Gigaset A680 User manual

1
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / Overview.fm / 02.11.2009
Gigaset A680*
* Manufactured by Gigaset Communications GmbH under trademark license of Siemens AG
V
09.22 11:56
INT MENU
1 Charge status of the
batteries
2Displaykeys
3Messagekey
Flashes: new messages
received
4 Handsfree key
5 Control key (u)
6Talkkey
7Directorykey
(press down on
the control key)
8 End call key and
On/Off key
9 Ringer tone on/off
(press and hold in
idle status)
10 Keypad lock on/off
(press and hold)
11 Recall key
- Consultation call
(flash)
- Dialling pause
(press and hold)
12 Microphone
13 Alarm clock key
Base station
Registration/Paging key (¢p. 9)
10
2
4
6
3
5
8
12
1
Handset
11
13
7
9
Where to find it all
First steps ¢p. 3
Making calls ¢p. 7
Using the directory and lists ¢p. 7
Registering handsets ¢p. 9
Using several handsets ¢p. 9
Setting the alarm clock ¢p. 10
Phone settings ¢p. 10
Operating the base station on the PABX
¢p. 10
Menu tree ¢p. 13
Display keys:
Pressing a key launches the function that
appears above that key in the display.
Display Function when pressed
INT Call other registered handsets
¢p. 9.
MENU Open main/submenu
(see Menu tree ¢p. 13).
“ Go back one menu level.
UScroll up/down or adjust volume
with u.
T Move cursor to left/right
with u.
˜Backspace deletes one
character at a time.
OK Confirm menu function or save
entry.

2
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / Overview.fm / 02.11.2009
Safety precautions
Emergency numbers cannot be dialled if the keypad lock
(¢p. 1) is activated!
Not all of the functions described in this user guide are
available in all countries.
Care
Wipe down the base station and handset with a
damp cloth (no solvents) or an antistatic cloth.
Never use a dry cloth. This can cause static.
Contact with liquid
If the handset should come into contact with liq-
uid:
◆Switch the handset off and remove the bat-
teries immediately.
◆Allow the liquid to drain from the handset.
◆Pat all parts dry, then with the battery compart-
ment open and the keypad facing down place
the handset in a dry, warm place for at least
72 hours (notin a microwave, oven etc.).
◆Do not switch on the handset again until it is
completely dry.
When it has fully dried out, you will normally be
able to use it again.
Read this user guide and the safety precautions carefully
before use. Explain their contents and the potential
hazards associated with using the telephone to your
children.
Only use the mains unit supplied.
Fit only the recommended, rechargeable
batteries (¢p. 11), i.e. never use a conven-
tional (non-rechargeable) battery or other bat-
tery types as this could result in significant
health risks and personal injury.
The operation of medical appliances may be
affected. Be aware of the technical conditions
in your particular environment, e.g. doctor's
surgery.
Do not hold the rear of the handset to your ear
when it is ringing. Otherwise you risk serious
and permanent damage to your hearing.
The handset may cause an unpleasant hum-
ming noise in hearing aids.
Do not install the phone in a bathroom or
shower room. The handset and base station
are not splashproof.
Do not use your phone in environments with a
potential explosion hazard, e.g. paint shops.
If you give your Gigaset to someone else, make
sure you also give them the user guide.
Please remove faulty base stations from use or
have them repaired by our service, as they could
interfere with other wireless services.
Disposal
Batteries should not be disposed of in general
household waste. Observe the local waste dis-
posal regulations, details of which can be
obtained from your local authority or the dealer
you purchased the product from.
All electrical and electronic equipment must be
disposed of separately from general household
waste using the sites designated by local
authorities.
If a product displays this symbol of a crossed-out
rubbish bin, the product is subject to European
Directive 2002/96/EC.
The appropriate disposal and separate collec-
tion of used equipment serve to prevent poten-
tial harm to the environment and to health.
They are a precondition for the re-use and recy-
cling of used electrical and electronic equip-
ment.
For further information on disposing of your
used equipment, please contact your local
authority, your refuse collection service or the
dealer you purchased the product from.
$
ƒ
ECO WDCT
You are helping to protect the environment with
your Gigaset A680.
Reduced energy consumption
Your telephone has an energy-saving adapter
plug and uses less energy.
Reduced transmission power
The transmission power of your telephone is
reduced automatically:
◆The handset's transmission power is reduced
depending on the distance to the base sta-
tion. The transmission power on the base
station is reduced to virtually zero when only
one handset is registered and the handset is
in the base station.
!

