GRANULDISK Lean Wash Center X2 User manual

Art. no EN28277
Granuldisk AB retains the right to make technical changes to the products.
No responsibility is taken for any printing errors.
www.granuldisk.com Tel. [phone]
Lean
Wash
Center®
X2
User Manual
serial # X2–02–00001

Rev. 2022-04 3
Contents
EC DECLARATION OF CONFORMITY FOR MACHINERY 5
1 General description and safety 7
1.1 Notes and warnings 7
1.2 Technical data 10
1.3 SIMpel — easy access to information 13
2 Operating 17
2.1 Control panel 17
2.2 Start and operation 18
2.3 Loading washware 22
3 User settings 27
4 Daily cleaning 29
5 Error icons and troubleshooting 33
5.1 Error icons in the display 33
5.2 Troubleshooting 34
6 Notes 37

EC DECLARATION OF CONFORMITY FOR
MACHINERY
Original
Directive 2006/42/EC, Annex II 1A
Manufacturer (and where appropriate his authorised representative):
Representative: Granuldisk
Address: Jägershillsgatan 13, 213 75 Malmö
Hereby declares that
Type of machinery: Ware washing machine for com-
mercial kitchens
No. of machinery: X2 Lean Wash Center®
Complies with the requirements of Machinery Directive 2006/42/EC.
Complies with the applicable requirements of the following EC
directives:
2014/35/EU, LVD
2014/30/EU, EMC
The following harmonized standards have been applied:
EN 60335–2–58:2017
EN 60335–2–58:2005/A12:2016
EN 55014–1:2017/A11:2020
EN 55014–2:2015
EN 61000–3–2:2019
EN 61000–3–3:2013/A1:2019
EN 61000–6–2:2019
EN 61000–6–3:2007/A1:2011/AC:2012
The following other standards and specifications have been applied:
SS-EN 1717:2000
Authorized to compile the technical file:
Name: Staffan Stegmark
Address: Jägershillsgatan 13, 213 75 Malmö
Signature:
Place and date: Malmö, 11.10.2021
Signature:
Name: Mikael Samuelsson
Position: CEO
Rev. 2022-04 5

1 General description and safety
1.1 Notes and warnings
NOTE
X2 Lean Wash Center® is a universal washing solution for
commercial kitchen that is designed for washing crockery,
cutlery and glasses as well as pots, pans and containers.
This manual is your guide for the correct use of X2 Lean
Wash Center®.
Granuldisk recommends that you study the manual thor-
oughly to be sure that X2 Lean Wash Center® is installed
and used correctly and safely.
Ensure that the manual is always available during the
whole lifetime of X2 Lean Wash Center®.
Granuldisk accepts no responsibility for damage to the
equipment or other damage or injury caused by not fol-
lowing the directions in this manual.
The user must not carry out any repairs or maintenance
works on the dishwasher. Service and maintenance must
be carried out by qualified and authorised personnel.
Any assistance required on this dishwasher must be car-
ried out by authorised personnel.
Use exclusively original spare parts, otherwise the product
warranty issued and the manufacturer´s responsibility will
become void.
The machine is designed for commercial kitchens with a
temperature between minimum 5°C and maximum 35°C.
Regarding the handling and use of detergent and rinse aid
with the product, please see the chemical manufacturer’s
instructions. Use high quality products for best wash result.
Also refer to information about detergent and rinse aid in
the Service manual.
Use protective gloves and eye protection when handling
the chemicals.
User manual in original.
Rev. 2022-04 7

1 General description and safety 1.1 Notes and warnings
WARNING
The following fundamental rules must be observed when
using this appliance:
• Never touch the appliance with wet hands or feet.
• Never use the appliance with bare feet.
• Do not install the appliance in workplaces where it could get sprayed/
splashed with water.
• Do not put your bare hands into water containing detergent. Wash the
hands thoroughly under running water straightaway if by accident this
happens.
WARNING
X2 Lean Wash Center is a professional machine. It must be
used by adults and authorised personnel only. It must be
installed and repaired exclusively by a qualified technician.
The manufacturer declines all forms of responsibility for
improper use, maintenance and repairs.
X2 Lean Wash Center must not be used by children or any-
body who has restricted physical, sensorial or mental ca-
pacity or by anybody who has not been appropriately
trained or properly supervised.
WARNING
X2 Lean Wash Center is designed only and exclusively to
wash glasses, dishware and cockware soiled with residues
of human food.
Do not use it to wash objects soiled with petrol or paint. Do
not wash pieces of steel or metal, fragile objects or objects
made of material that will not withstand the washing proc-
ess. Do not use acid or alkaline corrosive chemical prod-
ucts, solvents or chlorine based detergent.
WARNING
The machine uses hot water. Risk of scalding.
Do not open the hood when machine is running. The dish-
washer is equipped with a safety device that will immedi-
ately stop the machine to avoid leakage of water if the
hood is opened accidentally.
8 Rev. 2022-04

