Pro Xpc™ Auto Controller 333266F
EN
For controlling the Graco Pro Xpc Auto Electrostatic Spray Guns. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
Important Safety Instructions
Read all warnings and instructions in this manual and in your
Pro Xpc™ Auto Electrostatic Air Spray Gun manual. Save these
instructions.
PROVEN QUALITY. LEADING TECHNOLOGY.

Contents
Models............................................................... 3
Approved System Components ........................... 3
Related Manuals ................................................ 3
arnings ........................................................... 4
Introduction........................................................ 6
Controller Features and Options.......................... 6
Installation.......................................................... 7
Interlocks..................................................... 7
Installation Options ...................................... 9
No Integration.............................................. 10
Basic Integration.......................................... 11
PLC Integration............................................ 12
Pre-Installation Steps.......................................... 13
Ventilate the Spray Booth.............................13
Install the Pro Xpc Auto Spray Gun ............... 13
Interlock aterborne Isolation
Enclosure....................................... 13
Mount the Controller ........................................... 14
Location ...................................................... 14
Mounting ..................................................... 14
Grounding ................................................... 15
Controller Connections........................................ 16
Overview..................................................... 16
Connections ................................................ 17
Discrete I/O........................................................ 19
Isolation ...................................................... 19
I/O Grounding.............................................. 19
REMOTE Input Operation............................. 19
REMOTE Output Operation.......................... 19
Signals........................................................ 20
Analog Inputs .............................................. 24
Analog Outputs............................................ 24
Digital Inputs................................................ 25
Digital Outputs............................................. 25
Discrete I/O Interface Connections................ 25
Operation Modes and Timing Diagrams ............... 26
Standby Mode ............................................. 27
SAFE POSITION Mode................................ 28
Spray.......................................................... 30
Error Handling ............................................. 32
Purge.......................................................... 34
Controller Display and Features........................... 35
Screen Areas............................................... 35
Icons........................................................... 35
Input Keys and Switches .............................. 36
Additional Features ...................................... 36
Setup................................................................. 38
Setup Screen 0 (System Type) ..................... 40
Setup Screen 1 (Electrostatics Control
Mode)............................................ 40
Setup Screen 2 (Discrete I/O Select)............. 41
Setup Screen 3 (Analog Input Type
Select)........................................... 41
Setup Screen 4 (Analog Output Type
Select)........................................... 42
Setup Screen 6............................................ 42
Setup Screen 7 (Log Level) .......................... 42
Setup Screen 8 (Averaging Interval).............. 43
Setup Screen 9 (Blanking Time).................... 43
Setup Screen 10 (Discharge Time)................ 44
Setup Screen 11 (Transition Time)................44
Operation........................................................... 45
System Start-up........................................... 45
Presets........................................................ 45
Run Screen 1 (Electrostatics
Readings) ...................................... 46
Run Screen 2 (Arc Limits)............................. 47
Run Screen 3 (Maintenance Counters)........... 48
Arc Detection............................................... 49
Screen Map........................................................ 51
Troubleshooting.................................................. 54
Error Codes................................................. 54
Gun Power Cable Continuity......................... 56
Repair................................................................ 57
Main Circuit Board or Keypad Membrane
Removal ........................................ 57
Power Board Removal ................................. 59
Software Update.......................................... 60
Parts.................................................................. 61
Dimensions........................................................ 62
Technical Data ................................................... 65
Graco Standard arranty.................................... 66
2333266F

Models
Models
Controller Description Maximum Gun Voltage Output
24Y307 Pro Xpc Auto Controller, solventborne 100 kV
24Y308 Pro Xpc Auto Controller, waterborne 60 kV
Approved System Components
Specific controllers, guns, and gun power cables must be used together. Refer to the table below for
compatible models.
Controller Gun
Models Gun Power Ca les Product Type Controller Approvals
24Y307 LC1020
LC2020 17H040 17H041
17H042
Solventborne
CUS
24Y308 LC1028
LC2028 17H040
17H041
17H042
aterborne
Related Manuals
Manual
No. Description
332992 Pro Xpc Auto Electrostatic Air Spray
Gun
333266F 3

