golmar IP 6502/G+ User guide

6502/G+
12327402
INSTALLER MANUAL
(Manual based on FW version 1.04)

CATEGORY 1_HEADERCATEGORY 2_HEADER
2Footer Infos
IP G+ 6502/G+
www.golmar.es 2
INDEX
1. Safety cautions and warnings ...........................................................................................................................3
2. Specications....................................................................................................................................................3
3. Panel description..............................................................................................................................................3
4. Panel installation .......................................................................................................................................................... 4
5. Initial conguration ..................................................................................................................................................... 5
6. Initial alternative conguration through web client................................................................................................ 6
7. Settings........................................................................................................................................................................... 8
8. System operation.......................................................................................................................................................... 9
9. Installation diagram..................................................................................................................................................... 10

3
6502/G+ IP G+
www.golmar.es
- TCP/IP video intercom system with technology IP-G+.
- Installation over existing ethernet network (D4L-G+/POE are required).
- Up to 98 blocks in one system.
- Up to 19 entry panels at each block.
- Up to 19 general panels at each installation.
- Up to 799 ats per each block.
- Up to 19 guard units for the general compound and 9 guard units at each block.
2. SPECIFICATIONS
3. PANEL DESCRIPTION
- e installation and setup of this equipment must be done by an authorized installer.
- e current regulations oblige to protect the power supply by means of a thermal magnetic circuit breaker.
- All the installation conduits must distance at least 40 cm from any other installation.
- In regards of the power supply FA-G+:
- Do not tight with excessive strength the screws of the terminal block at FA-G+ power supply.
- Install the power supply in a dry and secure area, protected against water drops.
- Avoid placing the power supply close to heating sources, humid or dusty areas.
- Do not cover the power supply ventilation openings area to assure air ow circulation.
- To prevent damages, the power supply has to be strongly mounted. Use a DIN rail 46277 (8 DIN) to x it.
-To avoid an Electrical shock, do not remove the protection cover and do not manipulate the cables connected to the power terminals.
1. SAFETY CAUTIONS AND WARNINGS
09:27
PM
06-03-2020
3
Screw to x the header
Header
Door panel xation
RJ-45 conector
NC1
C1
NA1
GND
+12V
AP+
AP-
NA2
C2
NC2
- Front
- Connections terminal block.
(*) Anti-vandal tamper.
RFID reader
Light sensor
IK-07 and IP-65
Working temperature: -40~60ºC
Navigation menu
4,3” LCD TFT, 480x272 px.
Numeric Keypad
White leds for night vision
130 º wide angle camera
Exit button
Local power supply input
NO, NC door release
dry contacts.
Sensor IR
N.O, N.C door release
dry contacts
(**) In case to power the panel with a local power supply, the ethernet cable cannot be connected to a PoE output of the distributor
D4L-G+.

4
6502/G+IP G+
www.golmar.es
1 -Avoid locating the panel exposed to direct sun light or ex-
ternal light sources like streetlamps, to get a good image.
4. PANEL INSTALLATION
3- Make a hole in the wall where to t the embedding box CE-
6502/G+. e dimensions of the hole are 128(W) x 306 (H) x 44
(D). Assure the box is xed upside correctly.
2- Locate the top part of the entry panel at 1,65m height from
ground.
09:27
PM
06-03-2020
1
2
3
Mind the embedding box orienta-
tion.
It is recommended to oow the
instructions andtips mentioned in
the embedding box mount guide:
(https://bit.ly/3incuSb)
4- Connect the ethernet cable (1) and hang the upper part of the
panel in the nails which protrude out of the box (2), then tilt the
panel to t into the bottom part of the box.
5- Fix the bottom part of the panel using the screws supplied. 6- Slide up the header supplied, to cover the bottom part of the
panel and tight the screws underneath.
09:27
PM
06-03-2020
09:27
PM
06-03-2020
1
09:27
PM
20-09-2017
2
(*) Header screw should be tight using the supplied tool.