A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / starting.fm / 02.11.2009
3
First steps
Check the pack contents
◆One Gigaset A680 base station,
◆one mains adapter,
◆one Gigaset A68H handset,
◆one phone cord,
◆two batteries,
◆one battery cover,
◆one user guide.
If you have purchased a model with multiple handsets, the package should contain two
batteries, a battery cover and a charging cradle with mains adapter for each additional
handset.
Setting up the base station and charging cradle (if included)
The base station and charging cradle are designed for use in enclosed dry rooms with a
temperature range of +5 °C to +45 °C.
¤Set up the base station at a central location on a flat, non-slip surface in your house or
apartment.
The phone's feet do not usually leave any marks on surfaces. However, due to the multi-
tude of different varnishes and polishes used on today's furnishings, the occurrence of
marks on the surfaces cannot be completely ruled out.
Please note:
◆Never expose the telephone to the influence of heat sources, direct sunlight or other
electrical devices.
◆Protect your Gigaset from moisture, dust, corrosive liquids and vapours.
Connecting the base station
¤First connect the mains adapter 1.
¤Then connect the telephone jack 2
and insert the cables into the cable
ducts.
Please note:
◆The mains adapter must always be
connected, as the phone will not oper-
ate without mains connection.
◆Only use the mains adapter and phone
cord supplied. Pin connections on tele-
phone cables can vary.
1
1
1
2

A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / starting.fm / 02.11.2009
4
Connecting the charging cradle (if included)
Setting up the handset for use
The display is protected by a plastic film.
Please remove the protective film!
Inserting the batteries and closing the battery cover
1
2
1
2
¤Connect the flat plug from
the power supply 1.
¤Plug the mains adapter into
the plug socket 2.
If you need to disconnect the plug from the charging cradle,
press the release button 1and disconnect the plug 2.
Warning
Use only the rechargeable batteries recommended by Gigaset Communications
GmbH (¢p. 11). Never use a conventional (non-rechargeable) battery or other bat-
tery types as this could result in significant health risks and personal injury. For exam-
ple, the batteries could explode. The phone could also malfunction or be damaged as
a result of using batteries that are not of the recommended type.
¤Insert the batteries the right
way round.
The polarity is indicated in/on
the battery compartment.
¤First insert the battery cover at
the top a.
¤Then press the cover buntil it
clicks into place.
If you need to open the battery cover,
for instance to replace the batteries,
place your fingertip in the cavity on the
casing and pull the battery cover
upwards.
a
b

A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / starting.fm / 02.11.2009
5
Placing the handset in the base station and registering
If you have purchased a model with multiple handsets, repeat the registration process
for each individual handset. Handsets are assigned the lowest available internal number
(1-4). If more than one handset is registered to the base station, the internal handset
number appears in the top left of the display, e.g. 2. If the internal numbers 1–4 are
already assigned to other devices, the number 4 will be overwritten.
Initial charging and discharging of the batteries
The correct charge level can only be displayed if the batteries are first fully charged and
discharged.
Please note
◆Each key press interrupts the automatic registration.
◆If automatic registration does not work, the handset will have to be registered
manually (¢p. 9).
◆Only place the handset in the base station or charging cradle that is intended for
it.
V
Registering
V
INT MENU
Before you can use the phone, you must first register the
handset to the base station.
The handset registers automatically.
Registration can take up to 5 minutes.
Do not remove the handset from the
base station during this time.
After successful registration, the idle screen is displayed.
Charge status of the batteries:
–= e V U(flat to full)
–=flashes: batteries almost flat
–e V Uflashes: charging
V
Register HS
MENU
¤Place the handset with
the display facing up
in the base station.
¤Place the handset in the base station or charging cradle for eight hours.
¤Then remove the handset from the base station or charging cradle and
do not replace it until the batteries are completely discharged.
8 h