1.1 Notes and warnings 1 General description and safety
WARNING
Do not place any items on top of the hood.
Do not stand on the machine, it is not designed to hold the
weight of people.
ELECTRICAL
Do not use water to extinguish fire on electrical parts.
NOTE
When cleaning the machine, please follow carefully the in-
structions in chapter 4 Daily cleaning.
Rev. 2022-04 9

1 General description and safety 1.2 Technical data
1.2 Technical data
General
Design Compact and versatile cook-
ware and dishware washing
equipment
Stainless steel cookware washing
basket - Polypropylene dishware
washing basket - Polypropy-
lene glassware washing basket
External dimensions H x W x D (open and table height
860 mm)
1950 mm x 655 mm (+ handle 100
mm) x 745 mm (+ handle 95 mm)
(Standard delivery)
1950 mm x 655 mm (+ handle 100
mm) x 785 mm (+ handle 95 mm)
(with option automatic hood lift)
2125 mm x 655 mm (+ handle 100
mm) x 785 mm (+ handle 95 mm)
(with option EcoExchanger)
Weight (empty / filled) 138 / 178 kg (Manual hood lift
version)
150 / 190 kg (with option automatic
hood lift version)
160 / 200 kg (with option EcoEx-
changer version)
168 / 208 kg (with option automatic
hood lift and EcoExchanger
version)
Tank volume 30 litres
Clearance 430 mm
Rinse water volume 2,0 litres
Wash water temperature*** 60 °C
Rinse water temperature*** 85 °C
Sound pressure level < 64 dB(A) ISO 11203
PROGRAMS & CAPACITY
Cookware washing mode 6 min. (carbonized cookware)
3 min. (cookware)
10 Rev. 2022-04

1.2 Technical data 1 General description and safety
Dishware washing mode 2 min. (plates, cutlery, utensils)
1 min. (glasses)
EcoExchanger (option) Extends washing cycle by 30
seconds.
Capacity per program (cookware
washing mode)
2 GN 1/1 Depth 65 mm — 4 GN 1/2
Depth 65 mm – 1 Pot up to Ø 450 x
H 380 mm or sub sized – 1 GN 1/1
Depth 200 mm or sub-sized -
Capacity per program (dishware
washing mode)
18 Dinner plates or 12 Soup plates Ø
240 mm - 25 Glasses/mugs Ø 90
mm
Start-up time (filling and heating) 9 min. at 55 °C inlet water
temperature
Water exchange time 5 min. at 55 °C inlet water
temperature
ELECTRICAL CONNECTION
Voltage** 380 / 400 / 415 V / 3N~ / 50 Hz
230 V / 3N~ / 50 Hz
Fuse 16 A (400 V)
32 A (230 V)
Frequency 50 Hz
Maximum output 10 kW
Pot washing pump 1,5 kW
Dish washing pump 1,1 kW
Rinse pump 0,18 kW
Heater wash tank* 8 kW
Heater rinse tank* 8 kW
Enclosure rating IPX5****
WATER CONNECTION
Hardness/Connection Total hardness: < 4 °dH (7 °fH, 70
PPM)
Inlet hose with ¾” female
2 - 5 bar
VENTILATION & DRAIN
Ventilation requirements 600 m³/h
Rev. 2022-04 11

1 General description and safety 1.2 Technical data
Ventilation requirements with
EcoExchanger 450 m³/h
Heat emitted to room (total/sensi-
ble/latent)
5,8 kW / 2,1 kW / 3,6 kW
Heat emitted to room with EcoEx-
changer (total/sensible/latent) 4,9 kW / 2,1 kW / 2,8 kW
Drainage Drain hose Ø 28 mm - 1,5 m
Drain capacity requirement 50 l / min.
Drain water temperature 65 °C
Maximum lift height drain pump 800 mm
Drain pump 40 W
DETERGENT & RINSE AID
Liquid detergent and rinse aid dosing dispenser with peristaltic pumps
are integrated into X2 Lean Wash Center®
Prepared for dosing installation.
NOTE
X2 Lean Wash Center® must be installed according to na-
tional regulations. X2 Lean Wash Center® is supplied with a
2 metres long electric cable to be connected to an ap-
proved supply disconnecting device on the wall. The supply
disconnecting device is not included in the delivery.
* Not in use simultaneously
** For specific data regarding delivered units, please see rating plate
*** Factory settings. The settings can be changed according to the local
standards.
**** Do not clean the machine with high-pressure water.
12 Rev. 2022-04

