German pool HTW-115U User manual

P.1
360° Multi-Oscillation Fan RHS-126
Please read these instructions and warranty information carefully
before use and keep them handy for future reference.
Online Warranty Registration
USER MANUAL
Portable UVC Bathroom Heater HTW-115U

P.2
Please register your warranty information now !
For Warranty Terms & Conditions,
please refer to the last page of this user manual.
請即進行保用登記！
有關保用條款細則，請看說明書最後一頁。

P.3
Table of Contents
Warnings & Safety Precautions
Product Structure
Installation Instructions
Accessories
Operation Instructions
Cleaning & Maintenance
Technical Specication
Warranty Terms & Conditions
04
07
08
11
12
14
15
27

P.4
Warnings & Safety Precautions
WARNING!
Read all instructions carefully before using this product.
• This product is for domestic indoor use only. If this product is used for any commercial, industrial,
rental or other purposes, product warranty will be VOIDED.
• This product is not intended for use by children or persons with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of this product by an adult responsible for their safety.
• Mind your children and DO NOT let children play with this product.
• Cleaning and user maintenance shall not be made by children without supervision.
• Check the voltage indicated on the rating label before using this product.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid hazards.
• Unplug this product from the power source before cleaning and maintenance.
• Contact German Pool authorized service technician for repair or maintenance of this product.
Attention:
• IP23 protection rating only applies to when this product is installed and xed on the wall for
vertical operation.
• This product is a heater. Do not use this product as a fan.
WARNING!
• This product contains a UV emitter. DO NOT stare at the light source.
• DO NOT look directly into the UV light source from any angle as it may cause permanent damage
to your eyes.
• DO NOT let UV ultraviolet ray shine on exposed skin.
1. This product is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they DO NOT play with this product.
2. This product can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
4. Children of less than 3 years should be kept away unless continuously supervised.
5. Children aged from 3 years and less than 8 years shall only switch on/off this product provided
that it has been placed or installed in its intended normal operating position and they have been
given supervision or instruction concerning use of this product in a safe way and understand the

P.5
hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate,
clean or perform user maintenance on this product.
6. WARNING! Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
7. WARNING! In order to avoid overheating, do not cover this product.
8. DO NOT use this product in the immediate surroundings of a bath, a shower or a swimming pool.
9. This product must not be located immediately below a socket outlet.
10. WARNING! Do not use this product in small rooms when they are occupied by persons not
capable of leaving the room on their own, unless constant supervision is provided.
11. DO NOT use this product if it has been dropped.
12. DO NOT use if this product shows visible signs of damage.
13. Use this product on a straight and stable surface. (Note: After installation, the bottom of the
product should be 1 - 1.8m off the ground, and distance to the sidewall should be more than 0.3
meter. If this product is used in the bathroom, it should be at least 1 meter away from the water
source).
14. WARNING! To reduce the risk of re, keep textiles, curtains, or any other ammable material a
minimum distance of 1 m from the air outlet.
15. WARNING! The heater is to be installed so that switches and other controls cannot be touched
by a person in the bath or shower. The towel rail is to be installed so that switches and other
controls cannot be touched by a person in the bath or shower.
16. WARNING! In order to avoid a hazard for very young children, this product should be installed
so that the lowest heated rail is at least 1 meter above the oor.
17. WARNING! This product contains a UV emitter. DO NOT stare at the light source.
18. In case of malfunction, please contact German Pool Customer Service & Repair Centre. DO NOT
disassemble product or change parts by yourself.
19. DO NOT plug/unplug the power plug with wet hands to avoid electric shock.
20. DO NOT insert wooden stick or metal object into the air inlet or outlet.
21. DO NOT spray insecticides or inammable aerosols in the vicinity of this product.
22. DO NOT let air outlet blow directly on small children for an extended period of time.
23. When unplugging this product, pull out by grabbing onto the plug. DO NOT pull on the cord.
24. Before plugging into the power source, make sure the plug is clean and free of any foreign
substance, and make sure to plug in completely and securely.
25. If this product emits any odor or strange noise, stop using immediately and unplug from the power
source.
26. DO NOT fold or coil up the power cord, and DO NOT place any heavy object on the power cord.
27. When no one is at home, or if this product will be unused for an extended period of time, user
MUST turn off the heater and unplug the power cord.
28. Before using this product, make sure it is plugged into an electric socket that is compatible to the
specied capacity and in compliance with the current industry standards.
29. Make sure that the power supply voltage used is consistent with the voltage specied on the
rating label of this product.
Warnings & Safety Precautions

