colored mark on the second mast section. The unit
can become unstable and tip or fall, causing injury.
(000262)
WARNING
Personal Injury. Stop immediately if the mast hangs
up or the winch cable develops slack. Excess slack
could cause the mast to collapse, resulting in personal
injury or equipment damage. (000265)
(000279)
Personal injury or equipment damage. Do not raise
or lower the mast while the unit is operating.
Doing so can break the lenses and cause the
lamps to shatter.
WARNING
Discount-Equipment.com

Operation
Owner’s Manual for MLT Light Tower 15
Magnum Digital Controller (MDC) Features and Functions
Figure 3-3. Magnum Digital Controller
(A) Control Power Switch and Fine Voltage Adjust-
ment Screw
•Control Power Switch: This toggle switch powers
up the control panel.
•Fine Voltage Adjustment Screw: This screw may
be adjusted to set the generator output voltage
after the voltage selector switch has been changed
from one phase to another. This adjustment MUST
be accomplished within 45 seconds of startup,
during the “V Detect”, so that the unit does not
experience a shutdown alarm for “over or under
voltage.” For more information, refer to Fine
Voltage Adjustment.
(B) Status LEDs
One breaker is supplied for each light.
•Alarm/Fault: Indicates active or inactive alarms,
but not reset shutdown alarms.
•Warning: Indicates an active or inactive alarm, or
a warning alarm that has not been reset.
•Ready/Manual: Indicates the controller is ready to
start and in the Manual mode.
•Ready/Auto: Indicates the unit is in the Auto mode
ready for the remote start signal.
•Running: Indicates the unit is running.
•Supplying Load: Indicates a load is being applied
to the generator.
(C) Diagnostic Keypad
•:Press this button to scroll up within the LCD
window.
•: Press this button to scroll down within the LCD
window.
•Page Select: Pressing this button will select the
next display screen.
•Enter: Pressing this button will place you inside the
particular display to review the unit’s
preprogrammed setpoints or parameters.
(D) Liquid Crystal Display (LCD)
Displays screen upon startup of the unit. By viewing
these screens, the operator will be able to monitor both
the engine and generator status while the unit is running.
(E) Operation Keypad
•Engine Start: The unit must be in the “MAN” mode
in the upper left corner of the LCD window and the
Ready/Manual LED lit in the Status portion of the
controller.
•Engine Stop: Press the red Engine Stop button to
shut down the unit and start the stop value timer.
•Manual :Press this button to change from the
Automatic (Remote) mode to Manual mode.
•Auto :Press this button to change from Manual
mode to Automatic (Remote) mode.
•Alarm Cancel: When an alarm is activated, press
this button to silence and cancel the alarm.
•Fault Reset: Press this button to clear the fault
from the LCD window after the fault has been
corrected.
Generator Monitoring
See Figure 3-4. Generator information is shown in a
toggling manner with the engine information after the first
60 seconds of operation, then every five seconds. The
generator screen will show frequency, line to neutral
voltage, line to line voltage and amperage.
004679
A
B
D
E
C
Discount-Equipment.com

Operation
16 Owner’s Manual for MLT Light Tower
NOTE: When loading the generator, it is important to
observe the amperage to determine the load balance on
each line of the generator. Minor load unbalances,
usually 10% or less, will not cause any particular
problems. Every effort should be made to distribute the
load equally between all lines.
•Hertz: Displays output frequency.
•Generator Output Voltage: Line to Neutral
display, single phase (1Ø).
•Generator Output Voltage: Line to Line display, 3
phase (3Ø).
•Amps: Displays the AC output amperage
produced by the generator
Figure 3-4. Generator Screen
Engine Monitoring
Engine information is shown in a toggling manner with
the generator information after the first 60 seconds of
operation and then every five seconds. The engine
screen will show oil pressure, engine coolant
temperature, and battery voltage.
•Oil Press: Displays engine oil pressure. The
display registers oil pressure between 0-100 psi (0-
689 kPa). Normal operating pressure is between
35-80 psi (241-552 kPa).
•Engine Temp: Displays the temperature of the
engine’s coolant. If the coolant temperature
exceeds the maximum water temperature of 230°F
(110°C) the engine will automatically shut down.
Zero “0” will be displayed until a minimum
temperature of 100°F (38°C) is reached.
•Vbat: Displays the engine battery voltage. A
normal reading is 13-14V on 12 volt systems and
24-26V on 24 volt systems (with the engine
running).
Figure 3-5. Engine Screen
Additional information may be viewed while the unit is in
Manual or Auto mode. By pressing the Page Select
button, the operator will select one of the following
screens: Running, Password, or History. In each of these
page selections the operator may press the or 
buttons on the Diagnostics keypad to display additional
information as follows:
•See Figure 3-6. Running screen: Press the or
buttons on the Diagnostics keypad to display the
Alarm List screen, Run Hours screen, engine
display screen and generator screen.
Figure 3-6. Running Screen
•See Figure 3-7. Password screen: Press the 
or buttons on the Diagnostics keypad to move
the (>) cursor up or down a list of text.
Figure 3-7. Password Screen
•See Figure 3-8. History screen: Press the or
buttons to move the (>) cursor up or down a list
of recent alarm or shutdown codes. Pres Enter at a
particular selection to scroll to the right in the LCD
window to view the unit’s operating parameters at
the time of the alarm or shutdown. The history of
alarms or codes is saved in the digital controller.
004680
004681
004526
004527
