GST GST200N User manual

Leading innovative technology
Safeguarding lives and properties.
Fire Alarm System
The Intelligent Solution

Gulf Security Technology Co., Ltd, GST, is a key
player in the Asia fire and security industry and a
trusted provider of comprehensive fire system
solutions around the world. It is a subsidiary of
Carrier (Carrier Global Corporation), a leading
global provider of innovative HVAC, refrigeration,
fire, security and building automation technolo-
gies.
GST provides a wide range of fire products and
customized fire system solutions tailored to the
needs of different industries. With a sales infra-
structure that covers many countries and
regions, and includes a China-wide network of
more than 120 sales offices and several logistics
centers, GST has become an important part of
Carrier’s global business.
To satisfy the needs of its global customer base,
GST has established extensive R&D facilities in
Beijing and Qinhuangdao in northern China. It
constantly strives to develop innovative new
technologies and products. GST’s factory in
Qinhuangdao is a large manufacturing base
producing intelligent electronic products that
incorporate innovative technology. To ensure
superior product quality, it has advanced manu-
facturing and inspection equipment and strong
capabilities in quality control and process man-
agement.
GST has earned a range of national and interna-
tional certificates of conformity to standards such
as China’s CCC, the international UL, the global
LPCB, Europe’s CE, etc.
Gulf Security Technology Co., Ltd. (GST)

Contents
P02 / EN54 Addressable Products
P24 / EN54 Conventional Products
P33 / UL Listed Products
P47 / Gas Release Control Products
P51 / Explosion Proof Products
P58 / Gas Detector
P60 / Power Supply Unit
P62 /
P64 / Value Added Unit
P66 / System Diagram
P69 / Emergency Voice Evacuation
P79 / Emergency Telephone Products
GST Fire Alarm System
EN54 Addressable
Products
/DISABLE
ENABLE
SYSTEM
MODE
DISABLE
VIEW
LOCK
TEST
FAULT
RESET
BROWSE LOG
ESCENTER
VIEW
*
0
1
4
7
23
5 6
8 9
TAB
EVAC
SILENCE
ACK/MUTE
DELAY
MODE
TEST MODE
FLT/DIS
F.P.E.
FAULT
PRE-ALARM
SYSTEM
FAULT
POWER ONDISABLED
FAULT
COMMON
FIRE
POWER
EVACUATE
SILENCE
DETECTOR
DIRTYSOUNDER
FLT/DIS
S/C
FLT/D IS

02 GST Fire Alarm System GST Fire Alarm System 03
EN54 Addressable Products EN54 Addressable Products
GST200N Intelligent Fire Alarm Control Panel includes GST200N-1, and GST200N-2.
GST200N-1 is single loop panel, possible to be expanded the 2-loop version GST200N-2. They are suitable for small buildings
GST200N
Features
Overview
Wide range power supply, 100-240VAC, 50-60Hz
Max. 30 zones. Each zone has its own alarm and fault/disable indicator and a label
Capacity 235 addressable devices
Optional expanded to 2 loops, 477 loop devices
Compatible with GST intelligent and digital products
8X18 characters LCD screen
Non-Volatile memory ensures the data does not loss even if power supply is accidentally removed
P-9960A
CAN Class A Network Card
P-9930ModBus
ModBus Card for 3rd party interfacing
P-9905
USB Printer Interface
LC200
Loop Card For additional 2nd loop
P-9901A
Panel Printer
P-9930TCPIP
TCP/IP Network Card
P-9930
RS232 card for PC connection
P-9960
CAN Class B Network Card
Models
Description
Single loop, English
Dual loops, English
Single loop, Hungarian
Single loop, Portuguese
Single loop, Spanish
Single loop, Italian
Single loop, French
Single loop, Turkish
Single loop, Romanian
Model number
GST200N-1
GST200N-2
GST200N-HU
GST200N-PT
GST200N-SP
GST200N-IT
GST200N-FR
GST200N-TK
GST200N-RO

