GRANULDISK GRANULE SMART User manual

GRANULE
SMART ®
USER MANUAL.
Art.no EN16350201502
GRANULDISK AB retains the right to make te hni al hanges to the produ ts.
No responsibility is taken for any printing errors.
www.granuldisk. om Tel. [phone]

Contents
CE Declaration of Conformity 5
1 General Description and Safety 7
1.1 To t e user 7
1.2 Safety regulations 7
1.3 Tec nical data 8
2 Operating 11
3 Daily cleaning 25
3.1 Collecting and cleaning of PowerGranules 25
3.2 Cleaning inside t e tank 26
3.3 Replacement of cleaned items 30
3.4 Over nig t and at longer stoppages 30
3.5 GD Memo® 30
4 HACCP Hygiene and Operation
Documentation 33
5 Troubles ooting and alarms 35
6 Notes 39
3

CE Declaration of Conformity
The Manufa turer:
GRANULDISK AB
Jägershillgatan 15
SE-213 75 MALMÖ, Sweden
de lares that the following ma hinery:
The GRANULDISK system Granule Smart®.
The Granule Smart®is a Granule pot washing ma hine – a pot washing ma hine for ommer ial
kit hens that is designed for washing su h wares as pots and pans.
Basi on eption
a. the equipment, to whi h the CE Mark has been affixed, omplies with the Ma hinery
Dire tive, 2006/42/EU.
b. is besides the provisions under a) manufa tured a ording to the following dire tives: the
EC Low Voltage Dire tive 2014/35/EU and the EMC Directive 2014/30/EU.
c. is manufa tured in onformity with the following harmonised standards: EN 60204-1:2006,
EN 55014-1, EN 60335-2-58, EN 60439-1, EN 55022, EN ISO 13850:2008, EN ISO
13857:2008, EN 61000-6-3 and EN 61000-6-2
d. is manufa tured in a ordan e with EN 1717 and fitted with a type AB ba k flow prote tion
devi e with airgap in a ordan e with EN 13077:2008.
Malmö, Sweden 11.02.2012
Signed on behalf of
GRANULDISK AB
GRANULDISK AB
Jägershillgatan 13
213 75 MALMÖ
Phone: [phone]
Fax: [phone]
Peter S hön
President
Rev. 2015-02 5

CE De laration of Conformity

1 General Description and Safety
1.1 To t e user
Granule Smart®is a Granule pot washing ma hine – a pot washing ma hine for ommer ial
kit hens that is designed for washing pots and pans.
This manual is your guide for the orre t use of the Granule Smart®pot washing ma hine.
GRANULDISK re ommends that you study the manual thoroughly to be sure that the ma hine is
installed and used orre tly and safely.
Ensure that the manual is always available during the whole life of the ma hine.
GRANULDISK a epts no responsibility for damage to the equipment or other damage or injury
aused by not following the dire tions in this manual.
1.2 Safety regulations
The ma hine uses hot water. Avoid onta t with the skin as there is a risk for s alding!
Do not open the door during a wash y le! Risk of burn.
The plasti in the Granules is approved for use in onjun tion with food.
There is a risk of slipping if Granules are left on the floor.
Formaldehyde, whi h is dangerous if inhaled, may be formed if the Granules at h fire.
Regarding the handling of detergent in the manual, please see the manufa turer’s instru tions.
It is not allowed to sit or stand on the door.
Rev. 2015-02 7

1.3 Te hni al data 1 General Des ription and Safety
1.3 Tec nical data
Weight ................................. 381 kg (filled ma hine), 257 kg (empty ma hine)
External dimensions ................. 2034 (± 25) x 1024 x 1315 mm (H x W x D) open
Tank volume .......................... 108 litres
Granule amount ...................... 8 litres
Wash water temperature ............. 60–65 °C
Rinse water temperature ............ 85 °C
Wash programs w Granules ......... E o 2 min
Short 3 min (70 se longer with steam redu tion)
Normal 5 min (70 se longer with steam redu tion)
Wash programs w/o Granules ....... E o 2 min
Short 2 min 30 se
Normal 4 min 30 s
Rinse water volume .................. E o programme: 4 litres (A ording to DIN10512)
Short/Normal programme: 6 litres
To a hieve 3600 HUE a ording to NSF/ANSI 3 hygiene
guidelines, 6 litres is ne essary.
Loading volume ....................... 220 litres (Ø 700 mm x H 570 mm)
Design ................................. Round rotating stainless steel basket
Capa ity ............................... 6 GN 1/1, 65 mm deep or 3 GN 1/1 200 mm and 3 GN
65 mm, or equivalent in other utensils
Possible to load pots up to size Ø 500x400 mm
Voltage** .............................. 3~ 400 V/50 Hz or 60 Hz + PE
3~ 230 V/50 Hz + PE
3~ 380 V/50 Hz or 60 Hz + PE
3~ 415 V/50 Hz + PE
3~ 440 V/60 Hz + PE
Fuse** ................................. 400 V: 25 A hot water onne tion, 32 A old water
onne tion
230 V: 40 A hot water onne tion
380 V: 25 A hot water onne tion, 32 A old water
onne tion
415 V: 25 A hot water onne tion, 32 A old water
onne tion
440 V: 25 A hot water onne tion
Frequen y ............................. 50 Hz or 60 Hz
Maximum power ...................... 11,5 kW hot water onne tion
16,5 kW old water onne tion
Wash pump motor .................... 2,2 kW
Rinse pump motor .................... 0,11 kW
Wash tank element* .................. 9 kW hot water onne tion
14 kW old water onne tion
Rinse tank element* .................. 9 kW hot water onne tion
14 kW old water onne tion
En apsulation lass .................. IPX5
8 Rev. 2015-02