A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / starting.fm / 02.11.2009
6
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming calls,
and so that the alarm can be used.
MENU ¢Settings ¢OK ¢Date/Time ¢OK
¢Date: ¢~(enter the day, month and year in 6-digit format) ¢OK
¢Time: ¢~(enter hours and minutes in 4-digit format) ¢OK (display message: Saved)
¢a(press and hold to return to idle status)
Display in idle status
Once the phone is registered and the time set, the idle dis-
play is shown as in this example.
Activating/deactivating the handset
Press and hold the akey to activate or deactivate the hand-
set.
If you place a deactivated handset in the base station or
charging cradle, it will automatically activate.
Your phone is now ready for use.
If you have any questions about using your phone, please read the tips on troubleshooting
("Questions and answers" ¢p. 12) or contact our Customer Care team ¢p. 13.
Please note
◆After the first battery charge and discharge you may replace your handset in the
base station or charging cradle after every call.
◆Always repeat the charging and discharging procedure if you remove the batteries
from the handset and reinsert them.
◆The batteries may warm up during charging. This is not dangerous.
◆After a while, the charge capacity of the batteries will decrease for technical rea-
sons.
Please note
When entering the time and date, you can move the position of an entry to the left
or right by pressing the control button up or down.
V
11.12. 11:56
INT MENU

7
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Making calls
Making external calls and ending calls
External calls are calls using the public telephone
network.
~(Enter the phone number) ¢c.
The phone number is dialled. (Or you can first
press and hold c[dial tone] and then enter the
number.) During the call you can adjust the ear-
piece volume using tand set the volume with u.
End the call/cancel dialling:
Press the end call key a.
You can automatically insert a network provider
dialling code before any phone number
(see Menu tree "Preselection" ¢p. 13).
Accepting a call
The handset indicates an incoming call by ringing
and by a display on the screen.
Press the talk key cto accept the call.
When Auto Answer is activated (see Menu tree
¢p. 13), simply remove the handset from the
base station/charging cradle.
In idle status, use tto activate the menu for set-
ting the call volume and use uto set the volume.
Calling Line Identification
When you get a call, the caller's number will be dis-
played on your handset; the caller's name will be
displayed if it is stored in the directory.
Preconditions:
1You have asked your network provider for the
caller's number (CLIP) to be displayed on your
handset screen.
2The caller has asked the network provider for
his number to be identified (CLI).
®appears in the display if you have not
requested Calling Line Identification, Withheld
appears if the caller has withheld CLI, and Unavail-
able appears if CLI has not been requested.
Handsfree
Activating while dialling:
Enter the number ~and press the handsfree
key d.
Switching between earpiece and handsfree
mode:
During a call and press the handsfree key dto acti-
vate or deactivate handsfree talking.
During a call, use tto activate the menu for set-
ting the handsfree volume and use uto set the
volume.
Using the directory and lists
Directory
To open the directory: press h.
You can save up to 50 phone numbers
(max. 32 digits) with corresponding names
(max. 14 characters). Enter letters/characters
¢p. 11.
Saving the first number in the directory
h¢New Entry? ¢OK
¢~(enter number) ¢OK
¢~ (enter number) ¢OK
Storing a number in the directory
h¢MENU ¢New Entry ¢OK
¢~(enter number) ¢OK
¢~ (enter number) ¢OK
Selecting a directory entry
Open the directory with h.You have the following
options:
◆Use uto scroll through the entries until the
required name is selected.
◆Enter the first character of the name and scroll
to the entry with u, if required.
Dialling with the directory
h¢u (select entry) ¢c
Using other functions
h¢u(select entry) ¢MENU
The following functions can be selected with u:
Setting the shortcut key
h¢MENU ¢Scroll to uShortcut ¢Scroll uto
select a number (0,2-9), for example: Shortcut: 2
¢OK
New Entry Save new phone number.
Show Number Display the phone number.
Use Number Edit or add to the number. Then
dial or use other functions with
MENU.
Edit Entry Edit selected entry.
Delete Entry Delete selected entry.
Send Entry Send a single entry to another
handset (¢p. 8).
Delete List Delete all directory entries.
Send List Send the complete list to
another handset (¢p. 8).
Shortcut For shortcuts, assign the cur-
rent entry to a key.

