Grohe Sensia ARENA User manual

39378SH0
DESIGN + ENGINEERING
GROHE GERMANY
http://www.grohe.com
Sensia®ARENA
99.0613.031/ÄM 236196/08.16
安装手册
CN ......2
INSTALLATION MANUAL GB ......6
....10
377
±0.00
1000
670
205
220-240
270-290
675
660
305
420
R1/2
140-160 90-110
485
180

2 CN
CN
本手册由两部分组成：第一部分是安装座便器时的安全注意
事项及操作步骤说明，第二部分是图示安装方式。请参阅本
手册每个部分。
安全注意事项
为了本产品的安全安装及使用，安装前请务
必通读这些注意事项。
危险 如果未避免，即将发生的危险情况可能会
造成死亡或严重人身伤害。
警告 如果未避免，潜在的危险情况可能会造成
死亡或严重人身伤害。
注意 如果未避免，潜在的危险情况可能会造成
轻度或中度人身伤害，或者造成产品或其
它财产损坏。
危险
电源插头连接不当会导致触电危险。
所有电气安装作业必须由专业电工进
行操作。
有短路和/或触电的危险。
警告
请遵守本手册中叙述的各项说明，并
正确安装本产品。
否则可能会导致触电、火灾、受伤、
漏水和/或泛水。
切勿允许任何非授权技术服务人员进
行拆解、维修或改装本产品。
有触电或火灾的危险，且会导致产品
故障及人身伤害。
切勿用湿手连接或断开电源插头或电
源线。
有触电危险。
连接或断开电源插头时，请抓住插
头。
如果拉住电线连接或断开连接插头，
由于会损坏插插头或电线，因此有火
灾或触电的危险。
切勿将水或清洁剂泼到座便器座椅单
元、遥控器或电源插头内部或上面。
否则可能会造成触电或火灾。
本产品使用AC 220V，切勿使用任何
其它电源。另外，切勿采用任何其它
方式将插头连接到配置不当的插座。
使用时超过额定电压可能会导致触电
或火灾。
完整连接电源插头。
由于电线会损坏，因此有火灾或触电
的危险。
切勿损坏、弯曲、修改、过度扭曲、
捆绑电源线、将其夹在中间或者将重
物压在上面。
由于电线会损坏，因此有火灾或触电
的危险。
切勿将本产品安装在潮湿的地方，例
如沐浴室或蒸汽浴室内部。
有触电或火灾的危险。
切勿将本产品与饮用水以外的水源连
接。
否则可能会因座椅单元内部的电子部
件受到腐蚀而造成触电、火灾和皮肤
炎症。
切勿拆解或改装本产品。
否则可能会造成触电或火灾。
切勿使用松动的插座。
否则可能会造成触电或火灾。

3 CN
注意
座便器的腔体由陶瓷制成，而陶瓷属
于易碎物品。对座便器的腔体进行操
作时，请注意以下事项：
–安装以前，请确保座便器的腔体情
况良好且没有损坏。
–安装以后，请检查座便器的腔体是
否有任何损坏。
否则可能会造成人身伤害、漏水和/或
泛水。
连接产品以前，请将管中的异物或锈
清洗干净。
否则可能会造成产品内部的零部件损
坏，从而可能会导致漏水和/或泛水。
当使用过滤器时，请注意以下事项：
–拆下过滤器时，请关闭止水阀。
–安装过滤器时，请完全紧固，不要
留有缝隙。
–安装O形环时，请确认上面是否有
异物。
如果O形环上面有异物，可能会因
漏水而造成泛水。
安装后，调节止水阀并检查是否漏
水。
否则可能会造成漏水和/或泛水。
如果预计会出现冰冻，请将水从产品
中排出，再提供给客户。
否则可能会因冰冻造成的损坏而导致
火灾、漏水和/或泛水。
任何建筑施工或装修后，或断水后恢
复供水时，请排出管道内的空气。
如果水源中含有空气，则可能导致产
品或管道损坏或故障。有因为泛水而
导致人身伤害的危险，或可能损坏建
筑或设备。
电源
请根据以下规格安装电线和插座。
配电作业应交由电气承包商执行。
• 使用具有额定功耗的AC 220V电源。
如果产品与其它电气设备一起使用，请安装相应数量的插
座。
• 布线应适合额定功耗。
• 插座应安装在电线可及的范围内，且距离地面有足够的高
度，使插座不会接触到水。电源线长度为1000 mm。
安装完成前切勿将电源插头插入插座。会产生故障。
水源
• 只能使用饮用水作为水源。
使用其它水源（工业用水、井水等）可能会造成电气和机
械组件的耐用性下降，从而导致事故或故障。
• 水压必须大于0.1Mpa（流动时）或大于0.75Mpa（流体
静压）。
如果水压小于上述值，请咨询经销商。
• 如果水压高于0.75MPa，请使用减压阀降低水压。
最小安装间隙
有关所需最小安装间距，请参阅下图。
*1 建议在产品各侧保留70 mm或以上的空间。如果小于70
mm，则可能妨碍操作。
*2 请将止水阀置于距离墙壁50 mm位置。
15 （最小）
377
70（最小）*1
70（最小）*1
700（最小）
50（最小）
*2
1050（最小） 单位：mm

