Graf 340037 Operating and maintenance manual

[email protected]
www.graf.info
9 / 32
Instruction for installation and maintenance
GRAF Optimax-Pro Filter internal
Optimax-Pro Filter internal DN100
Order No. 340037
Carat Filter Package 3 –
Optimax-Pro Filter internal DN100
Order No. 342005
Optimax XL Filter internal DN150
Order No. 340108
Carat XL/XXL Filter Package 3 –
Optimax XL Filter internal DN150
Order No. 342042
The points described in these
instructions must be observed under
all circumstances. All warranty rights
are invalidated in the event of non-
observance. Separate installation
instructions are enclosed in the
transportation packaging for all
additional articles purchased from
GRAF.
The components must be checked
for any damage prior to installation
under all circumstances.
Missing instructions can be
downloaded on www.graf.info or can
be requested from GRAF.
Table of contents
1.GENERAL NOTES 10
1.1Safety 10
2.INSTALLATION CONDITIONS 10
2.1Optimax-Pro Filter internal - Connection DN 100 10
2.2Optimax XL Filter internal - Connection DN 150 10
3.TECHNICAL DATA 11
3.1Optimax-Pro Filter internal (DN 100) 11
3.TECHNICAL DATA 12
3.2Optimax XL Filter internal (DN 150) 12
4.ASSEMBLY 13
4.1Optimax-Pro Filter internal (DN 100) 13
4.2Optimax XL Filter internal (DN 150) 13
5.INSTALLATION AND ASSEMBLY 14
5.1Overview 14
5.2Installation of inflow pipe and overflow siphon 15
5.3Preparation filter for installation 15
5.4Insert the filter into the tank 16

[email protected]
www.graf.info
10 / 32
1. General notes
1.1 Safety
The relevant accident prevention regulations according to BGV C22 must be observed during all work.
Particularly when walking on the tanks, a 2nd person is required to secure the tank.
The relevant regulations and standards must additionally be taken into consideration during installation,
assembly, servicing, repair, etc. Relevant notes can be found in the corresponding sections of these
instructions.
During all work on the system or parts of the system, the entire system must always be rendered
inoperable and secured to prevent unauthorised reactivation.
GRAF offers an extensive range of accessories, all of which are designed to match each other and which
can be extended to form complete systems. The use of other accessories may lead to impediments to the
system's functional capability, therefore invalidating liability for resulting damage.
2. Installation conditions
2.1 Optimax-Pro Filter internal - Connection DN 100
The Optimax-Pro Filter internal is suitable for installation in a manhole or a underground tank.
The difference of level between inflow and outflow is 165 mm.
The filter is suitable for roof areas up to 350 m².
The mesh width of the sieve insert is 0.35 mm.
2.2 Optimax XL Filter internal - Connection DN 150
The Optimax XL Filter internal is suitable for installation in a manhole or a underground tank.
The difference of level between inflow and outflow is 165 mm.
The filter is suitable for roof areas up to 750 m².
The mesh width of the sieve insert is 0.35 mm.

[email protected]
www.graf.info
11 / 32
3. Technical data
3.1 Optimax-Pro Filter internal (DN 100)

[email protected]
www.graf.info
12 / 32
165
3. Technical data
3.2 Optimax XL Filter internal (DN 150)

[email protected]
www.graf.info
13 / 32
4. Assembly
4.1 Optimax-Pro Filter internal (DN 100)
Clear transparent cover/ filter inset
Filter body including nozzle holder
Support for Opticlean (340040)
4.2 Optimax XL Filter internal (DN 150)
Clear transparent cover/ filter inset
Filter body
Support for Opticlean XL (340117)







[email protected]
www.graf.info
14 / 32
165
5. Installation and assembly
5.1 Overview

[email protected]
www.graf.info
15 / 32
5. Installation and assembly
5.2 Installation of inflow pipe and overflow siphon
Insert the overflow siphon in the lower seal till block.
Insert the inflow pipe from outside.
5.3 Preparation filter for installation
Connect the filter body with a PVC pipe DN 100150 (on site) with the inflow pot (calmed down) 
(contained in filter package 3).
Fix all junctions with screws (against shift of pipes.
* (+ / - 10 mm)
Carat volume
(liter)
Optimax-Pro Filter
internal
Connection DN 100*
Optimax XL Filter internal
Connection DN 150*
2.700 1320 mm 1275 mm
3.750 1500 mm 1455 mm
4.800 1730 mm 1685 mm
6.500 2020 mm 1975 mm
8.500 2003 mm 1958 mm
10.000 2203 mm 2158 mm
from 16.000 2463 mm 2418 mm



[email protected]
www.graf.info
16 / 32
Otto Graf GmbH – Carl-Zeiss-Str. 2-6 – DE-79331 Teningen – Tel.: [phone] – Fax: [phone]
GRAF Distribution S.A.R.L – 45, route d´Ernolsheim – FR-67120 Dachstein Gare – Tél.:[phone] – Fax: [phone]
GRAF Iberica Tecnología del Plástico S.L. – Marquès Caldes de Montbui, 114 – ES-17003 Girona – Tel.: [phone] – Fax: [phone]
GRAF UK Ltd – Target House – Thorpe Way Ind. Estate – Banbury – Oxfordshire – UK-OX16 4SP – Tel.: [phone] – Fax: + 44 1295 21333
2015-11
5. Installation and assembly
5.4 Insert the filter into the tank
Insert the filter, prepared with the inflow pot (calmed down), in the tank.
Telescope the overflow from top into the siphon and fix the filter inflow with the spannfix collar (contained
in filter package 3.
6. Accessory
Handle Plus for Optimax – Pro Filter
Order No. 330220
7. Maintenance
Depending on the dirtiness of the roof surface water the sieve has to be cleaned several times a year.
Remove the transparent cover from the filter body. The sieve and the cover is one unit. Removing and
cleaning is unproblematic.