Overview
GST-IFP8 Intelligent Fire Alarm Control Panel is modularized multi-loop model, can be expanded to 8 loops (Max. 10 loops
without network function). The panel is suitable for small to medium projects.
GST-IFP8
Intelligent Fire Alarm Control Panel
Features
Max.999 zones, 140 have individual alarm and fault/disable LEDs and a label
8 Class A loops, total capacity of 1936 devices
15X40 LCD screen, assisting the 17 LEDs to display important information
Compatible with full series of GST addressable and digital products
Non-Volatile memory ensures the data does not loss even if power supply is accidentally removed
P-9965
CAN Class B Network Card
P-9935
RS232 card for PC connection
P-9935ModBus
ModBus Card for 3rd party interfacing
P-9965A
CAN Class A Network Card
P-9935TCPIP
TCP/IP Network Card
P-9904
USB Printer Interface
LCIFP8
Dual-Loop Card For additional loops P-9945RP
RS485 Repeater Card
04 | GST Fire Alarm System GST Fire Alarm System 05
EN54 Addressable Products EN54 Addressable Products
Models
Description
English
Portuguese
Hungarian
French
Italian
Spanish
Turkish
Model number
GST-IFP8
GST-IFP8-PT
GST-IFP8-HU
GST-IFP8-FR
GST-IFP8-IT
GST-IFP8-SP
GST-IFP8-TK

Overview
alarm system.
GST-NRP00
Network Repeater Panel
Features
Provide remote display and control of system
Password protected access levels
8X18 characters LCD screen
15 LEDs to display important information
Functional control of network panels
Network-wide operation: Acknowledge, Silence, Reset
Flush-mount or surface-mount structure
Meet network protocol by selecting suitable network card
P-9960
CAN Class B Network Card
P-9960A
CAN Class A Network Card
Overview
be connected with GST addressable panels through RS485 links.
GST852RP
LCD Repeater Panel
Features
Big size LCD display with backlight
Compatible with all GST intelligent panels
Mute and lamp test
Electrically addressing
Overview
location clearly. This addressable repeater is possible to be connected with GST addressable panels through RS485 links.
GST8903
Intelligent Graphic Repeater Panel
Features
Up to 100 LED indication points
Local buzzer alarm and mute
Custom Graphical layout to project requirement
Programmable to display zones or individual device
Programmable to indicate Fire, action and Fault conditions
A3, A2, A1 and A0 sizes
06 | GST Fire Alarm System GST Fire Alarm System 07
EN54 Addressable Products EN54 Addressable Products

08 | GST Fire Alarm System GST Fire Alarm System | 09
EN54 Addressable Products EN54 Addressable Products
DI-9101E
Intelligent Combination Heat
Photoelectric Smoke Detector
The multi-sensor combines both
smoke and heat detections to build
fast and reliable performance.
2 smoke sensitivity levels can be
set. Heat detection is based on both
FT & RR.
Overview
panels. With digital communication, the detectors can raise fast alarm signal within 1 second, and much more control can be
processed.
The detectors can be installed onto the common detector base DB-01.
A remote indicator C-9314P can be connected to each detector.
Features
Strong environmental adaptability due to drift compensation
Self-diagnostic
Reed switch test
Fire LED allows 360° viewing
C-9314P
Remote Indicator
DB-01
Common Detector
Base
DI-9102E DI-9103E
Intelligent Photoelectric Smoke
Detector
Intelligent Rate of Rise and
Fixed Temperature Heat Detector
The optical detector is designed
based on light scattering technology
with high performance chamber,
suitable for detecting slow burning or
2 sensitivity levels can be set.
The dual heat detector can provide
temperature status by semiconductor
heat sensor.
3 detection classes can be set A1R,
A2S & BS.
DZ-03
Common Detector
Base
Features
High sensitivity, reliable performance, dust-proof,
damp-proof and corrosion-proof
Three sensitivity levels
Built-in microprocessor stores 14 history data
Self-diagnostic
Overview
time to minimize losses as much as possible.
The detectors can be installed onto the common detector
base DZ-03.
I-9104
Intelligent Ultraviolet Flame Detector