Warnings
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific
risks. hen these symbols appear in the body of this manual or on warning labels, refer back to these
arnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout
the body of this manual where applicable.
WARNING
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work location can ignite or explode.
Paint or solvent flowing through the system can cause static sparking. To help prevent fire or
explosion:
• Electrostatic equipment must be used only by trained, qualified personnel who understand
the requirements of this manual.
• Ground all equipment, personnel, object being sprayed, and conductive objects in or close to
the spray location. Resistance must not exceed 1 megohm. See Grounding instructions.
• Do not use pail liners unless they are conductive and grounded.
• Stop operation immediately if static sparking occurs. Do not use equipment until you identify
and correct the problem.
• Check gun resistance and electrical grounding daily.
• Use and clean equipment only in a well ventilated location.
• Never spray or flush solvent at high pressure.
• Always turn the electrostatics off when flushing, cleaning, or servicing equipment.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and
plastic drop cloths (potential static arc).
• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.
• Keep spray location free of debris, including solvent, rags, and gasoline.
• Keep a working fire extinguisher in the work location.
For solvent orne systems only:
• Use cleaning solvents with highest possible flash point when flushing or cleaning equipment.
For water orne systems only:
• Do not spray or clean with flammable materials. Use water-based materials only.
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can
cause electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before
servicing or installing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes
and regulations.
4333266F

Warnings
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated
system component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data
in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete
information about your material, request the Safety Data Sheet (SDS) from distributor or
retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals
and create safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work location.
• Comply with all applicable safety regulations.
TOXIC FLUID OR FUMES
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
• Read the Safety Data Sheet (SDS) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable
guidelines.
PLASTIC PARTS CLEANING SOLVENT HAZARD
Many solvents can degrade plastic parts and cause them to fail, which could cause serious
injury or property damage.
• Use only compatible water-based solvents to clean plastic structural or pressure-containing
parts.
•See Technical Data in this and all other equipment instruction manuals. Read fluid and
solvent manufacturer’s Safety Data Sheet (SDS) and recommendations.
PERSONAL PROTECTIVE EQUIPMENT
ear appropriate protective equipment when in the work location to help prevent serious
injury, including eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective
equipment includes but is not limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent
manufacturer.
333266F 5

Introduction
Introduction
The Pro Xpc Auto Controller is designed exclusively
for controlling a Graco electrostatic spray gun as part
of a paint coating system.
The controller sends power to the gun power supply,
which increases the voltage to the level set at the
controller. The fluid is charged by the spray gun
electrode. The charged fluid is attracted to the
nearest grounded object, wrapping around and
evenly coating all surfaces.
Controller Features and
Options
• The full voltage setting is 100 kV for solventborne
guns and 60 kV for waterborne guns.
• The controller can be flush mounted at the front
plate or wall mounted. See Mounting, page 14.
The Pro Xpc Auto Controller provides the ability to:
• Display and set the voltage and current.
• Create and store spray presets.
• Operate the spray gun remotely via discrete I/O.
The controller has three interlocks. These interlocks
must be satisfied before the system will operate.
Check and follow all National, State, and Local codes
regarding properly interlocking your spray system.
Also see Ventilate the Spray Booth, page 13.
6333266F