4 CN
牢牢固定供水管
由于高水压可能导致振动，因此会影响到软管。
请牢牢固定供水管，使其不会松动。
有振动或泛水危险。
技术数据
额定电压
AC 220V 50Hz
额定功耗
850 W（环境温度20°C，水温15°C）
* 稳定状态的消耗电压。
设定
后清洗（水势强度：最高等级6，温水温度：高，精细清
洗：启动，按摩清洗：启动）
座圈温度：高
除臭：启动
微光：启动
最大额定功耗
1300 W
电源线长度
1 m /带漏电保护
供水软管长度
670 mm
防水等级
IPX4
认证
GB4706.1，GB4706.53，GB6952
水压范围
0.1MPa{1.0巴（1.0 keg/cm2）}[流动时]~
0.75MPa{7.5巴（7.5 kegs/cm2）}[流体静压]
水管连接剖面
R1/2
工作温度范围
0°C - 40°C
单位
V = 伏特，Hz = 赫兹，W = 瓦特，m = 米，
MPa = 兆帕，in = 英寸，°C = 摄氏度
冲水量
横排式：足量4.5 L，少量3.0 L
提供的物品
冲淋式坐便器和供水软管
止水阀和夹子
遥控器
螺钉、锚钉和AA电池（遥控器使用）
防盗螺母、螺钉和垫圈（遥控器使用）
排水管套
固定套件
螺钉、垫圈、锚钉、带帽螺钉
纸模板
安装支撑底座
k
整套手册
l
喷水罩
m
飘带
n
墙壁保护罩
排水管套（地面排水400 mm）
需要的工具
扳手（19 mm）
十字螺丝刀（No. 2）
平头螺丝刀（5 mm）
十字精密螺丝刀（No. 0）
锯子
水平仪
锉刀
胶带
尺子
笔
锤子
美工刀
黏合剂
彩色胶带
嵌缝材料
p
活动扳手（用于止水阀）
q
平头精密螺丝刀（2.5 mm）（用于遥控器）

5 CN
安装止水阀
用胶带缠绕止水阀的螺口。调节供水软管的接头方向，
并安装止水阀。旋转开/关手柄，确认止水阀已关闭。
墙壁供水
倾斜供水软管的接头，使其与地面成90°角。
地面供水
倾斜供水软管的接头，使其与墙壁成60°角。
安装排水管套
将垫圈安装在排水管套上。
固定排水管套。
*对于瓷砖或混凝土地面，请钻一个较低的孔，并使用
锚钉
确定固定套件的安装位置
沿着中心虚线切开纸模板。
让纸模板与排水管套的底座处于同一直线上，然后使用
彩色胶带进行固定。标记固定套件的螺钉位置。
临时放置固定套件。
沿着左右虚线切开纸模板，并固定固定套件。
*对于瓷砖或混凝土地面，请钻一个较低的孔，并使用
锚钉
说明
• 如果有间隙或松动，请用嵌缝材料填补排水管套。
安装座便器
抬起座便器腔体的前边缘，并将附送的安装支撑底座插
在陶瓷腔体的下方。将墙壁保护罩靠着墙壁。
将座便器腔体和安装支撑底座一起移动到排水管套的正
前方。
从座便器下方的螺钉孔开始垂直粘贴彩色胶带。
将手插入安装支撑底座的空档内，将座便器抬起。
将陶瓷腔体上的胶带位置调整到地面上有▲标记的位
置。
将排水管套放在座便器的排水出口上。
拉出安装支撑底座。
放下座便器腔体。确保地面上的纸模板上的▲标记位置
与陶瓷腔体上的胶带位置一致。
将螺钉插入座便器腔体侧面，紧固固定套件和座便器腔
体，然后盖上螺钉帽。拆下墙壁保护罩。
连接供水软管
取下防护盖，将供水软管插入闭水阀。
用夹子紧固。旋转夹子，检查供水软管是否通过夹子正
确紧固。
说明
• 将夹子折叠即可固定。
• 如果夹子固定不当，请拆下夹子重新固定。插入工具
打开夹子解开锁定。
完全打开供水软管的手柄，然后反方向转动90°。
说明
• 为了防止完全啮合，必须反方向转动90°。
连接电源
将电源插头插入插座。
安装遥控器
从托架中取出遥控器，然后插入电池。
说明
• 取出电池后屏幕上可能会出现竖线。这并非故障。将
电池插入遥控器后，这些竖线会消失。
确定遥控器的安装位置。
说明
• 在遥控器的安装位置上方保留一定空间。
按（ ）按钮并注册座便器。
将遥控器托架安装到墙壁上。
对于厚度小于5 mm的塑料板或胶合板
对于混凝土
将防盗螺母插入遥控器的凹槽。
将遥控器放入托架。
7
使用防盗垫圈和螺钉将遥控器固定到托架上。
检查漏水
按（ ）按钮，并检查漏水。
测试操作
用一块布或一张纸盖住座圈传感器。
然后将喷水罩放到座便器座圈下方，并放下座圈。
确认前后清洗都会喷水。
放下座圈并拆下喷水罩。
翻起座圈，确认暖风吹出。
清理
拆除座便器和地面上的胶带以及纸模板。
将飘带系在座圈盖上。

