Gilson MyPIPETMAN Select User manual

User’s Guide
EN
A
U
T
O
C
L
A
V
A
B
L
E
F
U
L
L
Y

2| MyPIPETMAN®
TABLE OF CONTENTS
INTRODUCTION | 3
Parts Checklist | 4
GLP Features | 4
Description | 4
Specifications | 5
SETTING THE VOLUME | 6
Simple Ratchet | 6
3-Position Locking System | 6
PIPETTING | 7
Fitting the Tip Ejector Adapter | 7
Fitting the Tips | 8
Pre-Wetting the Tips | 8
Aspirating | 9
Dispensing | 9
Ejecting the Tips | 9
Guidelines for Good Pipetting | 10
ACCESSORIES | 11
MyPIPETMAN Accessories for Extra Personalization | 11
TROUBLESHOOTING | 14
Troubleshooting Table | 14
Leak Test | 15
CLEANING AND DECONTAMINATION | 15
Cleaning for Single Channel Models | 15
Cleaning for Multichannel Models | 16
Autoclaving | 16
Chemical Decontamination | 17
MAINTENANCE | 18
Changing the Tip Ejector for Single Channel | 18
Changing the Tip Holder for Single Channel | 18
Changing the Tip Ejector for Multichannel | 18
Servicing the Piston Assembly | 19
SPARE PARTS | 20
WARRANTY | 21
TABLE OF CONTENTS

INTRODUCTION
3
MyPIPETMAN® |USER’S GUIDE
Chapter 1
INTRODUCTION
MyPIPETMAN® is an air displacement pipette that uses disposable pipette tips. This pipette, depending
on the version selected, is customizable to your needs while guaranteeing the Gilson quality standards.
It offers both technical and personalization options for optimal use in various workflows.
Lightweight, ergonomic, safe, and easy-to-use, MyPIPETMAN is a reliable, accurate, and precise pipette
that provides unique and state-of-the-art features and choices:
●Simple ratchet or 3-position volume locking system including a light click and a free volume
selection position
●Reduced or standard pipetting forces
●Considerably reduced or standard tip ejection forces, with a built-in ejection button integrated on
top of the pipette handle
●Colors and product personalization options
To meet users’ needs, MyPIPETMAN is available in three offers, each with different levels of technical
options and product customization, as described in Figure 1 below.
MyPIPETMAN®
Select
MyPIPETMAN®
Enterprise MyPIPETMAN®
Technical Options
Available
Volume Locking
Pipetting Forces
Tip Ejectors
(Single Channel, P2 to
P1000 Models)
3-Position Locking System
Simple Rachet
Metal
Plastic
Reduced
Standard
Customization Options
Pipette Colors
Special Text Printing
Special Logo Printing
Ordering Information
Minimum Order Quantity
Available Countries
1
Worldwide
Possible on Request
(Subject to Specific Conditions)
150 Units
(Mix of Dierent Models)
Worldwide US Web Sales Only
1
Possible on Request
Ejection Forces
Reduced
Standard
Figure 1
MyPIPETMAN® global offer
MyPIPETMAN is available as variable volume in either single or multichannel models.
●Eight single channel models cover a volume range from 0.2 μL to 10 mL.
●Eight multichannel models (4 models of 8 and 12 channels) cover a volume range from 0.5 μL to 300 μL.
MYPIPETMAN SERIES PART NUMBERS
Model MyPIPETMAN® Select MyPIPETMAN® Select
Text Printing On Demand MyPIPETMAN® Enterprise MyPIPETMAN® *
MyPIPETMAN® Single Channel
P2 FP10001S FP10001SP FP10001E FP10001
P10 FP10002S FP10002SP FP10002E FP10002
P20 FP10003S FP10003SP FP10003E FP10003
P100 FP10004S FP10004SP FP10004E FP10004
P200 FP10005S FP10005SP FP10005E FP10005
P1000 FP10006S FP10006SP FP10006E FP10006
P5000 FP10007S FP10007SP FP10007E FP10007
P10mL FP10008S FP10008SP FP10008E FP10008
MyPIPETMAN® Multichannel
P8x10 FP10009S FP10009SP FP10009E FP10009
P12x10 FP10010S FP10010SP FP10010E FP10010
P8x20 FP10011S FP10011SP FP10011E FP10011
P12x20 FP10012S FP10012SP FP10012E FP10012
P8x200 FP10013S FP10013SP FP10013E FP10013
P12x200 FP10014S FP10014SP FP10014E FP10014
P8x300 FP10015S FP10015SP FP10015E FP10015
P12x300 FP10016S FP10016SP FP10016E FP10016
*US web sales only

INTRODUCTION
4INTRODUCTION | MyPIPETMAN®
Single Channel Models
●MyPIPETMAN pipette
●Quick Guide
●Tip ejector adapter equipped on the
P2 and P10 models
●Bag of ten filters (only for P5000 and
P10mL models)
●Certificate of Conformity
●Safety bag
Multichannel Models
●MyPIPETMAN pipette
●Quick Guide
●Ejector spacer for D10 tips (only for P10 models)
●Certificate of Conformity
●Safety bag
Parts Checklist
After unpacking the pipette, verify that the following items were included and remain undamaged:
Good Laboratory Practice (GLP) Compliance
The serial number is engraved on the body of the pipette. It provides unique identification of your
pipette and the manufacturing date.
MyPIPETMAN Select and
MyPIPETMAN Enterprise serial
number type:
A A 50001
MyPIPETMAN serial number type:
MY 524 A A
Figure 2
Serial number identification example
Year Month Production
number
Model Random
Number
Month Year
The barcode on the box and the Certificate of Conformity provides traceability of your pipette.
YEAR CODE
2022 T
2023 U
2024 W
2025 X
2026 Y
2027 Z
MONTH CODE
January A
February B
March C
April D
May E
June G
July H
August J
September K
October L
November M
December N
Description
Please refer to the following chapters for a complete description of the different parts and functions
of the pipette.
Figure 3
MYPIPETMAN® single channel and multichannel model components
Color-coded
push button
Locking system
Tip ejector
button
Color ring
Connecting nut
Tip ejector
Ejector lock
Ejector clip
Tip holder
Cover
Single channel Multichannel
Customizable
handle
Colored
window

