Gold's Gym GR 7000 GGBE6974.1 User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Model No. GGBE6974.1
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT THE
STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-877-776-4777
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.goldsgympowerflex.com
USER’S MANUAL

2
WARNING DECAL PLACEMENT
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PART IDENTIFICATION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
CABLE DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
TABLE OF CONTENTS
The decal shown here has been applied in the
indicated locations. If a decal is missing or
illegible, call the telephone number on the
front cover of this manual and request a free
replacement decal. Apply the decal in the
location shown. Note: The decal may not be
shown at actual size.
HORIZONTAL WARNING
PN 218556 – Black Text/Clear Background
PN 218557 – White Text/Clear Background
GOLD'S GYM is a registered trademark of Gold's Gym International, Inc. This product is manufactured and
distributed under license from Gold's Gym Merchandising, Inc.

3
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over the age of 35 or per-
sons with pre-existing health problems.
2. Use the weight bench only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the weight bench are ade-
quately informed of all precautions.
4. The weight bench is intended for home use
only. Do not use the weight bench in any
commercial, rental, or institutional setting.
5. Keep the weight bench indoors, away from
moisture and dust. Place the weight bench
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is enough clearance around the weight
bench to mount, dismount, and use the
weight bench.
6. Inspect and properly tighten all parts regular-
ly.Replace any worn parts immediately.
7. Keep children under age 12 and pets away
from the weight bench at all times.
8. Keep hands and feet away from moving parts.
9. Always wear athletic shoes for foot protec-
tion while exercising.
10. Make sure that the cables remain on the pul-
leys at all times. If the cables bind as you are
exercising, stop immediately and make sure
that the cables are on the pulleys. Replace all
cables at least every two years.
11. Always set both spotters, both weight rests,
and both safety spotters at the same height.
12. The weight bench is designed to support a
maximum user weight of 300 lbs. (136 kg). Do
not place more than 310 lbs. (140 kg) on the
weight bar. Do not place more than 310 lbs.
(140 kg), including a barbell, on the weight
rests. Do not place more than 150 lbs. (68 kg)
on the weight carriage or the leg lever. Note:
The weight bench does not include a barbell
or weights.
13. Always place an equal amount of weight on
each side of the weight carriage, weight bar,
or barbell.
14.
Always exercise with a partner.Your partner
should be ready to catch the barbell if you
cannot complete a repetition.
15. Always lower the weight carriage and the
weight bar in a controlled manner; never let
the weight carriage or the weight bar drop.
16. Always remove the lat bar when performing
an exercise that does not require the use of
the lat bar.
17. Always move the bench out of the way when
performing an exercise that does not require
the bench.
18. Always make sure that the seat pin is fully
engaged before using the backrest.
19. If you feel pain or dizziness while exercising,
stop immediately and begin cooling down.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on the weight bench before using the weight bench.
ICON assumes no responsibility for personal injury or property damage sustained by or through the
use of the weight bench.
IMPORTANT PRECAUTIONS

4
Weight Carriage
Handle
Lat Bar
Butterfly Arm
Safety Spotter
Weight Rest
Storage Tube
Spotter
Upright
Right Side
Left Side
Note: The terms “right side” and “left side” are determined
relative to a person sitting on the bench; they do not corre-
spond to right and left on the drawings in the manual.
Backrest Foot Plate
Leg Lever
Curl Pad
Seat
Curl Bar
Weight Bar
BEFORE YOU BEGIN
Thank you for selecting the versatile GOLD’S GYM®
GR 7000 weight bench. The weight bench offers a
selection of weight stations designed to develop every
major muscle group of the body. Whether your goal is
to tone your body, build dramatic muscle size and
strength, or improve your cardiovascular system, the
weight bench will help you to achieve the specific
results you want.
For your benefit, read this manual carefully before
using the weight bench. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
To avoid a registration fee for any service needed
under warranty, you must register the weight bench
at www.goldsgympowerflex.com/registration.
Before reading further, please review the drawing below
and familiarize yourself with the parts that are labeled.
ASSEMBLED DIMENSIONS:
Height: 85 in. (216 cm)
Width: 83 in. (211 cm)
Depth: 106 in. (269 cm)