6 GB
GB
This manual consists of two parts; the first part contains
safety precautions and descriptions of the procedures
when installing the toilet, and the second part contains
visual installation methods. Please use this manual in
reference to each part.
Safety Precautions
For safe installation and use of the product,
please read the precautions thoroughly
before installing the product.
DANGER An imminently hazardous situation
which, if not avoided, will result in
death or serious injury.
WARNING A potentially hazardous situation
which, if not avoided, could result in
death or serious injury.
CAUTION A potentially hazardous situation
which, if not avoided, may result in
minor or moderate injury or damage to
the product or other property.
DANGER
Improper connection of the power
plug can result in a risk of electric
shock.
All electrical installation work
must be carried out by a qualified
electrician.
There is a danger of short circuit
and/or electric shock.
WARNING
Follow the instructions described
in this manual, and install the
product properly.
Failure to do so may cause electric
shock, fire, injury, water leakage,
and/or flooding.
Do not allow anyone except an
authorized service technician to
disassemble, repair, or modify the
product.
There is a danger of electric shock or
fire, and the product could
malfunction, causing injury.
Do not connect or disconnect the
power plug or power cord with
wet hands.
There is a danger of electric shock.
Hold the plug when connecting or
disconnecting the power plug.
If the plug is connected or
disconnected by holding the cord,
there is a danger of fire or electric
shock due to the plug or cord
becoming damaged.
Do not pour water or the cleanser
inside or onto the toilet seat unit,
remote control, or power plug.
It may cause electric shock or fire.
Do not use any power supply
other than AC 220V. Also, do not
use any other method to connect
the plug to an improperly
configured receptacle.
Exceeding the rated voltage for use
may cause an electric shock or fire.
Connect the power plug
completely.
There is a danger of fire or electric
shock due to the cord becoming
damaged.
Do not damage, bend, modify,
excessively twist, bind, sandwich,
or place heavy objects on the
power cord.
There is a danger of fire or electric
shock due to the cord becoming
damaged.
Do not install this product in a wet
or damp location, such as inside a
shower room or steam room.
There is a danger of electric shock or
fire.
Do not attach the product to any
water source other than potable
water.
It may cause electric shock, fire and
skin inflammation due corrosion of
electronic parts inside the seat unit.
Do not disassemble or modify the
product.
It may cause electric shock or fire.
Do not use loosen outlet.
It may cause electric shock or fire.