Installation
Installation
Interlocks
Interlocks are required to ensure that the system
is safe to operate. The controller can use internal
or external signals to receive verification that the
conditions the interlocks are monitoring are in a state
that is safe for the system to operate.
Determine how the following interlocks will be used.
The following table shows how to use the Pro
Xpc Auto Controller for each interlock. The table
also explains how to bypass the interlock if the
requirement is being satisfied in another manner.
If other forms of interlock are implemented that
precludetheneedtousethecontrollerinterlocks,the
controller interlocks can be disabled.
Interlock Pin Description
System
Interlock Input power
cord, Pin 3
(wire 3)
Pin3ontheInputPowerConnectionrequireslinevoltagetobeappliedfor
electrostatics to turn on. See Step 2 in Connections, page 17.
If not required, bypass the interlock by connecting wire 3 to line voltage on the
Input Power cord. The icon is displayed on the controller screen when
the System Interlock is satisfied. See Screen Areas, page 35.
24VDC
Interlock Discrete
I/O cable,
pin 19
Pin 19 on the Discrete I/O Cable Connection requires 24VDC to be applied for
electrostatics to turn on. This pin can be used to connect to an external device,
such as a ventilation interlock signal to the controller. Input signal values are:
0 (0VDC or GND): Interlock not satisfied; electrostatics disabled
1 (24VDC): interlock satisfied; electrostatics activation is not locked by
this input.
If not required, apply a constant 24VDC to Pin 19, or see
Disable Controller Interlocks, page 8 .
Symbol A9 on the display screen (see Screen Areas, page 35) will show that
this signal is satisfied.
SAFE
POSITION
Interlock
Discrete
I/O cable,
pin 18
Pin 18 on the Discrete I/O Cable Connection requires 24VDC to be applied for
electrostatics to turn on. Apply only when the applicator is in SAFE POSITION.
See SAFE POSITION Mode, page 28. If electrostatics are on, removing 24VDC
from this pin will not turn off the electrostatics.
0 (0VDC or GND): Interlock not satisfied; If electrostatics are off,
electrostatics disabled. If electrostatics are on, no change to electrostatics.
1 (24VDC): Interlock satisfied; electrostatics activation is not locked by
this input.
If not required, apply a constant 24VDC to Pin 18, or see
Disable Controller Interlocks, page 8 .
SymbolA10onthedisplayscreen(seeScreen Areas, page 35)willshowthat
this signal is satisfied.
333266F 7

Installation
Disable Controller Interlocks
If interlock requirements have been satisfied in
your system by means other than the Pro Xpc Auto
Controller, the controller interlocks can be disabled.
1. To disable the system interlock, connect wire 3
on the controller input power cord to line voltage.
The icon will be lit on the display screen.
2. Remove power from the controller.
3. Remove 4 screws and take off the access cover.
4. Locate the interlock switches on the main board.
hen the switches are in the ON position, the
interlocks are considered satisfied.
Switch 1 is the 24VDC Interlock (pin 19 on
the Discrete I/O cable). Switch 2 is the SAFE
POSITIONInterlock(Pin18ontheDiscreteI/O
cable).
Symbols in A9 and A10 (see
Screen Areas, page 35)onthedisplay
screen will show that these signals are satisfied.
ON
GOHO2
Switches shown in OFF position.
8333266F

Installation
Installation Options
Installation details vary widely depending on the
system requirements. This section shows three
typical installations. They are not actual system
designs. For assistance in designing a system to suit
your particular needs, contact your Graco distributor.
Installing and servicing this equipment requires
access to parts which may cause fire, explosion,
electric shock or other serious injury if work is not
performed properly.
• Do not install or service this equipment unless
you are trained and qualified.
• Besureyourinstallationcomplieswithnational,
state, and local codes for the installation of
electrical apparatus in a Class I, Division 1, or a
Group II, Zone 1 Hazardous Location.
• Comply with all applicable local, state, and
national fire, electrical, and other safety
regulations.
333266F 9

