Grange PORTICO PERGOLA User manual

A
B
D
C
A
B
D
C
To ensure longevity of your structure it is recommended that it is treated with a wood preservative on a yearly basis.
AFTERCARE
www.grangefen.co.uk
All products and related emblems featured are
trademarks of Grange Fencing Ltd.
©2015 Grange Fencing Ltd All rights reserved.
In line with the Company’s policy of
continuous product development, the right
is reserved to change and improve product
design without prior notice.
CODE: PKITPRTAG
PLAN
180cm
103cm
69.5cm
137cm
279.5cm
279.5cm
PKITPRTAG - 279.5cm [H] x 180cm [W] x 137cm [D]
PORTICO PERGOLA
Self-Assembly required Home Delivery available Pre-Painted available
Portico [A5 4page instructions] 19/9/17 10:01 Page 1

===
BEFORE YOU START
•Please ensure that you check all the component parts for quantity and quality before you commence building the
product. Report any missing parts immediately. The manufacturer will not accept any responsibility for damaged items
once any part of the product has been fitted or altered in any way.
•Timber is a natural material and will react to varying levels of moisture content - ie. will swell or shrink. All of the Timber
components are pressure treated green. However, should extra protection be required, they should be treated using a
wood preservative treatment, following the manufacturers instructions.
HEALTH AND SAFETY
DoNOT overstretch when working from the step ladder.
In order to reduce the risk of suffocation please keep all plastic bags and small parts away from children.
•When you are ready to start, make sure you have the right tools to hand, plenty of space and a
clean,dry area for assembly.
It is advisable for two people erect the structure.
PREPARATION
Make sure the area where the Portico is to be positioned is clear and ready for building the structure.
Thank you for choosing this garden structure from Grange. In order to gain the
most benefit from it please read the following instructions carefully.
TOOLS REQUIRED (Not Supplied)
POWER SCREWDRIVER
TAPE MEASURE
STEPLADDER
SPIRIT LEVEL
PARTS LIST
POSTS 4
SQUARE TRELLIS 2
RAFTERS 2
RAFTERS 4
HARDWARE PACK
SCREW 5 x 80 32
ASSEMBLY INSTRUCTIONS
SITE PREPARATION
Mark out the area where the
structure is to be sited using
the footprint shown right.
Excavate a hole for each post
to a depth of 30cm (see
fig.1)This will give your
structure adequate stability.
ASSEMBLY
STEP 1
Take two of the Posts (A) and
one piece of the Trellis (B)
and fix the trellis to each of
the posts using screws (x)as
shown in Fig.2.
STEP 2
Repeat for the other
two posts and trellis.
STEP 3
Determine the width
required between the two
assemblies and place one of
the rafters (C)into the top of
one of the posts. Set the
distance between the post
and the end of the rafter and
fixin place using screws (x)
as shown in Fig.3.
STEP 4
Fix theother Rafter (C)into
the post in the same
assembly in the same way -
see Fig.3.
STEP 5
Lift the two rafters and
locate into the top of the
other post and trellis
assembly. Set the rafters at
the same distance from the
end and screw in place using
screws (x).
STEP 6
Space the four Rafters (D)
across the assembly equally
and fix in place using screws
(x).
A
B
C
D
x
x
112.5cm
SITE PREPARATION
PORTICO
‘FOOTPRINT’
Measurements
indicated to
centres of posts.
69.5cm
30cm
A
B
D
C
STEP 1
Fig.2
STEP 3-4
STEP 6
Fig.3
Fig.1 A
B
x
x
x
x
A
A
A
C
D
A
B
C
C
==
x
D
C
A