8
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Using shortcut keys
To dial, press and hold the required shortcut key.
Sending the directory to another handset
Preconditions:
◆The sending and receiving handsets must both
be registered to the same base station.
◆The other handset and the base station can
send and receive directory entries.
h¢u (select entry) ¢MENU ¢Send Entry /
Send List ¢OK ¢~(enter the internal number of
the receiving handset) ¢OK
Last number redial list
This list contains the ten last dialled numbers.
Dialling from the last number redial list
c(press briefly) ¢u (select entry) ¢c
Managing entries in the last number redial list
c(press briefly) ¢u (select entry) ¢MENU
You can select the following settings:
Calls list/network mailbox list
An advisory tone sounds and the message key
flashes as soon as a new entry appears in the calls
list/answer machine list. A message appears in the
display.
When you press the fkey, all the lists are dis-
played. If only one list contains new messages, this
will be opened automatically.
Calls list
Precondition: CLIP (¢p. 7)
The call list contains all incoming calls.
The calls list is displayed as follows:
Number of new entries + number of old, read entries
Open the calls list
f¢CallsList 01+02 ¢OK
The last incoming call is displayed.
If necessary, use uto select another entry.
Using other functions
u(select entry) ¢MENU
The following functions can be selected with u:
Calling back a caller from the calls list
f¢CallsList 01+02 ¢OK ¢u(select entry)
¢c
Assigning key 1 for fast access to the
network mailbox
Simply press and hold key 1on the handset and
you will be connected directly to the network mail-
box.
See Menu tree ¢p. 14.
Use Number Edit or add to the number.
Then dial or use other functions
with MENU.
Copy to Dir. Copy an entry to the directory.
Delete Entry Delete selected entry.
Delete List Delete all entries.
Please note:
If calls are saved in the network mailbox, you will
receive a message if the appropriate settings have
been made (depending on your network pro-
vider).
Delete Entry Delete current entry.
Copy to Dir. Copy an entry to the directory.
Date/Time Call date and time (if set).
Status New Call: new missed call.
Old Call: entry already read.
Answ.: call taken.
Delete List Warning! All old and new
entries will be deleted.
CallsList 01+02

9
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Locating a handset ("paging")
You can locate your handset using the base station.
◆Briefly press the registration/paging key on the
base station (¢p. 1).
◆All handsets will ring simultaneously ("pag-
ing"), even if the ringer tones are deactivated.
End paging: briefly press the register/paging key
on the base station (¢p. 1) or the talk key con
a handset.
Registering handsets
You can register up to four handsets on your base
station (Gigaset A68H) recommended).
For automatic registration of handsets to
Gigaset A680, see ¢p. 5.
Manual registration of handsets to
Gigaset A680
1. On the handset: MENU ¢Settings ¢OK
¢Handset ¢OK ¢Register HS ¢Enter the sys-
tem PIN of the base station (default is 0000) ¢OK.
Registering flashes in the display.
2. On the base station: within 60 sec. of entering
the system PIN, press and hold the registration/
paging key (¢p. 1) (min. 3 sec.).
Registration takes approx. 1 minute.
De-registering handsets
Handsets can only be de-registered by resetting
the base station to its default settings. This will
also reset every other setting ¢p. 10.
If you have only registered handsets for other GAP-
compatible devices, these can only be de-regis-
tered with a hardware reset ¢p. 10.
Using several handsets
Making internal calls
Internal calls are no-cost calls to other handsets
that are registered to the same base.
Press the INT display key. All handsets are called.
When an internal participant answers you can
speak to them. To end the call, press a.
Internal consultation call/connecting
a call
You are in conversation with an external partici-
pant. Press the INT key to call all handsets. The
external participant hears the hold music.
◆Before the internal participant has answered,
press the end call key a; the call is diverted to
the participant who answers the call.
◆After the internal participant has answered,
you can talk to him. Press the end call key a;
the call is diverted, or press the display key ;
you are reconnected to the external participant.
Listening in to an external call
You are conducting an external call. An internal
participant can listen in on this call and take part in
the conversation (conference).
Precondition: The Listening in function must be
activated.
Activating/deactivating listening in
MENU ¢Settings ¢OK ¢Base ¢OK
¢Listening in ¢OK (‰= on)
Internal listening in (conference)
You want to listen in to an existing external call.
Briefly press and hold the ckey. You can listen in
to the call. All participants hear a signal tone.
To end: press the end call key a. All participants
hear a signal tone.
If the first internal participant presses the end call
key a, the handset that has "listened in" remains
connected to the external participant.
Please note:
Each additional handset must be registered on
the base station in order for it to work properly!