Overview
smoke detector that can be used as Addressable or Conventional. With excellent built-
in microprocessor, the detector can carry out system adjustment, drift compensation
application conditions. The detector is suitable to historical buildings, warehouses,
large storages, shopping malls, leisure centers, exhibition halls, hotel lobbies, printing
houses, clothing factories, museums and prisons.
distance less than 40 meters, and 4 pieces are prepared for long distance up to 100
meters
10 | GST Fire Alarm System GST Fire Alarm System | 11
EN54 Addressable Products EN54 Addressable Products
Features
Wide operating voltage range, large monitoring areas
Combination of the emitting and receiving part makes mounting easy and optical
pathway accurate
The detector can calibrate easily, which ensures a single person complete
Self-diagnostic function can monitor the internal fault
Drift compensation for factors changing, such as a certain of dust accumulation,
positional excursion and ageing transmitter
Electronically addressed by programmer
Attractive and decent appearance
Overview
DI-9204E digital manual call
point adopts the latest digital loop
protocol, compatible with GST
mount type. A back box is supplied
for surface mounting.
DI-9204E
Digital Manual Call Point
Features
Re-settable (non-breaking glass)
via special key
Dual activation indication
Electronically addressed
Friendly installation and test
Wiring before termination
Overview
D-92WPB Weather Proof Box is
for application of manual call point
outdoor installation to provide
proof box is able to protect the
manual call point from unwanted
activation. Furthermore, it is also
damage.
Internal space is designed to suit
most types of European style MCP.
D-92WPB
Water Proof Box
Features
of manual call point
Clear and durable PC cover
Surface mounting enables the
installation easily
60mm hole distance and enough
internal space to suit most types
of European style MCP
Reserved place for additional
micro-switch, battery, buzzer, etc
I-9105R
RP-9105
Overview
installed with D series manual call
point, to build a double action of the
MCP, prevent from accident trigger
operation.
D-92FC
Flip Cover
Features
Material: PMMA
Dimension: 87 X 92 X 20 (mm)
Thickness: 1.7mm

12 | GST Fire Alarm System GST Fire Alarm System | 13
EN54 Addressable Products EN54 Addressable Products
Overview
with conventional or non-addressable equipment.
The working mode of input module can be changed by hand hold programmer. It is suitable for connecting Flow Switch, Zonal
Valve, Fire Pump, and etc.
The zone monitor module has a wide range of active threshold, to suit most conventional detectors and manual call points.
The working mode of output module can be changed by hand hold programmer. The dry contact output mode is suitable
for controlling Elevator, Fire Door, etc or interfacing to 3rd party system. The power output is suitable to drive conventional
The modules are surface mount type with bottom cable entry. A back box B-9310 should be used for surface cabling.
Features
Self-diagnostic
LEDs for fault and active indication
Two part plug-in construction with base mounted termination allows easy installation and connection
Intelligent interface can be addressed and plugged in to base at time of commissioning
B-9310
Back Box
I-9300
Addressable Single Input Module
The I-9300 input module is loop powered, for receiving
normally-open or normally-closed contact signal. For
normally-open signal, the input cable can be monitored with
EOLR.
I-9319
Addressable Zone Monitor Module
The I-9319 monitor module is designed to connect
conventional detectors into addressable system, powered
by external 24VDC. Maximum 25 conventional detectors
can be connected to in each zone.
It is also useful to monitor equipment status with both active
and fault signals
I-9301
Addressable Single Output Module
The I-9301 output module is suitable to drive conventional
in 4-wire mode by external 24VDC power supplying, and
also possible to provide dry contact output in loop powered
mode. Maximum 1A output current can be controlled in
4-wire mode.

