GRANULDISK Lean Wash Center X2 User manual

Art. no EN28277
Granuldisk AB retains the right to make technical changes to the products.
No responsibility is taken for any printing errors.
www.granuldisk.com Tel. [phone]
Lean
Wash
Center®
X2
User Manual

Rev. 2021-10 3
Contents
EC DECLARATION OF CONFORMITY FOR MACHINERY 5
1 General Description and Safety 7
1.1 To the user 7
1.2 Safety regulations 8
1.3 Technical data 9
1.4 SIMpel — easy access to information 12
2 Operating 15
2.1 Control panel 15
2.2 Start and operation 16
2.3 Loading washware 20
3 User settings 23
4 Daily cleaning 25
5 Error icons and troubleshooting 29
5.1 Error icons in the display 29
5.2 Troubleshooting 30
6 Notes 31

EC DECLARATION OF CONFORMITY FOR
MACHINERY
Original
Directive 2006/42/EC, Annex II 1A
Manufacturer (and where appropriate his authorised representative):
Representative: Granuldisk
Address: Jägershillsgatan 13, 213 75 Malmö
Hereby declares that
Type of machinery: Ware washing machine for com-
mercial kitchens
No. of machinery: X2 Lean Wash Center®
Complies with the requirements of Machinery Directive 2006/42/EC.
Complies with the applicable requirements of the following EC
directives:
2014/35/EU, LVD
2014/30/EU, EMC
The following harmonized standards have been applied:
EN 60335–2–58:2017
EN 60335–2–58:2005/A12:2016
EN 55014–1:2017/A11:2020
EN 55014–2:2015
EN 61000–3–2:2019
EN 61000–3–3:2013/A1:2019
EN 61000–6–2:2019
EN 61000–6–3:2007/A1:2011/AC:2012
The following other standards and specifications have been applied:
SS-EN 1717:2000
Authorized to compile the technical file:
Name: Staffan Stegmark
Address: Jägershillsgatan 13, 213 75 Malmö
Signature:
Place and date: Malmö, 11.10.2021
Signature:
Name: Mikael Samuelsson
Position: CEO
Rev. 2021-10 5

1 General Description and Safety
1.1 To the user
X2 Lean Wash Center® is a universal washing solution for commercial
kitchen that is designed for washing crockery, cutlery and glasses as well
as pots, pans and containers.
This manual is your guide for the correct use of the X2 Lean Wash
Center®
Granuldisk recommends that you study the manual thoroughly to be
sure that the X2 Lean Wash Center® is installed and used correctly and
safely.
Ensure that the manual is always available during the whole lifetime of
the X2 Lean Wash Center®.
Granuldisk accepts no responsibility for damage to the equipment or
other damage or injury caused by not following the directions in this
manual.
User manual in original.
Rev. 2021-10 7

1 General Description and Safety 1.2 Safety regulations
1.2 Safety regulations
NOTE
Read the safety notes and operating instructions in this
manual carefully. Keep the operating instructions for future
reference. Granuldisk does not assume liability or warranty
in case of non-adherence to these safety and operating
instructions.
Do not make changes, additions or reconstructions in the
ware washer without the approval of the manufacturer.
Use the ware washer only after you have read and under-
stood the user manual. Allow Granuldisk to provide infor-
mation about the operation and functioning of the ware
washer.
Always operate the machine as described in these operat-
ing instructions. Train the operating personnel about han-
dling of the machine and inform them about the safety
notes. Repeat the training sessions at regular intervals to
prevent accidents.
WARNING
The machine uses hot water. Risk of scalding.
Do not open the hood when machine is running. Risk of
scalding.
WARNING
Do not place any items on top of the hood.
NOTE
Regarding the handling and use of detergent and rinse aid
with the product, please see the chemical manufacturer’s
instructions. Use high quality products for best wash result.
Also refer to information about detergent and rinse aid in
the Service manual.
Use protective gloves and eye protection when handling
the chemicals.
8 Rev. 2021-10