10
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Setting the alarm clock
Activating/deactivating the alarm clock
MENU ¢Alarm Clock ¢OK ¢Activation
¢OK (‰= on)
or:
press the alarm clock key g
When activated:
¢Set the wake-up time ¢OK
When the alarm clock rings, press any key to switch
it off for 24 hours. If the alarm clock is set, the
wake-up icon lwill appear on the screen and the
wake-up time will be displayed instead of the date.
Setting the wake-up time
MENU ¢Alarm Clock ¢OK ¢Wake-up time ¢OK
Enter the wake-up time in hours and minutes, then
press OK.
Phone settings
For details on how to make audio settings, see
Menu tree ¢p. 13.
For details on how to set the system PIN on the
base station, see the Menu tree ¢p. 13.
Resetting the handset
You can reset individual settings and changes that
you have made. Entries in the directory, the calls
list and the handset's registration to the base sta-
tion will be retained.
MENU ¢Settings ¢OK ¢Handset ¢OK
¢Reset Handset ¢OK
Cancel the reset with a.
Restoring the base station to the factory
settings
When restoring factory settings:
◆All handsets are de-registered
◆Individual settings are reset
◆All lists are deleted
◆The system PIN is reset to the original code
0000
Only the date and time are retained.
Software reset
MENU ¢Settings ¢OK ¢Base ¢OK
¢Base Reset ¢OK
Hardware reset
Disconnect the power cord from the base station.
Hold down the registration/paging key (¢p. 1)
on the base station while reconnecting the power
cable to the base station. Release the key after
approximately 5 seconds.
Operating the base station on
the PABX
The following settings are only necessary when
your PABX requires them, see the user guide for
your PABX.
When entering the digits, enter them slowly one
after the other.
Changing the dialling mode
MENU ¢I I O 1 1 ¢The number for the set dial-
ling mode flashes: 0= touch tone dialling (DTMF);
1= dial pulsing (DP) ¢enter number ¢OK.
Setting recall
MENU ¢I I O 1 2 ¢The number for the current
recall flashes: 0= 80 ms; 1= 100 ms; 2= 120 ms;
3= 400 ms; 4= 250 ms; 5= 300 ms; 6 = 600 ms;
7= 800 ms ¢enter number ¢OK.
Changing pause after line seizure
You can set the length of the pause inserted
between pressing the talk key cand sending the
phone number.
MENU ¢I I O 1 O ¢The number for the current
pause length flashes: 1= 1 sec.; 2= 3 sec.; 3= 7 sec.
¢enter number ¢OK.
Changing the pause after the recall key
MENU ¢I I O 1 4 ¢The number for the current
pause length flashes: 1= 800 ms; 2= 1600 ms;
3 = 3200 ms ¢enter number ¢OK.

11
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Appendix
Entering letters/characters
Press the relevant key the number of times indi-
cated.
Briefly press the hash key #to switch from
"Abc" to "123" mode, from "123" to "abc"mode and
from "abc" to "Abc" mode.
Standard characters
1) Space
Specifications
Recommended batteries
Technology: Nickel-metal-hydride (NiMH)
Size: AAA (Micro, HR03)
Voltage: 1.2 V
Capacity: 400–800 mAh
We recommend the following types of battery:
◆GP 550/700 mAh
◆Yuasa Phone 700/800 mAh
◆Peacebay 550/650 mAh
(Valid at the time of going to press)
The handset is supplied with recommended batter-
ies.
Base station power consumption
General specifications
1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x
11£$¥¤
2a b c 2 ä á à â ã ç
Id e f 3 ë é è ê
4gh i 4 ï í ì î
5j k l 5
Lm n o 6 ö ñ ó ò ô õ
Mp q r s 7 ß
Nt u v 8 ü ú ù û
Ow x y z 9 ÿ ý æ ø å
Q. , ? ! 0 + - : ¿ ¡ " ’ ; _
P* / ( ) < = > %
#Abc
-->
123
123
-->
abc# @ \ & §
1)
In standby mode
– Handset in base station
– Handset outside base station
approx. 1.3 W
approx. 1.3 W
During a call approx. 1.5 W
WDCT standard is supported
No. of channels 80 duplex channels
Radio frequency range 2400-2483.5 Mhz
Duplex method Time multiplex,
10 ms frame length
Bit rate 576 kbit/s
Modulation GFSK
Transmission power 25 mW, average power
per channel
Base station power supply 230 V ~/50 Hz
Environmental conditions
in operation
+5 °C to +45 °C; 20% to
75% humidity
Dialling mode DTMF (touch tone dial-
ling)/DP (dial pulsing)