14 | GST Fire Alarm System GST Fire Alarm System | 15
EN54 Addressable Products EN54 Addressable Products
I-9300S
Addressable Input Interface
Loop powered addressable input interface, designed to
monitor dry contact signal.
Overview
Small size, suitable to be installed in back box
Cable monitored for open circuit and short circuit
Built-in microprocessor processes messages intelligently
I-9301S
Addressable Output Interface
Overview
The I-9303 module occupies two addresses, each address can be controlled
independently, energizes the relative relay and light the indicator. Each address
corresponds to one input. After receiving feedback signal from controlled
equipment, the module transmits feedback message to FACP.
Features
Built-in microprocessor processes messages intelligently
Providing two input channels, working mode can be set normally open and
normally closed through handhold programmer
Plug-in structure
I-9303
Addressable Dual I/O Module
DI-9309
Addressable Multi-Channel Interface
Overview
An integrated solution for application of multi-input signals, saving
mounting space and installation cost.
Each output channel occupies an individual address and receives
start command from FACP, energizes the related relay, gives dry
contact output. Each input is corresponded to one address to
receive the state signal and transmit it to FACP. The quantity of
channels can be set by jumpers.
Features
Max. 16 channels of independent inputs. The quantity can be set as required
Two channels of independent dry contact outputs
3-18 consecutive addresses, changing with selected channel quantity
Power supply monitored
Cable monitored for open circuit and short circuit
Features
Input signals: 75VDC, 100VDC VA signal or 24VDC power
Connect input port (XF+, XF-) with output port (SP+, SP-) when receiving start signal from the control panel
Electrically addressed, can be programmed on site by handhold programmer
Loop-powered
Output circuit monitored. Report fault message when the output circuit is short or broken
Plug-in structure
I-9305
Voice Alarm Zone Control Module
Overview
The I-9305 Voice Alarm Zone Control Module is designed to
possible to monitor the power supply, output circuit, report fault in
case of abnormal condition.
Set as auto feedback mode, the module can transmit feedback
alarm broadcasting.

16 | GST Fire Alarm System GST Fire Alarm System | 17
EN54 Addressable Products EN54 Addressable Products
I-9401
Addressable Sounder Strobe
Overview
attention or evacuate in case of emergency.
Features
Red Plexiglas lens, hi-light red, striking, long-life
Sound level over 85dB
Two part plug in structure for easy installation
Overview
I-9403 Intelligent Sounder Strobe and I-9404
devices, can be controlled directly by loop
command following preprogrammed equations.
The sounder strobe provides pre-alarm/alarm
while the sounder provides sound only.
Features
programmer
Two parts construction with base mounted
termination allows easy installation
16 programmable alarm tones
Optional Evacuate + Alert mode
Optional loop powered or external 24VDC
powering
Optional power saving mode or normal
mode
I-9403
Intelligent Sounder Strobe
16 programmable tones with
normal/low power consumption
mode, powered by loop or external
24VDC source.
Strobe provided by high intensity
LED cluster
It also can be programmed works
in Light or sound and Light +sound
I-9404
Intelligent Sounder
16 programmable tones with
normal/low power consumption
mode, powered by loop or
external 24VDC source.
DI-9300E
Digital Single Input Module
The DI-9300E digital single input module is loop powered, designed to receive
normally open or normally closed switch signals, and transmitting the signals to
DI-9301E
Digital Single Input and Output Module
The DI-9301E digital single input and output module is loop powered, occupy
one or two loop addresses, provides dry contact output (normally open and/or
transmits to FACP. The input and output can be programmed to monitor and
DI-9305E
Digital Single Riser Output Module
The DI-9305E digital single riser output module powered by loop and external
to end devices. Able to connect conventional VADs or voice alarm system
speakers, relay capacity 2A@30VDC or maximum 60W 70V/100V audio
speakers.
DI-9319E
Digital Zone Monitor Module
The DI-9319E digital zone monitor unit, occupy one address, powered by
loop and external 24V, it is designed to connect conventional detectors into
and displays the address of the module. Maximum 30 conventional detectors or
manual call points can be connected to each module. The module also provides
a FORM-C dry contact output with the capacity of 2A @ 30VDC
Overview
interface with conventional or non-addressable equipment. The working mode of input module can be changed by hand hold
programmer. It is suitable for connecting Flow Switch, Zonal Valve, Fire Pump, and etc. The zone monitor module has a wide
range of active threshold, to suit most conventional detectors and manual call points. The working mode of output module can be
changed by hand hold programmer. The dry contact output mode is suitable for controlling Elevator, Fire Door etc. or interfacing
mount.
Features
Self-diagnostic
LEDs for fault and active indication Loop-powered
Digital communications with Panels
Low power consumption
Loop powered (except for DI-9319E and DI-9305E)
Ground fault detection (Need to work with the compatible FACP)