INTRODUCTION
5
MyPIPETMAN® |USER’S GUIDE
Specifications
MyPIPETMAN is a high-quality pipette that has excellent accuracy and precision, especially when
used with PIPETMAN® DIAMOND Tips. The data given in the “Gilson Maximum Permissible Errors”
table below was obtained using PIPETMAN DIAMOND Tips. These values are guaranteed only when
genuine PIPETMAN DIAMOND Tips are used.
Each pipette is inspected and validated by qualified technicians in accordance with the Gilson
quality system. Gilson declares that its manufactured pipettes comply with the requirements of the
ISO 8655 standard by type testing.
The adjustment is carried out under strictly defined and monitored conditions (ISO 8655-6).
MYPIPETMAN® SINGLE CHANNEL MODELS
Model
PIPETMAN®
DIAMOND
Tips
Vol.
(µL)
Maximum Permissible Errors
Gilson ISO 8655
Systematic
Error
(µL)
Random
Error
(µL)
Systematic
Error
(%)
Random
Error
(%CV*)
Systematic
Error
(µL)
Random
Error
(µL)
Systematic
Error
(%)
Random
Error
(%CV*)
MyPIPETMAN
P2
D10
DL10
0.2
0.5
1
2
± 0.024
± 0.025
± 0.027
± 0.030
≤0.012
≤0.012
≤0.013
≤0.014
± 12.0
± 5.0
± 2.7
± 1.5
≤6.0
≤2.4
≤1.3
≤0.7
± 0.08
± 0.08
± 0.08
± 0.08
≤0.04
≤0.04
≤0.04
≤0.04
± 40.0
± 16.0
± 8.0
± 4.0
≤20.0
≤8.0
≤4.0
≤2.0
MyPIPETMAN
P10
D10
DL10
1
5
10
± 0.025
± 0.075
± 0.100
≤0.012
≤0.030
≤0.040
± 2.5
± 1.5
± 1.0
≤1.2
≤0.6
≤0.4
± 0.12
± 0.12
± 0.12
≤0.08
≤0.08
≤0.08
± 12.0
± 2.4
± 1.2
≤8.0
≤1.6
≤0.8
MyPIPETMAN
P20 D200
2
10
20
± 0.10
± 0.10
± 0.20
≤0.030
≤0.050
≤0.060
± 5.0
± 1.0
± 1.0
≤1.5
≤0.5
≤0.3
± 0.2
± 0.2
± 0.2
≤0.1
≤0.1
≤0.1
± 10.0
± 2.0
± 1.0
≤5.0
≤1.0
≤0.5
MyPIPETMAN
P100 D200
10
50
100
± 0.35
± 0.40
± 0.80
≤0.10
≤0.12
≤0.15
± 3.5
± 0.8
± 0.8
≤1.0
≤0.24
≤0.15
± 0.8
± 0.8
± 0.8
≤0.3
≤0.3
≤0.3
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN
P200 D200
20
100
200
± 0.50
± 0.80
± 1.60
≤0.20
≤0.25
≤0.30
± 2.5
± 0.8
± 0.8
≤1.0
≤0.25
≤0.15
± 1.6
± 1.6
± 1.6
≤0.6
≤0.6
≤0.6
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN
P1000 D1000
100
500
1000
± 3.0
± 4.0
± 8.0
≤0.6
≤1.0
≤1.5
± 3.0
± 0.8
± 0.8
≤0.6
≤0.2
≤0.15
± 8.0
± 8.0
± 8.0
≤3.0
≤3.0
≤3.0
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN
P5000 D5000
500
2500
5000
± 12
± 15
± 30
≤3
≤5
≤8
± 2.4
± 0.6
± 0.6
≤0.6
≤0.2
≤0.16
± 40
± 40
± 40
≤15.0
≤15.0
≤15.0
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN
P10mL D10mL
1000
5000
10000
± 30
± 40
± 60
≤6
≤10
≤16
± 3.0
± 0.8
± 0.6
≤0.6
≤0.2
≤0.16
± 60
± 60
± 60
≤30.0
≤30.0
≤30.0
± 6.0
± 1.2
± 0.6
≤3.0
≤0.6
≤0.3
MYPIPETMAN® MULTICHANNEL MODELS
Model
PIPETMAN®
DIAMOND
Tips
Maximum Permissible Errors
Vol.
(µL)
Gilson ISO 8655
Systematic
error
(µL)
Random
error
(µL)
Systematic
error
(%)
Random
error
(%CV*)
Systematic
error
(µL)
Random
error
(µL)
Systematic
error
(%)
Random
error
(%CV*)
MyPIPETMAN
P8x10 D10
DL10
0.5
1
5
10
± 0.08
± 0.08
± 0.20
± 0.20
≤0.04
≤0.05
≤0.10
≤0.10
± 16.0
± 8.0
± 4.0
± 2.0
≤8.0
≤5.0
≤2.0
≤1.0
± 0.24
± 0.24
± 0.24
± 0.24
≤0.16
≤0.16
≤0.16
≤0.16
± 48.0
± 24.0
± 4.8
± 2.4
≤32.0
≤16.0
≤3.2
≤1.6
MyPIPETMAN
P12x10
MyPIPETMAN
P8x20 DL10
D200
2
10
20
± 0.10
± 0.20
± 0.40
≤0.08
≤0.10
≤0.15
± 5.0
± 2.0
± 2.0
≤4.0
≤1.0
≤0.75
± 0.4
± 0.4
± 0.4
≤0.2
≤0.2
≤0.2
± 20.0
± 4.0
± 2.0
≤10.0
≤2.0
≤1.0
MyPIPETMAN
P12x20
MyPIPETMAN
P8x200 D200
20
100
200
± 0.50
± 1.00
± 2.00
≤0.25
≤0.40
≤0.50
± 2.5
± 1.0
± 1.0
≤1.25
≤0.4
≤0.25
± 3.2
± 3.2
± 3.2
≤1.2
≤1.2
≤1.2
± 16.0
± 3.2
± 1.6
≤6.0
≤1.2
≤0.6
MyPIPETMAN
P12x200
MyPIPETMAN
P8x300 D300
20
30
150
300
± 1.00
± 1.00
± 1.50
± 3.00
≤0.35
≤0.35
≤0.60
≤1.00
± 5.0
± 3.3
± 1.0
± 1.0
≤1.75
≤1.17
≤0.4
≤0.33
± 8.0
± 8.0
± 8.0
± 8.0
≤3.0
≤3.0
≤3.0
≤3.0
± 40.0
± 26.67
± 5.33
± 2.67
≤15.0
≤10.0
≤2.0
≤1.0
MyPIPETMAN
P12x300
*CV means Coefficient of Variation
NOTE
The data given in this table conform to the ISO 8655-2 standard. With a precise pipetting technique,
the P2 model can be used to aspirate volumes as low as 0.1 μL and the P10 model as low as 0.5 μL.