Installation
No Integration
The defining characteristics of a No Integration
installation include:
• No integration of the Pro Xpc Auto Air Spray Gun
or Controller.
• Local operation using the Pro Xpc Auto Controller
interface.
• Interlocks managed independently of the spray
gun installation.
To reduce the risk of fire and explosion, the
controller (B) must be electrically interlocked with
the spray booth ventilation fans to prevent the gun
from operating without ventilation fans operating.
Non-Hazardous Location Hazardous Location
KEY:
A
Pro Xpc Auto Air Spray Gun
B
Pro Xpc Auto Controller
C Gun Power Cable
D
Fluid Supply
F ‡
Fluid Hose Ground Bracket
G ‡ Fluid Bracket Ground ire
H
‡ Fluid Supply Tube
(Graco-supplied) to gun
fluid inlet, maximum 8 ft (2.4
m) length
† Graco aterborne Fluid
Supply Hose, from fluid
regulator (L) to gun inlet
(hose must be a single,
uninterrupted length).
J ‡
Fluid Supply Hose
K
Pro Xpc Auto Controller
Ground ire
L Fluid Regulator
N † Isolation Enclosure
X
Pro Xpc Auto Controller
Power Cord
† aterborne systems only
‡ Solventborne systems only
Typical Installation ith No Integration
10 333266F

Installation
Basic Integration
The defining characteristics of a Basic Integration
installation include:
• Integration of basic gun and controller functions.
• Integration of controller interlocks.
• Local operation of setup and error functions.
This example shows a basic integration using 6, of
the available 19, signals available on the Discrete
I/O cable.
• Preset Select 1 (Pin 1) and Preset Select 2 (Pin 2):
Used to select Presets P000-P003. For example:
Select Preset P002 by applying 24V to Pin 2 and
Ground or no connection to Pin 1.
• Remote Ena le/Disa le (Pin 4): Enable remote
control by applying 24V to Pin 4.
• Electrostatic Ena le (Pin 5): Use a switched
voltage source for Pin 5 to activate/trigger the
electrostatics.
• GND (Pins 8, 12, 17): Used as ground reference
for I/O signals.
• Interlocks: See Interlocks, page 7 , for information
on how to set up the required interlocks.
To reduce the risk of fire and explosion, the
controller (B) must be electrically interlocked with
the spray booth ventilation fans to prevent the gun
from operating without ventilation fans operating.
Non-Hazardous Location Hazardous Location KEY:
A Pro Xpc Auto Air Spray Gun
B Pro Xpc Auto Controller
C Gun Power Cable
D Fluid Supply
E Discrete I/O Signals
F ‡ Fluid Hose Ground Bracket
G ‡ Fluid Bracket Ground ire
H
‡ Fluid Supply Tube
(Graco-supplied) to gun fluid
inlet, maximum 8 ft (2.4 m) length
† Graco aterborne Fluid Supply
Hose, from fluid regulator (L) to
gun inlet (hose must be a single,
uninterrupted length).
J ‡ Fluid Supply Hose
K Pro Xpc Auto Controller Ground
ire
L Fluid Regulator
M Discrete I/O Cable
N † Isolation Enclosure
X Pro Xpc Auto Controller Power Cord
Typical Installation ith Basic Integration
† aterborne systems only
‡ Solventborne systems only
333266F 11

Installation
PLC Integration
The defining characteristics of a PLC (Programmable
Logic Controller) Integration installation include:
• PLC integration of all gun and controller functions.
See Discrete I/O, page 19, for a complete description
of the signals.
To reduce the risk of fire and explosion, the
controller (B) must be electrically interlocked with
the spray booth ventilation fans to prevent the gun
from operating without ventilation fans operating.
Non-Hazardous Location Hazardous Location
KEY:
A
Pro Xpc Auto Air Spray
Gun
B
Pro Xpc Auto Controller
C Gun Power Cable
D
Fluid Supply
E Robot or Reciprocator
F ‡
FluidHoseGroundBracket
G ‡ Fluid Bracket Ground ire
H
‡ Fluid Supply Tube
(Graco-supplied) to gun
fluid inlet, maximum 8 ft
(2.4 m) length
† Graco aterborne Fluid
Supply Hose, from fluid
regulator (L) to gun inlet
(hose must be a single,
uninterrupted length).
J ‡ Fluid Supply Hose
K
Pro Xpc Auto Controller
Ground ire
L Fluid Regulator
M
Discrete I/O Cable
N † Isolation Enclosure
P
PLC
X
Pro Xpc Auto Controller
Power Cord
Typical Installation ith PLC Integration
† aterborne systems only
‡ Solventborne systems only
12 333266F