18 | GST Fire Alarm System GST Fire Alarm System 19
EN54 Addressable Products EN54 Addressable Products
DI-9405
Addressable Sounder Base
16 programmable tones, powered by loop. Share 1 address
with detector in 2-address mode, or individual control in
single-address / double-address mode
Overview
be controlled directly by loop command following preprogrammed equations.
The sounder bases are “sandwich” type, can be easily inserted between the standard base DB-01 and detector.
Features
Three programmable modes
16 selectable tones
Sandwich structure for easy installation. No additional cable required
DI-9406
Addressable Flashing Beacon Base
16 programmable tones, powered by loop. Share 1 address
with detector in 2-address mode, or individual control in
single-address / double-address mode
Flash light provided by high intensity LED
Overview
C-9503E Loop Isolator is the protection facility for
addressable loop, can isolate the shorted circuit from the
complete loop to ensure normal operation of other parts and
locate the isolated part. The isolator is applicable to all kinds
C-9503E
Loop Isolator
Features
Polarity-sensitive external connections. Input and output can be used inversely without direction
Delayed power-up to output end devices, avoids strong transient current when the load is heavy
Plug-in structure
DC-9504E
Base Mount Isolator
Isolator base to replace DB-01 common base, compatible
with DI series detectors
Overview
Loop Isolator is the protection facility that can isolate the trouble part from the whole loop in case of short circuit occurs, to ensure
the normal operation of other parts and locate the isolated part.
The base mounted isolator is compatible with DI-91xxE detectors.
Features
Isolates faulty part of the loop in the event of a short circuit
Automatically reset once the fault has been cleared
LED status indicator
Support Class A and Class B loop connection
Maximum 128 isolators can be connected to each loop. Maximum 50 devices between two isolators.
DC-9503E
Short Circuit Isolator
Module type isolator to be installed and terminated
individually
C-94DB
Deep Base
Use with I-9403 I-9404 I-9407
C-9403 C-9404 for Surface
Cable Entry

20 | GST Fire Alarm System GST Fire Alarm System | 21
EN54 Addressable Products EN54 Addressable Products
GST-100
Intelligent Fire Alarm Control Panel
Overview
operation and maintenance, which make it ideal for smaller systems.
Features
Class A loop, maximum capacity of 128 addressable devices
122×32 lattice LCD assisting the LED indicators to display important information
Non-volatile memory ensuring system data not lost on shutdown of power
3 relay outputs available which are SOUNDER OUTPUT (R+ and R-), ALARM OUTPUT and FAULT OUTPUT
P-9943
RS485 Communication Card
For connecting repeater panel or network
CAN100H-4
CAN Hub
4 Routes
CAN100H-8
CAN Hub
8 Routes
CAN Hub
12 Routes
CAN100H-16
CAN Hub
16 Routes
Overview
connected in star topology.
Features
Communication Distance: 3000 meters
Nodes capacity of each branch: 112
Total system capacity based on panel models
Overview
CAN100F is used to convert CAN signal to Fiber-
optic, possible to expand communication distance up
to 25km.
CAN100F
Fiber Optic Converter
Features
Transmission distance extends Max. 25 km
Preventing against electromagnetic interference
Overview
The CAN100S is used to extend CAN network distance.
And when the network nodes are over limit, the relay can
expand system capacity.
CAN100S
CAN Relay
Features
Increase 3000 meters of network distance
Expand network nodes capacity. Max. 112 nodes under
each relay

22 | GST Fire Alarm System
EN54 Addressable Products
Overview
In GST intelligent system, all addressable devices are electronically addressed. P-9910B Hand Held Programmer is the tool for
programming. It can also be used to read the parameters and set the working mode of those devices.
P-9910B
Hand Held Programmer
Features
Hand held unit, portable tool
Convenience operation
Quadruple digit alphanumeric LCD display
Low-consumption hibernation and power saving function
Low battery indication
WEEE & RoHS Compliant
Overview
area, the signal may need to be protected. The P-9903 loop relay module can provide such functions.
P-9903
Loop Relay Module
Features
Enhance loop appearance of distance and reliability
Increase 1000 meters of loop distance
Maximum 2 pieces of relays can be connected in serial
Opt-isolated output signal, resistant to industrial interference
Output supports Class B loop connection only
WEEE & RoHS Compliant
EN54 Conventional
Products

