Genie SSAHD2BVAF User manual

Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference. All the examples and pictures used
here are for reference only. The contents of this manual are subject
to change without notice.
2MP Stainless Steel AHD IR
Bullet Camera with 2.8-12mm
Auto Lens
SSAHD2BVAF

Quick Start Guide 2MP Stainless Steel AHD IR Bullet Camera with 2.8-12mm Auto Lens
2
Features
• 1/2.8” Sony Starvis CMOS image sensor
• Full HD (1920 × 1080) resolution
• Auto compensation and long range transmission
• Stainless steel body (AISI 316L grade)
• 2 pcs pearl LED’s
• 2.8~12mm DC auto iris motorised megapixel lens
• True day & night with ICR mechanism
• Excellent low illumination performance
• 3D DNR (Digital Noise Reduction)
• Sens-up
• D-WDR (Digital Wide Dynamic Range)
• IP67 ingress protection
• DC12V
• Wall mount bracket option
• NDAA compliant
Specifications
Camera
Image Sensor 1/2.8” Sony Starvis CMOS sensor
Scanning System Progressive
Resolution 1080p
Minimum Illumination 0.01 Lux at IR off (F1.0), 0.00 Lux at IR on
Lens 2.8~12mm motorised DC auto iris lens (ICR)
S / N Ratio More than 50dB (AGC Off)
Video Output Universal AHD, CVI, TVI: 1080p, 720p
Analogue: NTSC/ PAL CVBS
Functions
Sens-Up Off / x2 – x30
DNR Off / Low / Middle / High
Backlight Off / BLC / HSBLC
D-WDR Off / 0–8
Motion Detection Off / On
Privacy Mask 4 Masks
Others
Ingress Protection IP67
Power Supply DC12V (± 10%)
Power Consumption Max 4.0W
Working Environment Temperature: – 10°C ~ 50°C,
Humidity: 10 % ~ 85 %
Dimensions 76 × 158.5 × 120 mm
Weight 2080g

Quick Start Guide 2MP Stainless Steel AHD IR Bullet Camera with 2.8-12mm Auto Lens
3
Dimensions
Cable
CAUTION! Please use regulated power supply DC12V 500mA
Reverse Polarity Protection
Installation
Step 1
158.5mm
121.5mm
120mm
76mm
Accessories
Fix bracket in desired place. Adjust the angle of view
with the 3-axis bracket.
Step 2
L-Wrench
Wall Mount Bracket
(Option)
Mounting Screws
Mounting screws
Wall mount bracket (option)Screws
Serve cable
Mounting screws
Wall mount bracket (option)Screws
Serve cable
Mounting screws
Wall mount bracket (option)
Screws
Serve cable
Screws
DC12V
VIDEO
OSD