SETTING THE VOLUME
6SETTING THE VOLUME | MyPIPETMAN®
Chapter 2
SETTING THE VOLUME
The volume of liquid to be aspirated is set using the volume display. The dials are colored either black or
red to indicate the position of the decimal point, depending on the model (refer to Figure 4 below).
Volume selection differs according to your configuration. To obtain maximum accuracy when setting the
volume, proceed as follows:
●When decreasing the volume setting, slowly reach the required setting, making sure not to
overshoot the volume mark.
●When increasing the volume setting, pass the required value by 1/3 of a turn and slowly decrease to
reach the volume, making sure not to overshoot the volume mark.
MODEL
COLOR OF VOLUMETER NUMBERS
BLACK RED INCREMENT
MyPIPETMAN SINGLE CHANNEL
MyPIPETMAN P2 µL 0.01 µL 0.002 µL
MyPIPETMAN P10 µL 0.1 µL 0.02 µL
MyPIPETMAN P20 µL 0.1 µL 0.02 µL
MyPIPETMAN P100 µL - 0.2 µL
MyPIPETMAN P200 µL - 0.2 µL
MyPIPETMAN P1000 0.01 mL mL 0.002 mL
MyPIPETMAN P5000 0.01 mL mL 0.002 mL
MyPIPETMAN P10mL mL 0.1 mL 0.02 mL
MyPIPETMAN MULTICHANNEL
MyPIPETMAN P8x10 µL 0.1 µL 0.02 µL
MyPIPETMAN P12x10 µL 0.1 µL 0.02 µL
MyPIPETMAN P8x200 µL - 0.2 µL
MyPIPETMAN P12x200 µL - 0.2 µL
MyPIPETMAN P8x300 µL - 0.2 µL
MyPIPETMAN P12x300 µL - 0.2 µL
1
5
P2
1.25 µL
2
0
7
5
P10
7.5 µL
1
2
5
P20
12.5 µL
P100
0
7
5
75 µL
P200
1
2
5
125 µL
P1000
0
7
5
0.75 mL
P5000
1
2
5
1.25 mL
P10mL
0
7
5
7.5 mL
0
7
5
x10
7.5 µL
1
2
5
x20
12.5 µL
x200
1
2
5
125 µL
x300
1
2
5
125 µL
Multichannel
model
Single channel
model
Figure 4
Dial colors by model
Simple Ratchet
For pipettes mounted with a simple ratchet, select the volume
by turning the push button (refer to Figure 5).
3-Position Locking System
For pipettes equipped with a 3-position locking system, turn the
selector to your desired position (refer to Figure 6).
Free volume selection position
1. Turn the selector to the left until the cursor reaches the
unlocking 1.
2. Select the volume by turning the push button.
Light click volume selection position
1. Turn the selector until the cursor reaches the middle 2.
2. Select the volume by turning the push button. Figure 5
Simple ratchet
Figure 6
3-position locking
system
NOTE
When selecting the volume, you will hear
click sounds, allowing for more precise
settings.Use these sounds for final fine
volume selection.
321
Secure Pipetting
After selecting your volume, turn the selector to the right
until the cursor reaches the locking 3for secure pipetting.
NOTE
To ensure good performance, always lock
the pipette before pipetting by selecting the
locking icon.

PIPETTING
7
MyPIPETMAN® |USER’S GUIDE
Chapter 3
PIPETTING
Fitting the Tip Ejector Adapter
Single Channel Models
AFor P2 and P10 pipettes equipped with a stainless-steel tip ejector,
a dual-position adapter is required to fit and eject DL10 tips (long tips)
and D10 tips (short tips).
To fit the adapter for short and long tips (refer to Figure 7):
1. Pull the adapter down from the stainless steel tip ejector.
2. Turn the adapter 180°.
3. Refit the adapter so that the end of the stainless steel tip
ejector engages the shorter or longer slot of the adapter.
BFor P2 and P10 pipettes equipped with a plastic tip ejector,
a dual-position adapter is required to fit and eject D10 tips (short
tips).
To fit a tip ejector extension (refer to Figure 7):
1. Slide the extension over the tip holder.
2. Push the extension firmly onto the end of the tip ejector until it clicks into place.
To remove a tip ejector extension:
1. Gently twist the adapter.
2. Pull it away from the pipette.
Multichannel Models
For P8x10 and P12x10 models, according to the tip used, either D10 or DL10, you might have to fit the
ejector adapter. Long collar tips can be inserted without it.
1. Remove the tip ejector, keep both ejector locks depressed 1, and then pull the tip ejector down 2.
2. Fit the ejector adapter 3and click it to the tip ejector.
3. To refit the tip ejector, gently re-insert the tip ejector vertically into the rails of the ejector support 4.
NOTE
Long tips can be used without tip ejector adapter.
Figure 7
Tip ejector dual position adapter and
extension for P2L and P10L
Short collar
tips
Long collar
tips
180°
To fit To remove
1
2 3 4
A B