24 | GST Fire Alarm System GST Fire Alarm System | 25
EN54 Conventional Products EN54 Conventional Products
Overview
or corridor. Beside the ordinary EOLR cable monitor method, the AEOL solution can keep cable continuity even with detector
removed.
Day/Night mode, Output Program, Delay Output, Repeater Link, etc.
Mains supply, 220/230VAC, 50/60Hz
2/4/8/16 zones. Each zone can have maximum 15 conventional detectors
Compatible with GST conventional products
Integrated charger and battery management program, fully comply with latest EN54-4 standard requirement
Easy operation to enable/disable zones, sounder outputs and alarm output
Output programmable for interlink between zones and sounder outputs, alert or evacuate tone, with or without delay
Alarm output and Fault output are available for integrating into third party system
Dimension: 380mm x 320mm x 108mm
RB102A
Relay Board for GST102A
RB104A
Relay Board for GST104A
RB108A
Relay Board for GST108A
RB116A
Relay Board for GST116A
DP-9907
Active End of Line
Compatible with DC series conventional detectors
GST102A
Conventional Fire Alarm Panel
GST104A GST108A GST116A Overview
connection continuity even if a detector is removed, and provide faulty indication at the same time, so that
the downstream devices of the missing detector is still operational.
The AEOL is compatible with all GST conventional panel, and compatible with addressable zone interface
I-9319.
A diode base is required for each detector instead of standard base, DZ-03D is suitable for C range
detectors, DB-01D is suitable for DC range detector.

GST-RP16
Conventional Repeater Panel
Overview
The GST-RP16 repeater panel is compatible with GST102A/4A/8A/16A conventional panels. It is powered from FACP directly,
providing Zonal Fire and general Fault indication
Max. 16 zones
Dimension: 280mm x 110mm x 46mm
GST101
Conventional Fire Alarm Panel
Overview
Mains supply, 220/230VAC, 50/60Hz
Zone capacity 15 conventional detectors
Compatible with GST conventional products
Dimension: 210mm x 297mm x 90mm
26 | GST Fire Alarm System GST Fire Alarm System | 27
EN54 Conventional Products EN54 Conventional Products
DC-9101E
Conventional Combination Heat
Photoelectric Smoke Detector
The multi-sensor combines both
smoke and heat detections to build
fast and reliable performance.
2 smoke sensitivity levels can be
set. Heat detection is based on RR.
Overview
With the new designed smoke chamber and intelligent program, the detectors have the ability of drift compensation and dust
resistance.
The detectors can be installed onto the common detector base DB-01. DB-01D will be suitable for connecting with Active End
of Line Unit DP-9907.
A remote indicator C-9314P can be connected to each detector.
Features
Strong environmental adaptability due to drift compensation
Self-diagnostic
Reed switch test
Fire LED allows 360° viewing
DC-9102E DC-9103E
Conventional Photoelectric Smoke
Detector
Conventional Rate of Rise and Fixed
Temperature Heat Detector
The optical detector is designed
based on light scattering technology
with high performance chamber,
suitable for detecting slow burning or
2 sensitivity levels can be set.
The dual heat detector can provide
temperature status by semiconductor
heat sensor.
3 detection classes can be set A1R,
A2S & BS.

28 | GST Fire Alarm System GST Fire Alarm System | 29
EN54 Conventional Products EN54 Conventional Products
Co-operate with DP-9907, keep loop continuity even if a
detector is removed.
DB-01D
Diode Detector Base
DP-9907
Active End of Line
Co-operate with DB-01D, keep loop continuity even if a
detector is removed.
C-9314P
Remote Indicator
DB-01
Common Detector Base Overview
as much as possible.
The detectors can be installed onto the common detector base DZ-03.
C-9104
Conventional Ultraviolet Flame Detector
Features
High sensitivity, reliable performance, dust-proof, damp-proof and corrosion-proof
Self-diagnostic
DZ-03D
Diode Detector Base
Co-operate with P-9907, keep loop continuity even a detector is removed.
DZ-03
Common Detector Base