1.3 Technical data 1 General Description and Safety
1.3 Technical data
General
Design Compact and versatile cook-
ware and dishware washing
equipment
Stainless steel cookware washing
basket - Polypropylene dishware
washing basket - Polypropy-
lene glassware washing basket
External dimensions H x W x D (open and table height
860 mm)
1950 mm x 655 mm (+ handle 100
mm) x 745 mm (+ handle 95 mm)
(Standard delivery)
1950 mm x 655 mm (+ handle 100
mm) x 785 mm (+ handle 95 mm)
(with option automatic hood lift)
2125 mm x 655 mm (+ handle 100
mm) x 785 mm (+ handle 95 mm)
(with option EcoExchanger)
Weight (empty / filled) 138 / 178 kg (Standard delivery)
150 / 190 kg (with option automatic
hood lift)
160 / 200 kg (with option
EcoExchanger)
168 / 208 kg (with option automatic
hood lift and EcoExchanger)
Tank volume 30 litres
Clearance 430 mm
Rinse water volume 2,6 litres
Wash water temperature*** 60 °C
Rinse water temperature*** 85 °C
Sound pressure level < 64 dB(A) ISO 11203
PROGRAMS & CAPACITY
Cookware washing mode 6 min. (carbonized cookware)
3 min. (cookware)
Rev. 2021-10 9

1 General Description and Safety 1.3 Technical data
Dishware washing mode 2 min. (plates, cutlery, utensils)
1 min. (glasses)
EcoExchanger (option) Extends washing cycle by 30
seconds.
Capacity per program (cookware
washing mode)
1 Pot up to Ø 450 x H 380 mm or sub
sized - 1 GN 1/1 Depth 200 mm or
sub-sized - 2 GN 1/1 Depth 65 mm
Capacity per program (dishware
washing mode)
18 Dinner plates or 12 Soup plates Ø
240 mm - 25 Glasses/mugs Ø 90
mm
Start-up time (filling and heating) 9 min. at 55 °C inlet water
temperature
Water exchange time 5 min. at 55 °C inlet water
temperature
ELECTRICAL CONNECTION
Voltage** 380 / 400 / 415 V / 3N~ / 50 Hz
230 V / 3N~ / 50 Hz
Fuse 16 A (400 V)
32 A (230 V)
Frequency 50 Hz
Maximum output 10 kW
Pot washing pump 1,5 kW
Dish washing pump 1,1 kW
Rinse pump 0,18 kW
Heater wash tank* 8 kW
Heater rinse tank* 8 kW
Enclosure rating IPX5
WATER CONNECTION
Hardness/Connection Total hardness: < 4 °dH (7 °fH, 70
PPM)
Inlet hose with ¾” female
2 - 5 bar
VENTILATION & DRAIN
Heat emitted to room (total/sensi-
ble/latent)
5,8 kW / 2,1 kW / 3,6 kW
10 Rev. 2021-10

1.3 Technical data 1 General Description and Safety
Heat emitted to room with EcoEx-
changer (total/sensible/latent) 4,9 kW / 2,1 kW / 2,8 kW
Drainage Drain hose Ø 28 mm - 1,5 m
Drain capacity requirement 50 l / min.
Drain water temperature 65 °C
Maximum lift height drain pump 800 mm
Drain pump 40 W
DETERGENT & RINSE AID
Liquid detergent and rinse aid dos-
ing dispenser with peristaltic
pumps are integrated into the X2
Lean Wash Center®
* Not in use simultaneously
** For specific data regarding delivered units, please see rating plate
*** Factory settings. The settings can be changed according to the local
standards.
NOTE
The X2 Lean Wash Center® must be installed according to
national regulations. X2 Lean Wash Center® is supplied with
a 2 metres long electric cable to be connected to an ap-
proved supply disconnecting device on the wall. The supply
disconnecting device is not included in the delivery.
Rev. 2021-10 11

1 General Description and Safety 1.4 SIMpel — easy access to
information
1.4 SIMpel — easy access to information
To make it easier for the operator to find information and how to use the
unit there is a QR-code on the X2 Lean Wash Center®.
The sticker is placed in the lower right corner of the hood.
Fig. 1 QR-code on the sticker
11 Scan the QR code on the
sticker.
See Fig. 1 QR-code on the
sticker
12 Rev. 2021-10

1.4 SIMpel — easy access to
information 1 General Description and Safety
Fig. 2 Menu
22 When you scan the QR code,
you enter the following menu.
(Note that the interface may
vary depending on the de-
vice used).
See Fig. 2 Menu
33 Select the language in the upper right corner. English is default.
Explanation of the different boxes:
1. CALL OUT REQUEST Make a service call on the machine
2. VIDEO AND
DOCUMENTATION User manuals and videos of accessories/
daily cleaning
3. TECHNICIAN AREA Only for technicians/service partners
4. CODES AND
INFORMATION List of error codes
Rev. 2021-10 13