PIPETTING
8PIPETTING | MyPIPETMAN®
Fitting the Tips
It is recommended to use PIPETMAN DIAMOND Tips with MyPIPETMAN for optimum performance.
These tips are made from pure polypropylene. Plastic tips are for a single application and should be
disposed of after use—please do not clean for reuse.
Single Channel Models
To fit a new PIPETMAN DIAMOND Tip, push the tip holder into the tip using a slight twisting motion to
ensure a firm and airtight seal.
PIPETMAN DIAMOND Tip
Compatibility for Single Channel
P2, P10 D10, DL10, DF10ST, DFL10ST
P20 D200, DF30ST
P100 D200, DF100ST
P200 D200, D300, DF200ST, DF300ST
P1000 D1000, D1200, DF1000ST, DF1200ST
P5000 D5000
P10mL D10mL
NOTE
D5000 and D10mL PIPETMAN DIAMOND Tips do not have any filter. P5000 and P10mL
models are sold with a bag of 10 filters. Bags of filters are also available as accessories. Refer to
ACCESSORIES page.
The filters, made of polyethylene, oer the same properties as the filters which are inside the
PIPETMAN DIAMOND filter tips. They maintain the pipette’s original accuracy and precision by
creating an ecient barrier to aerosols or corrosive vapors such as acids which could damage
mechanical parts.
Insert the filter directly in the pipette tip holder.
Change the filter every day or more frequently depending on the intensity of use and/or
concentration of the solution.
Filters are not autoclavable and must be disposed of after use.
Multichannel Models
PIPETMAN DIAMOND Tips: TIPACK AND TOWERPACK
PIPETMAN DIAMOND tips are best fitted with the ROCKY RACK technique, invented by Gilson, available
only in our TIPACK and TOWERPACK.
PIPETMAN DIAMOND Tip
Compatibility for Multichannel Models
P8x10, P12x10 D10*, DL10, DF10ST, DFL10ST
P8x20, P12x20 DL10, D200, DFL10ST, DF30ST
P8x200, P12x200 D200, D300, DF200ST, DF300ST
P8x300, P12x300 D200, D300, DF200ST, DF300ST
*Using an ejector adapter, you can adapt a D10 tip (refer to page 7).
Figure 8
ROCKY RACK technique
Pre-Wetting the Tips
Pre-wetting the tips before pipetting helps prepare the tips for
the best pipetting performance. Ideally, the pre-wet includes both
immersing the tip in the liquid and performing one pipetting step.
Pre-wetting the tips helps ensure that volumes that you pipette
will achieve accuracy and precision within specifications.

PIPETTING
9
MyPIPETMAN® |USER’S GUIDE
Aspirating
1. Press the push button to the first stop (this corresponds to the set volume of liquid).
2. Hold the pipette vertically and immerse the tip in the liquid (refer to Guidelines for Good Pipetting).
3. Release the push button slowly and smoothly to the top position to aspirate the set volume of liquid.
4. Wait one second (refer to Guidelines for Good Pipetting) and then withdraw the pipette tip from
the liquid. You may wipe any droplets away from the outside of the tip using a medical wipe.
However, if you do so, take care to avoid touching the tip’s orifice.
NOTE
For the multichannel models, use a reagent reservoir.
Dispensing
1. Place the end of the tip against the inside wall of the recipient vessel (at an angle of 10° to 40°).
2. Press the push button slowly and smoothly to the first stop.
3. Wait for at least a second, then press the push button to the second stop to expel any residual
liquid from the tip. Keep the push button pressed fully, and while removing the pipette, draw the tip
along the inside surface of the vessel.
4. Release the push button smoothly. Eject the tip by pressing firmly on the tip ejector button.
Second stop
First stop
Aspirate DispensePrepare Purge Home
Figure 9
Pipetting motion - aspirate and dispense
Rest Position
Ejecting the Tips
To avoid touching used tips, hold the pipette over the waste container and press the tip ejector push
button.
NOTE
P5000 and P10mL models are not equipped with tip ejectors, and tips must be carefully removed by the
user. The use of gloves is recommended for tip removal when pipetting contaminated, toxic, or corrosive
liquids.

PIPETTING
10 PIPETTING | MyPIPETMAN®
Guidelines for Good Pipetting
●Make sure that you operate the push button slowly and smoothly.
●When aspirating, keep the tip at a constant depth below the surface of the liquid
(refer to the table below).
Model Immersion Depth
(Millimeters)
Wait Time
(Seconds)
P2, P10, P8x10, P12x10 1 1
P20, P8x20, P12x20, P8x200, P12x200 2-3 1
P8x300, P12x300 2-4 1
P1000 2-4 2-3
P5000 3-6 4-5
P10mL 5-7 4-5
●Change the tip before aspirating a different liquid, sample, or reagent.
●Change the tip if a droplet remains at the end of the tip from the previous pipetting operation.
●Pre-wet each new tip with the liquid to be pipetted.
●The liquid should never enter the tip holder; to prevent this:
○Press and release the push button slowly and smoothly.
○Never turn the pipette upside down.
○Never lay the pipette on its side when there is liquid in the tip.
●If you use the same tip with a larger volume, pre-wet the tip.
●For volatile solvents, saturate the air cushion in your pipette by aspirating and dispensing the
solvent repeatedly before aspirating the sample.
●When the liquid temperature is different from the ambient temperature, pre-wet the tip several
times before use.
●You may remove the tip ejector (refer to Fit the Tip Ejector Adapter) to aspirate from very narrow
tubes.
●After pipetting acids or other corrosive liquids that emit vapors, remove the tip ejector and tip
holder, rinse with distilled water, dry, and lubricate the piston (refer to MAINTENANCE). For the
P1000L model, use a specific tip holder equipped with a filter to increase the lifetime of the piston
(refer to ACCESSORIES).
●Do not pipette liquids with temperatures above 70°C or below 4°C. The pipette can be used
between +4°C and +40°C, but the gravimetric performance may vary according to the temperature
(refer to the ISO 8655-2 standard for conditions of use).
NOTICE
MyPIPETMAN should be held in the vertical position. For detailed information about pipetting techniques,
refer to the Gilson Guide to Pipetting available on the Gilson website (www.gilson.com).