Registro correcto. El sistema se reiniciará ahora
5
6502/G+ IP G+
www.golmar.es
Marcar el número de vivienda
o pulsar para mostrar la agenda
Introducir longitud del código de llamada (5 o 6 dígitos)
Introducir contraseña
Introducir número de edicio (1 a 99)
Menú de ajustes
Introducir número de placa (1 a 19)
Ajustes de la placa
Registro correcto. El sistema se reiniciará ahora
1
5
2
6
3
7
4
8
Select automatic IP assignment. In
this way the system will assign to the
master panel 10.0.14.9 IP address
9
In this moment, panel will reboot
and will be congured like man-
ager panel.
For a manual assignment of the IP address, follow the same process as described above, but in step 8 choose the Manual mode, then
follow the steps described below:
Registro correcto. El sistema se reiniciará ahora
9
Enter the desired IP address of
the panel and press validation
icon.
Registro correcto. El sistema se reiniciará ahora
10
Enter subnet mask and press
validation icon.
,
Registro correcto. El sistema se reiniciará ahora
11
Enter Gateway address and press
validation icon.
Registro correcto. El sistema se reiniciará ahora
12
Enter the IP Server address.
It is IP address of the system
manager panel.
Once all the steps have been completed, will appear the same conrmation screen as in automatic option.
Access to conguration. Type the installer PIN code
“2718” with the keypad and press validation
Select the second option in
settings menu (1/3).
Select second option in settings
menu (1/2).
Select 5 digits dialling length.
*6 digits dialling code length in the
case you like to indicate the oor
Type “1” for building number and
press validation icon.
Type “1” for panel number and
press validation icon.
- One of the panels of the installation is in charge to manage the system, thus it is not necessary to assign IP addresses or to cong the
changes applied to each one of the devices of the installation.
To congure a panel as system manager, follow the steps:
5. INITIAL CONFIGURATION

CATEGORY 1_HEADERCATEGORY 2_HEADER
6Footer Infos
www.golmar.es
IP G+ 6502/G+
6
6502/G+ coded panel can be congured via its web client.
To do this, you need to connect your computer to the network.
e factory IP address of the panel is 10.0.0.254. Check that your computer network connection is in the same range. You will perform
the following steps:
It follows the explanations on how to review the registered conguration.
Marcar el número de vivienda
o pulsar para mostrar la agenda
Introducir contraseña
Menú de ajustes
Menú de ajustes (3/3)
1 2 3 4
Access to conguration. Type the installer PIN code
2718 with the keypad and press validate.
Press the right arrow button to
go to settings menu (3/3).
Select the fourth option.
Edicio
Placa
Dirección IP
Máscara de red
Puerta de enlace
Dirección Mac
Block and door panel
number set.
(*) Check the quick guide of the monitor to know the monitor’s conguration, in order to communicate with the panel.
In systems with general entry panels, will require to follow the same process described before, but in step 6, the number of building
should be 99. e number of entry panel will run from 1 to 19 (max. number of general entry panel is 19).
6. ALTERNATIVE INITIAL CONFIGURATION THROUGH WEB CLIENT.
Go to network settings in control panel. Change the active Ethernet network.
Enter into “properties”. 4Select Internet
protocol IPv4.
5Set the IP range.
IP address should start by 10.
Next three numbers should
have a value lower than 255.
Assign 10.0.0.1 as Gateway.
Do not assign DNS Conrm settings.
1 2
3

7
6502/G+ IP G+
www.golmar.es
Type the IP in the browser: Factory IP: 10.0.0.254
GO
10.0.14.9
Search
GO
10.0.14.9
Search
e password is 888999.
Now the computer is congured to work in the same IP range in which the panel is located.
e only thing le to do is to:
Log in to the Web Client:
Now the initial screen of the web client is described:
On this initial screen, there are various sections on the bottom
right-hand side. For the system manager panel initial conguration,
you only will acceess to the “Settings” section.
You shall set out in descending order:
• Dialing code length: 5
• Block number: 1
• Panel number: 1
• Floor number: 1
You can also activate the villa mode, the tamper, in addition to
changing the date and time.
You will be able to establish panel IP address manually from this same screen.
Active the manual data input by clicking icon.
You must ll in the “Local IP” eld with the desired panel IP address, “Subnet Mask” eld with panel subnet mask, “Gateway” eld with
the Gateway address and “Server IP” eld with the server IP address.
Remember that, in system manager panel case, the server IP address is its own IP address.
L
Illumination leds*
TFT always ON
Prompt messages**
Speaker level
*Illumination modes
0OFF - 1ON - 2Auto
**Prompt modes
0OFF
1Spanish
2Danish
4English
5French
6Greek
7Portuguese
8Ring tones
Previous

By clicking “Next” tab, you will be taken to the next screen. Here you
will be able to set panel illumination modes, set whether you want to
keep the panel’s TFT always on or not and set the opening time of the
electric lock openers 1 and 2.
You also will be able to enable or disable prompt messages and set the
language in which they are reproduced.
NOTE: For more information about web client, visit its manual.