5
M6 Washer (86)
M8 Washer (94)
M10 Split Washer (93)
M8 Nylon Locknut (78)
M10 Washer (84)
M10 Nylon Locknut (79)
M6 Nylon Locknut (80)
M10 x 65mm Carriage Bolt (83)
M10 x 42mm Button Bolt (96)
M8 x 42mm Hex Bolt (130)
M6 x 64mm Screw (89)
M
M10 Large Washer (76)
M10 x 62mm Button Bolt (88)
M10 x 67mm Button Bolt (90)
M10 x 53mm Button Bolt (147)
M10 x 46mm Button Bolt (100)
M10 x 49mm Button Bolt (104)
M10 x 25mm Button Screw (98)
M10 x 180mm Button Bolt (145)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been preattached. If a part is not in the hardware kits, check to see if it has been preattached.

6
M10 x 82mm Button Bolt (106)
M10 x 85mm Button Bolt (144)
M10 x 93mm Button Bolt (97)
M10 x 95mm Button Bolt (92)
M8 x 76mm Carriage Bolt (143)
M8 x 19mm Shoulder Bolt (85)
M4 x 16mm Screw (82)
M4 x 10mm Screw (95)
M6 x 16mm Screw (148)
M6 x 35mm Screw (149)
M6 x 38mm Screw (146)
M6 x 77mm Screw (87)
M8 x 20mm Hex Screw (21)
M10 x 73mm Button Screw (103)
M10 x 76mm Button Bolt (102)
M10 x 19mm Buton Bolt (77)
M10 x 116mm Button Bolt (101)
M10 x 154mm Button Bolt (99)
M10 x 73mm Hex Bolt (105)

7
ASSEMBLY
Before beginning assembly, carefully read the
following information and instructions:
• To hire an authorized service technician to
assemble the weight bench, call 1-800-445-2480.
• Assembly requires two persons.
• Because of its size, the weight bench should be
assembled in the location where it will be used.
Make sure that there is enough clearance to walk
around the weight bench as you assemble it.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
• For help identifying small parts, use the PART
IDENTIFICATION CHART on pages 5 and 6.
• As you assemble the weight bench, make sure all
parts are oriented as shown in the drawings.
• Tighten all parts as you assemble them, unless
instructed to do otherwise.
• Assembly requires the included hex key(s)
and the following tools (not included):
two adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
Make Assembly Easier
Everything in this manual is designed to ensure
that the weight bench can be assembled suc-
cessfully by almost anyone. By setting aside
plenty of time, assembly will go smoothly.
1.
Attach a Small Foot Plate (50) to a Base (1) with
two M4 x 16mm Screws (82).
Orient a Large Foot Plate (51) as shown. Attach
the Large Foot Plate to the Base (1) with two M4
x16mm Screws (82).
Insert four M10 x 65mm Carriage Bolts (83) up
through the Base (1). Place a piece of tape over
the bolt heads to hold them in place.
Repeat this step with the other Base (1). Note
the orientation of the Large Foot Plate (51).
1
Before beginning assembly,make sure
that you understand the information in the
box above.
1
1
82
51
51
82
50 83
83

8
2. Insert two M10 x 65mm Carriage Bolts (83) up
through the Center Base (2). Place a piece of
tape over the bolt heads to hold them in place.
Attach a Base (1) to the Center Base (2) with two
M10 x 93mm Button Bolts (97), an M10 Split
Washer (93), two M10 Washers (84), and an M10
Nylon Locknut (79). Do not tighten the Button
Bolts yet.
Attach the other Base (not shown) to the
Center Base (2) in the same manner.
3. Attach the Backrest Upright (8) to the Center
Base (2) with the indicated two M10 x 65mm
Carriage Bolts (83) and two M10 Nylon Locknuts
(79). Do not tighten the Nylon Locknuts yet.
83
279
97
84
93
2
1
3
8
79
79
2
83