ACCESSORIES
11
MyPIPETMAN® |USER’S GUIDE
Chapter 4
ACCESSORIES
To make pipetting more comfortable and more secure, Gilson has developed several accessories to
assist in your pipetting workflows.
Description Part Number
CARROUSEL pipette Stand (7 pipettes) F161401
TRIO Pipette Stand (3 pipettes) F161405
Universal Multichannel Stand* F161417
SINGLE Pipette Holder F161406
* Universal multichannel stand is for multichannel models only.
Disposable Reagent Reservoirs are ideal for dispensing reagent with multichannel pipettes.
Description Part Number
Reagent reservoir 25 mL, x100 F267660
Reagent reservoir 50 mL, x100 F267670
With the JIMMY™ Microtube Opener, a hands-free microtube opener, you can open both snap-cap
and screw-cap microtubes.
Description Part Number
JIMMY Microtube Opener (set of 3) F144983
For P5000 and P10mL models, disposable filters maintain the pipette’s original accuracy and precision
by creating an efficient barrier to aerosols or corrosive vapours such as acids which could damage
mechanical parts.
Description Part Number
Bag of 10 Filters for P5000 /P10mL F161280
Bag of 100 Filters for P5000 / P10mL F161241
To protect the piston when pipetting corrosive liquids, you can use a specific tip holder and filter for the
model P1000.
Description Part Number
Corrosion Protection Kit
(tip holder + a bag of 10 filters) F144570
Corrosion Protection Kit Filter (Bag of 10)* F144571
Corrosion Protection Kit Filter (Bag of 50)* F144572
*Filters can be inserted in the specific tip holder provided in the Corrosion Protection Kit (part Number F144570)
SINGLE™
CARROUSEL™ TRIO™
Universal
Multichannel
Stand

ACCESSORIES
12 ACCESSORIES | MyPIPETMAN®
MyPIPETMAN Accessories for Extra Personalization
For identification, extra personalization, or more convenient use, an offer of complementary
accessories is available for use with MyPIPETMAN.
COLORED WINDOWS
Model Part Number
Window 3digit Dark Blue MyPIPETMAN FP070101
Window 3digit White MyPIPETMAN FP070102
Window 3digit Blue MyPIPETMAN FP070103
Window 3digit Red MyPIPETMAN FP070104
Window 3digit Yellow MyPIPETMAN FP070105
Window 3digit Green MyPIPETMAN FP070106
METAL TIP EJECTORS
Model Part Number
Metal Ejector Dark Blue P2/P10 MyPIPETMAN FP070111
Metal Ejector White P2/P10 MyPIPETMAN FP070112
Metal Ejector Dark Blue P20 MyPIPETMAN FP070121
Metal Ejector White P20 MyPIPETMAN FP070122
Metal Ejector Dark Blue P100 MyPIPETMAN FP070131
Metal Ejector White P100 MyPIPETMAN FP070132
Metal Ejector Dark Blue P200 MyPIPETMAN FP070141
Metal Ejector White P200 MyPIPETMAN FP070142
Metal Ejector Dark Blue P1000 MyPIPETMAN FP070151
Metal Ejector White P1000 MyPIPETMAN FP070152
PLASTIC TIP EJECTORS
Model Part Number
Plastic Ejector Dark Blue P2/P10 MYPIPETMAN FP070161
Plastic Ejector White P2/P10 MYPIPETMAN FP070162
Plastic Ejector Dark Blue P20 MYPIPETMAN FP070171
Plastic Ejector White P20 MYPIPETMAN FP070172
Plastic Ejector Dark Blue P100 MYPIPETMAN FP070181
Plastic Ejector White P100 MYPIPETMAN FP070182
Plastic Ejector Dark Blue P200 MYPIPETMAN FP070191
Plastic Ejector White P200 MYPIPETMAN FP070192
Plastic Ejector Dark Blue P1000 MYPIPETMAN FP070201
Plastic Ejector White P1000 MYPIPETMAN FP070202
Dark blue White Blue Red Yellow Green
Dark blue stainless
steel tip ejector
White stainless
steel tip ejector
Dark blue plastic
tip ejector
White plastic tip
ejector
EJECTOR ADAPTORS
Model Part Number
Metal Ejector Adaptor P2/P10 Translucent FP070210
Metal Ejector Adaptor P2/P10 White FP070212
Plastic Ejector Adaptor P2/P10 White FP070222 Translucent
adaptor for
metal ejector
White adaptor
for metal
ejector
Adaptor for
plastic ejector

ACCESSORIES
13
MyPIPETMAN® |USER’S GUIDE
TIP HOLDERS
Model Part Number
Tip Holder Dark Blue P2 MyPIPETMAN FP070231
Tip Holder White P2 MyPIPETMAN FP070232
Tip Holder Dark Blue P10 MyPIPETMAN FP070241
Tip Holder White P10 MyPIPETMAN FP070242
Tip Holder Dark Blue P20 MyPIPETMAN FP070251
Tip Holder White P20 MyPIPETMAN FP070252
Tip Holder Dark Blue P100 MyPIPETMAN FP070261
Tip Holder White P100 MyPIPETMAN FP070262
Tip Holder Dark Blue P200 MyPIPETMAN FP070271
Tip Holder White P200 MyPIPETMAN FP070272
Tip Holder Dark Blue P1000 MyPIPETMAN FP070281
Tip Hholder White P1000 MyPIPETMAN FP070282
Tip Holder Dark Blue P5000 MyPIPETMAN FP070291
Tip Holder White P5000 MyPIPETMAN FP070292
Tip Holder Dark Blue P10mL MyPIPETMAN FP070301
Tip Holder White P10mL MyPIPETMAN FP070302
PLASTIC EJECTORS
Model Part Number
Plastic Ejector 8X Dark Blue MyPIPETMAN FP070311
Plastic Ejector 8X White MyPIPETMAN FP070312
Plastic Ejector 12X Dark Blue MyPIPETMAN FP070321
Plastic Ejector 12X White MyPIPETMAN FP070322
Dark blue
plastic tip
ejector
White plastic
tip ejector
Dark blue
tip holder
White tip
holder
EJECTOR ADAPTERS
Model Part Number
Ejector Adapter 8X White FG07064
Ejector Adapter 12X White FG07065 Ejector adapter