1.3 SIMpel — easy access to
information 1 General description and safety
1.3 SIMpel — easy access to information
To make it easier for the operator to find information and how to use the
unit there is a QR-code on X2 Lean Wash Center®.
The sticker is placed in the lower right corner of the hood.
Fig. 1 QR-code on the sticker
11 Scan the QR code on the
sticker.
See Fig. 1 QR-code on the
sticker
Rev. 2022-04 13

1 General description and safety 1.3 SIMpel — easy access to
information
Fig. 2 Menu
22 When you scan the QR code,
you enter the following menu.
(Note that the interface may
vary depending on the de-
vice used).
See Fig. 2 Menu
33 Select the language in the upper right corner. English is default.
Explanation of the different boxes:
1. CALL OUT REQUEST Make a service call on the machine
2. VIDEO AND
DOCUMENTATION User manuals and videos of accessories/
daily cleaning
3. TECHNICIAN AREA Only for technicians/service partners
4. CODES AND
INFORMATION List of error codes
14 Rev. 2022-04

1.3 SIMpel — easy access to
information 1 General description and safety
5. ABOUT GRANULDISK Link to Granuldisk.com
6. CONTACT INFORMATION Contact information to service partner
Rev. 2022-04 15

2 Operating
2.1 Control panel
1. ON/OFF
2. MENU — to enter the User settings.
3. Arrow UP — to toggle up in the display.
4. Arrow DOWN — to toggle down in the display.
5. CONFIRM
6. If automatic hood: deactivate the hood by pressing the red button on
the right side of the panel.
When deactivated the hood can be used manually.
Rev. 2022-04 17

2 Operating 2.2 Start and operation
2.2 Start and operation
11 Switch on the main electrical switch.
The display lights up and goes in OFF-mode.
If automatic hood: the hood goes down to calibrate.
Fig. 3 Filling with water
22 Press and hold the ON/OFF
button in the upper left corner.
The display lights up and X2
Lean Wash Center® starts to
fill with water and heat up to
the correct temperatures in
the wash and rinse tank.
If automatic hood: the hood
goes up and will remain open
during the filling and heating
phase.
The filling and heating time is
approx. 9 min at 55 °C water
inlet temperature.
The CONFIRM button is yellow
during the filling and heating
phase.
See Fig. 3 Filling with water
Fig. 4 X2 is ready to use
33 X2 Lean Wash Center® is
ready to operate when the
CONFIRM button has turned
green.
See Fig. 4 X2 is ready to use
18 Rev. 2022-04

2.2 Start and operation 2 Operating
Fig. 5 Glassware/Cookware
Fig. 6 Dishware/Burnt cookware
44 Choose wash program with
the buttons UP and DOWN.
X2 Lean Wash Center® has 2
wash modes. Which one is
activated depends on which
basket is loaded.
1.
• Glassware — 1 min
• Cookware — 3 min
2.
• Dishware — 2 min
• Burnt cookware — 6 min
See Fig. 5 Glassware/Cook-
ware and Fig. 6 Dishware/
Burnt cookware
NOTE
30 seconds will
be added to
each cycle if X2
Lean Wash Cen-
ter® has the op-
tion
EcoExchanger.
Fig. 7 Foot mechanism
55 Start X2 Lean Wash Center®
by:
•Automatic hood: By using
the foot mechanism or
pressing the CONFIRM
button.
See Fig. 7 Foot mechanism
•Manual hood: the operator
has to lower the hood
manually.
Rev. 2022-04 19

2 Operating 2.2 Start and operation
Fig. 8 Countdown
66 When X2 Lean Wash Center®
is running the display will
show a countdown of the
wash cycle and the CONFIRM
button turns blue.
See Fig. 8 Countdown
Fig. 9 Thermostop
77 If the rinse temperature is not
achieved the wash phase
continues until the correct
temperature is reached (85°).
See Fig. 9 Thermostop
88 The program is ready when the CONFIRM button turns green.
•Automatic hood— the hood goes up automatically.
•Manual hood— lift up the hood manually.
Fig. 10 Choose Water change
99 If water change is needed,
press and hold the ON/OFF
button and choose by arrow
down “Water change”
See Fig. 10 Choose Water
change
Confirm by pressing the
CONFIRM button.
Draining, filling and heating
the tank again takes about 5
min.
20 Rev. 2022-04