12
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Service (Customer Care)
We offer you support that is fast and tailored to
your specific needs!
Our Online Support on the Internet:
www.gigaset.com/customercare
For more information on aftersales service, please
refer to your local warranty card.
In some countries repair and replace services are
impossible where the products are not sold
through our authorised dealers.
Questions and answers
If you have any queries about the use of your
phone, you can contact us any time at
www.gigaset.com/customercare.
The table below contains a list of common prob-
lems and possible solutions.
Problem Cause Solution
Nothing
appears in
the display.
The handset is not
switched on.
The batteries are
flat.
Press the end call
keyafor approx.
5 seconds or place
the handset in the
base station.
Charge or replace the
batteries.
No wireless
connection
to the base
station,
Base flashes
in the display.
The handset is
outside the range
of the base sta-
tion.
The handset is not
registered.
The base station is
not turned on.
Move the handset
closer to the base
station.
Register the handset
¢p. 9.
Check the mains con-
nector on the base
station ¢p. 3.
You cannot
hear a ringer/
dialling tone
from the fixed
line network.
The phone cord
supplied has not
been used or has
been replaced by
a new cord with
the wrong jack
connections.
Please always use the
phone cord supplied
or ensure that the
pin connections are
correct when purchas-
ing from a retailer:
3-4 assignment of
telephone leads/
EURO CTR37.
Error tone
sounds after
system PIN
prompt.
PIN forgotten.
The system PIN
you have entered
is incorrect.
Reset the system PIN
to the default 0000
¢p. 10.
All handsets are
de-registered. All
settings are reset.
All lists are deleted.

13
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Menu tree
Your phone has an extensive range of features.
These are offered in the form of menus.
To select a function while the phone is in idle sta-
tus, press MENU (open menu), use the tand
vkeys to scroll to the function you require and
press OK to confirm.
To return to idle status:press and hold the
akey.
As an alternative to selecting functions using the
tand vbuttons, you can also enter the digit
combination that is in front of the function in the
menu tree.
For setting the time and date, for example:
MENU ¢3 1 ¢OK
1Alarm Clock
1-1 Activation Activating/deactivating the alarm clock
1-2 Wake-up time Input format: HHMM
2Audio Settings
2-1 Ringer Volume 5 levels + "crescendo" available
2-2 Ringer Melody 2-2-1 External Calls 10 ringer tones available for external calls
2-2-2 Internal Calls 10 ringer tones available for internal calls
2-2-3 Alarm Clock 10 ringer tones available for alarm clock
2-3 Advis. Tones During a conversation
2-4 Battery Low 2-4-1 Off Warning tone to indicate
battery is almost flat:
never
2-4-2 On always
2-4-3 During Call only during a call
3Settings
3-1 Date/Time Enter date (DDMMYY format), then time (HHMM format)
3-2 Handset 3-2-1 Language Set the display language
3-2-2 Auto Answer Automatically activate/deactivate auto answer ¢p. 7
3-2-3 Register HS Manually register the handset ¢p. 9
3-2-4 Reset Handset Reset the handset ¢p. 10
3-3 Base 3-3-1 System PIN Change system PIN (default is 0000)
3-3-2 Base Reset Restore factory settings ¢p. 10
3-3-3 Listening in Activate/deactivate the function ¢p. 9
3-3-4 Preselection 3-3-4-1 Presel. Number Network provider dialling code,
should be inserted automatically
before the dialled phone number.
3-3-4-2 With Preselect First digits of the dialling codes,
should be dialled with preselection.
3-3-4-3 Without Presel First digits of dialling codes, should
be dialled without preselection.

14
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
4Voice Mail
4-1 Set Key 1
(all devices)
4-1-1 Netw. Mailbx Assign key 1with network mailbox and enter the network mailbox
number (in idle status, press and hold key 1to dial).
Netw. Mailbx: your network provider's answer machine; must be
requested separately. The network mailbox list can be displayed if
your network provider supports this function and if key 1has been
assigned with the network mailbox.

15
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009

16
A680 (L2) / PHL-TWN eng / A31008-M2005-Z401-1-7619 / main.fm / 02.11.2009
Issued by
Gigaset Communications GmbH
Frankenstr. 2
D-46395 Bocholt
Manufactured by Gigaset Communications GmbH
under trademark license of Siemens AG. As of 1
Oct. 2011 Gigaset products bearing the trademark
"Siemens" will exclusively use the trademark
"Gigaset".
© Gigaset Communications GmbH 2009
All rights reserved. Subject to availability.
Rights of modification reserved.
www.gigaset.com
This user guide is made from 100% recycled paper.
A31008- M2005- Z401- 1- 7619
Version: 04-11-2009