TROUBLESHOOTING
14 TROUBLESHOOTING | MyPIPETMAN®
Chapter 5
TROUBLESHOOTING
A quick inspection of the pipette may help you detect a potential problem.
NOTE
You may download the Two Minute Inspection Poster LT800520 from the Gilson website
(www.gilson.com), which shows how to perform a quick diagnosis of your pipette.
WARNING
Before returning any pipette to your local Gilson Service Center, ensure that it is completely
free of chemical, biological, or radioactive contamination (refer to CLEANING AND
DECONTAMINATION). Please use the included safety bag to return the pipette to your local
Gilson-authorized Service Center (Click here to find your Gilson Service Center).
Troubleshooting Table
The following table may help you identify and correct the potential problem you might encounter.
NOTE
Please make sure the tips are correctly fitted. Refer to Fitting the Tips.
For single channel and multichannel models
Symptom Possible Cause Action Model*
Pipette is leaking
sample
Damaged tip holder Replace the tip holder S
Worn O-ring or seal Replace both parts and lubricate S
Pipette will not
aspirate
Worn O-ring Replace O-Ring and seal and lubricate S
Damaged tip holder Replace the tip holder S
Connecting nut is loose Tighten connecting nut S+M
Damaged or corroded piston Return pipette to supplier S
Improper repair or assembly Refer to MAINTENANCE S
Pipetted volume is
inaccurate
Improper repair or assembly Refer to MAINTENANCE S
Unscrew tip holder Tighten connecting nut S
Connecting nut is loose Tighten connecting nut S+M
Pipette is not precise
Tip holder is loose Tighten connecting nut S
Connecting nut is loose Tighten connecting nut S+M
Incorrect operator technique Operator training S+M
Damaged or corroded piston(s) Return pipette to supplier S
Damaged tip holder(s) Replace the tip holder(s) S
Worn O-ring or seal Replace both parts and lubricate S
Low quality tips Use PIPETMAN DIAMOND Tips S+M
Damaged tip holder(s)
Replace the tip holder(s) for single channel
model. Contact your local Gilson Service
Center for multichannel model
S+M
Damaged tip ejector adapter Damaged tip ejector adapter S+M
Damaged ejector Replace the tip ejector S+M
Dirty tip holder Clean the tip holder with isopropanol or
ethanol S+M
The tip ejector is loose Assemble the tip ejector properly S
The ejector lock is misaligned Align the ejector lock S
Pipetting seize up Piston needs lubricant Lubricate piston assembly S
S = Single Channel
M = Multichannel
NOTE
If you cannot solve the problem, contact your local Gilson-authorized Service Center.

CLEANING AND DECONTAMINATION
15
MyPIPETMAN® |USER’S GUIDE
Leak Test
This test may be performed at any time to check that the pipette does not leak, especially after
performing a maintenance or decontamination procedure. If a pipette fails this test, replace the
O-ring and seal. After making sure that the pipette is correctly reassembled, repeat this test.
For the P2 to P200 single channel models:
1. Fit a PIPETMAN DIAMOND Tip.
2. Set the pipette to the maximum volume given in the specifications and pre-wet.
3. Aspirate the set volume from a beaker of distilled water.
4. Maintain the pipette in the vertical position and wait for 20 seconds:
○If a water droplet appears at the end of the tip, there is a leak.
○If you see no droplets, re-immerse the tip below the surface of water. The water level inside the
tip should remain constant; if the level goes down, there is a leak.
For the P1000, P5000, and P10mL single channel models:
1. Fit a PIPETMAN DIAMOND tip.
2. Set the pipette to the maximum volume given in the specifications.
3. Aspirate the set volume from a beaker of distilled water.
4. Maintain the pipette in the vertical position and wait for 20 seconds:
○If a water droplet appears at the end of the tip, there is a leak.
For the multichannel models:
1. Fit the PIPETMAN DIAMOND tip.
2. Set the pipette to the maximum volume given in the specifications, and pre-wet the tips.
3. Aspirate the set volume from a reagent reservoir of distilled
water.
4. Maintain the pipette in the vertical position and wait for 20
seconds:
○If a water droplet appears at the end of the tip, there is a
leak.
○If you see no droplets, for volumes below 200 µL,
re-immerse the tip below the surface of water.
○The water level inside the tip should remain constant;
there is a leak if the level goes down.
no leak
Figure 10
MyPIPETMAN® multichannel leak test
Chapter 6
CLEANING AND DECONTAMINATION
MyPIPETMAN pipettes are fully autoclavable without disassembly for maximum convenience as well as
protection from contamination.
NOTICE
You may refer to the decontamination procedure available on www.gilson.com.
Liquid must never enter any pipette’s upper part (handle).
Cleaning for Single Channel Models
The pipette must be cleaned, as described below, before it is decontaminated. Soap solution is
recommended for cleaning MyPIPETMAN.
External
1. Remove the tip ejector (refer to Changing the Tip Ejector for Single Channel Models).
2. Wipe the entire pipette and the tip ejector with a soft-cloth or lint-free tissue soaked with soap
solution to remove all dirty spots or marks. If the pipette is very dirty, a brush with soft, plastic
bristles may be used.
3. Wipe the entire pipette and the tip ejector with a soft cloth or lint-free tissue soaked with distilled
water.
4. Refit the tip ejector and allow the pipette to dry.