79
97
84 55
9
4. Attach the Left Support (6) to the left Base (1)
with the indicated two M10 x 65mm Carriage
Bolts (83) and two M10 Nylon Locknuts (79). Do
not tighten the Nylon Locknuts yet.
Attach an Upright Cap (34) to the Left Upright (3)
with two M4 x 16mm Screws (82).
Attach the Left Upright (3) to the Base (1) with the
indicated two M10 x 65mm Carriage Bolts (83)
and two M10 Nylon Locknuts (79). Do not tight-
en the Nylon Locknuts yet.
See the inset drawing. Identify the Guide Rods
(5) and the Carriage Guides (64).
Attach a Guide Rod (5) to the Base (1) with an
M10 x 93mm Button Bolt (97), two M10 Washers
(84), two 25mm Spacers (55), and an M10 Nylon
Locknut (79). Do not tighten the Nylon Locknut
yet.
Repeat this step with the Right Support (7),
the Right Upright (not shown), the other Guide
Rod (not shown), and the other Base (1).
5. Orient the two Carriage Guides (64) with the rings
near the bottom. Attach the Carriage Guides to
the Center Base (2) with an M10 x 154mm Button
Bolt (99), two M10 Washers (84), two 6mm
Spacers (75), and an M10 Nylon Locknut (79).
Do not tighten the Nylon Locknut yet.
Slide two Guide Bumpers (27) onto the Carriage
Guides (64). Slide the Weight Carriage (41) onto
the Carriage Guides as shown.
82 82
3
56
7
34
4
1
1
84
83
55
79
79
83
79
5
99
84
84
79
2
75
27
41
64
64
27
564

10
6. Orient the Left Spotter (24) as shown. Slide the
Left Spotter and two Guide Bumpers (27) onto
the left Guide Rod (5). Then, engage the Left
Spotter onto the Left Upright (3).
Repeat this step with the Right Spotter (not
shown) and the right Guide Rod (not shown).
8. Attach a Barbell Adapter (22) to one end of the
Weight Bar (17) with an M10 x 25mm Button
Screw (98), an M10 Split Washer (93), and an
M10 Large Washer (76). Repeat this step on the
other end of the Weight Bar.
Tighten an M8 x 20mm Hex Screw (21) into the
Left Guide (20). Repeat this step with the Right
Guide (not shown).
7. Slide the Right Guide (19) and the Left Guide
(20) onto the Guide Rods (5).
Slide the Weight Bar (17) through the Left Guide
(20), the Locking Bar (18), and the Right Guide
(19). Engage the Locking Bar onto the Uprights
(3, 4).
27
6
24
5
3
27
21
20
17
8
22
76 93
98
7
19
18
20
17
5
3
4
5

11
990
13
84
6
84
79
33
93 98
84
93
5
3
103
9. Insert a Side Rod Cap (33) into a Side Top Frame
(13). Set the Top Frame onto the left Guide Rod
(5) and insert it into the Left Support (6).
Attach the Side Top Frame (13) to the Left
Upright (3) and the Left Support (6) with two M10
x73mm Button Screws (103), two M10 x 25mm
Button Screws (98), four M10 Split Washers (93),
and four M10 Washers (84). Do not tighten the
Button Screws yet.
Insert an M10 x 67mm Button Bolt (90) through
the Left Upright (3) and the Side Top Frame (13).
Hand tighten an M10 Washer (84) and an M10
Nylon Locknut (79) onto the Button Bolt.
Repeat this step with the other Side Top Frame
(13) and the right side of the weight rack.
10. Orient the Center Top Frame (14) with the decal
in the position shown. Make sure that the Rod
Cap (33) is inside of the left Side Top Frame
(13).
Attach the Center Top Frame (14) to the Side Top
Frame (13) with two M10 x 93mm Button Bolts
(97), two 17mm Spacers (66), two M10 Washers
(84), and two M10 Nylon Locknuts (79). Do not
tighten the Nylon Locknuts yet.
Repeat this step with the right Side Top Frame
(not shown).
97
14
13
33
66
79
84
97
Decal
10
66
11
13
13
15
15 97
97
79
79
92 8
92
79
84
11. Attach a Support Frame (15) to the left Side Top
Frame (13) with two M10 x 93mm Button Bolts
(97), two M10 Washers (84), and two M10 Nylon
Locknuts (79). Do not tighten the Nylon
Locknuts yet.
Attach the other Support Frame (15) to the
right Side Top Frame (13) in the same manner.
Attach the two Support Frames (15) to the
Backrest Upright (8) with two M10 x 95mm Button
Bolts (92) and two M10 Nylon Locknuts (79). Do
not tighten the Nylon Locknuts yet.