1 General Des ription and Safety 1.3 Te hni al data
Sound pressure level ................ < 70 dB(A)
Water onne tion ..................... ½” (DN15), 55-65 °C hot water onne tion and/or old
water onne tion, 3-10 °dH (5–18 °fH, 54–179 ppm)
NB! Reverse osmosis water and totally softened water
must not be used.
Water pressure/flow .................. 1-6 bar, 15 l/ min hot or old water
3–6 bar, 15 l/min, old water for steam redu tion (option)
Re ommended ventilation apa ity . 500 m³/h (without steam redu tion)
150 m³/h (with steam redu tion)
Outflow ................................ Pipe Ø 32 mm
Drain ................................... Required apa ity 50 l/min. The ma hine should not be
pla ed dire tly above the drain.
* Not in use simultaneously
** For spe ifi data regarding delivered ma hines, please see ma hine rating plate
NOTE
The Granule Smart®is supplied with a 2 metres long electric cable to be
connected to an approved supply disconnecting device on the wall. The supply
disconnecting device is not included in the delivery.
Rev. 2015-02 9

1.3 Te hni al data 1 General Des ription and Safety

2 Operating
Start up
1. Empty the Granule Colle tor with
PowerGranules into the left part of the wash
tank. Basket wheel and tank grid need to
be taken out (Figure 1 Granule filling).
Figure 1: Granule filling
2. Pla e the tank grid in position (Figure 2
Tank grid).
Figure 2: Tank grid
Rev. 2015-02 11

2 Operating
3. Put the basket wheel in pla e (Figure 3
Basket wheel).
Figure : Basket wheel
4. Close the drain valve on the right hand side
of the ma hine (Figure 4 Drain valve).
5. Swit h on the main ele tri al swit h.
Figure 4: Drain valve
12 Rev. 2015-02

2 Operating
Filling wit water
1. Close the door.
2. Press the Confirm (1) button in order to fill
the wash tank.
Fill wash tank?
3. The ma hine will now fill with water and
heat up to the orre t temperature. On the
panel, the diodes for programme sele tion
(3-5) flash out of sequen e with the diodes
for washing with or without Granules (6-7)
during filling. The following message is
displayed:
XX°C XX°C
Filling the wash
tank
4. Filling and heating take about 20 minutes
(standard; hot water onne tion, +55 °C).
For optional old water onne tion (+10 to
12 °C), filling and heating take about 40
minutes. If the orre t temperature has not
been attained in the wash tank after filling,
the following message is displayed;
50°C 60°C
Heating the
wash tank, 65 C
Figure 5: Control panel
Rev. 2015-02 13

2 Operating
5. Ready to use when the orre t temperature
has been attained in the wash tank. A
presele ted programme is now displayed;
65°C 85°C
Eco program
with Granules
wash time: 2:00
NOTE
Indication lamps
RED LAMP; indicates that
the machine is working.
Do not open the door!
GREEN LAMP; indicates
that the machine is ready
for use.
Figure 6: Indication lamps
Preparing utensils
1. Empty and s rape off all food remains
before loading the utensils (see Figure 7
S rape off food).
• No soaking or s rubbing is needed.
• No usage of hand-soap or similar (to
avoid foaming whi h ould lead to
extended problem)
2. Pots and pans ontaining moist protein-ri h
food remains may need a splash of water
before being loaded into the ma hine.
Figure 7: Scrape off food
Loading utensils
All utensils must be loaded with the inside fa ing the spray pipes, thus outwards. It is important that
all items are firmly in pla e when being washed.
14 Rev. 2015-02