Pre-Installation Steps
Pre-Installation Steps
Ventilate the Spray Booth
Provide fresh air ventilation to avoid the buildup of
flammable or toxic vapors when spraying, flushing,
or cleaning the gun. Do not operate the gun unless
ventilation fans are operating.
Electrically interlock the controller (B) with the
ventilators to prevent gun operation without
ventilating fans operating. Use the 24 VDC Interlock
pinontheDiscreteI/Ocabletoconnecttothe
ventilator interlock. Check and follow all National,
State, and Local codes regarding air exhaust velocity
requirements.
NOTE: High velocity air exhaust will decrease the
operating efficiency of the electrostatic system. The
minimum allowable air exhaust velocity is 60 ft/minute
(19 linear meters/minute).
Install the Pro Xpc Auto Spray Gun
See the Pro Xpc Auto Air Spray Gun Manual
(332992) for installation instructions.
Interlock Waterborne Isolation
nclosure
To reduce the risk of electric shock, interlock the
controller with the voltage isolation system to shut
off the electrostatics anytime the isolation system
enclosure is opened.
For information about the interlocks and their use,
see Interlocks, page 7 .
333266F 13

Mount the Controller
Mount t e Controller
To reduce the risk of fire or explosion, do not install
equipment approved only for a non-hazardous
location in a hazardous location.
Location
Install the Pro Xpc Auto Controller in a non-hazardous
location only.
Mounting
The Pro Xpc Auto Controller can be flush mounted
at the front plate or wall mounted.
Wall Mount (Flat Panel)
An optional method of mounting the controller is to
use a panel with a cutout and mounting holes.
1. See Dimensions, page 62.
2. Determine the mounting location. Ensure that
the location will support the mounting panel and
the controller.
3. Prepare the panel by cutting out the opening and
preparing the mounting holes for the controller:
a. If the two controller front panel screws are to
be used to attach the controller to the panel,
the panel holes will require tapping threads,
or providing some other sort of threaded
fastener, such as PEM nuts on the panel.
b. If an alternative fastener will be used, it may
be necessary to back out the two threaded
fasteners from the controller front cover so
that the mounting hardware can use the
existing controller front panel mounting holes.
Wall Mount (Mounting Bracket)
An optional wall mount bracket (17H288) is available
to mount the controller on any flat wall.
1. See Dimensions, page 62.
2. Determine mounting location. Ensure that the
wall is strong enough to support the weight of the
mounting bracket and the controller.
3. Position the mounting bracket on the wall and
mark mounting holes using the plate of the
bracket as a template.
4. Drill holes and attach the mounting bracket to the
wall.
5. Attach the controller to the wall mount bracket
using two 6 mm screws (provided).
14 333266F