7 GB
CAUTION
The toilet bowl is made of
ceramics, and ceramics are
fragile. Note the following when
handling the toilet bowl:
–Prior to installation, make sure that the
toilet bowl is in a good condition and not
damaged.
–After installation, check the toilet bowl for
any damages.
Failure to do so may cause injury,
water leakage and/or flooding.
Wash out foreign materials or rust
inside the pipes before connecting
the product.
Failure to do so could damage the
internal parts of the product, which
may cause water leakage and/or
flooding.
Note the following when using the
strainer:
–Close the water shutoff valve when
removing the strainer.
–When installing the strainer, tighten it fully
so there is no gap.
–Check that the O-ring is free from foreign
materials when attaching it.
If foreign materials are attached to the O-ring,
it may cause flooding due to water leakage.
Adjust the water shutoff valve and
check for water leakage after the
installation.
It may cause water leakage and/or
flooding.
If the water is expected to be
frozen, drain the water out from
the product until rendering it to
the client.
Failure to do so may cause fire,
water leakage, and/or flooding due to
damage from freezing.
Drain the air from the pipes after
any building construction or
renovation, or when water supply
is restored after an interruption.
If the water supply contains air, it
may cause damage or malfunction to
the product or pipes. There is a
danger of injury or damage to the
building or furniture due to flooding.
Power Supply
Install the cord and outlet according to the specifications
below.
The power distribution work should be done by an
electrical contractor.
• Use an AC 220V power supply with a consumption
rating.
If the product is used with other electric appliances, set
the corresponding number of outlets.
• The wiring should be appropriate for the rated power
consumption.
• Set the outlet within the reach of the cord and high
enough from the floor so that water does not reach it.
The length of the power cord is 1000 mm.
Do not insert the power plug into the outlet until the
installment is complete. There is danger of malfunction.
Water Supply
• Only use potable water as the water supply.
Using a different water supply (industrial water, well
water, etc.) may cause the durability of the electrical and
mechanical components to deteriorate, resulting in an
accident or malfunction.
• The water pressure must be more than 0.1MPa
(when flows) or more than 0.75MPa (hydrostatic
pressure).
If the water pressure is lower than the above, please
consult your dealer.
• If the water pressure is higher than 0.75MPa,
decompress the pressure by using a decompression
valve.
Minimum Installation Clearance
For the required minimum installation clearance, refer
to the figure below.
*1 A space of 70 mm or more on each side of the product
is recommended.
If it is less than 70 mm, it may hinder the operation.
*2 Place the water shutoff valve to 50 mm from the wall.
15 (min.)
377
70 (min.)*1
70 (min.)*1
700 (min.)
50 (min.)*2
1050 (min.) Unit: mm

8 GB
Firmly fix the water supply pipe
An impact applied to the hose due to high water pressure
may cause vibrations.
Fix the water supply pipe firmly so that it does not loosen.
There is a danger vibration or flooding.
Technical Data
Rated voltage
AC 220V 50Hz
Rated power consumption
850 W (environment 20°C, water 15°C)
It is a consumption voltage in a steady state.
Setting
Rear washing (SPRAY STRENGTH: The highest level 6,
WATER TEMP: High, NARROW: ON, MASSAGE: ON)
SEAT TEMP: High
ODOR ABSORPTION: ON
NIGHT LIGIHT: ON
Max rated power consumption
1300 W
Length of the power cord
1 m /with leakage protection
Length of the water supply hose
670 mm
Waterproof grade
IPX4
Approval
GB4706.1, GB4706.53, GB6952
Water pressure range
0.1MPa{1.0 bar (1.0 keg/cm2)} [when flows]
0.75MPa{7.5 bar (7.5 kegs/cm2)} [hydrostatic pressure]
Water connection cross section
R1/2
Operating temperature range
0°C - 40°C
Units
V = volt, Hz = hertz, W = watt, m = meter,
MPa =mega pascal, in = inch, °C = degrees Celsius
Flushing water volume
P trap: full 4.5 L, light 3.0 L
Supplied Items
Shower Toilet and Water Supply Hose
Water Shutoff Valve and Clip
Remote Control
Screws, Anchors, and AA Batteries (For Remote
Control)
Anti-theft Nut, Screw, and Washer (For Remote
Control)
Water Drain Socket
Securing Member
Screw, Washer, Anchor, Screw with Cap
Paper Guide
Installation Support Base
k
Manual Set
l
Spray Hood
m
Banderole
n
Wall Protection Cover
Water Drain Socket (Floor drain 400mm)
Necessary Tools
Spanner (19 mm)
Crosshead Screwdriver (No. 2)
Flat-blade Screwdriver (5 mm)
Crosshead Precision Screwdriver (No. 0)
Saw
Level
File
Tape
Ruler
Pen
Hammer
Utility Knife
Adhesive
Colored Tape
Caulking Material
p
Monkey Wrench (For Water Shutoff Valve, etc.)
q
Flat-blade Precision Screwdriver (2.5 mm)
(For Remote Control)
Attaching the Water Shutoff
Valve
Wrap tape around the screw of water shutoff valve.
Adjust the direction of the joint outlet of the water
supply hose and attach the water shutoff valve.
Rotate the open/close lever and confirm that the water
shutoff valve is closed.
For a wall supply
Tilt the joint outlet of the water supply hose at a
90°angle to the floor.
For a floor supply
Tilt the joint outlet of the water supply hose at a 60°
angle to the wall.
Installing the Drain Socket
Attach the gasket to the drain socket.
Secure the drain socket.
*For tile or concrete floors, drill a lower hole and use
an anchor.