CLEANING AND DECONTAMINATION
16 CLEANING AND DECONTAMINATION | MyPIPETMAN®
Internal
Only the following components can be immersed in a cleaning solution: connecting nut, tip ejector, tip
holder, piston assembly, seal, and O-ring.
1. Disassemble the pipette (refer to MAINTENANCE).
2. Set aside the upper part in a clean, dry place.
3. Clean the individual components of the lower part of the pipette using an ultrasonic bath (20
minutes at 50°C) or with a soft-cloth and brushes. Note that the piston assembly and seals must be
degreased with isopropanol or ethanol before being immersed in another ultra sonic bath. Small
round brushes with soft plastic bristles may be used to clean the interior of the tip holder.
4. Rinse the individual components with distilled water.
5. Leave the parts to dry by evaporation or wipe them with a clean, soft cloth or lint-free tissue.
6. Reassemble the pipette (refer to MAINTENANCE).
Cleaning for Multichannel Models
Only the following components can be immersed in a cleaning solution: tip ejector (including the ejector
locks), and ejector spacer.
1. Remove the tip ejector and the ejector spacer.
2. Immerse the tip ejector and ejector spacer in the cleaning solution or wipe
them with a soft cloth or lint-free tissue soaked with the cleaning solution.
3. Rinse the components with distilled water.
4. Wipe the entire pipette with a soft cloth or lint-free tissue soaked with the
cleaning solution.
5. Wipe it with distilled water.
6. Leave the parts to dry by evaporation or wipe them with a clean soft-cloth
or lint-free tissue.
7. Refit the tip ejector (refer to Changing the Tip Ejector for Multichannel
Models).
Autoclaving
MyPIPETMAN pipettes are fully autoclavable without disassembly for maximum convenience and
protection from contamination.
1. Before autoclaving
Set the pipette volume to the nominal volume of the model before placing it in the autoclave.
NOTE
For pipettes equipped with the 3-position locking system, turn the selector to the left until the
cursor reaches the autoclaving icon.
2. Procedure
MyPIPETMAN can be sterilized by steam autoclaving at 121°C (252°F), 1 bar relative pressure for 20
minutes without disassembly.
When autoclaving, the pipette will dry better and faster without using a bag.
3. After autoclaving
Following the autoclaving cycle, let the pipette cool down overnight to
room temperature and dry thoroughly before use. Checking should be
carried out according to your standard operating procedure. Leak test may
also be performed to ensure that the pipette does not leak, as described in
TROUBLESHOOTING, part Leak Test.

CLEANING AND DECONTAMINATION
17
MyPIPETMAN® |USER’S GUIDE
Chemical Decontamination
You may choose to decontaminate your pipette chemically in accordance with your own procedures.
Whatever decontaminant you use, check with the supplier of the decontaminant that it is compatible
with stainless steel and the plastics used in the construction of the pipette: PA (Polyamide),
PBT (Polybutylene Terephthalate), PC (Polycarbonate), PC/PBT (Polycarbonate/ Polybutylene
Terephthalate), POM (Polyoxymethylene), PVDF (Polyvinylidene Fluoride), PP (Polypropylene), PPA
(Polyphthalamide), or PPS (Polyphenylene Sulfide).
Upper Part (Handle)
1. Wipe the upper part (handle) of the pipette with a soft cloth or lint-free tissue soaked with the
chosen decontaminant.
2. Wipe the upper part of the pipette with a soft cloth or lint-free tissue soaked with distilled water or
sterile water.
Lower Part (Volumetric Module)
SINGLE CHANNEL MODELS
Only the following components only can be immersed in a decontaminant solution: connecting nut, tip
ejector, and tip holder.
NOTE
The piston assembly and seals must be degreased with isopropanol or ethanol in a separate vessel
before being immersed in decontamination solution.
1. Disassemble the pipette (refer to MAINTENANCE).
2. Immerse tip ejector, tip holder, and connecting nut in the decontamination solution.
3. Disassemble and degrease the piston assembly (Refer to Servicing Piston Assembly).
4. Rinse the connecting nut, tip ejector, and tip holder with distilled water.
5. Let the parts dry by evaporation (or wipe the tip ejector, the tip holder, and connecting nut with a
soft cloth).
6. Lubricate the piston assembly and the seals (Refer to Servicing Piston Assembly).
7. Reassemble the piston assembly, the tip holder, and the tip ejector.
MULTICHANNEL MODELS
Only the following components only can be immersed in a decontamination solution: tip ejector with
ejector locks, and ejector spacer.
1. Remove the tip ejector and the ejector spacer.
2. Immerse the tip ejector, ejector locks, and ejector adapter in the decontamination solution or wipe
them with a soft cloth or lint-free tissue soaked with the decontamination solution.
3. Rinse the components with distilled water.
4. Wipe the entire pipette with a soft cloth or lint-free tissue soaked with the decontamination solution.
5. Wipe it with distilled water.
6. Let the parts dry by evaporation or wipe them with a clean soft cloth or lint-free tissue.
1. Refit the tip ejector (refer to Fitting the Tip Ejector Adapter).