2 Operating
Loading t e basket
Take the basket half way out of the ma hine (the
basket standing partly on the door.)
When the basket is loaded with pots and pans,
slide the wash basket into the ma hine. The
basket is designed so that you learly feel when
the basket is pla ed orre tly on the basket
wheel.
Che k that nothing is sti king out from the
basket’s sides or bottom. The basket rotation
must not be hindered.
See Figure 8 Loading and unloading.Figure 8: Loading and unloading
Basket lift
Through the built in basket lift, the basket an
smoothly be taken out onto the door (integrated
table) for loading and unloading.
Figure 9: Basket lift
Standard was basket (19999)
Capa ity: 6 GN 1/1 65 mm or 3 GN 1/1 up to 200
mm + 3 GN 1/1 up to 65 mm. Equipped with small
hooks whi h enables up to 12 small ontainers
(1/4, 1/6, 1/9) to be loaded dire tly into the wash
basket. See Figure 10 Standard wash basket.
Figure 10: Standard wash basket
Rev. 2015-02 15

2 Operating
Possible to load 6 x GN 1/3.
Possible to load 12 x small GN ontainers.
Choose among GN 1/4, GN 1/6, GN 1/9. See
Figure 11 Standard wash basket.
Figure 11: Standard wash basket
Insert for trays (19992)
To be pla ed inside standard wash basket
(19999). Holds 2 GN 2/1 or, 6 baking trays
600x400 mm up to 20 mm edge and 2 GN 1/1
sized trays, up to 16 grids, up to 8 hopping
boards and GN 1/1 lids.Figure 12 Insert for trays
with GN 2/1.
Figure 12: Insert for trays with GN 2/1
Possible to load grids, hopping boards, baking
trays, flat trays and GN 1/1 lids. See Figure 13
Insert for trays.
Figure 1 : Insert for trays
16 Rev. 2015-02

2 Operating
Holder for bowls & pots wit integrated ladle
older (13756)
To be pla ed inside standard wash basket
(19999). Capa ity: up to 5-6 bowls or pots.
Containers from approx 60 mm to 170 mm deep
an be washed.
Possible to load ladles, whisks, spatulas and
similar in the net basket in the middle of the
holder. Height of ladles up to 500 mm.
This a essory is pla ed in the standard wash
basket, small pegs in the bottom of the basket
hold it in pla e. See Figure 14 Holder for pots
and bowls.
Figure 14: Holder for pots and bowls
Flexible pot older (13789)
Rubber strap with two hooks. Rubber strap to be
pla ed around pot and hooked on to the basket.
Be areful when fastening and releasing the
rubber bands as the hooks may ause harm.
See Figure 15 Flexible pot holder.
Figure 15: Flexible pot holder
Rev. 2015-02 17

2 Operating
Multiflex older for saucepans, small bowls,
sieves (20554)
To be pla ed inside standard wash basket
(19999). Capa ity: up to 3-4 sau epans or up to
4-5 small bowls, sieves et . Figure 16 Multiflex
holder.
Figure 16: Multiflex holder
Pot basket (21423)
Holds 2 large pots (200 mm) or 1 large pot (400
mm) Pla ed in ma hine instead of Standard
wash basket. See.
Figure 17: Pot basket
When pla ing one large pot in the Pot basket,
use one or two Flexible pot holders to fixate the
pot.
Hook the rubber band as shown in the pi ture
(Figure 18 Pot basket). Wrap it around the pot
and hook on to the bar on the other side.
Figure 18: Pot basket
18 Rev. 2015-02

2 Operating
Control Panel
1. Confirm button is used to answer “yes” to a
question shown in the display window
2. The Stop button is used to reset potential
alarms.
It is also used to enter sleep mode. After 30
se onds the display light goes out and the
ma hine goes into sleep mode. The Stop
button’s red diode stays lit during sleep
mode, but all fun tions in the ma hine are
dea tivated.
Push any button to rea tivate the ma hine.
In sleep mode t ere is no eating of t e
was tank or rinse tank.
3. Start E o programme
4. Start Short programme
5. Start Normal programme
6. Washing with Granules
7. Washing without Granules
Rev. 2015-02 19

2 Operating
Start and Operation
1. Press the Confirm button (1)
• If temperature is lower than 65 °C in wash tank at the time of the first start, on e the wash
tank has been filled, the ma hine will ontinue heating.
• Washing at a too low temperature in reases the risk of foaming and the items not being
hygieni ally lean.
• Reprogramming may be arried out by authorised personnel only.
62°C (blinking) 59°C
Heating the
wash tank, 65°C
2. Sele t washing with or without Granules (6) or (7). For slightly soiled pans or spe ifi items
with Granule “traps” (i.e perforated ontainers), hoose programme without Granules. Normal
to heailyy soiled pots and pans, hoose the right powerful Granule y les to blast the utensils
lean.
3. Sele t required wash time (3), (4) or (5)
E o
2 min (with Granules),
2 min (without Granules)
Short
3 min (with Granules),
2 min, 30 s (without Granules)
Normal
5 min (with Granules),
4 min, 30 s (without Granules)
65°C 85°C
Eco program
with Granules
Time remaining: 1:40
20 Rev. 2015-02