12
12. Attach the Butterfly Frame (12) to the Backrest
Upright (8) with two M10 x 67mm Button Bolts
(90), two M10 Washers (84), and two M10 Nylon
Locknuts (79). Do not tighten the Nylon
Locknuts yet.
13. Apply some of the included grease to an M10 x
85mm Button Bolt (144) and the two Arm
Bushings (31) in the Left Arm (10). Attach the Left
Arm to the Butterfly Frame (12) with the Button
Bolt and an M10 Nylon Locknut (79). Do not
overtighten the Nylon Locknut; the Left Arm
must pivot easily.
Repeat this step with the Right Arm (11).
8
12
79
84
84
90
90
12
13 144
79
10
11
12 31
31
Grease
Grease
14. Attach the Top Frame (16) to the Center Top
Frame (14) with two M10 x 116mm Button Bolts
(101), four M10 Washers (84), and two M10
Nylon Locknuts (79). Do not tighten the Nylon
Locknuts yet.
Attach the Top Frame (16) to the Butterfly Frame
(12) and the Backrest Upright (8) with four M10 x
67mm Button Bolts (90), four M10 Washers (84),
and four M10 Nylon Locknuts (79). Do not tight-
en the Nylon Locknuts yet.
Attach the Top Frame (16) to the Carriage Guides
(64) with two M10 x 93mm Button Bolts (97), four
M10 Washers (84), four 25mm Spacers (55), and
two M10 Nylon Locknuts (79). Do not tighten the
Nylon Locknuts yet.
101
84
90
84
16
14
14
84
79
79
12 84
84
79
55
55
64
97
8
79

13
16. The following steps are shown from the rear
of the weight rack. See the CABLE DIAGRAMS
on pages 29 and 30 to identify cables as you
assemble them.
Identify the Butterfly Cable (71). Attach the
Cable to the Right Arm (11) with an M8 x 19mm
Shoulder Bolt (85) and an M8 Nylon Locknut (78).
Do not overtighten the Nylon Locknut; the
Cable must pivot easily.
15. Attach the Foot Plate (9) to the Center Base (2)
and the Backrest Upright (8) with four M10 x
19mm Button Bolts (77) and four M10 Nylon
Locknuts (79).
See steps 2–12. Tighten all of the bolts,
screws, and nylon locknuts.
See steps 14–15. Tighten all of the bolts,
screws, and nylon locknuts.
17. Route the Butterfly Cable (71) over a “V”-pulley
(60). Attach the “V”-pulley,aLarge Cable Trap
(61), an M10 Washer (84), and two Full Finger
Guards (39) to the Backrest Upright (8) with an
M10 x 62mm Button Bolt (88) and an M10 Nylon
Locknut (79). Make sure that the Large Cable
Trap is oriented to hold the Cable in the
groove of the “V”-pulley.
85
16
71
11
78
17
88
61 60
84
79
8
39
71 39
15
77 79
79
9
2
8
77
18. Route the Butterfly Cable (71) under a 90mm
Pulley (58). Attach the Pulley and two Half Finger
Guards (40) to the Double “U”-bracket (46) with
an M10 x 46mm Button Bolt (100) and an M10
Nylon Locknut (79).
100
46
71
58
40
79
18

14
19. Route the Butterfly Cable (71) over a “V”-pulley
(60). Attach the “V”-pulley, a Large Cable Trap
(61), an M10 Washer (84), and two Full Finger
Guards (39) to the Backrest Upright (8) with an
M10 x 62mm Button Bolt (88) and an M10 Nylon
Locknut (79). Make sure that the Large Cable
Trap is oriented to hold the Cable in the
groove of the “V”-pulley.
21. Locate the High Cable (73). Route the Cable up
through the Top Frame (16) and over a 90mm
Pulley (58). Attach the Pulley inside of the Top
Frame with an M10 x 93mm Button Bolt (97), two
M10 Washers (84), two 25mm Spacers (55), and
an M10 Nylon Locknut (79).
22. Route the High Cable (73) over a 90mm Pulley
(58) and down through the Top Frame (16).
Attach the Pulley inside the Top Frame with an
M10 x 93mm Button Bolt (97), two M10 Washers
(84), two 25mm Spacers (55), and an M10 Nylon
Locknut (79).
20. Attach the Butterfly Cable (71) to the Left Arm
(10) with an M8 x 19mm Shoulder Bolt (85) and
an M8 Nylon Locknut (78). Do not overtighten
the Nylon Locknut; the Cable must pivot easi-
ly. 85
78
71
10
58
55 55 84
97
79 16
73
21
84
39
39
60
71
79
61
8
88
84
19
22 73 58
55 84
55
84
79
16
97
20

