Grange AREZZO ARBOUR User manual

ASIDE SECTIONS 2
BSEAT BACK
PANEL
2
CSEAT 1
DROOF SECTIONS 2
EROOF FASCIA 4
FFINIAL 2
GROOF COVER
STRIP
1
TScrew 3. 5 x 30 mm 8
UScrew 3. 5 x 50 mm 8
VScrew 3. 5 x 70 mm 8
WScrew 4 x 60 mm 10
XScrew 4 x 90 mm 2
YScrew 4 x 120 mm 4
ZNails 4
AREZZO ARBOUR
ASSEMBLY
INSTRUCTIONS
CARE OF YOUR ARBOUR
The Arezzo Arbour is made of planed pressure treated and FSC certified timber and
as such is guaranteed against rot for a minimum of 15 years. However, it must be
remembered that as a natural product, timber is subject to movement and weather-
ing as it seasons. It is not uncommon for small spits to occur when drying and warp-
ing when timber is allowed to dry too rapidly. These will normally go back when
humidity rises, it is nature at work and not considered a fault.
Its colour will also change with time, a re-treatment, as required with a proprietary
wood treatment is recommended.

Tools required (NOT SUPPLIED)
Power screwdriver with Pozidrive No.2 bit. Tape measure.
3mm pilot drill Hammer.
Before you start.
Check the packs and make sure that you have all of the parts listed above. If not
contact your retailer who will be able to help you.
When you are ready to start make sure you have the right tools to hand, plenty of
space and a clean dry area for assembly.
It is advisable for two people to carry out the work.
ASSEMBLY
1. Take one of the side sections A and
one of the back sections B. Fix the
back panel to the side section using
two screws V. Make sure the top of
the panel is level with the top of the
post of the side section as Fig 1..
2. Now fix the other side section to the
back panel in the same way.
3. Turn the assembly on to the top end
of the back panel and fix the re-
maining back panel between the
posts ensuring it is firmly butted up
to the fixed panel. Again use two
screws either side as Fig 2.
4. Turn the assembly onto its back
so that the seat may be fitted.
Be sure to support the side sec-
tions during this step. Fix the
seat in place as shown in Fig 3.
5. Next take the two roof sections
D and screw together using
screws X as shown in Fig 4.
6. Raise the roof onto the seat
assembly and fix through into
the top of the posts as shown in
Fig 5.
7. There are fascia boards for the front and
rear of the arbour. The straight edge
should be fixed flush with the lower
edge of the roof sections. Fix these in
place using screws T as shown in Fig. 6
8. Fit the finials front and back as Fig 6
using screws U.
9. Finally, locate the roof cover strip H and
nail in place with the nails provided.
Fig 1
Fig 2
450m
w
w
Fig 3
Fig 5
Fig 6
T
T
X
Fig 4
Y
Y
Y
Y
