Grange MONTEBELLO User manual

ASIDE SECTIONS 2
BSEAT BACK 1
CSEAT 1
DBACK TRELLIS 1
ECURVED ROOF
BEAMS
4
FROOF STRUTS 7
GFINIAL 2
HSUPPORT
STRUTS
2
WScrew 3. 5 x 35 mm 4
XScrew 3. 5 x 50 mm 4
YScrew 3. 5 x 70 mm 12
ZScrew 4 x 60 mm 22
MONTEBELLO
ARBOUR
ASSEMBLY
INSTRUCTIONS
CARE OF YOUR ARBOUR
The Montebello Arbour is made of planed pressure treated and FSC certified timber
and as such is guaranteed against rot for a minimum of 15 years. However, it must
be remembered that as a natural product, timber is subject to movement and weath-
ering as it seasons. It is not uncommon for small spits to occur when drying and
warping when timber is allowed to dry too rapidly. These will normally go back
when humidity rises, it is nature at work and not considered a fault.
Its colour will also change with time, a re-treatment, as required with a proprietary
wood treatment is recommended.

Tools required (NOT SUPPLIED)
Power screwdriver with Pozidrive No.2 bit. Tape measure.
3mm pilot drill Hammer.
Before you start.
Check the packs and make sure that you have all of the parts listed above. If not
contact your retailer who will be able to help you.
When you are ready to start make sure you have the right tools to hand, plenty of
space and a clean dry area for assembly.
It is advisable for two people to carry out the work.
ASSEMBLY.
1First of all assemble the seat as
Fig 1. using two screws W each
side.
2Lay one of the side sections A flat
on the ground.
3Position the seat as shown in Fig 2
and fix it to the side section using
screws Z.
4Take the other side section A and
fix it to the free end of the seat
using screws Z, making sure the
seat height is the same both sides.
5You may now stand the assembly
up carefully.
w
w
Fig 1
6. The back trellis should now be fit-
ted. Use two screws Y either side to
fix to the side section posts as Fig 3.
7. Now fix the struts between the bot-
tom of the seat and the post at the
front of the seat as Fig 4.
450mm
Z
Z
Fig 2
Fig 4
Y
Fig 3
y
y
8. Take two of the curved sections
for the roof. The curves have location
slots for the roof struts as Fig 5.
9. Fix one of the roof struts at the join of the curved beams from
the outside (plain) side using the Finial to form the joint as
Fig 6 & 7.
10. Using the remaining two curved beams fix them to the other
end of the roof strut in the same way.
11. Raise this assembly and locate onto the tops of the posts of
the seat assembly. Insert the roof struts between the curved
beams in the slots provided and fix the curved beams to the
top of the post using two screws Z at each post as Fig 8..
12. Your arbour is now completed.
F
E
E
G
Z
Fig 5
Fig 6 Fig 7
Fig 8
X
