Grange RGTBR User manual

ASSEMBLY INSTRUCTIONS
ROUND GARDEN TABLE WITH BACKRESTS
PARTS LIST
HARDWARE
AREA REQUIRED FOR ASSEMBLED STRUCTURE
Base Supports [upper] x 2
Base Supports [lower] x 2
Bench Seats x 4
D
Seat Backrests [sets] x 4
E
Round Table Top x 1
F
Seat Support Strut x 8
G
Seat Support [front] x 8
H
Seat Support [back] x 8
J
Base Table Supports x 4
C
B
A
5x50 screws x32
u
A
B
D E
FH
G
J
C
5x70 screws x16
v
M8 Nut x40
w
M8 Washer x40
x
M8x120 x22
y
M8x120 x18
z
dia.
243cm
BEFORE YOU START
•Please ensure that you check all the
component parts for quantity and quality
before you commence building the product.
Report any missing parts immediately. The
manufacturer will not accept any responsibility
for damaged items once any part of the
product hasbeen fitted or altered in any way.
•Timber is a natural material and will react to
varying levels of moisture content - ie. will
swell or shrink. All of the Timber components
are pressure treated green.
However, should extra protection be required,
they should betreated using a wood
preservative treatment, following the
manufacturers instructions.
HEALTH AND SAFETY
DO ensure there is adequate working space
In order to reduce the risk of suffocation
please keep all plastic bags and small parts
away from children.
•When you are ready to start, make sure you
havethe right tools to hand, plenty of space
andaclean, dry area for assembly.
RGTBR - 71.2cm [H - table] / 44cm [H - bench] x 243cm [dia.]
ROUND GARDEN TABLE
WITH BACKRESTS
Self-Assembly required Home Delivery available
www.grangefen.co.uk
All products and related emblems featured are
trademarks of Grange Fencing Ltd.
©2018 Grange Fencing Ltd All rights reserved.
In line with the Company’s policy of
continuous product development, the right
is reserved to change and improve product
design without prior notice.
CODE: RGTBR
PLAN
table
height
71.2cm
bench height 44cm
bench width 114cm
table dia. 118cm
dia. 243cm
bench
28cm
RGTBR (A5 label & assembly) 12/1/18 11:34 Page 1

STAGE 3
Table Assembly
Use M8 Nuts and
Washers wand x
Use M8 Bolt y
F
F
D
D
Fixing Seats to Base
A
C
F
yw
x
C
Use M8 Nuts and
Washerswandx
u
z
STAGE 1
Base Assembly
STAGE 2
Seat Assembly
UseM8 Nuts and
Washers wand x
A
B
C
C
y
y
DH
G
G
J
D
H
G
H
y
z
H
J
J
E
=
=
v
v
v
RGTBR (A5 label & assembly) 12/1/18 11:34 Page 2