P.6
30. When moving to a new location, make sure the new supply voltage matches the voltage specied
on the rating label of this product.
31. DO NOT place any object on this product.
32. DO NOT ingest battery, Chemical Burn Hazard.
33. WARNING! This product contains a coin / button cell battery. If the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
34. Keep new and used batteries away from children.
35. If the battery compartment does not close securely, stop using the product and keep it away from
children.
36. If you think batteries might have been swallowed or placed inside any part of the body, seek
immediate medical attention.
37. The batteries contain materials which are hazardous to the environment; they must be removed
from this product before it is scrapped and that they are disposed of safely.
Warnings & Safety Precautions

P.7
Product Structure
Front
Back
Control Panel
Front Cover
Air Outlet Grille
Non-slip Rubber Pad
Filter Cover
Back Cover

P.8
Installation Instructions
Installation Safety Requirements
WARNING!
For IP23 Protection Rating to apply, this product must be mounted on the wall.
(Note: When installed, the bottom of the product should be 1-1.8m above the ground, and distance to
the sidewall should be more than 0.3 meter. If it is used in the bathroom, it should be at least 1 meter
away from the water source).
The following requirements should be observed when installing the product on the wall:
• Keep a distance of at least 500mm from the ceiling.
• Keep a distance of at least 300mm from the wall.
• Keep a distance of 1,000-1,800 mm from the oor.
WARNING!
• DO NOT install this product inside ZONE 1 and 2 (see diagram on P.9).
• This product must be installed at a location where its power switch and other controls are out of
reach of persons inside the bath or shower.
Distance from wall
Distance from ceiling
Distance from oor

P.9
Installation Instructions
ZONE 3
ZONE 1
ZONE 2
Danger
Danger
Safe
60cm
75cm
225cm
60cm
75cm
60cm
225cm
radius
60cm
60cm
ZONE 3
ZONE 1
ZONE 2
Danger
Danger
Safe
60cm
75cm
225cm
60cm
75cm
60cm
225cm
radius
60cm
60cm
Mounting With Wall Kit
1. Drill two 6mm holes (29mm in depth) on the wall. The distance between them should be 74mm.
2. Insert the wall plugs into the holes.
3. Screw the wall kit rmly into the wall plugs.
Wall Hook Wall Plug
74mm
2 holes of φ6mm D29mm
29mm
6mmφ

P.10
Installation Instructions
Large Mounting Hole Small Mounting Hole
4. Hang the product onto the wall kit: Fit the large mounting hole on the back of the product onto
the wall kit, then slide the product to the right until the pegs sit into the small mounting hole (see
diagram).

P.11
Accessories
Detachable Towel Rail
To attach the towel rail, pull the two ends of the towel rail slightly outwards and mount it into the holes
on both sides of the product.
Detachable Hook
1. Hook the wall kit onto the the back of the product.
2. Fit the pegs of the detachable hook into the large mounting holes on the wall kit, and slide the
hook to the right until the pegs sit into the small mounting holes.

P.12
Operation Instructions
UVC
MODE
Press 3 sec.
turn on UVC
LED Display Control Buttons
Cool Air Mode
Warm Air Mode - Low
Warm Air Mode - High
UVC Mode
Timer Function
Mode Button
Timer Button
On/Off Button
On / Off
1. Connect to the power source, the buzzer will beep twice.
2. Press On/Off Button to turn on the product. By default, product will run on Warm Air Mode –
Low, and indicator light will light up constant.
Air Mode
1. When the product is turned on, press Mode Button to cycle among Warm Air Mode – High
> Cool Air Mode > Warm Air Mode - Low . The corresponding indicator light will light up
constant.
2. The default running time for all air modes is 12 hours. If user wishes to turn off the product
manually before 12 hours, press On/Off Button .
Note:
• When switching from Warm Air Mode – Low to Warm Air Mode – High , PTC will be delayed
by 10 seconds.
• When user turns off the product while it is running on Warm Air Mode, the fan will continue to run
for 10 seconds to dissipate residual heat.