Mount the Controller
Grounding
hen operating the electrostatic gun, any
ungrounded objects in the spray location (people,
containers, tools, etc.) can become electrically
charged. Improper grounding can result in static
sparking, which can cause a fire, explosion, or
electric shock. Ground all equipment, personnel,
object being sprayed, and conductive objects in or
close to the spray location. Follow the grounding
instructions below.
The following are minimum grounding requirements
for a basic electrostatic system. Your system may
include other equipment or objects which must
be grounded. Check your local electrical code for
detailed grounding instructions. Your system must be
connected to a true earth ground.
• Pro Xpc Auto Controller: Ground the Pro Xpc
Auto Controller with a grounded power cord and
grounded socket. Also ground the controller with
the ground connection and ground wire.
• Pump: ground the pump by connecting a ground
wire and clamp as described in your separate
pump instruction manual.
• Fluid Bracket for solventborne systems only):
ground the fluid bracket by connecting the bracket
ground wire to a true earth ground. Mount the
fluid bracket a distance behind the gun that can be
reached by a hose with a maximum length of 8 ft
(2.4 m).
• Fluid Tube for solventborne systems only): ground
the fluid tube by connecting it to the grounded fluid
bracket.
• Fluid Hose for waterborne systems only): the hose
is grounded through the conductive layer. Install
thehoseasinstructedinthegunmanual.
• Electrostatic Air Spray Gun: ground the gun by
connecting the gun power cable to a properly
grounded controller.
• Air compressors and hydraulic power supplies:
ground the equipment according to the
manufacturer’s recommendations.
• Allelectricalcables must be properly grounded.
• All persons entering the spray location: shoes
must have conductive soles, such as leather; or
personal grounding straps must be worn. Do not
wear shoes with non-conductive soles such as
rubber or plastic.
• Object being sprayed: keep the workpiece hangers
clean and grounded at all times. Resistance must
not exceed 1 megohm.
• The floor of the spray location: must be electrically
conductive and grounded. Do not cover the floor
with cardboard or any non-conductive material
which would interrupt ground continuity.
• Flammable liquids in the spray location: must be
kept in approved, grounded containers. Do not
use plastic containers. Do not store more than the
quantity needed for one shift.
• All electrically conductive objects or devices in the
spray location: including fluid containers and wash
cans, must be properly grounded.
333266F 15

Controller Connections
Controller Connections
Overview
A Back panel D Input Power Connection
BEnclosure E
Discrete I/O Cable Connection — use
in a system that requires integration
CFront Plate with control and display
elements FGun Power Cable Connection
GGrou
nd Connection
HCAN Connection (not enabled)
16 333266F

Controller Connections
Connections
1. Connect the ground wire to the ground
connection (G). Connect the other end to a true
earth ground. This connection is required for all
installations.
2. Connect the supplied controller input power cord
to the input power connection (D) and secure with
the connector screw. This connection is required
for all installations. The controller can operate
at 100–240 VAC (50–60 Hz). Connect the leads
to a power source according to local electrical
codes. Pin 3 on the input power connection is the
system interlock. Pin 3 must have line voltage
applied to satisfy the system interlock. hen the
system interlock pin is connected to line voltage,
the icon will appear on the controller.
See Screen Areas, page 35.
Controller Input Power Connection
Pin No. Function Wire Marking
1 Neutral conductor power supply 1
2 Phase (100-240 VAC) 2
3 System Interlock ON/OFF
(100-240 VAC) = ON 3
Controller Power Cord PE Grounding PE Green/Yellow
3. Connect the 7-pin end of the gun power cable
to the gun power cable connection (F) on the
controller. Connect the 4–pin end of the gun
power cable to the spray gun. Follow instructions
in the gun manual. This connection is required
for all installations.
Pre-wired Gun Power Cable Connection
Controller Gun
Connector (F) Ca le Ca le Power Supply Connector
Electrical Schematic for this cable:
NOTE: Connector pins not shown are not connected
toawireinthecable.
333266F 17

Controller Connections
4. Connect the Discrete I/O cable to the Discrete
I/O cable connection (E) on the controller. The
Discrete I/O cable is required for any installation
that involves integration. Two discrete I/O
interlock connections are supplied and must
be satisfied. (See Interlocks, page 7 )See
Discrete I/O, page 19 for a more detailed
explanation of each pin.
Discrete I/O cable Connection
Pin No. Function Wire Color
1 Preset Select 1 hite
2 Preset Select 2 Brown
3 Error Reset Green
4 Remote Enable/Disable Yellow
5Electrostatics Enable Gray
6 Safe-to-Move Output Pink
7Error Output Blue
Controller
8 I/O Ground Red
9Current Setpoint Input Black
10 Voltage Setpoint Input Purple
11 Reserved Input Gray/Pink
12 I/O Ground Red/Blue
13 Actual Spraying Current Output hite/Green
14 Actual Spraying Voltage Output Brown/Green
15 Electrostatic Discharge hite/Yellow
16 Analog Output External Power (24 VDC) Yellow/Brown
17 I/O Ground hite/Gray
18 SAFE POSITION Interlock Input Gray/Brown
Ca le
19 24VDC Interlock Input Pink/Brown
and
Pink/ hite
See DiscreteI/O,page19for more information.
5. CAN connections (H) are not enabled.
18 333266F