15
24. Wrap the High Cable (73) over a 90mm Pulley
(58) and over the indicated rod in the Top Frame
(16). Attach the Pulley to the Top Frame with an
M10 x 42mm Button Bolt (96) and an M10 Nylon
Locknut (79).
26. Attach the High Cable (73) inside of the Weight
Carriage (41) with an M10 x 67mm Button Bolt
(90), two M10 Washers (84), two 24mm Spacers
(45), and an M10 Nylon Locknut (79).
Attach the lower Carriage Bushing (42) inside the
Weight Carriage (41) with an M10 x 67mm Button
Bolt (90), two M10 Washers (84), a 51mm Spacer
(44), and an M10 Nylon Locknut (79).
25. Wrap the High Cable (73) over a 90mm Pulley
(58). Attach the Pulley to the Top Frame (16) with
an M10 x 42mm Button Bolt (96) and an M10
Nylon Locknut (79).
90
84 45
73
26
79
84
41
45
42
44 84
79
25 79
96
16
58
73
23. Wrap the High Cable (73) under a 90mm Pulley
(58). Attach the Pulley, a Small Cable Trap (63),
and two Half Finger Guards (40) to the two Pulley
Plates (74) with an M10 x 53mm Button Bolt
(147) and an M10 Nylon Locknut (79). Make sure
that the Small Cable Trap is oriented to hold
the Cable in the groove of the Pulley.
23
147
40
40
79
74
74
58 63
73
79
96
16
24
73
58
Rod

27. Identify the Low Cable (72). Route the Cable
through the Backrest Upright (8) and under a
110mm Pulley (59). Attach the Pulley inside the
Upright with an M10 x 93mm Button Bolt (97),
two M10 Washers (84), two 25mm Spacers (55),
and an M10 Nylon Locknut (79).
27
97
8455
7255
59
84 79
8
16
29. Route the Low Cable (72) under a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to the Center Base (2) with an M10 x
46mm Button Bolt (100) and an M10 Nylon
Locknut (79).
30. Wrap the Low Cable (72) over a 90mm Pulley
(58). Attach the Pulley, a Small Cable Trap (63),
and two Half Finger Guards (40) to the second
hole from the bottom of the two Pulley Plates (74)
with an M10 x 53mm Button Bolt (147) and an
M10 Nylon Locknut (79). Make sure that the
Cable Trap is oriented to hold the Cable in the
groove of the Pulley.
79
72
58
2
40
40
100
29
28. Route the Low Cable (72) over a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to the Double “U”-bracket (46) with
an M10 x 46mm Button Bolt (100) and an M10
Nylon Locknut (79).
28
46
40
40
79
100
72
58
30
40
40
58
72
74
74
63
147
79

17
31. Route the Low Cable (72) under a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to the Center Base (2) with an M10 x
46mm Button Bolt (100) and an M10 Nylon
Locknut (79).
32. Wrap the Low Cable (72) over a 90mm Pulley
(58). Attach the Pulley to the Top Frame (16) with
an M10 x 42mm Button Bolt (96) and an M10
Nylon Locknut (79).
31 72
40
40
58
2
79
100
79
96
16
72
32
58
34. Locate the Long Cable (54). Route the Cable
over a 90mm Pulley (58), and up through a
Swivel Arm (32) and the Left Upright (3). Attach
the Pulley inside the Swivel Arm with an M10 x
53mm Button Bolt (147), two M10 Washers (84),
two 6mm Spacers (75), and an M10 Nylon
Locknut (79).
79
34
84 75
84
32
3
58
54
147
75
33. Attach the Low Cable (72) to the “U”-bracket (47)
with an M6 Washer (86) and an M6 Nylon
Locknut (80). See the inset drawing. Do not
overtighten the Nylon Locknut; it should be
threaded onto the end of the Cable so that
only two threads are showing below the Nylon
Locknut.
33
72
47
86
80 72 45
47