P.13
Operation Instructions
UVC Mode
1. When product is turned on (in any air mode), long-press Mode Button for 3 seconds to activate
UVC Sterilization Mode. UVC indicator light will light up constant.
2. To deactivate UVC Mode, long-press for 3 seconds again. UVC indicator light will turn off.
WARNING!
• DO NOT look at the UVC ray from any angle, as it may cause permanent damage to the eye.
• DO NOT allow the UVC ray to shine on exposed skin.
Off-Timer
1. When product is turned on (in any air mode), press Timer Button to activate the Timer
Function, indicator light will light up constant, and LED display will show timer countdown.
2. Press Timer Button again to select the time you want the product to turn off. Each press
increases the turn-off time by 5 minutes. Timer can be set to between 5-90 minutes.
3. When countdown time is completed, the product will automatically turn off.
Note:
Anytime during timer countdown, user can press On/Off Button and the product will turn off
immediately.

P.14
Cleaning & Maintenance
WARNING!
Before cleaning, turn off the product and unplug from the socket, in order to avoid the danger of
electric shock.
1. Clean the surface of the product with a damp cloth (can be moistened with diluted detergent if
desired). DO NOT clean this product with gasoline, thinner, corrosive cleanser or solvent etc., and
DO NOT rinse or immerse this product in water.
2. Heavy dust and dirt adhering to the lter will affect the performance of the product. Please clean
the lter at least once every other month.
Cleaning The Filter
1. Remove the lter cover and mesh lter (see diagram below).
2. Soak the mesh lter in cleaning agent for several minutes, then rinse and let to air dry completely.
3. Reinstall the mesh onto the lter cover, and reinstall the lter cover properly back into place.
Storage
1. If product will not be used for an extended period of time, please unplug from the socket and wrap
product in a dust-proof bag to prevent dust from entering the product.
2. Before wrapping with dust-proof bag, please make sure the product and lter are completely dry.
3. Store the product in a cool, dry and ventilated place away from direct sunlight.

P.15
Technical Specication
• Specication is subject to change without prior notice.
• If there is any inconsistency or ambiguity between the English version and the Chinese version,
the Chinese version shall prevail.
• Refer to www.germanpool.com for the most updated version of the User Manual.
Model
Voltage
Frequency
Power
Product Dimensions (without towel rail)
Product Dimensions (with towel rail)
Net Weight
HTW-115U
220-240 V~
50 Hz
1500 W
(H) 264 (W) 228 (D) 127 mm
(H) 430 (W) 250 (D) 127 mm
1.6 kg

P.16
目錄
警告及注意事項
產品結構
安裝說明
跟機配件
操作說明
清潔與保養
技術規格
保用條款
17
19
20
22
23
25
26
27

P.17
警告及注意事項
警告！
使用本產品前，請仔細閱讀所有說明。
• 本產品只限家居室內日常使用，如產品作任何商業、工業、出租或其他用途，保用證即告失
效。
• 請勿讓兒童或身體有殘障、精神不健全及對本產品缺乏經驗或知識的人士單獨使用本產品；如
需使用，必須要在負責任的成年人監管下方可使用。
• 應照顧好兒童，確保他們不會玩耍本產品。
• 無成年人監管下，勿讓兒童清潔及維護本產品。
• 使用前，請先檢查所有電壓是否與本產品標籤上的電壓相符。
• 如果電源線損壞，為免發生意外，電源線必須由廠方、廠方指定的維修中心或同等合格的技術
人員進行更換。
• 清潔或檢查本產品前，必須先關機及拔掉插頭。
• 請聯繫德國寶授權的技術人員進行維修或保養本產品。
注意：
• IP23防水防塵級別只適用於當產品垂直固定安裝於牆壁使用。
• 本產品不可作風扇用途。
警告！
• 本產品配備紫外線燈，嚴禁凝視紫外線光源。
• 嚴禁任何角度望紫外線，以免對眼睛造成永久性損害。
• 嚴禁將紫外線照射皮膚，或讓皮膚曝露在紫外線之中。
1. 本產品不適用於身體、感官或精神有缺陷，及缺乏必要經驗和知識的人群（包括小孩），除非
在能對其安全負責的人的監管下使用。兒童必須進行監管，以確保他們不玩耍本產品。
2. 當本產品由8歲或以上兒童、感官或精神有缺陷、及缺乏必要經驗和知識的人使用時，必須有
對其安全負責的人進行監管，並確保使用者的安全及其明白當中潛在危險。當兒童對本產品進
行清潔和維護時，必須有對其安全負責的人進行監管。
3. 如果電源軟線損壞，為了避免危險，必須由製造商、其維修部或類似部門的專業人員更換。
4. 3歲以下的幼兒必須遠離本產品，除非有對其安全負責的人進行持續監管。
5. 當本產品被放置或安裝在正常工作位置時，在有對其安全負責的人的指導或協助、並確保使用
者的安全及其明白當中潛在危險的前提下，3至8歲的兒童只可開啟或關閉本產品。3至8歲的兒
童不可調節、清潔、保養本產品，亦不可把本加產品插頭連接電源。
6. 警告！本產品的某些部分可能變得非常熱並導致燒傷。兒童和弱勢群體在場時必須特別注
意。
7. 警告！為避免過熱，嚴禁覆蓋本產品。
8. 在浴缸、噴頭或泳池的四周嚴禁使用本產品。
9. 本產品不得直接置於電源插座下方。
10. 對於行動不便的人在狹小空間使用本產品時，必須有對其安全負責的人進行持續監管。
11. 如本產品有跌落過，嚴禁使用。
12. 如本產品有明顯的損壞跡象，嚴禁使用。