Discrete I/O
Discrete I/O
Thecontrollercanacceptupto19I/Ointerface
signals. Systems can be designed to integrate from
1 signal up to all 19 signals. The examples in this
manual describe a basic integration (6 I/O signals
used) and a complex integration (all 19 I/O signals
used).
Discrete I/O input signals are only monitored
if the Pro Xpc Auto Controller has been
placed in the Discrete I/O mode. See
Setup Screen 2 (Discrete I/O Select), page 41.
See Signals, page 20 for available signals.
Isolation
The discrete I/O interface signals are isolated from
circuit ground. Isolation is required to prevent
disturbance of the measurement of the spraying
current.
NOTE: The isolation is not designed to isolate
hazardous potentials.
I/O Grounding
Pins 8, 12, and 17 are the I/O Ground pins. Connect
a ground from each connecting device to one or more
of these pins. This will match the potential of the Pro
Xpc Auto Controller and the connecting device.
R MOT Input Operation
In order to accept remote input commands from the
discrete I/O interface, the following conditions must
be met:
• The discrete I/O interface must be selected by
setting Parameter P02 = 1.
See SetupScreen2(DiscreteI/OSelect),page41.
• The REMOTE Enable input, on the Discrete I/O
cable, pin 4, must have 24VDC (logical “1”) applied
to it to select REMOTE mode.
Connect the desired input signals. During REMOTE
input operation, error confirmation is the only local
input (using the keypad) possible.
NOTE: Values for presets P001 – P003 must be set
up prior to entering REMOTE mode. Preset P000
istheonlypresetwhichcanbealteredusingthe
Discrete I/O cable signals when the controller has
been placed in REMOTE mode. Presets P004 - P250
are not accessible in REMOTE mode.
R MOT Output Operation
Connect the desired signals. Digital output signals
are generated unconditionally. Analog output signals
require 24VDC on Analog Output External Power (pin
16) on the discrete I/O Interface cable.
333266F 19

Discrete I/O
Signals
Note on Digital Inputs and Outputs: A “0 (or Low)” is used to indicate that GND or no signal is present. A “1 (or
High)” is used to indicate that a 24 VDC signal is present.
Pin Type Description
1 Digital
Input
Preset Select 1 (Pin 1) and Preset Select 2 (Pin 2)
Use to specify the Preset selection in REMOTE operation:
Pin 2 Pin 1
0 0 Preset P000
0 1 Preset P001
1 0 Preset P002
1 1 Preset P003
2 Digital
Input
In REMOTE mode, the values for Preset P000 are based on the analog signals received on
the discrete I/O interface. These values will overwrite any existing values in Preset P000.
The values for Presets P001–P003 must be entered locally, using the keypad, prior to
placing the controller in REMOTE mode. It is not possible to change the values of these
Presets remotely.
Presets P004–P250 are not accessible in REMOTE mode.
3 Digital
Input
Error Reset
Use to allow error codes to be acknowledged remotely. Acknowledging an error code does
not correct the condition that created the error.
0➔1 transition: Reset all reported errors
NOTE: Additional errors will be logged, regardless of the state of the Error reset. To
perform additional error resets, transition from 0 to 1 again.
4 Digital
Input
REMOTE Ena le/Disa le
Use to enable or disable REMOTE operation. Enabling REMOTE operation locks out
local control and allows the controller to use the discrete I/O interface. hen enabled,
the icon on the display is shown.
0: Local control
1: REMOTE control
5Digital
Input
Electrostatic Ena le
Use to enable or disable electrostatics output.
0: Turn off electrostatics.
1: Enable electrostatics. All other conditions for turning on electrostatics must be met.
20 333266F