9 GB
Decide the installation position
of Securing Member
Cut off the paper guide along the central dotted line.
Place the paper guide in line with the base of the
water drain socket and secure it with colored tape.
Mark screw position of securing member.
Place the securing member temporarily.
Cut off the paper guide along the right and left dotted
line and secure the securing member.
*For tile or concrete floors, drill a lower hole and use
an anchor.
Note
• If there is a gap or looseness, bond the drain socket
with caulking.
Installing the Toilet Bowl
Lift up the front edge of the toilet bowl and insert the
supplied installation support base under the ceramic
bowl. Set wall protection cover against the wall.
Move the toilet bowl with installation support base to
just before the drain socket.
Attach colored tape vertically from the screw hole on
the lower side of the toilet bowl.
Insert your hand in the space of the installation
support base and lift up the toilet bowl.
Adjust the tape position on ceramic bowl to the
▲mark position on the floor.
Set the drain socket on the drain outlet of the toilet.
Pull out the installation support base.
Lower the toilet bowl. Make sure that the position of
the ▲mark on the guide paper on the floor coincides
with the position of the tape on the ceramic bowl.
Insert the screw into the toilet bowl side, secure the
securing member and toilet bowl, and then attach the
screw cap. Remove the wall protection cover.
Connecting the water supply
hose
Remove the protective cap and insert the water supply
hose into water shutoff valve.
Fasten with the clip. Rotate the clip and check if the
water supply hose is properly secured with the clip.
Note
• Secure the clip by folding it.
• If the clip is not secured properly, remove and secure
again. Insert the tool to open the clip and unlock it.
Fully open the lever of the water supply hose and
rotate it 90°in reverse.
Note
• To prevent anchoring, be sure to rotate the lever
90°in reverse.
Connecting to the Power
Supply
Insert power plug into the outlet.
Installing the Remote Control
Remove the remote control from the holder and insert
the batteries.
Note
• Vertical lines may appear on the screen when the
batteries are removed. This is not a malfunction.
These vertical lines will disappear when batteries are
inserted into the remote control.
Determine the installation position of the remote
control.
Note
• Leave a space above the remote control’s mounting
position.
Press the ( ) button and register to the toilet unit.
Mount the remote control holder onto the wall.
For plasterboard or plywood that is thinner than 5 mm
For concrete
Insert the anti-theft nut into the groove on the remote
control.
Attach the remote control to the holder.
7
Secure the remote control to the holder with the
anti-theft washer and screw.
Check for Water Leakage
Press the ( ) button and check for water leakage.
Test operation
Cover the seat sensor with a piece of paper or rag.
Place the spray hood under the toilet seat and lower
the seat.
Confirm that water sprays for rear and front washing.
Lower the seat and remove the spray hood.
Lift the seat and confirm that warm air blows.
Cleaning up
Remove the tape on the toilet bowl side and on the
floor, and the paper guide. Attach the banderole to the
seat lid.

10
k
l
m
n
14 046 000
19 mm
No. 2
5mm
No. 0
p
q
2.5 mm

11
150±10
100±10
150±10
330
~
330
305
280±10
230±10
230±10
280±10
100±10
90°
FL
60°
WL

12
No.2
Φ8×55
55 mm
Φ8mm
WL
Φ6×40
Φ6×63
Φ6×40
Φ6×63
]
WL

13
No.2
Φ6×40
Φ8×55
55 mm
Φ8mm

14
42kg
No.2
②
①

15
90°
AC220V

16
800-1200 mm
600-900 mm
No.2
No.2
No.2
100 mm
6 mm
Max.
5 mm
1
2
6 mm
33 mm
1
2

17
7
No.0

18
DRYER

19

PCW-1343-CN (16090)