P.18
13. 本產品必須擺放在平坦及穩固的表面上使用。（注意：安裝後，本產品底部必須距離地面1米
至1.8米，距離牆壁大於0.3米，如果在浴室使用，必須垂直安裝，並確保安裝位置離水源的距
離大於1米）。
14. 警告！為避免引起火災，出風口1米範圍內，嚴禁擺放任何布料、窗簾或其他易燃物料。
15. 警告！安裝本產品時，必須確保在浴缸內或淋浴區的人不能夠觸及到開關和其他控制器。
安裝毛巾架時，必須確保開關和其他控制裝置不會被浴缸或淋浴中的人觸及。
16. 警告！為避免對嬰兒造成傷害，本產品的安裝應確保最低的加熱軌距地面至少1米。
17. 警告！本產品配備紫外線燈，嚴禁盯著紫外線光源。
18. 若本產品發生故障，請聯絡德國寶客戶服務及維修中心，嚴禁擅自拆卸、更換零部件。
19. 嚴禁用濕手觸摸電源線插頭。
20. 嚴禁將木棍、金屬棍等異物塞入進、出風口。
21. 嚴禁在產品周圍噴灑殺蟲劑及可燃性噴霧劑。
22. 嚴禁將產品出風口長時間、直接向幼兒吹風。
23. 拔除電源線插頭時，嚴禁拉扯電線。
24. 必須確保電源線插頭沒有粘附異物，並將插頭完全插入。
25. 當本產品在使用期間出現異味、異音時，必須立即停止使用，並拔除電源。
26. 嚴禁折疊或將重物放置在電源線上。
27. 外出或長時間不使用本產品時，必須關機，並將電源線插頭從插座中拔出。
28. 使用本產品前，必須使用經檢查符合要求的合格電源插座。
29. 必須確保使用的電源電壓與本產品銘牌上所標示的電壓一致。
30. 搬遷時必須確認使用電壓。
31. 嚴禁將物品放置在機體上。
32. 嚴禁吞食電池，否則會導致化學灼傷危險。
33. 警告！本產品含有鈕扣電池。如果吞下鈕扣電池，僅2小時即可造成嚴重的內部灼傷，並可
能導致死亡。
34. 必須讓兒童遠離新舊電池。
35. 如電池倉未牢固關閉，必須停止使用本產品並將其遠離兒童。
36. 如您認為電池可能已被吞食或進入身體的任何部位，必須立即就醫。
37. 電池含有對環境有害的材料，必須在報廢前將其從本產品中取出並安全處置。
警告及注意事項

P.19
產品結構
正面
控制面板
面蓋
出風口
底部
防滑腳墊
網蓋
底蓋

P.20
安裝說明
安裝注意事項
警告：
IP23防水防塵級別只適用於掛牆安裝（注意：產品底部離地距離必須為1-1.8米，距離牆壁
大於0.3米，如果在浴室使用，請確保安裝位置離水源的距離大於1米）。
請確保該安裝距離滿足下圖要求
• 頂部距離至少為500毫米。
• 側壁距離至少為300毫米。
• 地面距離應為1,000-1,800毫米。
警告：
• 本產品不得安裝在ZONE1或2（如下圖）。
• 安裝時必須確保開關和其他控制裝置不會被沐浴或淋浴的人觸摸。
ZONE 3
ZONE 1
ZONE 2
Danger
Danger
Safe
60cm
75cm
225cm
60cm
60cm
60cm
75cm
60cm
225cm
半徑
側壁距離
頂部距離
地面距離