1 General Description and Safety 1.4 SIMpel — easy access to
information
5. ABOUT GRANULDISK Link to Granuldisk website
6. CONTACT INFORMATION Contact information to service partner
14 Rev. 2021-10

2 Operating
2.1 Control panel
1. ON/OFF
2. MENU — to enter the User settings
3. Arrow UP — to toggle up in the display
4. Arrow DOWN — to toggle down in the display
5. CONFIRM
Rev. 2021-10 15

2 Operating 2.2 Start and operation
2.2 Start and operation
11 Switch on the main electrical switch.
The display lights up and goes in OFF-mode.
If automatic hood: the hood goes down to calibrate.
Fig. 3 Filling with water
22 Press and hold the ON/OFF
button in the upper left corner.
The display lights up and the
X2 Lean Wash Center® starts
to fill with water and heat up
to the correct temperatures
in the wash and rinse tank.
If automatic hood: the hood
goes up and will remain open
during the filling and heating
phase.
The filling and heating time is
approx. 9 min at 55 °C water
inlet temperature.
The CONFIRM button is yellow
during the filling and heating
phase.
See Fig. 3 Filling with water
Fig. 4 The X2 is ready to use
33 The X2 Lean Wash Center® is
ready to operate when the
CONFIRM button has turned
green.
See Fig. 4 The X2 is ready to
use
16 Rev. 2021-10

2.2 Start and operation 2 Operating
Fig. 5 Glassware/Cookware
Fig. 6 Dishware/Burnt cookware
44 Choose wash program with
the buttons UP and DOWN.
X2 Lean Wash Center® has 2
wash modes. Which one is
activated depends on which
basket is loaded.
1.
• Glassware — 1 min
• Cookware — 3 min
2.
• Dishware — 2 min
• Burnt cookware — 6 min
See Fig. 5 Glassware/Cook-
ware and Fig. 6 Dishware/
Burnt cookware
NOTE
30 seconds will
be added to
each cycle if the
X2 Lean Wash
Center® has the
option
EcoExchanger.
Fig. 7 Foot mechanism
55 Start the X2 Lean Wash Cen-
ter® by:
•Automatic hood: By using
the foot mechanism or
pressing the CONFIRM
button.
See Fig. 7 Foot mechanism
•Manual hood: the operator
has to lower the hood
manually.
Rev. 2021-10 17

2 Operating 2.2 Start and operation
Fig. 8 Countdown
66 When the X2 Lean Wash Cen-
ter® is running the display will
show a countdown of the
wash cycle and the CONFIRM
button turns blue.
See Fig. 8 Countdown
Fig. 9 Thermostop
77 If the rinse temperature is not
achieved the wash phase
continues until the correct
temperature is reached (85°).
See Fig. 9 Thermostop
88 The program is ready when the CONFIRM button turns green.
•Automatic hood— the hood goes up automatically.
•Manual hood— lift up the hood manually.
Fig. 10 Choose Water change
99 If water change is needed,
press and hold the ON/OFF
button and choose by arrow
down “Water change”
See Fig. 10 Choose Water
change
Confirm by pressing the
CONFIRM button.
Draining, filling and heating
the tank again takes about 5
min.
18 Rev. 2021-10

2.2 Start and operation 2 Operating
NOTE
When the unit is not used for 20 minutes (this time can be
programmed from the technicians menu) it will enter
Standby mode, keeping the temperatures lower to save
energy. To exit the function, press any button or open the
hood.
Fig. 11 Standby mode
Rev. 2021-10 19

2 Operating 2.3 Loading washware
2.3 Loading washware
Fig. 12 Cookware basket with 2 GN 1/1
Load pots, pans and contain-
ers in the specially designed
cookware basket.
Capacity: 2 GN 1/1 depth 65
mm or 1 GN 1/1 depth 200 mm
or sub-sized.
See Fig. 12 Cookware basket
with 2 GN 1/1
Fig. 13 Cookware basket with 1 GN 1/1
and one pot
Fig. 14 Cookware basket with 1 GN 1/1
and smaller containers
The cookware basket can be
loaded with 1 GN 1/1 and one
pot or with smaller containers.
See Fig. 13 Cookware basket
with 1 GN 1/1 and one pot
See Fig. 14 Cookware basket
with 1 GN 1/1 and smaller
containers
20 Rev. 2021-10