CATEGORY 1_HEADERCATEGORY 2_HEADER
8Footer Infoswww.golmar.es
IP G+ 6502/G+
- Language selection.
Select the language for the vocal messages and navigation menu. e available languages are English, Spanish, French, Dutch and
Portuguese.
7. SETTINGS
Marcar el número de vivienda
o pulsar para mostrar la agenda
1 2
Access to languages. Select the required one.
- Door panel volume adjustment
Marcar el número de vivienda
o pulsar para mostrar la agenda
Introducir contraseña
Menú de ajustes
Ajustes de la placa
1 2 3 4
Access to conguration. Type the installer PIN code
“2718” and press validation icon.
Select the second option from
settings menu (1/3).
Press the right arrow button to go to
door panel settings menu (1/2).
Ajustes de la placa (2/2)
Seleccionar el volumen del altavoz
5 6
Access to volume Adjust the volume to a level between
1-10 by using the arrows, once adjusted
select the fourth option to validate it.
- RFID cards.
Marcar el número de vivienda
o pulsar para mostrar la agenda
Introducir contraseña
Menú de ajustes
Menú de ajustes (2/3)
1 2 3 4
Access the conguration. Type the installer PIN code
2718 and press validation icon.
Press the right arrow button to
go to settings menu (2/3).
Select the second option in the
settings menu (2/3).
Tarjetas de acceso
09:27 PM
20-09-2017
5 7
Select the second option,
access cards.
Swipe the cards which you like to link to this
apartment.
A maximum of 5 cards per apartment can be
(*) It is possible to delete or transfer the cards to other panels. To proceed, select the option or in the step 5.
Seleccionar o introducir el número de vivienda
VIVIENDA 5
VIVIENDA 4
VIVIENDA 3
VIVIENDA 2
VIVIENDA 1
Tarjeta añadida
6 8
Select the apartment to which associate
the access cards, once selected press the
validate button.
Once the card has been added, a
conrmation tone will be emitted.
e screen will display “card added”.
www.golmar.es 8
NL PT
3

9
6502/G+ IP G+
www.golmar.es
8. SYSTEM OPERATION
09:27PM
20-09-2017
CALLING
UNIT
CALLING
ADDRESSBOOK
BY UNIT
NUMBER
Marcar el número de vivienda
o pulsar para mostrar la agenda SERGIO SANCHO
ALBERT ESTOPA
MARC CUADRAS
JUAN FERNANDEZ
ANTONIO GARCÍA
Pulsar para iniciar la llamada
SEARCH UNIT
NUMBER
MOVE THROUGH
ADDRESSBOOK
09:27PM
20-09-2017
ADDRESS
CODE
OPEN
DOOR
PROXIMITY
ACCESS
CODE
Marcarel número de vivienda
opulsar paramostrar la agenda
1
2
(*) e push button allows to make a direct call to the available guard units.
e call process lasts for a maximum of 45 seconds. e panel will prompt the voice message ”call is in progress” and will display that
message on screen. If aer 45 seconds the call has not been answered, it will indicate “No response, try it later”.
e communication process lasts for a maximum of 90 seconds. From the time that the monitor picks up the call, the panel will
display “In communication”. Once the communication is nished, the panel will prompt a voice message “Communication is
nished” and will display that message on screen.
001 Monitor 1
Llamada en curso
44
No responde. Pruebe más tarde.
001Monitor 1
En comunicación
001Monitor 1
Comunicación nalizada

10
6502/G+IP G+
www.golmar.es
During a door release process, the panel will display on screen “Door is open”.
Puerta abierta
We can choose which door opener enable through the openning code entering, access card presentation or in a call process between
the door panel and the monitor in the next way:
Marcar el número de vivienda
o pulsar para mostrar la agenda
Introducir contraseña
Menú de ajustes
1 2 3
Access the conguration. Type the installer PIN code
2718 and press validation icon.
Press the third option
“Openning settings menu”.
Menú de ajustes
Ajustes de apertura
Abrepuertas 1 y 2
Apertura mediante código de acceso
5 6
Access to the fourth option
“Unlock with access code”
Choose between the four available
options: Disable, Lock 1 only, Lock 2
only or Lock 1 and 2.

CATEGORY 1_HEADER CATEGORY 2_HEADER
11 Footer Infos
6502/G+ IP G+
11
9. INSTALLATION DIAGRAM
***
*Power up the D4L-G+/POE switches with the FA-G+, 18Vdc power supply unit..
** e maximum distance between the power supply and more distant device is 70m.
e maximum number of devices powered with each FA-G+ is 8 monitors or 4 entry panels.
It is required one power supply FA-G+ for every 8 devices.
Each switch can be powered locally, by connecting the terminals “+” and “-” to the power supply.
e Jumper positicion of the switch must be as follow:
It can be also powered through the riser from OUT terminal at the switch placed just before . e position of the jumper
should be as follows:
IN OUT
Power
Columna
Riser
*** e door lock to be connected could be an AC lock (AC transformer will be necessary, recommended TF-104) or a DC lock ( DC
power supply will be necessary, recommended HRF-12/1,25A).
**
*
TERMINAL BLOCK CONNECTION
TERMINAL BLOCK
6502/G+
LOCAL
POWER
COLUMN
POWER

Sist
emas de comunicación S.A.
C/ Silici 13. Poligon Industrial Famadas
08940 – Cornellà del llobregat – Spain
[e-mail]
Telf: 934 800 696
www.golmar.es
Golmar reserves the right to make any changes without prior noce.