30 | GST Fire Alarm System GST Fire Alarm System | 31
EN54 Conventional Products EN54 Conventional Products
Overview
The bell has a simple structure and red coated steel casing,
with novel pattern and easy installation. It is applicable to
as large and medium sized buildings, provides clear and
continuous alarm sound.
GST-JL
Alarm Bell
Overview
DC-9204E innovation manual call point is non-addressable.
It alarms by pressing the glass. It can be simply connected
manufacturers. This MCP is suitable for public places.
panel.
DC-9204E
Innovation Manual Call Point
Features
Re-settable (non-breaking glass) via special key
Dual activation indication
Friendly installation and test
Wiring before termination
Features
24VDC power, 23mA operation
6” bell, 95dB@3m
Overview
signal when powered by 24VDC, to draw attention or evacuate in case of
emergency.
C-9401
Conventional Sounder Strobe
Features
Red Plexiglas lens, hi-light red, striking, long-life
Sound level over 85dB
Two part plug in structure for easy installation
C-94DB
Deep Base
C-9404
Conventional Sounder
2 selectable tones
Overview
signals when 24VDC supplied.
Features
Two parts construction with base mounted termination
allows easy installation
2 selectable alarm tones
C-9403
Conventional Sounder Strobe
2 selectable tones
Strobe provided by high intensity LED cluster
Use with I-9403
I-9404 C-9403
C-9404 for
Surface Cable
Entry

UL Listed Products
GST Fire Alarm System | 33
UL Listed Products
GST-IFP4M
Intelligent Fire Alarm Control Panel
GST-IFP4M Intelligent Fire Alarm Control Panel complies with UL864 standard with features of easy installation, operation and
system for most applications.
Features
7-inch Touch Screen
Wide range power supply 100-240V 50/60Hz
Multi languages: Standard English language and other regional languages such as Portuguese, Spanish, Russian, etc.
Support 1-6 loops in Class A style (additional battery box is required for 5 or 6 loops application)
242 addressable devices per loop mixing various types of devices, Max. 1452 addresses
History records of 100,000 events
“Walk test”, silent or audible
PAS (Positive Alarm Sequence) per point
Report device type mismatch and duplicated loop address
CAN/Fiber Networking, Panel grouping
Connecting with BMS via Modbus Card
Overview

34 | GST Fire Alarm System GST Fire Alarm System | 35
UL Listed Products UL Listed Products
LC401
Single Loop Card
LC402
Dual Loops Card
P-9966A
CAN Class A Network Card
P-9983
Fibre Network Card
P-9956-ModBus
ModBus Card for 3rd party interfacing
MP-401
Redundancy CPU Card
P-9981
Zone Display Panel
P-9981F
Zone Display Panel
P-9982
Zone Display and Control Panel
P-9982F
Zone Display and Control Panel
PR-400
Thermal Printer
connected through RS232. It can print all or customized real time system
events or system log of the control panel manually or automatically, easy to
operate and convenient for checking.
GST-MNA2C
Network Annunciator
connect with GST-IFP4M panel via CAN network, easy for installation,
operation, and maintenance. The powerful CPU, inbuilt Linux OS and touch-
screen provide a user-friend operation interface.
GST-MNA2F
Network Annunciator
connect with GST-IFP4M panel via Fiber-Optic network, easy for installation,
operation, and maintenance. The powerful CPU, inbuilt Linux OS and touch-
screen provide a user-friend operation interface.
Features
Receive message and send command (Reset, Silence, ACK etc.) through
network
Network interface: CAN, Class A
LCD display unit of 800 x 480, 7.0” color TFT LCD
Capacitive Touch screen
Password and key-protected nonvolatile memory
User programmable password
Features
Receive message and send command (Reset, Silence, ACK etc.) through
network
Network interface: Fiber-Optic, Class-A type
LCD display unit of 800 x 480, 7.0” color TFT LCD
Capacitive Touch screen
Password and key-protected nonvolatile memory
User programmable password