18
35. Route the Long Cable (54) over a 90mm Pulley
(58). Attach the Pulley and a Small Cable Trap
(63) to the left Side Top Frame (13) with an M10 x
49mm Button Bolt (104) and an M10 Nylon
Locknut (79). Make sure that the Cable Trap is
oriented to hold the Cable in the groove of the
Pulley.
36. Route the Long Cable (54) under a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to a Base (1) with an M10 x 46mm
Button Bolt (100) and an M10 Nylon Locknut (79).
37. Route the Long Cable (54) around a 110mm
Pulley (59). Attach the Pulley,aLong Cable Trap
(62), an M10 Washer (84), and a Large Full
Finger Guard (150) to the Center Base (2) with
an M10 x 76mm Button Bolt (102) and an M10
Nylon Locknut (79). Make sure that the Cable
Trap is oriented to hold the Cable in the
groove of the Pulley.
54
58
40
40
79 1
100
36
37
79
54
59 84
150
62
102
2
79
13
63
58
54
104
35
38. Route the Long Cable (54) under a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to the Center Base (2) with an M10 x
46mm Button Bolt (100) and an M10 Nylon
Locknut (79).
38
79
40
40 58
54 2
100

19
39. Route the Long Cable (54) over a 90mm Pulley
(58). Attach the Pulley, a Small Cable Trap (63),
and two Half Finger Guards (40) to the lower hole
of the “U”-bracket (47) with an M10 x 53mm
Button Bolt (147) and an M10 Nylon Locknut (79).
Make sure that the Cable Trap is oriented to
hold the Cable in the groove of the Pulley.
40. Route the Long Cable (54) under a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to the Center Base (2) with an M10 x
46mm Button Bolt (100) and an M10 Nylon
Locknut (79).
41. Route the Long Cable (54) around a 110mm
Pulley (59). Attach the Pulley,aLong Cable Trap
(62), an M10 Washer (84), and a Large Full
Finger Guard (150) to the Center Base (2) with
an M10 x 76mm Button Bolt (102) and an M10
Nylon Locknut (79). Make sure that the Cable
Trap is oriented to hold the Cable in the
groove of the Pulley.
40
240
40
54 58
79
100
41
79
59
84
54
150
62
102
2
54
58
63
40 40
79
147
47
39
42. Route the Long Cable (54) under a 90mm Pulley
(58). Attach the Pulley and two Half Finger
Guards (40) to a Base (1) with an M10 x 46mm
Button Bolt (100) and an M10 Nylon Locknut (79).
42
58 79
40
40
54
1
100

20
44. Route the Long Cable (54) through the Right
Upright (4) and a Swivel Arm (32). Then, route
the Cable over a 90mm Pulley (58). Attach the
Pulley inside the Swivel Arm with an M10 x 53mm
Button Bolt (147), two M10 Washers (84), two
6mm Spacers (75), and an M10 Nylon Locknut
(79).
45. Slide a Clip Cover (52) onto the Long Cable (54).
Hold an M6 Nylon Locknut (80) inside of a Clip
(53), and insert the Long Cable (54) into the Clip
and the Nylon Locknut. Hold the crimp on the
Cable with a pair of pliers. Insert a screwdriver
between the Nylon Locknut and the Clip. Rotate
the screwdriver, the Clip, and the Nylon Locknut
together until two threads of the Cable show past
the Nylon Locknut.
Slide the Clip Cover (52) over the Clip (53).
45
54
52
80
53
147
84 75
75
44
84
79
58
54
32
4
43
54
58
13
104
63
79
43. Route the Long Cable (54) over a 90mm Pulley
(58). Attach the Pulley and a Small Cable Trap
(63) to the right Side Top Frame (13) with an M10
x49mm Button Bolt (104) and an M10 Nylon
Locknut (79). Make sure that the Small Cable
Trap is oriented to hold the Cable in the
groove of the Pulley.
29
86
89
46
8
86
89
46. Attach the Butterfly Backrest (29) to the Backrest
Upright (8) with two M6 x 64mm Screws (89) and
two M6 Washers (86).