MAINTENANCE
18 MAINTENANCE | MyPIPETMAN®
Chapter 7
MAINTENANCE
Routine maintenance will help keep your pipette in good condition, ensuring a continued high level of
performance.
NOTICE
Gilson recommends maintenance and calibration at least annually, more frequently as
needed, depending on use. The instructions provided below detail how to perform some basic
maintenance yourself. Please contact your local Gilson service provider (Click here to find your
local Gilson representative) to have Gilson provide maintenance and calibration for you or to ask
any service-related questions.
Maintenance is limited to:
●Cleaning or decontamination (refer to CLEANING AND DECONTAMINATION)
●Replacing spare parts
●Greasing the piston assembly
Changing the Tip Ejector for Single Channel
To remove
1. Push the ejection button 1.
2. Turn the tip ejector clockwise 2.
3. Slide and remove the tip ejector 3.
To refit
1. Push the ejection button.
2. Slide the tip ejector along the tip holder.
3. Clip the tip ejector on the body of the pipette.
Changing the Tip Holder for Single Channel
1. Push the ejection button.
2. Turn the tip ejector clockwise.
3. Slide and remove the tip ejector.
4. Unscrew the connecting nut by turning it clockwise.
5. Carefully separate the lower and upper parts.
6. Reassemble the pipette with the changed tip holder.
7. Tighten the connecting nut (turn counterclockwise)
NOTICE
Removing the tip holder could impact pipette performance. Performance should be checked upon
refitting the new tip holder. Extra care should be taken with the piston for the P2/P10 volumes,
improper installation can cause critical damage to the piston. Users should also keep track of
seals/O-rings and make sure they are reinstalled properly. Failure to reinstall correctly can result in a
leaking pipette.
Changing the Tip Ejector for Multichannel Models
To remove
1. Keep both ejector locks depressed 1.
2. Pull the tip ejector down 2.
To refit
1. Gently re-insert the tip ejector vertically into the rails of the ejector support 3.
2. Pull lightly on the tip ejector to check the position.
1
2
3
1
23

MAINTENANCE
19
MyPIPETMAN® |USER’S GUIDE
1
2
Locking system
Tip ejector
button
Figure 11
MyPIPETMAN® piston assembly (disassembled)
2
3
4
Color-coded
push buton
Connecting nut
Tip ejector
Tip
holder
Piston
assembly
P10, P20,
P100, P200
P1000
P5000
P10mL
Servicing the Piston Assembly
You may remove the piston assembly for cleaning purposes only. If the piston assembly is changed, the
pipette must be adjusted and calibrated at an authorized Gilson Service Center.
NOTE
As models P2 and P10 contain miniaturized parts, it is best not to disassemble these pipettes
yourself.
Separate the upper part and the lower part
1. Push the ejection button 1.
2. Turn the tip ejector clockwise 2.
3. Slide and remove the tip ejector 3.
4. Unscrew the connecting nut 4.
Carefully separate the tip holder from the upper part (refer to Figure 11)
1. Remove the piston assembly, O-ring, and the seals (refer to Changing the Tip
Ejector for Single Channel).
2. Leave the piston exposed, clean it with isopropanol or ethanol, and lubricate
lightly (lubricant P/N: 5440011070).
3. Clean, autoclave, or replace the tip holder. If necessary, lightly lubricate the
piston and its seals.
NOTE
For P20, P100, P200, models: lubricate only the useful part of the piston (25 ±/-5 mm length) and
the O-ring (refer to Figure 12).
For P1000 model: lubricate the piston.
For P5000, P10mL models: disassemble the seals, lubricate the internal part of the seal, and then
lubricate the useful part of the piston. Do not lubricate the O-ring.
4. Reassemble the pipette.
5. Tighten the connecting nut (turn counterclockwise).
6. Refit the tip ejector
NOTE
If the piston assembly is changed, the pipette must be adjusted and calibrated in at an authorized
Gilson Service Center.
Figure 12
Lubricate the
internal part of
the piston

SPARE PARTS
20 SPARE PARTS | MyPIPETMAN®
Chapter 8
SPARE PARTS
The parts listed below include MyPIPETMAN accessories, also mentioned in chapter 4 – ACCESSORIES
for extra personalization.
MyPIPETMAN MULTICHANNEL SPARE PARTS
MODEL DARK BLUE PLASTIC
TIP EJECTOR
WHITE PLASTIC
TIP EJECTOR
EJECTOR
ADAPTER
MyPIPETMAN P8x10 FP070311 FP070312 FG07064
MyPIPETMAN P12x10 FP070321 FP070322 FG07065
MyPIPETMAN P8x20 FP070311 FP070312 -
MyPIPETMAN P12x20 FP070321 FP070322 -
MyPIPETMAN P8x200 FP070311 FP070312 -
MyPIPETMAN P12x200 FP070321 FP070322 -
MyPIPETMAN P8x300 FP070311 FP070312 -
MyPIPETMAN P12x300 FP070321 FP070322 -
SPARE PARTS FOR ALL MODELS
MODEL PART NUMBER
Window 3digit Dark Blue MyPIPETMAN FP070101
Window 3digit White MyPIPETMAN FP070102
Window 3digit Blue MyPIPETMAN FP070103
Window 3digit Red MyPIPETMAN FP070104
Window 3digit Yellow MyPIPETMAN FP070105
Window 3digit Green MyPIPETMAN FP070106
Lubricant Tube for PIPETMAN (1g) 5440011070
NOTICE
For pipette service and maintenance, or for extra spare parts, please contact your
local Gilson Service provider.
MyPIPETMAN SINGLE CHANNEL SPARE PARTS
Model
Seal+
O-ring
(5 sets)
Adpator
for Metal
Ejector
Adapter
for Plastic
Ejector
White
Stainless
Steel Tip
Ejector
Dark Blue
Stainless
Steel Tip
Ejector
White
Plastic Tip
Ejector
Dark blue
Plastic
Tip Ejector
White
Tip
Holder
Dark Blue
Tip Holder
P2 F144861 FP070212
FP070210* FP070222 FP070112 FP070111 FP070162 FP070161 FP070232 FP070231
P10 FA07012 FP070212
FP070210* FP070222 FP070112 FP070111 FP070162 FP070161 FP070242 FP070241
P20 FA07013 - - FP070122 FP070121 FP070172 FP070171 FP070252 FP070251
P100 FA07014 - - FP070132 FP070131 FP070182 FP070181 FP070262 FP070261
P200 FA07015 - - FP070142 FP070141 FP070192 FP070191 FP070272 FP070271
P1000 FA07016 - - FP070152 FP070151 FP070202 FP070201 FP070282 FP070281
P5000 FA07307 - - - - - - FP070292 FP070291
P10mL FA07308 - - - - - - FP070302 FP070301
*Translucent Adapter
