GENUINE CU 500 User manual

Owner’s Manual
CU 500

NOTICE
This manual contains many NOTICE, WARNING and CAUTION statements
concerning the safe operation and potential consequences if safe setup, operation and
maintenance are not performed. The notes, warnings and cautions contained within
the manual and marked by this triangular Caution Symbol should also be given special
care. For your safety, follow all safety warnings contained within the owner's manual
and the labels applied to your bicycle.
!
This owner's manual contains important safety, operational and maintenance information. Any person operating
this bicycle should carefully read and fully understand the entire contents of the owner's manual prior to riding
the bicycle. If you are a parent or guardian, you are responsible for the activities and safety of your children. The
CU 500 E-Bike is not designed for use by children.
If you have any questions, please ask your customer service representative for assistance.
! WARNING
Lithium-Ion Batteries and/or products that contain Lithium-Ion Batteries can expose you to chemicals
including cobalt, lithium, nickel oxide, and nickel, which are known to the State of California to cause
cancer and birth defects or other reproductive harm.
For more information go to www. P65Warnings.ca.gov.
1

You should keep this manual, along with any other documents that were included with your bicycle, for
future reference, however all content in this manual is subject to change or withdrawal without notice.
Visit https://www.genuinescooters.com/owners-manuals/ to download the latest version.
GENUINE makes every effort to ensure accuracy of its documentation and assumes no responsibility of
liability if any errors or inaccuracies appear within.
Assembly and first adjustment of your bicycle requires special tools and skills and it is recommended that these
actions should be performed by a trained bicycle mechanic whenever possible. For your safety, please check to
ensure all parts are in good condition and adjusted properly prior to riding your bicycle. Contact your customer
service representative in the event you have difficulty or questions.
INTRODUCTION
Your bicycle can provide many years of riding enjoyment. You must take responsibility for your own safety and
the safety of others. There are many steps you can take to protect yourself and others while riding. Following
operational guidelines within this manual and wearing proper safety apparel are two ways to begin cultivating
safe riding habits.
Because it is impossible to anticipate every situation or condition which can occur while riding, this manual
makes no representations about the safe use of bicycles under all conditions. There are risks associated with
the use of any bicycle which cannot be predicted or avoided, and which are the sole responsibility of the rider.
2

TABLE OF CONTENTS
3
NOTICE ............................................................................ 1
INTRODUCTION ............................................................ 2
TABLE OF CONTENTS ................................................ 3
PRODUCT SPECIFICATIONS .................................... 4, 5
SAFE RIDING
Wear Safety Gear, Make Yourself Visible ............. 6
Know Your Limits, Road Conditions ........................... 6
RECOMMENDED TORQUE VALUES ......................
7
BICYCLE LAYOUT
Overview ........................................... ...................... 8
Handlebar Controls ...................................................... 9
Suspension .................................................................. 10
DIGITAL DISPLAY LAYOUT ...................................... 11
DIGITAL DISPLAY OPERATION
Power On / Off, Display Interface .......... ................. 12
Settings .. ................................................................... 13
Battery Capacity, Motor Output, USB Charging ... . 14
Walk Mode, Lighting, Pedal Assistance ................. 15
SAFETY CHECKLIST .............................................. 16,17
OPERATION
Sidestand, Pedal Assist Level Selection ................ 18
Pedal Assist, Throttle, USB Charging ........ ............ 19
Shifting Gears, Brakes ............................................. 20
Suspension Preload Adjustment . ............................ 21
Suspension Rebound Adjustment . .......................... 22
BATTERY
Battery Removal, Battery Installation ...................... 23
Battery Charging .................................................... 24
Battery Range, Battery Safety . ................................ 25
TROUBLESHOOTING ........................................ 26,27
PARKING, TRANSPORT, STORAGE .................... 28
CARGO ................................................................... 29
BICYCLE CARE ...................................................... 30
MAINTENANCE SCHEDULE ................................. 31
MAINTENANCE LOG ............................................. 32

Product Specifications
4
48v 13Ah Lithium Battery
500W Brushless Geared Motor 26” * 18” 6061 Aluminum
LCD Display Tektro Aries 180mm
Shimano-Altus-7 Speed US Standard 3.0 A Quick Charger
20mph throttle, 25mph pedal assist Shimano 7 Speed
40+ Miles
Intelligent 5 Level Pedal Assist Shimano Tourney
Half Twist Throttle 27.5” x 2.4”
5 ~ 6 Hours 62 Ibs
5' 2” ~ 6' 4”
300 Ibs
Battery
Motor
Display
Derailleur
Max Speed
Estimated Range
Pedal Assist
Throttle
Charging time
Recommended
Rider Height Front Fork
Frame
Brake
Charger
Freewheel
Lighting
Shifter
Tires
Weight
Max Load
LED
Adjustable spring preload / rebound
dampening with lockout capability
